VERINT CONFIDENTIAL This document contains proprietary and confidential information of Verint Systems Inc. 1 This document presents the S3100 series wireless portfolio. S3100 series are wireless access point used to bridge video data coming from wireless (from S1100 series wireless video encoders) to Ethernet LAN. S3100 series are for outdoor industrial used and is usually installed in low accessibility places like light pools and roofs top. The S3100 series are not available for general public and need professional installation. S3100 series are sold in an outdoor aluminum die cast enclosure. S3100 The S3100 has three flavors, the S3100, S3100-BR and S3100-RP. All have the same base hardware. As with the S1100, a marketing difference is made to highlight the three different types of deployments: access point, system level repeater (-RP) and bridge (-BR). The access point is composed of one S3100 with PoE power input; whereas the system level repeater (-RP) come as a kit with two 24 VAC powered S3100s connected back to back thru a wired LAN link. The bridge (-BR) come as a kit of two 24VAC powered S3100 connecting two independent wired LAN networks. PART NUMBER DESCRIPTION S3100-24 2.4 GHz Wireless Access Point (48V DC input) comes with power-over-Ethernet injector, 25- meter outdoor Ethernet cable, wall mount, pole mount brackets (antenna not included). S3100-5x 5 GHz Wireless Access Point (48V DC input) comes with power-over-Ethernet injector, 25- meter outdoor Ethernet cable, wall mount, pole mount brackets (antenna not included). S3100-POE 5GHz and 2.4GHz Wireless Access Point (48V DC input) comes with power-over-Ethernet VERINT CONFIDENTIAL This document contains proprietary and confidential information of Verint Systems Inc. 2 injector, 25-meter outdoor Ethernet cable, wall mount, pole mount brackets (antenna not included). S3100-BR-24 Outdoor 2.4 GHz wireless Ethernet bridge (24V AC input) with two 25-meter outdoor Ethernet cable, wall-mount and pole-mount brackets (2 antennas not included). S3100-BR-5X Outdoor 5 GHz wireless Ethernet bridge (24V AC input) with two 25-meter outdoor Ethernet cable, wall-mount and pole-mount brackets (2 antennas not included) S3100-RP-24 2.4 GHz system level repeater (24V AC input) with 1 meter outdoor Ethernet cable, wall- mount and pole-mount brackets (2 antennas not included). S3100-RP-5x 5 GHz system level repeater (24V AC input) with 1 meter outdoor Ethernet cable, wall-mount and pole-mount brackets (2 antennas not included). S3100-24AC 5 GHz Wireless Access Point (24V AC input) comes with power-over-Ethernet injector, 25- meter outdoor Ethernet cable, wall mount, pole mount brackets (antenna not included).

Host - external Host - external

ID Label S3100 Model Labels S3100 S3100-BR

Module in Host: Module in Host: Host – rear side: Host without Module – front: Module without host – front:

Prediction of MPE limit at a given distance Verint Nextiva S3100 Equation from page 18 of OET Bulletin 65, Edition 97-01where: S = power density P = power input to the antennaG = power gain of the antenna in the direction of interest relative to an isotropic radiatorR = distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal: 19.68 (dBm) Maximum peak output power at antenna input terminal: 92.89663868 (mW) Antenna gain(typical): 16 (dBi) Maximum antenna gain: 39.81071706 (numeric) Prediction distance: 30 (cm) Prediction frequency: 2437 (MHz) MPE limit for uncontrolled exposure at prediction frequency: 1 (mW/cm^2) Power density at prediction frequency: 0.327000 (mW/cm^2) 3.269999 (W/m^2) Maximum allowable antenna gain: 20.85452373 (dBi) Margin of Compliance: 4.854523735 dB 2 4 R PG S π =

www.nemko.com FCC Part 15 Subpart C, 15.247: July 2007 Test Report: 88791-3R2TRFWL Applicant: Verint Systems Canada Inc. 1800 Berlier LAVAL, QC H7L 4S4 Apparatus: S3100-24VAC, S3100-RP-24, S3100-POE, S3100- RP-5x, S3100-5x, S3100-24, S3100-BR-5x, S3100- BR-24 FCC ID: VKHCM9S3100 In Accordance With: FCC Part 15 Subpart C, 15.247 FHSS System and Digitally Modulated Radiators 902-928MHz, 2400 - 2483.5 MHz, 5725-5850MHz Tested By: Nemko Canada Inc. 303 River Road Ottawa, Ontario K1V 1H2 Authorized By: Xu Jin, Wireless Specialist Date: October 22, 2007 Total Number of Pages: 58 Nemko Canada Inc. REPORT SUMMARY Report Number: 88791-3R2TRFWL FCC ID: VKHCM9S3100 Specification: FCC Part 15 Subpart C, 15.247 Page 2 of 58 Report Summary These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with Part 15, Subpart C. Radiated tests were conducted in accordance with ANSI C63.4-2003. Radiated emissions are made on an open area test site. A description of the test facility is on file with the FCC. The assessment summary is as follows: Apparatus Assessed: S3100-24VAC, S3100-RP-24, S3100-POE, S3100-RP-5x, S3100-5x, S3100-24, S3100-BR-5x, S3100-BR-24 Specification: FCC Part 15 Subpart C, 15.247 Compliance Status: Complies Exclusions: None Non-compliances: None Report Release History: Original Release Author: Roman Kuleba, EMC/Wireless Specialist Note that the results contained in this report relate only to the items tested and were obtained in the period between the date of initial receipt of samples and the date of issue of the report. This test report has been completed in accordance with the requirements of ISO/IEC 17025. Nemko Canada Inc. authorizes the applicant to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko Canada Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. Nemko Canada Inc. REPORT SUMMARY Report Number: 88791-3R2TRFWL FCC ID: VKHCM9S3100 Specification: FCC Part 15 Subpart C, 15.247 Page 3 of 58 TABLE OF CONTENTS Report Summary......................................................................................................................................... 2 Section 1: Equipment Under Test.............................................................................................................. 4 1.1 Product Identification.................................................................................................................................4 1.2 Samples Submitted for Assessment ...........................................................................................................4 1.3 Theory of Operation...................................................................................................................................4 1.4 Technical Specifications of the EUT .........................................................................................................5 Section 2: Test Conditions.......................................................................................................................... 6 2.1 Specifications.............................................................................................................................................6 2.2 Deviations From Laboratory Test Procedures ...........................................................................................6 2.3 Test Environment.......................................................................................................................................6 2.4 Test Equipment ..........................................................................................................................................6 2.5 Measurement Uncertainty ..........................................................................................................................7 Section 3: Observations .............................................................................................................................. 8 3.1 Modifications Performed During Assessment ...........................................................................................8 3.2 Record Of Technical Judgements ..............................................................................................................8 3.3 EUT Parameters Affecting Compliance.....................................................................................................8 3.4 Test Deleted 8 3.5 Additional Observations ............................................................................................................................8 Section 4: Results Summary ...................................................................................................................... 9 4.1 FCC Part 15 Subpart C: Test Results .......................................................................................................10 Appendix A: Test Results ......................................................................................................................... 11 Clause §15.207(a) AC Powerline Conducted Emissions.....................................................................................11 Clause 15.209(a) Radiated Emissions within Restricted Bands ..........................................................................16 Clause 15.247(a)(2) Systems using digital modulation techniques .....................................................................27 Clause 15.247(b)(3) Maximum peak output power of systems using digital modulation in the 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz bands..................................................................31 Clause 15.247(b)(4) Maximum peak output power .........…
