VIP-DVA6Car Multimedia Receiver

Android Powered - 2 Din Multimedia Receiver with Built-in Bluetooth Android Powered - 2 Din Multimedia Receiver with Built-in Bluetooth Moteur Android– Multimédia 2 Din Récepteur avec Bluetooth Intégré Owner’s Manual DVA6 Manual de Instrucciones DVA6 Guide de l’Utilisateur DVA6 English Español Français English 2 Welcome Statement & Warnings Thank you for purchasing the RYDEEN DVA6, that it will make your driving experience easier & hassle-free. The DVA6 provides an easy-to-use touch screen user interface and innovative functionality in a stylish design that replaces the factory radio. Please read this Owner’s Manual carefully. If you have any further questions about your DVA6 operation, feel free to call RYDEEN, Toll Free at 1-877-777-8811 (within USA only) for product support, or visit our website: www.rydeenmobile.com. PRECAUTIONS & WARNINGS IMPORTANT INFORMATION PLEASE READ CAREFULLY BEFORE USING THIS PRODUCT We recommend that you read and follow all information and instructions in this Owner’s Manual for the best performance and satisfaction of your DVA6. • Your DVA6 navigation software IS NOT a substitute for personal judgment. The route suggestions should never supersede any local traffic regulation, personal judgment or knowledge of safe driving practices. Before making any maneuvers (for example, a U-turn or a left turn) suggested by the DVA6 system, please be sure that such a maneuver can be completed legally and safely. Do not follow route suggestions that could put you or your vehicle in a potentially unsafe or illegal circumstance. • You should not depend on DVA6 to locate emergency services (such as police, fire stations, hospitals and clinics). The database may not include all emergency service providers. It is the best to call your local police department and ask for directions in these situations. • Set the unit volume at a level that will allow you to hear outside traffic and emergency vehicles. • Avoid placing cell phones or wireless transceiver devices near the GPS antenna as their signals may weaken or interfere with the GPS satellite signal being received by your DVA6, causing it to perform poorly. • The DVA6 should not be programmed while driving. The driver can only program the unit while the vehicle is parked in a safe location. • Moving pictures display on the DVA6 screen should not be watched or touched while the vehicle is in motion. • Parking brake safety system should be installed correctly according to the instruction on the owner’s manual. Otherwise, RYDEEN and its retailers are not responsible for any accident caused by improper installation or misuse of the DVA6 unit. • SEVERE INJURY RISK -DO NOT mount your DVA6 on the surface of, or in the deployment field of your vehicle’s driver and passenger airbag units. • Position the unit in a location that does not obstruct the driver’s view of the road, instruments or vehicle controls. • Position the unit so the screen can be viewed with just a quick glance. Glance at the unit screen or manipulate the in-route touch screen controls ONLY WHEN VEHICLE IS COMPLETELY STOPPED AND IT IS SAFE to do so. • Be sure the DVA6 unit is securely attached to the vehicle’s dash structure with the supplied bracket and screws. • DO NOT attempt to modify or disassemble the DVA6 unit, personal injury or damage could result. If a problem occurs, stop using the system immediately and contact RYDEEN. Changes or modifications to the DVA6 will void the warranty and its compliance with FCC rules thus making it illegal to use. • If you notice any of the following: (unidentified liquid on the unit; smoke rising out of the unit; unusual odor emanating from the unit) – STOP USING THE UNIT IMMEDIATELY. Contact the nearest RYDEEN retailer or call RYDEEN Customer Service for assistance Toll Free @ 1-877-777-8811 (within USA only). • DO NOT mount your DVA6 on any non-automotive form of transportation (motorcycles, bikes, ATV’s, watercraft). English 3 WARNINGS • Avoid dropping your DVA6 unit or subjecting it to excessive shock and vibrations as this may cause it to malfunction. • DO NOT use any sharp object to operate your unit’s touch-screen display. Excessive force could damage the LCD display. • Keep the DVA6 unit out of reach of small children. Removable parts (microSD memory card) can be a choking hazard. • The DVA6 unit IS NOT WATERPROOF. Avoid exposing it to rain or other forms of excessive moisture. Water damage is not covered under the warranty. WARNINGS • THE FOLLOWING INSTRUCTIONS ARE INTENDED FOR AUTHORIZED RYDEEN MOBILE INSTALLERS ONLY • PROFESSIONAL INSTALLATION BY AUTHORIZED RYDEEN RETAILER REQUIRED TO BE COVERED UNDER WARRANTY Technical Support Contact Info If you have other questions about the RYDEEN DVA6, please contact your retailer or Technical Support: • Telephone: 1-877-777-8811 (within USA only) • [email protected] • Web Address: www.rydeenmobile.com English 4 Precautions To ensure safe driving, please adjust the volume to a safe & comfortable level in case of emergency situations. Never expose this unit, amplifier or speakers to moisture or water to prevent electronic sparks or fires. Please don’t change the fuse on the power cord without professional guidance, using an improper fuse may cause damage to this unit or even cause fire. Please power off this unit at once and send it back to the after-sales service center or the dealer /distributor you purchased from if one of the following symptoms is found: (a). No audio output; (b). No image output; (c). Water or other obstacle enters the unit; (d). Smoking; (e). Peculiar smell. Only connect the unit to a 12-volt power supply with proper negative grounding. MUTE OK MUTE OK Never install this unit where the operation and condition for driving safely is compromised. MUTE OK MUTE OK Never use the video display while the car is in motion. The use of video playback while driving is a violation of traffic laws and increases the risk of traffic accidents. MUTE OK MUTE OK MUTE…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (current) 3.0 4.0 May-23-2014

