VGD-MAGNA888WIRELESS NETWORK ACCESS POINT

Magna Systems, L.L.C.
WIRELESS NETWORK ACCESS POINT - FCC ID VGD-MAGNA888 - Magna Systems, L.L.C.
Click to zoom

Application Details

Equipment Class
DXT - Part 15 Low Power Transceiver, Rx Verified
Date of Grant
Jul 26, 2007
Application Purpose
Original Equipment
Date of Application
Jul 25, 2007
Equipment Note
WIRELESS NETWORK ACCESS POINT
Frequency Range
915.00000000 - 915.00000000
Company
Magna Systems, L.L.C.
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Block Diagram

↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗
↗

Internal Photos

↗

Operational Description

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

GateWay Wireless Network Access Point Copyright  2007 by Magna Systems, L.L.C. Revision A (07/2007) 1 Warranty General Terms Magna Systems, L.L.C. warrants this product to be free from defects in material and workmanship for a period of one year from the date of shipment. If this product is found to be defective during the warranty period, the product will either be repaired or replaced at Magna Systems’ sole option. To Use This Warranty To exercise this warranty, write or telephone your local Magna Systems representative or contact Magna Systems headquarters in California. Detailed contact information may be found on the Magna Systems web site, www.magnasystems.net . You will receive prompt assistance and return instructions. Send the product, shipping prepaid, to the indicated service facility. The repaired or replacement product will be returned to you with shipping prepaid. The repaired or replaced product will be warranted for the remainder of the original warranty term or ninety days whichever is longer. Limitation of Warranty This warranty does not apply to defects or malfunctions resulting from modification or misuse of any product or part. This warranty does not apply to fuses or other circuit protection components, to batteries or damage from battery leakage. Entire Warranty This warranty is the complete warranty and stands in lieu of any or all other warranties, expressed or implied, including any implied warranty of merchantability or suitability for a particular use. Magna Systems, L.L.C. shall not be liable for any indirect, special or consequential damages. Rev. A ii Symbols Used in This Manual CAUTION Indicates potential for equipment damage. Refer to procedures or instructions. CAUTION Indicates potential risk of electrical shock. Take suitable precautions. Regulatory Statements Industry Canada Notice to Users Operation is subject to the following two conditions: (1) This device may not cause interference and (2) This device must accept any interference, including interference that may cause undesired operation of the device. See RSS-GEN 7.1.5 FCC Notice to Users Magna Systems has not approved any changes or modifications to the ThermoSpyder made by the user. Antenna modification, antenna replacement or use of an antenna not approved by Magna Systems is not authorized. Any changes or modifications could void the user’s authority to operate this equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio / TV technician for help. Rev. A iii Important Safety Information Exposure to Radio Frequency (RF) Energy The GateWay contains a radio transmitter and receiver. Whenever powered, the GateWay will receive and emit radio frequency energy. The GateWay is designed to comply with local regulatory requirements including those concerned with the exposure of human beings to RF energy. Explosive Environments DO NOT USE THE GateWay IN EXPLOSIVE ENVIRONMENTS Areas with potentially explosive atmospheres are often, but not always, posted. Such areas may include, but are not limited to, fueling areas, enclosed areas where fumes may accumulate (such as below decks on boats or areas near poorly ventilated gas powered appliances), chemical transfer or storage areas, laboratories and areas when there are airborne particulates such as grain, dust, aerosolized paints or fine metal powders. DO NOT USE THE GateWay IN SUCH AREAS. The installation or removal of batteries may cause sparks which could cause an explosion or fire. Not Vacuum Compatible The GateWay is not vacuum compatible. Do not use the GateWay in vacuum as this could damage the GateWay and / or contaminate your vacuum chamber and associated hardware. Rev. A iv Table of Contents Warranty..............................................................................................................ii Symbols Used in This Manual..........................................................................iii Regulatory Statements......................................................................................iii Important Safety Information............................................................................iv Care of Your New GateWay................................................................................2 Getting Started....................................................................................................3 How the GateWay Works....................................................................................5 Troubleshooting..................................................................................................6 Technical Specifications....................................................................................7 Rev. A 1 Care of Your New GateWay DO NOT EXPOSE YOUR GateWay TO ANY OF THE FOLLOWING- Liquids Don’t expose your GateWay to water, rain, extreme humidity, cleaning solvents, fuels or other liquids. Extreme Heat or Cold Avoid temperatures outside of the operating range of 0 to 80ºC (32 to 176ºF). M…

Text truncated - open the document above for the full version.

