VL5-840066Bluetooth Indoor/Outdoor Speaker

840066_INS_Big Blue GoInstructions Doc. Size: 450mm W x 115mm H Folded Size: 50mmW x 115mmH Output at 100% Prints 1/1 Black Finishing: Trim to Crops; Accordion Fold: 8 folds NiMH BATTERY WARNINGS This device contains a NiMH battery. The battery must be recycled or disposed of properly. Contact your local waste management office for information on battery recycling or disposal. FCC INFORMATION This equipment has been tested and found to comply with the limits for a Class B Digital Device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the distance between the equipment and receiver. • Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This equipment may not cause harmful interference. 2. This equipment must accept any interference received, including interference that may cause undesired operation. Modifications not authorized by the manufacturer may void the user’s authority to operate this device. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. RSS INFORMATION This device complies with RSS-210 of the IC Rules; Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must Big Blue Go XXXXXX 840066 Merrimack, New Hampshire, USA 03054 800-846-3000 • Brookstone.com accept any interference received, including interference that may cause undesired operation. Cet appareil est conforme à la norme RSS-210 de la règlementation d'Industrie Canada ; son utilisation est soumise aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. The device meets the exemption from the routine evaluation limits in section 2.5 of RSS 102 and compliance with RSS-102 RF exposure, users can obtain Canadian information on RF exposure and compliance. Le dispositif rencontre l'exemption des limites courantes d'évaluation dans la section 2.5 de RSS 102 et la conformité à l'exposition de RSS-102 rf, utilisateurs peut obtenir l'information canadienne sur l'exposition et la conformité de rf. This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada LOCATION OF PARTS AND CONTROLS 1. Charging LED Indicator (behind speaker grill) 2. LED Ring 3. Pairing/Play/Pause Button 4. Micro USB Charging Port 5. Power/Battery Level Switch 6. Volume Up Button 7. Volume Down Button 8. Call Answer/Track Forward Button 9. Call End or Ignore/Track Back Button 10. Vehicle Suction Mount 11. 12V Car Adapter 12. AC/DC Adapter 13. USB to Micro USB Charging Cable LOCATION OF PARTS AND CONTROLS CHARGING THE SPEAKER 1. Insert the included USB cable's MICRO USB connection into the MICRO USB CHARGING PORT on the speaker. 2. The speaker can be charged several ways: • Plug the USB cable's USB connection into the included AC/DC power adapter. Plug the AC/DC power adapter into an electrical wall outlet. • Plug the USB cable's USB connection into the included 12V CAR ADAPTER and plug the 12V CAR ADAPTER into your vehicle's 12V DC socket. • Plug the USB cable's USB connection into your computer’s USB port. 3. The CHARGING LED INDICATOR is RED while the speaker is charging. When the speaker is fully charged, the CHARGING LED INDICATOR is GREEN. For first time use, charge the speaker for at least 3 hours. 4. When speaker's battery is low, the CHARGING LED INDICATOR will flash RED. NEED FINAL NAME AND ESSENCE STATEMENT FROM FROM PACKAGE NEED PHOTO FROM PACKAGE 6 7 8 9 4 5 2 3 1 10 12 13 11 BLUETOOTH ® DEVICES The speaker pairs with devices that use the Bluetooth® Hands Free Profile (HFP) and/or the Advanced Audio Distribution Profile (A2DP). HFP enables hands-free communication and the A2DP dictates how audio is streamed from one device to another over a Bluetooth® connection. When you pair devices to the speaker, the devices operate according to their protocols. For example, when you pair a smartphone to the speaker, it handles calls and plays music since it has both the H2P and A2DP protocols. MP3 players with Bluetooth® and A2DP only play music and cell phones (not smartphones) only handle calls. PAIRING YOUR DEVICE 1. Prepare your device to pair using Bluetooth ® wireless technology, making sure you are within 33 feet of the speaker. Refer to your device’s owners manual for details if necessary. 2. Slide the POWER SWITCH to l to turn the speaker on. A tone will sound and the LED RING will illuminate solid blue for 5 seconds. Note: When the LED RING is off and any button is pressed, the LED RING will illuminate solid blue for 5 seconds and then turn off. 3. To put the speaker into pairing mode, press and hold the PAIRING BUTTON until the LED RING starts flashing. The speaker will wait for a connection in pairing mode for two minutes. 4. Once the…

Text truncated - open the document above for the full version.

Plastoform Industries Ltd Confidentiality Letter Date: Aug.5 th ,2013 Subject: Confidentiality Request for FCC ID: VL5-840066 and IC : 10612A-840066 Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC/IC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term Permanent Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Part List/Tune-Up Procedure Short Term Permanent Schematics Short Term Permanent User’s Manual Plastoform Industries Ltd. has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___(specify number of days not to exceed 180 ) ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify TUV Rheinland in the event information regarding the product or the product is made available to the public. TUV Rheinland will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Sincerely, By: ______ _ ___ Winny Mak (Signature/Manager) (Print name)

R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:VL5-840066 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13139 14-1 14. PHOTOS OF THE EUT Figure 1 General Appearance of the EUT Figure 2 General Appearance of the EUT R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:VL5-840066 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13139 14-2 Figure 3 General Appearance of the EUT Figure 4 General Appearance of the EUT

-

R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:VL5-840066 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13139 14-3 Figure 5 Inside of the EUT Figure 6 Inside of the EUT R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:VL5-840066 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13139 14-4 Figure 7 Inside of the EUT Figure 8 Inside of the EUT R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:VL5-840066 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13139 14-5 Figure 9 Inside of the EUT Figure 10 Battery of the EUT R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:VL5-840066 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13139 14-6 Figure 11 Label of the Battery Figure 12 Component of the PCB Board R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:VL5-840066 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13139 14-9 Figure 17 Component of the PCB Board Figure 18 Component of the PCB Board R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:VL5-840066 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13139 14-10 Figure 19 Component of the PCB Board Figure 20 Component of the PCB Board R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:VL5-840066 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13139 14-11 Figure 21 Speaker Figure 22 Speaker R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:VL5-840066 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13139 14-12 Figure 23 Power Adapter Figure 24 Power Adapter R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:VL5-840066 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13139 14-13 Figure 25 Power Adapter Figure 26 USB Cable

R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:VL5-840066 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13139 13-1 13. PHOTOGRAPH OF TEST 13.1. Photos of Conducted Emission at Mains Terminals Test R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:VL5-840066 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13139 13-2 13.2. Photos of Radiated Emission Test (30-1000MHz) R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:VL5-840066 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F13139 13-3 (Above 1000MHz)