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012

Label’s Location on EUT

Antenna

RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b) FCC ID：VIP-DVA6 EUT Specification EUT Car Multimedia Receiver Frequency band (Operating) WLAN: 2.412GHz ~ 2.462GHz WLAN: 5.18GHz ~ 5.32GHz / 5.50GHz ~ 5.70GHz WLAN: 5.745GHz ~ 5825GHz Others Device category Portable (<20cm separation) Mobile (>20cm separation) Others ___ Exposure classification Occupational/Controlled exposure (S = 5mW/cm2) General Population/Uncontrolled exposure (S=1mW/cm2) Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power -0.54dBm(0.883mW) Antenna gain (Max) 0 dBi Evaluation applied MPE Evaluation SAR Evaluation Limits for Maximum Permissible Exposure(MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500-100000 -- -- 1 30 Friis transmission formula: Pd=(Pout*G)\(4*pi*R2) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in Mw G= gain of antenna in linear scale Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm2. If we know the maximum gain of the antenna and total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. Measurement Result Channel Frequency (MHz) Output Peak power (mW) Antenna Gain (dBi) Antenna Gain (numeric) Power density at 20cm (mW/ cm 2 ) Power density Limits (mW/cm 2 ) 2402 0.883 0 1 0.0001757 1 2441 0.793 0 1 0.0001578 1 2480 0.697 0 1 0.0001387 1 2402 0.661 0 1 0.0001315 1 2441 0.583 0 1 0.0001160 1 2480 0.502 0 1 0.0000999 1 2402 0.701 0 1 0.0001395 1 2441 0.610 0 1 0.0001214 1 2480 0.528 0 1 0.0001050 1 Signature: Print: Sam Lv Title: Manager Company: DONGGUAN EMTEK CO., LTD. Address: No.281, Guantai Road, Nancheng District, Dongguan, Guangdong, China Date: 2014-09-02