Block Diagram

Page 1 of 3 450C First Street Los Altos, CA 94022 www.magnasystems.net GATEWAY™ BLOCK DIAGRAM Page 2 of 3 450C First Street Los Altos, CA 94022 www.magnasystems.net GATEWAY™ BLOCK DIAGRAM For radio communications this device uses the CC1020 Single Chip Low Power RF Transceiver for Narrowband Systems manufactured by ChipCon AS / Texas Instruments. The transceiver is a true single-chip RF communications solution which requires a minimum number of external components. Communications and control of the transceiver is affected via digital interface signals from the microcontroller unit (MCU). A block diagram of the radio frequency section is shown below. RADIO FREQUENCY SECTION BLOCK DIAGRAM MCU USB 2.0 COMPLIANT INTERFACE Flash Memory Real Time Clock Radio Transceiver USB I/F LED Status Indicator RX Output Matching Network Single-Chip Radio Transceiver CC1020 Input Matching Network Digital Control Interface Digital Data Interface TX Tx / Rx Switch ANT 14.7456 MHz Crystal Page 3 of 3 Output matching is accomplished with a π-type network which provides an impedance match at the fundamental frequency and harmonics. The use of a transmit / receive switch reduces power consumption during transmission at high output power levels and also improved receiver sensitivity. The switch is controlled by digital signals from the transceiver chip. The simplified transceiver block diagram is reproduced from the manufacturer’s datasheet. The manufacturer’s datasheet provides a discussion of the architecture and features of the transceiver as well as instructions for design of circuitry and operation of devices utilizing the CC1020. The datasheet may be accessed by the Internet here- http://focus.ti.com/lit/ds/symlink/cc1020.pdf TRANSCEIVER BLOCK DIAGRAM FROM CC1020 DATASHEET (CHIPCON AS / TEXAS INSTRUMENTS)

Cover Letter(s)

SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 June 29, 2007 To: Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: VGD-MAGNA888 FCC ID: VGD-MAGNA666 We hereby request that the information accompanying this application, as designated below, be treated with permanent confidentiality: • Schematic diagrams (file name: schematics.pdf) We hereby request that the information accompanying this application, as designated below, be treated with short-term confidentiality: • Internal photographs (file name: EUT internal photos.pdf) The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 and Section 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Steven M. Clark Managing Member Magna Systems, L.L.C. 450C First Street Los Altos, CA 94022 +1 650 917 5900 www.magnasystems.net

Cover Letter(s)

SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 June 29, 2007 Federal Communication Commission 7435 Oakland Mills Road Columbia, MD 21046 RE: FCC ID: VGD-MAGNA888 FCC ID: VGD-MAGNA666 TIMCO Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 To Whom It May Concern: This letter is to ascertain that the Magna Systems, L.L. C, Gateway and ThermoSpyder has been the unit used for conducting FCC and IC compliance testing. If you have any question or concerns, please contact me. Sincerely, Steven M. Clark Managing Member Magna Systems, L.L.C. 450C First Street Los Altos, CA 94022 +1 650 917 5900 www.magnasystems.net

External Photos

Magna Systems L.L.C. Wireless Network Access Point , Gateway, Test Unit Photo EUT Front View EUT Rear View

ID Label/Location Info

Sample FCC Label for GateWayâ„¢ Product FCC ID: VGD-MAGNA888 IC: 7231A-MAGNA888 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Mfr:MAGNASYSTEMSGATEWAYâ„¢

ID Label/Location Info

FCC Labeling Location FCC ID: VGD-MAGNA888 IC: 7231A-MAGNA888 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Internal Photos

Magna Systems L.L.C. Wireless Network Access Point , Gateway, Test Unit Photo Unit Cover Off View EUT Main Board Top View EUT Main Board Bottom View

Operational Description

Page 1 of 2 450C First Street Los Altos, CA 94022 www.magnasystems.net GATEWAY™ OPERATIONAL DESCRIPTION Page 2 of 2 450C First Street Los Altos, CA 94022 www.magnasystems.net How the GateWay™ Works A simplified block diagram of the GateWay wireless network access point is shown below. The GateWay is designed to function as a wireless network access point providing communications and network management functionality. The GateWay is only able to be used with Magna Systems’ DataLink application program. The GateWay uses the USB interface for both communications and power. When the USB connection is established, the GateWay executes power-on diagnostics and then acts as a radiofrequency link between DataLink and the radio network. DataLink issues network management commands and communicates with networked devices via the GateWay. The GateWay’s indicator LEDs provide visual indicators of network status during operation. MCU USB 2.0 COMPLIANT INTERFACE Flash Memory Real Time Clock Radio Transceiver USB I/F LED Status Indicator

