VIX-SP880Bluetooth Wireless Speaker

interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. está instalado o no se lo utiliza de acuerdo con las instrucciones, puede ocasionar interferencias perjudiciales para las comunicaciones de radio. Sin embargo, no existe ninguna garantía de que no se vaya a producir una interferencia en una instalación particular. Si este equipo produce una interferencia perjudicial con la recepción de la radio o la televisión, lo cual podría determinarse apagando y encendiendo el equipo, se le pide al usuario que intente corregir la interferencia siguiendo una o varias de las siguientes medidas. • Reoriente o reubique la antena receptora • Aumente la separación entre el equipo y el receptor • Conecte el equipo a un toma corriente diferente al que conecta el receptor • Clean only with dry cloth. • Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifi ers) that produce heat. • Refer all servicing to qualifi ed service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. ADDITIONAL SAFETY INFORMATION • Do not use unauthorized chargers or power adapters. Use only chargers that came with your • No use este aparato cerca del agua. • Limpie solamente con un paño seco. • No instale cerca de fuentes de calor tales como radiadores, registros de calor, estufas, u otros aparatos (incluyendo amplifi cadores) que produzcan calor. • Refi era todo el servicio a personal de servicio califi cado. El servicio es requerido cuando el aparato ha sido dañado de alguna forma, tal como daño a la clavija o al cable de corriente, cuando se ha derramado líquido o han caído objetos dentro del aparato, el aparato ha sido expuesto a lluvia o humedad, no funciona normalmente, o ha sido tirado. product or that is listed in the user’s guide. • Apparatus shall not be exposed to dripping or splashing and no objects fi lled with liquids, such as vases, shall be placed on the apparatus. • Do not attempt to disassemble the cabinet. This product does not contain customer serviceable components. • The marking information is located at the bottom of apparatus. Important battery information Warning: Your product contains a battery and charging system which is designed to work in temperatures that do not exceed 50°C (122°F). Leaving this product in a closed automobile or the trunk of an INFORMACION ADICIONAL DE SEGURIDAD • No use cargadores o adaptadores de corriente no autorizados. Utilice solamente los cargadores que vinieron con su producto o que estén listados en la guía del usuario. • El aparato no debe quedar expuesto a goteos o salpicaduras de líquidos, y, por lo tanto, no se deben colocar sobre el aparato objetos que contengan líquidos, como por ejemplo vasos. • No intente desensamblar el gabinete. Este producto no contiene componentes que requieran servicio por parte del cliente. • La información de señalamiento está ubicada en la parte inferior del aparato. automobile where temperatures may exceed 50°C may result in permanent battery damage, fi re, or explosion. Please remove your product from the automobile when you exit, do not place your product in the trunk of your automobile, and do not leave your product in any location where temperatures may exceed 50°C. Ecology Your product must be disposed of properly according to local laws and regulations. Because this product contains a battery, the product must be disposed of separately from the household waste. Información importante sobre la batería Advertencia: su producto contiene una materia y un sistema de carga que están diseñados para trabajar a temperaturas que no excedan de 50°C (122°F). Dejar este producto en un automóvil cerrado o en la cajuela de un automóvil donde las temperaturas puedan exceder de 50°C puede resultar en daño permanente a la batería, fuego o explosión. Por favor retire su producto del automóvil al salir, no coloque el producto en la cajuela de su automóvil, y no deje su producto en alguna ubicación donde la temperatura pueda exceder de 50°C. Product registration Thank you for purchasing an Acoustic Research product. We pride ourselves on the quality and reliability of all our electronic products, but if you ever need service or have a question our customer service staff stands ready to help. Contact us at www.808headphones.com. PURCHASE REGISTRATION: Registering Online will allow us to contact you in the unlikely event a safety notifi cation is required under the Federal Consumer Safety Act. Register Online at: WWW.808HEADPHONES.COM. Click on Product Registration and Fill Out the Brief Questionnaire. Enregisregistro del productotrement du produit Gracias por comprar un producto Acoustic Research. Nos enorgullece la calidad y fi abilidad de todos nuestros productos electrónicos, pero si alguna vez necesita servicios técnicos o si tiene alguna pregunta nuestro personal de atención al cliente está a su disposición para ayudarle. Comuníquese con nosotros en www.808headphones.com. REGISTRO DE COMPRA: El registro en línea nos permitirá comunicarnos con usted en el caso de tener que enviarle algún aviso de seguridad en virtud de la Ley Federal de Seguridad del Consumid…

Text truncated - open the document above for the full version.