TRF No. FCC 15.247/A Page 1 of 62 Report No.: KAD140814059E Ver.1.0 ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART C REQUIREMENT OF Car Multimedia Receiver Model No.: DVA6, DVA6.1, DVA6.2, DVA60, DVA61, DVA62, DVA600, DVA610, DVA620 Brand Name: RYDEEN FCC ID: VIP-DVA6 Report No.: KAD140814059E Issue Date: September 01, 2014 Prepared for HUIZHOU FORYOU GENERAL ELECTRONICS CO.,LTD. Building 2, A Zone, Foryou Industrial Park, 1# North Shangxia Road,Dongjiang Hi-tech Industry Park,Huizhou,Guangdong,China Prepared by DONGGUAN EMTEK CO., LTD. No.281, Guantai Road, Nancheng District, Dongguan, Guangdong, China TEL: 86-769-22807078 FAX: 86-769-22807079 TRF No. FCC 15.247/A Page 2 of 62 Report No.: KAD140814059E Ver.1.0 VERIFICATION OF COMPLIANCE Applicant: HUIZHOU FORYOU GENERAL ELECTRONICS CO., LTD. Building 2, A Zone, Foryou Industrial Park, 1# North Shangxia Road, Dongjiang Hi-tech Industry Park, Huizhou, Guangdong, China Manufacturer: HUIZHOU FORYOU GENERAL ELECTRONICS CO., LTD. Building 2, A Zone, Foryou Industrial Park, 1# North Shangxia Road, Dongjiang Hi-tech Industry Park, Huizhou, Guangdong, China Product Description: Car Multimedia Receiver Brand Name: RYDEEN Model Number: DVA6, DVA6.1, DVA6.2, DVA60, DVA61, DVA62, DVA600, DVA610, DVA620 (Note: The samples are the same except appearance and model number. So we prepare DVA6 for EMC test.) Kind of Device: Bluetooth Ver. 2.1+EDR File Number: KAD140814059E Date of Test: August 14, 2014 to September 01, 2014 We hereby certify that: The above equipment was tested by DONGGUAN EMTEK CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2009) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.247(2013). The test results of this report relate only to the tested sample identified in this report. Approved By Sam Lv / Q.A. Manager DONGGUAN EMTEK CO., LTD. TRF No. FCC 15.247/A Page 3 of 62 Report No.: KAD140814059E Ver.1.0 Modified Information Version Summary Revision Date Report No. Ver.1.0 Original Report / KAD140814059E TRF No. FCC 15.247/A Page 4 of 62 Report No.: KAD140814059E Ver.1.0 Table of Contents 1. GENERAL INFORMATION ....................................................................................... 6 1.1 PRODUCT DESCRIPTION............................................................................................................... 6 1.2 RELATED SUBMITTAL(S) / GRANT (S) ............................................................................................ 6 1.3 TEST METHODOLOGY .................................................................................................................. 6 1.4 SPECIAL ACCESSORIES ................................................................................................................ 6 1.5 EQUIPMENT MODIFICATIONS ........................................................................................................ 6 1.6 TEST FACILITY ............................................................................................................................. 7 2. SYSTEM TEST CONFIGURATION ........................................................................... 8 2.1 EUT CONFIGURATION .................................................................................................................. 8 2.2 EUT EXERCISE ............................................................................................................................ 8 2.3 TEST PROCEDURE ....................................................................................................................... 8 2.4 LIMITATION .................................................................................................................................. 8 2.5 CONFIGURATION OF TESTED SYSTEM ........................................................................................ 12 3. SUMMARY OF TEST RESULTS ............................................................................. 13 4. DESCRIPTION OF TEST MODES ........................................................................... 13 5. RADIATED EMISSION TEST .................................................................................. 14 5.1 MEASUREMENT PROCEDURE ..................................................................................................... 14 5.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ............................................................... 15 5.3 MEASUREMENT EQUIPMENT USED: ............................................................................................ 16 5.4 MEASUREMENT RESULT ............................................................................................................. 16 5.5 RADIATED MEASUREMENT PHOTOS: ........................................................................................... 26 6. CHANNEL SEPARATION TEST ............................................................................. 27 6.1 MEASUREMENT PROCEDURE ..................................................................................................... 27 6.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ............................................................... 27 6.3 MEASUREMENT EQUIPMENT USED: ............................................................................................ 27 6.4 MEASUREMENT RESULTS: .......................................................................................................... 27 7. 20DB BANDWIDTH TEST ....................................................................................... 34 7.1 MEASUREMENT PROCEDURE ..................................................................................................... 34 7.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ..........…
