VIC-C0553C0553 PCB module

- INSTALLATION INSTRUCTIONS CRISON INSTRUMENTS S.A. Assembly EC5 DL.doc Pag 1 of 2 04/08/2011 FCC/IC INSTALLATION ASSEMBLY INSTRUCTIONS for Modular Approved RF Device Model C0553 w CC2500 RF Chip (C0553 PCB Module) in sensION TM + EC 5 DL Meter FCC ID: VIC-C0553 FCC ID: VIC-C0554 IC ID: 6149-C0553 IC ID: 6149-C0554 This device complies with Part 15 of FCC Rules and Industry Canada Iicense-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d’industrie Canada applicable aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes: (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. Warning - Unauthorized modification or changes to this wireless communication equipment will void the right to use it. Changes or modifications to this unit not expressly approved by the party responsible for compliance will void the user’s authority to operate the equipment. Any change to the equipment will void the Industry Canada certification and FCC grant. Avertissement - La modification ou les changements non autorisée à cet équipement de communication sans fil annuleront la droite pour I’utiliser. Les changements ou les modifications à cette unité pas expressément approuvé par le parti responsable de la conformité annuleront l’autorité de l’utilisateur pour fonctionner l’équipement. N’importe quel changement à l’équipement annulera la certification de Canada d’industrie et FCC accorde. - INSTALLATION INSTRUCTIONS CRISON INSTRUMENTS S.A. Assembly EC5 DL.doc Pag 2 of 2 04/08/2011 Assembly of PCBs EC5 DL C0547A: PCB main board. C0546B: PCB E.C. analog board. C0553: PCB Wireless communication equipment. PCB: C0547A PCB: C0546B PCB: C0553 Model: C0553 w CC2599 RF Chip

23 August, 2011 To: Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Short Term Confidentiality Request for FCC ID: VIC-C0553 To Whom It May Concern: Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 45 days: - User Manual - Setup - Internal/External Photos The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, Gail Birdsall Hach Compliance Dept Manager Phone: 970 669-3050 x2682 E-mail: [email protected] PO Box 389 5600 Lindberg Dr. Loveland, CO 80538 USA

23 August, 2011 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: VIC-C0553 We hereby request confidential treatment of information accompanying this application as outlined below: - schematics - Block Diagrams - Theory of Operation The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Gail Birdsall Hach Compliance Dept Manager Phone: 970 669-3050 x2682 E-mail: [email protected] PO Box 389 5600 Lindberg Dr. Loveland, CO 80538 USA

Host Model: sensION + DO 6 DL EUT – Top View with Sensor EUT – Back View with Sensor EUT – Top View without Sensor EUT – Back View without Sensor Host Model: sensION + EC 5 DL EUT – Top View with Sensor EUT – Back View with Sensor EUT – Top View without Sensor EUT – Back View without Sensor Host Model: sensION + PH 1 DL EUT – Top View with Sensor EUT – Back View with Sensor EUT – Top View without Sensor EUT – Back View without Sensor Host Model: sensION + MM 110 DL EUT – Top View with Sensor EUT – Back View with Sensor EUT – Top View without Sensor EUT – Back View without Sensor Host Model: sensION + MM 150 DL EUT – Top View with Sensor EUT – Back View with Sensor EUT – Top View without Sensor EUT – Back View without Sensor

CRISON INSTRUMENTS S.A. Labels_Meter-Dongle Proposals [Final Proposal 3] Crison.doc Pag. 2 de 3 29/08/2011 Label’s module. This label is of paper and we will put it before varnish.

RF Chip CC2500 Module (C0553) – Component View RF Chip CC2500 Module (C0553) – Solder View

