VO8-R9Bluetooth Headset

4 Product overview The Bluetooth Stereo Headset is composed of: 1.MF Button ( ) 2.Microphone( ) 3.Charging Jack( ) 4.Speaker( ) 5.Earhook( ) 6.Indicator Light( ) 7.Previous Song/Volume (-) Button( ) 8.Next Song/Volume (+) Button( ) Charging the headset Your headset uses a rechargeable battery. You must charge the battery fully before using the headset for the first time. Please make sure to turn off the headset before charging. 1. Plugging the charging cradle in the port. 2. The red indicator light remains solid when charging. 3. The fully charging takes approximately2-3 hours. 4. The indicator light is in solid blue when charging completed. How to turning on/off: Turn on:Press the MF button until you hear the beep and the blue indicator light flashes. Turn off: Press the MF button until you hear the beep and the blue indicator light flashes twice. Redialing the previous call Press and hold the MF button for 2 seconds until you hear a long beep. Playing music When you are listening to the music, you can press the MF button to play music or make a pause and the volume control buttons is to select previous song and next song (Briefly press the Volume + to go to next song and Volume to go to the previous song.). 67 phone. Take the headset away from the mobile phone for more than 10 meters (33ft). Reconnect the paired headset with the mobile phone If you want to connect the paired headset with the mobile phone, you can do as below: Turning on the headset and setting up the connection in the Bluetooth list of your mobile phone Pressing once the MF button of the headset. (You have to do the setting in your mobile phone to allow the automatic connection with the paired headset.) Answering a call When you hear the ring tone, press the MF button once If you prefer answering the call by your phone, you can transfer the call from the headset on your phone. Ending a call Press and release the MF button once or end call on your phone's keypad. Answering or rejecting a call when listening to music If there is ring tone of incoming call when you are listening to music from your phone or PC or other Bluetooth enabled devices, press the MF button to answer the call and press and hold the MF button for 2 seconds to reject the call. Pause or put a call on hold During the phone call, just press and hold the MF button for 2 seconds to put a call on hold. If you want to resume to the call, you can also press and hold the MF button for 2 seconds. (This is subject to the mobile phone's feature.) Volume control Press and hold the Volume Control (+) to increase volume and release when it reaches your preferred volume. Vice versa! 