PREMIER Congratulations on your purchase of this Acoustic Research Premier Series speaker, the ultimate in stereo-capable wireless sound. This speaker offers two setup options: Single-Speaker setup for one Premier speaker Stereo setup for two Premier speakers This guide takes you through the steps for either setup option. A Instructions en français ...........................9 Instrucciones en español .......................17 2 Bluetooth wireless is a quick and easy way to connect a smartphone to a speaker or a headset. There are basically two steps to making Bluetooth work. P Ò m a phone.” The two devices get to know each other. The two devices do something together (like play music). This guide takes you through the steps to get started. C CTING: Ò m a speaker.” Make sure the following items came in this package. • Wireless speaker • AC power adapter • 3.5mm Aux in cable S aker back ÑÑ Insert 8 AA batteries (not included) in the battery compartment on the bottom of the speaker. Plug it in with the included AC power adapter. This speaker offers two power options: 3 S aker back Single-Speaker Setup 1 Left-Mono-Right switch to Mono. 2 On/Off !! back of the speaker to turn it on. The left Status " #$ t on the back of the speaker blinks blue. 3 E ! % " & luetooth on your device (if it isn’t already on). Wi-Fi Bluetooth Bluetooth Settings VPN Settings Wi-Fi Settings 8:45PM Notes: Make sure the left Status light on the back of the speaker is blinking blue. (If it isn’t, press and hold the Pair button on the back of the speaker until the speaker gives an audio signal.) If you’ve previously paired a different Bluetooth device with this speaker, the speaker will automatically attempt to reconnect to that device when you switch the speaker on. If you want to pair to a new device, press and hold the Pair button on the speaker until the speaker gives an audio signal. Headset AR Speaker Computer 8:45 P M Blue tooth devices 4 "' AR Speaker ( om the list of Bluetooth devices available. Notes: If you don’t see AR Speaker in the list of Bluetooth devices on your phone, choose “Scan” from your phone’s Bluetooth menu. The process of enabling Bluetooth and connecting varies from device to device. See your device’s owners manual for more information and specific instructions. T ) % * $# + % ! % , # #$! % " - !# / 0 !# , '!!'# !$ 1 smartphone. The left Status " #$ t on the back of the speaker turns solid blue. Saker back Solid blue Continues on the next page... S aker back B2345346 blue 4 5 % ) " %1 # !$ 7 #'! 1 Bluetooth device. 8 :45 PM T ) % * % %7 # !$ 1 music wirelessly. To control the volume, press the + and – buttons on the back of the speaker, or use the volume controls on your Bluetooth device. 89:; tooth Wireless Connection Tips • Make sure the Bluetooth capability of your device is turned on. • Make sure there’s nothing plugged into the speaker’s Aux In jack when you’re trying to use Bluetooth. • The Bluetooth wireless connection works up to a range of roughly 33 feet (10 meters). This range may vary, however, based on other factors, such as room layout, wall material, obstacles, your device’s Bluetooth performance, etc. If you’re having problems connecting to the speaker, move closer to it. • If your device asks you for a password to connect, use “0000”. Single-Speaker Setup Note: Make sure your Bluetooth device is set to at least 75% volume. 5 LINKED Stereo Setup 1 Left-Mono-Right switch on one speaker to Left. Set the Left-Mono-Right - # '! the other speaker to Right. 2 On/Off ton on the back of the left speaker to turn it on. Press the On/Off ton on the back of the right speaker to turn it on. The right Status " #$ t on the back of the left speaker blinks white slowly. The right Status " #$ t on the back of the right speaker blinks white slowly. 3 W% # (#$ Status " #$ t on both speakers to turn solid white. Right speakerLeft speaker Solid white The left Status " #$ t on the left speaker will start blinking blue. This means the two speakers are linked for stereo and ready to pair with your Bluetooth device. R < = L>? = Continues on the next page... S aker back S aker back @DFGH5IJHK5 B2345346 white M36N t speaker back B2345346 white SO23QUN3F V XYZ[\] ^_`aZbc_]d_ebfff 6 4 E ! % " & luetooth on your device (if it isn’t already on). Wi-Fi Bluetooth Bluetooth Settings VPN Settings Wi-Fi Settings 8:45 P M Headset AR Stereo Computer 8:45PM Bluetooth devices 5 "' AR Stereo ( om the list of Bluetooth devices available. Make sure the left Status light on the back of the left speaker is blinking. (If it isn’t, press and hold the Pair button on the back of the left speaker until the speaker gives an audio signal.) Note: If you’ve previously paired a different Bluetooth device with this speaker, the speaker will automatically attempt to reconnect to that device when you switch the speaker on. If you want to pair to a new device, press and hold the Pair button on the speaker until the speaker gives an audio signal. If you don’t see AR Stereo in the list of Bluetooth devices on your phone, choose “Scan” from your phone’s Bluetooth menu. Note: The process of enabling Bluetooth and connecting varies from device to device. See your device’s owners manual for more information and specific instructions. T "( ) % * $# + % ! % , # #$! % " when it’s finished connecting to your smartphone. The left Status " #$ t on the back of the speaker turns solid blue. Left speaker 6 % ) " %1 # !$ 7 #'! 1 Bluetooth device. 8 :45PM T ) % * % %7 # !$ 1 music wirelessly, in True Stereo. To control the volume, press the + and – buttons on the back of the left speaker, or use the volume controls on your Bluetooth device. Stereo Setup SO23QJ2g VXYZ[\] ^_`aZbc_]d_ebfff Note: Make sure your Blu…
Text truncated - open the document above for the full version.