RV-0000000 Project No.: 1306088 Page 2 of 11 Neutron Engineering Inc. 1306088 130608 8 RV-0000000 Project No.: 1306088 Page 3 of 11 Neutron Engineering Inc. 1306088 130608 8 RV-0000000 Project No.: 1306088 Page 11 of 11 Neutron Engineering Inc. 1306088 130608 8

11

RV-0000000 Project No.: 1306088 Page 4 of 11 Neutron Engineering Inc. 1306088 130608 8 RV-0000000 Project No.: 1306088 Page 5 of 11 Neutron Engineering Inc. 1306088 RV-0000000 Project No.: 1306088 Page 6 of 11 Neutron Engineering Inc. 1306088 130608 8 RV-0000000 Project No.: 1306088 Page 7 of 11 Neutron Engineering Inc. Bluetooth Module 1306088 130608 8 Antenna RV-0000000 Project No.: 1306088 Page 8 of 11 Neutron Engineering Inc. Bluetooth Module 1306088 RV-0000000 Project No.: 1306088 Page 9 of 11 Neutron Engineering Inc. 1306088 RV-0000000 Project No.: 1306088 Page 10 of 11 Neutron Engineering Inc. 1306088 130608 8

RV-0000000 Report No.: NEI-FCCP-1-1306088 Page 103 of 107 Neutron Engineering Inc. 12 RF EXPOSURE COMPLIANCE 12.1 LIMIT Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2 m normally can be maintained between the user and the device. (A) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 (B) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 NOTE: f = frequency in MHz ; *Plane-wave equivalent power density. 12.2 MEASUREMENT INSTRUMENTS LIST Item Kind of EquipmentManufacturer Type No. Serial No. Calibrated until 1 Power Meter Anritsu ML2487A 6K00004714 Feb. 26, 2014 2 Power Meter Sensor Anritsu MA2491A 34138 Feb. 26, 2014 NOTE: N/A: denotes No Model Name, No Serial No. or No Calibration specified. 12.3 MPE CALCULATION METHOD E (V/m) ＝ d GP××30 Power Density: Pd (W/m²) ＝ 377 2 E E ＝ Electric field (V/m) P ＝ Peak RF output power (W) G ＝ EUT Antenna numeric gain (numeric) d ＝ Separation distance between radiator and human body (m) The formula can be changed to Pd ＝ 2 377 30 d GP × ×× From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained RV-0000000 Report No.: NEI-FCCP-1-1306088 Page 104 of 107 Neutron Engineering Inc. 12.4 TEST SETUP LAYOUT 12.5 DEVIATION FROM TEST STANDARD No deviation 12.6 EUT OPERATING CONDITIONS The EUT tested system was configured as the statements of 4.6 Unless otherwise a special operating condition is specified in the follows during the testing. 12.7 TEST RESULTS The power is so low so there is no need for RF calculations.