5 Pairing with your Bluetooth phone 1. The distance between the Bluetooth headset and your Bluetooth phone would be better within 1 meter when pairing, the closer the better. 2. Ensuring the headset is off. 3. Pressing still the Multifunctional Button until you see the blue light remains solid. 4. Set your Bluetooth phone to discover the headset by following your phone's guide. Typically, the steps involved are going to a "Setup" "Connect" or "Bluetooth" menu on your phone and then select the option to discover Blueto- oth devices. 5. Your phone will find the headset and ask if you want to pair with it. Confirming this by pressing “yes” or “ok”. 6.Enter passkey “0000”, then press “yes” or “ok”. IMPORTANT：If pairing is successful, the indicator light will flash in blue 10 times rapidly before going to flashing every 3 seconds, If unsuccessful, the light remains on, and you will need to reattempt the pairing. While the light will go out if the pairing time takes more than 60 seconds, in that case, you need to turn off the headset and turn it on for pairing again. Disconnect the headset from the mobile phone If you want to disconnect the headset from the mobile phone, you can do as below: Turn off the headset Disconnect the headset from the Bluetooth list the mobile 2.将充电器插头插入耳机充电接口( ),另一端插到交流电 源插座上(如图）.此时耳机开始充电,充电时,红灯( )恒亮. 3.耳机充足电,大约需要2-3个小时,充满后蓝灯( )恒亮或红 灯熄灭. 蓝牙配对步骤: 1.配对时,请将蓝牙耳机和手机的距离控制在1米范围内, 越近越好. 2.确认蓝牙耳机处于开机状态. 3.按多功能键( ),到蓝灯( )恒亮或红蓝灯( )同时(交 替)亮,此时耳机进入蓝牙配对状态. 4.按照蓝牙手机的说明书,打开"蓝牙搜索"或"添加新设备" 选择耳机名称,确认后按手机的提示输入"0000"确认. 注意:蓝牙耳机的配对时间是有限的"一般为60秒",如果蓝 灯( )熄灭变为红灯( )闪烁状态说明蓝牙配对状 态已停止.如果您这时仍未配对成功,请重复步骤1~4 再次配对. 开机或关机 开启耳机时,请按住多功能键( ),耳机会蜂鸣且蓝色指示灯 ( )会快速闪烁或长按多功能键( )进入配对状态。 关闭耳机时,请按住多功能键( ),耳机会蜂鸣且蓝色指示灯 ( )会快速闪烁两下. 将已配对耳机重新连接至手机 要连接耳机和手机,请打开耳机,使用手机的"蓝牙"功能表建立 连接,或按一下多功能键( ). 断开耳机与手机的连接 要断开耳机与手机的连接(例如,将手机连接至其他蓝牙设备), 请采用以下任一方式: 关闭耳机 使用手机的"蓝牙"功能表断开耳机与手机的连接. 将耳机移至距离手机10米(约30英尺)以远的位置. 用户使用说明书 USER GUIDE 1 耳机由以下部分组成: 1.多功能键( ) 2.麦克风( ) 3.充电插孔( ) 4.听筒( ) 5.耳挂( ) 6.指示灯( ) 7.上一曲/音量-（ ） 8.下一曲/音量+（ ） 使用入门 耳机充电 本耳机使用内置式不可拆卸充电电池. 请勿尝试从耳机中取出 电池,以免损坏耳机. 1.充电时,先将耳机关机 使用充电器给本耳机充电前,请先检查充电器是否为耳机配套 充电器. 警告: 必须使用配套的充电器给耳机充电,使用不配套 的充电器可能会损坏耳机 充电器和电池 您可以设置手机,使其在耳机启动时自动与耳机建立连接.在手 机中,要实现这一目的,请在"蓝牙"功能表中更改配对设备设置. 接听来电 ( ) 来电时,耳机内发出来电提示音或铃声,按下耳机多功能键, 即可接听来电,或使用手机接听键,接听来电 挂断通话 ( ) 按下耳机多功能键或使用手机挂断键即可挂断通话. 暂停或保留通话 通话时，长按多功能键( )2秒可保留现有通话，如需恢复通 话,则长按多功能键( )2秒。(是否支持本功能,取决于手机) 末位重拨 耳机支持末位重拨功能：长按2秒耳机多功能键( )即可实现 末位重拨。 音乐播放/暂停/选曲 收听音乐时可以操作多功能键( )播放或暂停,上一曲、下一 曲进行选曲等。(短按一次"+"为下一曲,短-次"-"为上一曲) 音量调节 ：， 音量键调节音量的大小长按住"+"3秒为音量增大长按住 "-"3秒为音量减小(注:当音量达到最大或最小时会有蜂鸣声 提示) 拒绝来电 长按2秒耳机多功能键( )或直接用手机挂断键即可拒绝来电. 23 R Bluetooth Stereo Headset FCC STATEMENT: 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE:This equipment has been tested and found to comply with the limitsfor a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses an…