HACH COMPANY C0553 PCB Module MODEL: C0553 W CC2500 RF CHIP Host Model: sensION™+ DO 6 DL, EC 5 DL, PH 1 DL, MM 110 DL, MM 150 DL June 28 2011 Report No.: SL11012002-HAC-001(FCC & IC) Rev1.0 (This report supersedes SL11012002-HAC-001(FCC & IC) ) 0 Modifications made to the product : None This Test Report is Issued Under the Authority of: Dan Coronia Compliance Engineer Leslie Bai Director of Certification This test report may be reproduced in full only. All Test Data Presented in this report is only applicable to presented Test sample. Title: RF Test Report of Hach Company, model :C0553 w CC2500 RF Chip To FCC 15.249 2010, RSS-210 Issue 8: 2010 Serial# SL11012002-HAC-001(FCC & IC) Rev1.0 Issue Date June 28 2011 Page 2 of 76 www.siemic.com M Laboratory Introduction SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one- stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management through out a project. Our extensive experience with China , Asia Pacific, North America, European, and international compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets . Accreditations for Conformity Assessment Country/Region Accreditation Body Scope USA FCC, A2LA EMC , RF/Wireless , Telecom , SAR Canada IC, A2LA, NIST EMC, RF/Wireless , Telecom , SAR Taiwan BSMI , NCC , NIST EMC, RF, Telecom , Safety Hong Kong OFTA , NIST RF/Wireless ,Telecom Australia NATA, NIST EMC, RF, Telecom , Safety Korea KCC/RRA, NIST EMI, EMS, RF , Telecom, Safety , SAR Japan VCCI, JATE, TELEC, RFT EMI, RF/Wireless, Telecom Mexico NOM, COFETEL, Caniety Safety, EMC , RF/Wireless, Telecom Europe A2LA, NIST EMC, RF, Telecom , Safety, SAR Accreditations for Product Certifications Country Accreditation Body Scope USA FCC TCB, NIST EMC , RF , Telecom Canada IC FCB , NIST EMC , RF , Telecom Singapore iDA, NIST EMC , RF , Telecom EU NB EMC & R&TTE Directive Japan MIC, (RCB 208) RF , Telecom HongKong OFTA (US002) RF , Telecom Title: RF Test Report of Hach Company, model :C0553 w CC2500 RF Chip To FCC 15.249 2010, RSS-210 Issue 8: 2010 Serial# SL11012002-HAC-001(FCC & IC) Rev1.0 Issue Date June 28 2011 Page 3 of 76 www.siemic.com This page has been left blank intentionally Title: RF Test Report of Hach Company, model :C0553 w CC2500 RF Chip To FCC 15.249 2010, RSS-210 Issue 8: 2010 Serial# SL11012002-HAC-001(FCC & IC) Rev1.0 Issue Date June 28 2011 Page 4 of 76 www.siemic.com CONTENTS 1 EXECUTIVE SUMMARY & EUT INFORMATION...............................................................................................................6 2 TECHNICAL DETAILS.....................................................................................................................................................7 3 MODIFICATION...............................................................................................................................................................8 4 TEST SUMMARY.............................................................................................................................................................9 5 MEASUREMENTS, EXAMINATION AND DERIVED RESULTS.......................................................................................10 ANNEX A. TEST INSTRUMENT & METHOD...........................................................................................................................40 ANNEX B EUT AND TEST SETUP PHOTOGRAPHS..............................................................................................................44 ANNEX C. TEST SETUP AND SUPPORTING EQUIPMENT......................................................................................................44 ANNEX D USER MANUAL, BLOCK & CIRCUIT DIAGRAM.....................................................................................................48 ANNEX E. SIEMIC ACCREDITATION CERTIFICATES.............................................................................................................49 Title: RF Test Report of Hach Company, model :C0553 w CC2500 RF Chip To FCC 15.249 2010, RSS-210 Issue 8: 2010 Serial# SL11012002-HAC-001(FCC & IC) Rev1.0 Issue Date June 28 2011 Page 5 of 76 www.siemic.com This page has been left blank intentionally. Title: RF Test Report of Hach Company, model :C0553 w CC2500 RF Chip To FCC 15.249 2010, RSS-210 Issue 8: 2010 Serial# SL11012002-HAC-001(FCC & IC) Rev1.0 Issue Date June 28 2011 Page 6 of 76 www.siemic.com 1 Executive Summary & EUT information The purpose of this test program was to demonstrate compliance of the Hach Company, C0553 PCB Module, and model: C0553 w CC2500 RF Chip against the current Stipulated Standards. The C0553 PCB Module have demonstrated compliance with the FCC 15.249 2010, RSS-210 Issue 8 : 2010. EUT Information EUT Description : The CC0553 PCB Module with CC2500 RF Transceiver chip provides extensive hardware support for packet handling, data buffering, burst transmissions, clear channel assessment, link quality indication, and wake-on radio. The C0553 PCB Module series are single and multi-parameter electromechanical measuring instruments. These instruments measure temperature, conductivity, the pH/ORP, and the Dissolved Oxygen (DO) concentration of liquids samples. Model No : C0553 w CC2500 RF Chip (Host model: sensION™ + DO 6 DL, EC 5 DL, PH 1 DL, MM 110 DL, MM 150 DL) Serial No : 115001 Input Power : 4.5 Vdc (3) 1.5V AA type Batteries Classification Per Stipulated Test Standard : DXT / Device Title: RF Test Report of Hach Company, model :C0553 w CC2500 RF Chip To FCC 15.249 2010, RSS-210 Issue 8: 2010 Serial# SL11012002-HAC-001(FCC & IC) Rev1.0 Issue Date June 28 2011 Page 7 of 76 www.siemic.com 2 TECHNICAL DETAILS Purpose Compliance t…