Test Report

TEST REPORT FROM FOR Magna Systems LLC Wireless Network Access Point Model: Gateway TM TO 47 CFR 15.249 :2007 Test Report Serial No.: SL07062101-MSL-001(GateWay) This report supersedes None Remarks: Equipment complied with the specification [X ] Equipment did not comply with the specification [ ] This Test Report is Issued Under the Authority of: ............................................................................................................. Tested by: Snell Leong, Test Engineer ............................................................................................................. Reviewed by: Leslie Bai, Reviewer Issue date: 06 July 2007 Manufacturer: Magna Systems LLC This test report may be reproduced in full only. This test report may be reproduced in full only. Registration No. 783147 Registration No. 2195 Registration No. 4842 RTA No. D23/16V Lab Code: KR0032 Title: Magna Systems LLC FCCID: VGD-MAGNA888 To: 47 CFR 15.249 :2007 Serial# SL07062101-MSL-001(GateWay) Issue Date 06 July 2007 Page 2 of 23 www.siemic.com This page has been left blank intentionally. Title: Magna Systems LLC FCCID: VGD-MAGNA888 To: 47 CFR 15.249 :2007 Serial# SL07062101-MSL-001(GateWay) Issue Date 06 July 2007 Page 3 of 23 www.siemic.com CONTENTS EXECUTIVE SUMMARY ................................................................................................................................................. 5 1 TECHNICAL DETAILS ............................................................................................................................................. 6 2 TESTS REQUIRED ..................................................................................................................................................... 7 3 ANTENNA REQUIREMENT .................................................................................................................................... 8 4 MEASUREMENTS, EXAMINATIONS AND DERIVED RESULTS .................................................................. 9 5 TEST INSTRUMENTATION .................................................................................................................................. 14 APPENDIX A: EUT TEST CONDITIONS.................................................................................................................... 15 APPENDIX B: EXTERNAL PHOTOS .......................................................................................................................... 16 APPENDIX C: 99% BANDWIDTH AND EMISSION DESIGNATOR .................................................................... 17 APPENDIX D: INTERNAL PHOTOS ........................................................................................................................... 18 APPENDIX E: PRODUCT DESCRIPTION.................................................................................................................. 19 APPENDIX F: FCC LABEL LOCATION ..................................................................................................................... 20 APPENDIX G: USER MANUAL .................................................................................................................................... 21 APPENDIX H: CIRCUIT / BLOCK DIAGRAM.......................................................................................................... 22 Title: Magna Systems LLC FCCID: VGD-MAGNA888 To: 47 CFR 15.249 :2007 Serial# SL07062101-MSL-001(GateWay) Issue Date 06 July 2007 Page 4 of 23 www.siemic.com This page has been left blank intentionally. Title: Magna Systems LLC FCCID: VGD-MAGNA888 To: 47 CFR 15.249 :2007 Serial# SL07062101-MSL-001(GateWay) Issue Date 06 July 2007 Page 5 of 23 www.siemic.com Executive Summary The purpose of this test programme was to demonstrate compliance of the Magna Systems LLC, Wireless Network Access Point, model Gateway TM against the current 47 CFR 15.249 :2007. The Wireless Network Access Point demonstrated compliance with the 47 CFR 15.249 :2007. Magna Systems LLC is the applicant and claimed manufacturer of this tested product. For the detailed description of this product, please refer to the Wireless Network Access Point User Manual. The equipment under test operating frequency is 915MHz. The test has demonstrated that this unit complies with stipulated standards. Title: Magna Systems LLC FCCID: VGD-MAGNA888 To: 47 CFR 15.249 :2007 Serial# SL07062101-MSL-001(GateWay) Issue Date 06 July 2007 Page 6 of 23 www.siemic.com 1 Technical Details Purpose Compliance testing of Wireless Network Access Point with 47 CFR 15.249 :2007 Applicant / Client Magna Systems LLC 450C First Street Los Altos CA Manufacturer Magna Systems LLC Laboratory performing the tests SIEMIC Labs 2206 Ringwood Avenue San Jose, CA 95131 Test location(s) SIEMIC Labs 2206 Ringwood Avenue San Jose, CA 95131 Test report reference number SL07062101-MSL-001(GateWay) Date EUT received 02 July 2007 Standard applied 47 CFR 15.249 :2007 Dates of test (from – to) 02 July 2007 to 02 July 2007 No of Units: 1 Equipment Category: DXT Trade/Product Name: Magna Systems, L.L.C. Type/Model Name/No: Gateway TM Technical Variants: N/A FCC ID No. VGD-MAGNA888 IC ID No. 7231A-MAGNA888 Title: Magna Systems LLC FCCID: VGD-MAGNA888 To: 47 CFR 15.249 :2007 Serial# SL07062101-MSL-001(GateWay) Issue Date 06 July 2007 Page 7 of 23 www.siemic.com 2 Tests Required The product was tested in accordance with the following specifications. The test results recorded in this Test Report are exclusively referred to the tested sample(s). Test Standard Description Pass / Fail 47 CFR Part 15.249: 2007 RSS 210 Issue 7: 2007 15.203 RSS GEN 7.1.4 Antenna Requirement Pass 15.207(a) RSS GEN 7.2.2 Conducted Emissions Voltage Pass 15.249 RSS 210 A.2.9 (a) 7 (b) Fundamental & Radiated Spurious Emission Limits Pass ANSI C63.4: 2003 / RSS-Gen Issue 2: 2007 Notes: Deviations to above standards are outlined in specific test sections if applicable. Cable loss and exter…

Text truncated - open the document above for the full version.

Test Setup Photos

Magna Systems L.L.C. Wireless Network Access Point , Gateway, Test Unit Photo Radiated Emission Test Setup AC Line Conducted Emission Test Setup

Contact Information

Applicant

Steven Manning Clark
[email protected]650 917-5902Fax: 650 917-5901

Test Firm

SIEMIC LaboratoriesLeslie Bai
[email protected]408-526-1188Fax: 408-526-1088

Technical Specifications

#Rule PartsFrequency RangePower Output
115C915 MHz - 915 MHz-
Confidentiality
Long Term