Text truncated - open the document above for the full version.

LI BATTERY 5V ADAPTER ANT1 3.7V LDO IS1621N-152 U2 ANT LED X 2 MIC MFB, MUSIC CONTROL PUSH BUTTON K1 Headphone Driver 16M Crystal

SCS-F18: Project and Product Certification Representative Authorization LetterPage1of2Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) FromTo Approved Date Initial Release (current)1.01.0Nov-14-2006 Revised wording(current)1.02.0Sept–25-2007 SCS-F18: Project and Product Certification Representative Authorization LetterPage2of2Rev 2.0 East Notice Certification Service Co., Ltd. 09/03/2010 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re:Project and ProductCertification Representative Authorization Letter We, _East Notice Certification Service Co., Ltd.hereby authorize SIEMIC, INC. to act as a Certification Bodyforcertifyingfor the following project(s): Product Description:Bluetooth Headset ModelName:R9 We affirm that between SIEMIC andEast Notice Certification Service Co., Ltd., any difference in understanding, includingtest plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, SamLiu/engineer Tel: 020-23314234 Fax: 020-82568534 E-mail: [email protected] 317/319, 3/F,HuiCheng Building, XiangPu Street, DongPu,TianHe, GuangZhou, China

The results shown in this test report refer only to the sample(s) tested unless otherwise stated and the sample(s) are retained for 30 days only. The document is issuedby ENC, this document cannot be reproduced except in full with our prior written permission. The document is available on request and the brief informationfor its validation can be assessable and confirmed athttp://www.enc-lab.com. 317/3193/FHuiCheng Building, XiangPuTel:+86-020-23314234Fax:+86-020-8256 8534 Street, DongPu, TianHe, GuangZhouE-mail: enc@ enc-lab.comHttp://www.enc-lab.com EastNoticeCertification Report No.:ENC100825GZ38F1-1 Page1of3 ATTACHMENTI PHOTOGRAPHS OF EUT ALL VIEW OF SAMPLE The results shown in this test report refer only to the sample(s) tested unless otherwise stated and the sample(s) are retained for 30 days only. The document is issuedby ENC, this document cannot be reproduced except in full with our prior written permission. The document is available on request and the brief informationfor its validation can be assessable and confirmed athttp://www.enc-lab.com. 317/3193/FHuiCheng Building, XiangPuTel:+86-020-23314234Fax:+86-020-8256 8534 Street, DongPu, TianHe, GuangZhouE-mail: enc@ enc-lab.comHttp://www.enc-lab.com EastNoticeCertification Report No.:ENC100825GZ38F1-1 Page2of3 TOP VIEW BOTTOM VIEW The results shown in this test report refer only to the sample(s) tested unless otherwise stated and the sample(s) are retained for 30 days only. The document is issuedby ENC, this document cannot be reproduced except in full with our prior written permission. The document is available on request and the brief informationfor its validation can be assessable and confirmed athttp://www.enc-lab.com. 317/3193/FHuiCheng Building, XiangPuTel:+86-020-23314234Fax:+86-020-8256 8534 Street, DongPu, TianHe, GuangZhouE-mail: enc@ enc-lab.comHttp://www.enc-lab.com EastNoticeCertification Report No.:ENC100825GZ38F1-1 Page3of3 LEFT VIEW RIGHT VIEW

The results shown in this test report refer only to the sample(s) tested unless otherwise stated and the sample(s) are retained for 30 days only. The document is issuedby ENC, this document cannot be reproduced except in full with our prior written permission. The document is available on request and the brief informationfor its validation can be assessable and confirmed athttp://www.enc-lab.com. 317/3193/FHuiCheng Building, XiangPuTel:+86-020-23314234Fax:+86-020-8256 8534 Street, DongPu, TianHe, GuangZhouE-mail: enc@ enc-lab.comHttp://www.enc-lab.com EastNoticeCertification Report No.:ENC100825GZ38F1-2 Page1of3 ATTACHMENTII InternalPhotos The results shown in this test report refer only to the sample(s) tested unless otherwise stated and the sample(s) are retained for 30 days only. The document is issuedby ENC, this document cannot be reproduced except in full with our prior written permission. The document is available on request and the brief informationfor its validation can be assessable and confirmed athttp://www.enc-lab.com. 317/3193/FHuiCheng Building, XiangPuTel:+86-020-23314234Fax:+86-020-8256 8534 Street, DongPu, TianHe, GuangZhouE-mail: enc@ enc-lab.comHttp://www.enc-lab.com EastNoticeCertification Report No.:ENC100825GZ38F1-2 Page2of3 The results shown in this test report refer only to the sample(s) tested unless otherwise stated and the sample(s) are retained for 30 days only. The document is issuedby ENC, this document cannot be reproduced except in full with our prior written permission. The document is available on request and the brief informationfor its validation can be assessable and confirmed athttp://www.enc-lab.com. 317/3193/FHuiCheng Building, XiangPuTel:+86-020-23314234Fax:+86-020-8256 8534 Street, DongPu, TianHe, GuangZhouE-mail: enc@ enc-lab.comHttp://www.enc-lab.com EastNoticeCertification Report No.:ENC100825GZ38F1-2 Page3of3