RV-0000000 Report No.: NEI-FCCP-1-1306088 Page 1 of 107 Neutron Engineering Inc. Radio Test Report FCC ID: VIX-SP880 This report concerns (check one) : Original Grant Class II Change Issued Date : Jun. 28, 2013 Project No. : 1306088 Equipment : Bluetooth Wireless Speaker Model Name : SP880-A Applicant : Voxx Accessories Corp. Address : 3502 Woodview Trace, Suite 220, Indianapolis, IN. 46250 Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Jun. 20, 2013 Date of Test: Jun. 20, 2013 ~ Jun. 25, 2013 Testing Engineer : (Rush Kao) Technical Manager : (Jeff Yang) Authorized Signatory : (Andy Chiu) Neutron Engineering Inc. B1, No. 37, Lane 365, YangGuang St., NeiHu District 114, Taipei, Taiwan. TEL: +886-2-2657-3299 FAX: +886-2-2657-3331 RV-0000000 Report No.: NEI-FCCP-1-1306088 Page 2 of 107 Neutron Engineering Inc. Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C., or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences or generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. RV-0000000 Report No.: NEI-FCCP-1-1306088 Page 3 of 107 Neutron Engineering Inc. Table of Contents REPORT ISSUED HISTORY 6 1 CERTIFICATION 7 2 . SUMMARY OF TEST RESULTS 8 2.1 TEST FACILITY 9 2.2 MEASUREMENT UNCERTAINTY 9 3 GENERAL INFORMATION 10 3.1 GENERAL DESCRIPTION OF EUT 10 3.2 DESCRIPTION OF TEST MODES 12 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 13 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 14 3.5 DESCRIPTION OF SUPPORT UNITS 15 4 CONDUCTED EMISSION 16 4.1 LIMIT 16 4.2 MEASUREMENT INSTRUMENTS LIST 16 4.3 TEST PROCEDURES 17 4.4 TEST SETUP LAYOUT 17 4.5 DEVIATION FROM TEST STANDARD 17 4.6 EUT OPERATING CONDITIONS 18 4.7 TEST RESULTS 19 5 ANTENNA CONDUCTED SPURIOUS EMISSION 21 5.1 LIMIT 21 5.2 MEASUREMENT INSTRUMENTS LIST 21 5.3 TEST PROCEDURES 21 5.4 TEST SETUP LAYOUT 21 5.5 DEVIATION FROM TEST STANDARD 21 5.6 EUT OPERATING CONDITIONS 21 5.7 TEST RESULTS 22 6 HOPPING CHANNEL SEPARATION 30 6.1 LIMIT 30 6.2 MEASUREMENT INSTRUMENTS LIST 30 6.3 MEASURING INSTRUMENTS SETTING 30 6.4 TEST PROCEDURES 30 6.5 TEST SETUP LAYOUT 30 6.6 DEVIATION FROM TEST STANDARD 30 6.7 EUT OPERATING CONDITIONS 30 6.8 TEST RESULTS 31 7 MAXIMUM PEAK CONDUCTED OUTPUT POWER 39 7.1 LIMIT 39 RV-0000000 Report No.: NEI-FCCP-1-1306088 Page 4 of 107 Neutron Engineering Inc. Table of Contents 7.2 MEASUREMENT INSTRUMENTS LIST 39 7.3 TEST PROCEDURES 39 7.4 TEST SETUP LAYOUT 39 7.5 DEVIATION FROM TEST STANDARD 39 7.6 EUT OPERATING CONDITIONS 39 7.7 TEST RESULTS 40 8 RADIATED SPURIOUS EMISSION (9 KHZ TO 1 GHZ) 44 8.1 LIMIT 44 8.2 MEASUREMENT INSTRUMENTS LIST 45 8.3 MEASURING INSTRUMENTS SETTING 45 8.4 TEST PROCEDURES 46 8.5 DEVIATION FROM TEST STANDARD 46 8.6 TEST SETUP LAYOUT 46 8.7 EUT OPERATING CONDITIONS 47 8.8 TEST RESULTS 48 9 RADIATED SPURIOUS EMISSION (ABOVE 1 GHZ) 50 9.1 LIMIT 50 9.2 MEASUREMENT INSTRUMENTS LIST 51 9.3 MEASURING INSTRUMENTS SETTING 51 9.4 TEST PROCEDURES 52 9.5 DEVIATION FROM TEST STANDARD 52 9.6 TEST SETUP LAYOUT 52 9.7 EUT OPERATING CONDITIONS 53 9.8 TEST RESULTS 54 9.9 TEST RESULTS (RESTRICTED BANDS) 78 10 NUMBER OF HOPPING FREQUENCY 86 10.1 LIMIT 86 10.2 MEASUREMENT INSTRUMENTS LIST 86 10.3 MEASURING INSTRUMENTS SETTING 86 10.4 TEST PROCEDURES 86 10.5 TEST SETUP LAYOUT 86 10.6 DEVIATION FROM TEST STANDARD 86 10.7 EUT OPERATING CONDITIONS 86 10.8 TEST RESULTS 87 11 AVERAGE TIME OF OCCUPANCY 89 11.1 LIMIT 89 11.2 MEASUREMENT INSTRUMENTS LIST 89 11.3 TEST PROCEDURES 89 RV-0000000 Report No.: NEI-FCCP-1-1306088 Page 5 of 107 Neutron Engineering Inc. Table of Contents 11.4 TEST SETUP LAYOUT 89 11.5 DEVIATION FROM TEST STANDARD 89 11.6 EUT OPERATING CONDITIONS 90 11.7 TEST RESULTS 91 12 RF EXPOSURE COMPLIANCE 103 12.1 LIMIT 103 12.2 MEASUREMENT INSTRUMENTS LIST 103 12.3 MPE CALCULATION METHOD 103 12.4 TEST SETUP LAYOUT 104 12.5 DEVIATION FROM TEST STANDARD 104 12.6 EUT OPERATING CONDITIONS 104 12.7 TEST RESULTS 104 13 EUT TEST PHOTO 105 RV-0000000 Report No.: NEI-FCCP-1-1306088 Page 6 of 107 Neutron Engineering Inc. REPORT ISSUED HISTORY Revised Version No. Description Issued Date - Initial Issue. Jun. 28, 2013 RV-0000000 Report No.: NEI-FCCP-1-1306088 Page 7 of 107 Neutron Engineering Inc. 1 CERTIFICATION E q u i p m e n t : Bluetooth Wireless Speaker Brand Name : 808 Model Name : SP880-A A p p l i c a n t : Voxx Accessories Corp. Date of Test : Jun. 20, 2013 ~ Jun. 25, 2013 Standards : FCC Part 15, Subpart C: 2012 ANSI C63.4: 2009 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-1-1306088) were obt…

Text truncated - open the document above for the full version.

RV-0000000 Report No.: NEI-FCCP-1-1306088 Page 105 of 107 Neutron Engineering Inc. 13 EUT TEST PHOTO Conducted emission test photos 1306088 1306088 RV-0000000 Report No.: NEI-FCCP-1-1306088 Page 106 of 107 Neutron Engineering Inc. Radiated spurious emission test photos Below 1 GHz 1306088 1306088 RV-0000000 Report No.: NEI-FCCP-1-1306088 Page 107 of 107 Neutron Engineering Inc. Radiated spurious emission test photos Above 1 GHz 1306088 1306088