FILE NAME: APPROVED BY: DRAWN BY: MATERIAL/THICKNESS: DATE: DATE: DWG.NO: SHEET 1OF 1 MODEL: AWSEE2 PART NO: REV: A0 TITLE: CHECKED BY: DATECHG.BYPART NODESCRIPTIONECN NOREVISION REVISION RECORD BLOCK DIAGRAM OF AWSEE2 AAI Acoustic Arc International Ltd. DATE: BLOCK DIAGRAM OF AWSEE2 1.PART1: M1 MCU_SOC Contains RF Preamplifier, mixing, IF amplifier,Demodulation FUNCTIONAL DESCRIPTION 2.PART2: Line Input And U6 Bluetooth Input U2 Switch Function U5 Volume Control 5.PART5: LED1 KEY OPERATING And Working instructions LED AAi-E-BL-A-0304 M1 Bluetooth_MCU PART1 PART2 PART3 ANT PART4 3.PART3: U4 PAM8006A AUDIO AMPLIFIER IC 4.PART4: DC BATTERY INPUT POWER SUPPLY AMP_VDD U1,3 Manostat 5.0V_3.3V U4 PAM8006A U2 S7201 3.5mm Line_IN XZ2107 Q4 AMP_VDD 7805_5.0V U1 DC14V POWER SUPPLY BATTEERY 1.5AA X8PCS DC_IN D1 D9 S H U T _ D O W N D C _ S D U6 4558 LINE_SW PART5 2.400-2.483GHz XZ1803_3.6V U3 U5 M62429L I2C_CLK I2C_DATA 16MHz L E D 1 - A B L U E L E D 1 - B W H I T E V O L + V O L - P A I R P O W E R 3.6V The Block Diagram
INTERTEK TESTING SERVICES External Photos external photos - 1 of 2 INTERTEK TESTING SERVICES External Photos external photos - 2 of 2
Glendale(BS1470) Bluetooth speaker rating label P/N: 95-09-BS1470-01 Portable bluetooth speaker rating label Note: Size: 40*18mm Print: White font,Black ground,back glue. Unit: mm Tolerance: +/-0.5mm Scale: 1:1 Model: AWSEE2 Power Source: 14V 1A Battery Type: 8 X 1.5V (AA) battery FCC ID:VIXAWSEE2 IC: 342H-AWSEE2 Portable Bluetooth speaker BC CAN ICES-3 (B)/NMB-3 (B) Model: AWSEE2 Power Source: 14V 1A Battery Type: 8 X 1.5V (AA) battery FCC ID:VIXAWSEE2 IC: 342H-AWSEE2 Portable Bluetooth speaker BC CAN ICES-3 (B)/NMB-3 (B)
INTERTEK TESTING SERVICES Internal photos internal photos - 1 of 7 INTERTEK TESTING SERVICES Internal photos internal photos - 2 of 7 INTERTEK TESTING SERVICES Internal photos internal photos - 3 of 7 INTERTEK TESTING SERVICES Internal photos internal photos - 4 of 7 INTERTEK TESTING SERVICES Internal photos internal photos - 5 of 7 \ INTERTEK TESTING SERVICES Internal photos internal photos - 6 of 7 INTERTEK TESTING SERVICES Internal photos internal photos - 7 of 7
Technical Description The Equipment Under Test (EUT) is a 2.4GHz Bluetooth 2.1 + EDR transceiver speaker. The EUT is power by an AC Adapter (Model: K15S140100U; Input 100-240V, 50/60Hz, 0.5A; Output: 14.0V, 1.0A) or 8x 1.5VDC AA size Alkaline Battery. The Bluetooth module in the EUT is operating in the frequency range from 2402MHz to 2480MHz (79 channels with 1MHz channel spacing). After pairing, the audio signal can be fed to the speaker. Also there is an Aux port for audio input only 2.4GHz Bluetooth Module: Modulation Type: GFSK Antenna Type: Integral, Internal Frequency Range for 2.1: 2402MHz - 2480MHz, 1MHz channel spacing, 79 channels Nominal field strength is 92.9dBμV/m @ 3m Production Tolerance of field strength is 95.9 dBμV/m Antenna gain is 0dBi The functions of main ICs are mentioned below. 1. Part 1: MCU_SOC Contains RF Preamplifier, mixing, IF amplifier, Demodulation 1)M1 acts as the 2.4GHz radio core of Bluetooth module 2)Crystal (16MHz) to provide system clock for M1 2. Part 2: Line Input, Bluetooth Input, Switch Function and Volume Control 1)U6 acts as XZD4558 SOP-8 Dual operational amplifier 2)U2 acts as SPDT Analog Switch CRT 3) U5 acts as Volume Control IC 3. Part 3: AUDIO AMPLIFIER IC 1) U4 acts as 15WClass-D Audio Power Amplifier with Power Limit IC AMP PAM8006A QFN5*5-32L 4. Part 4: DC BATTERY INPUT POWER SUPPLY AMP_VDD U1,3 Manostat 5.0V_3.3V 1) U3 acts as 15WClass-D Audio Power Amplifier with Power Limit IC AMP PAM8006A QFN5*5-32L 2) U1 acts as a Voltage Regulator IC 3) Q4 acts as MOSFET XSZ2107 5. Part 5: LED1 KEY OPERATING And Working instructions LED ZYM-BT55_V1.0 Bluetooth Module Datasheet 2 Document History RevisionDateChange Reason V1.02011-12-10First release Copyright 2011 by JIAXING GLEAD ELECTRONICS CO.,Ltd. All Rights Reserved. Reproduction of this document in part or in whole, by any means is prohibited without written permission from JIAXING GLEAD ELECTRONICS Co.,Ltd. The information contained herein is believed to be accurate as of the date of publication. However, JIAXING GLEAD ELECTRONICS Co.,Ltd is not liable for any damages, including indirect or consequential from the use of software this document represents, or any reliance of the accuracy of this document.JIAXING GLEAD ELECTRONICSCo.,Ltd reserves the right to change the contents of this document at any time without notice. This document contains proprietary confidential trade secrets and may be subject to additional restrictions contained in the licensing agreement under which this document was obtained. 3 TABLE OF CONTENTS 1 Introduction and Block Diagram.............................................................................................. 4 1.1 General Introduction................................................................................................................................... 4 1.2 Block Diagram..............................................................................................................................................4 2 Key Features and Application Area.........................................................................................5 2.1 Key Features................................................................................................................................................5 2.2 Application Area...........................................................................................................................................5 3 Technical Specifications............................................................................................................ 6 3.1 General Specification..................................................................................................................................6 3.2 Electrical Characteristics............................................................................................................................6 3.2.1 Absolute Maximum Rating............................................................................................................. 6 3.2.2 Recommended Operating Conditions.......................................................................................... 6 3.2.3 Stereo Codec: Analogue to Digital Converter.............................................................................6 3.2.4 Stereo Codec: Digital to Analogue Converter.............................................................................7 4 Mechanical Dimensions and Pin Assignment......................................................................9 4.1 Mechanical Dimensions............................................................................................................................. 9 4.2 Pin Assignment..........................................................................................................................................10 5 Example Application Schematic............................................................................................ 12 6 NOTICE!........................................................................................................................................ 13 6.1 General information...................................................................................................................................13 6.2 Electro Static Discharge (ESD)...............................................................................................................13 7 Recommended Reflow Temperature Profile.......................................................................14 8 Order information.......................................................................................................................15 8.1 Order information.......................................................................................................................................15 8.2 Contacts.................................................................................................................................…
Text truncated - open the document above for the full version.
Analysis Report The Equipment Under Test (EUT) is a 2.4GHz Bluetooth 2.1 + EDR transceiver speaker. The EUT is power by an AC Adapter (Model: K15S140100U; Input 100-240V, 50/60Hz, 0.5A; Output: 14.0V, 1.0A) or 8x AA size Alkaline Battery. The Bluetooth module in the EUT is operating in the frequency range from 2402MHz to 2480MHz (79 channels with 1MHz channel spacing). After pairing, the audio signal can be fed to the speaker. Also there is an Aux port for audio input only. 2.4GHz Bluetooth Module: Modulation Type: GFSK Antenna Type: Integral, Internal Frequency Range for Bluetooth 2.1: 2402MHz - 2480MHz, 1MHz channel spacing, 79 channels Nominal field strength is 92.9dB μV/m @ 3m Production Tolerance of field strength is +/- 3dB Antenna gain is 0dBi Based on the Maximum allowed field strength of production tolerance was 95.9dBμV/m at 3m in frequency 2.4GHz, thus; The EIRP = [(FS*D) ^2*1000 / 30] =0.00117W= 1.17mW According to MPE, Conducted power = Radiated Power (EIRP) – Antenna Gain So; Conducted Power = 1.17mW The power density at 20cm = 1.17 *1.00/ 4πR 2 = 0.0020 mWcm-2 In the frequency range of 1,500 - 100,000MHz, the MPE limit is 1.0 mWcm -2 for general population and uncontrolled exposure. As the measured power density at Error! Reference source not found.cm from the transmitter is lower than the MPE limit, the compliance to the MPE limit can be ensured by indicating the minimum Error! Reference source not found.cm separation between the transmitter's radiating structures and body of the user or nearby persons. The following RF exposure statement is proposed to be included in the user manual: “ FCC RF Radiation Exposure Statement Caution: To maintain compliance with the FCC’s RF exposure guidelines, place the base unit at least Error! Reference source not found.cm from nearby persons.”