Circuit Description Bluetooth is a short-range wireless communication technology. The design applied is in internationalidentification ISM (Industrial Scientific and Medical) frequency bandwidth environment that is2.4GHz~2.48GHz bandwidth. TheR9Bluetooth Headset is a wirelessstereoheadset manufactured with the Latest Bluetoothtechnology, complied Bluetooth specification v2.0. Within a range of 10 meters, R9Bluetoothheadset can connect to other Bluetooth devices which have built-in audio gateway, such as MobilePhone, Desktop, Notebook Computer or PDA etc.. The Headset consists of the Changer Circuit, 1.8V Switched mode Regulator, Bluetooth HeadsetModule IS1601G, Audio Speaker Circuit, Microphone Bias, Status indicating LED and ThreeMultifunctionButtons for power on/off, pairing, call control, Volume Control etc. Charger Circuit The Headset are often powered internally using a 3.7 volt Lithium-ion Polymer with short circuitprotection and a capacity of 120mAh, The battery charger is based on theU2, U2 has a VCC input forthe power source from an external5.0~5.5volt DC supply. An output to the battery, Battery volt is forMicrophone Bias circuit and Bluetooth Module power 1.8V DC/DC circuit. Bluetooth module IS1601G The IC/CPU is a Class 2 Bluetooth sub-system using BlueCore2-Headset ROM chipset fromleading Bluetooth chipset supplier ISSC with a maximal output power of less than 4dBm. The moduleblock includes Bluecore02 IC, EEPROM, Band pass Filter and Crystal for clock. The RF circuit includes the antenna matching components and a ceramic antenna welded in the circuitboard. The crystal provides the whole circuit the standard reference frequency of 16MHz. There is no externalground connection.Theground is only that of the printed circuit board. Switched mode 1.8 Volt regulator For optimum efficiency, a switch mode power supply provides the 1.8V for digital, analogue and RFportions of the device. This converter is powered from a Li-polymer battery.

.512.05 1.70 3.10 1.63 1.12 2.05 1.08 FCC ID :VO8-R9 Bluetooth (Portable device) According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB 447498 (2)(a)(i) Frequency Range Low Frequency (MHz)High Frequency(MHz) Center frequency (MHz) 60/f SAR Limitation (mw) 24022480244124.5 Maximum measured transmitter power: Conducted Power (mw)Max Antenna Gain (dBi)EIRP (mw) 1.8 Remark：EIRP=P*G=*1=mW Threshold at which no SAR required is 25 mw. Maximum Tx power is24.5mw EIRP. Conclusion: No SAR is required. SIMULTANEOUS TRANSMISSION EVALUATION Signature RayZhou/ ManagerSep.9,2010 1.8 1.8 3.10

123456 A B C D 6 54321 D C B A Title NumberRevisionSize B Date:8-Sep-2010 Sheet of File:F:\卢工\新建文件夹 (2)\6款PCB-152\6款PCB-152\R9-152立体声OK\1621N-152.DdbDrawn By: AOHPR 1 VDDAO 2 AOHPMS 3 AOHPM 4 VSSAO 5 AOHPL 6 VDDA 7 VSSA 8 VCOM 9 MICP2 10 MICN2 11 MICN1 13 MIC_BIAS 14 VDD_IO 15 P23 16 P15 17 RST_N 18 P12 / SCL 19 P13 / SDA 20 1V8 21 GND 22 CODEC_VOUT 23 3V1_O 24 3V1_IN 25 1V8_O 26 1V8_IN 27 ADAP_IN 28 BAT_IN 29 SAR_AVDD 30 SYS_P WR 31 BK_VDD 32 BK_LX 33 BK_GND 34 BK_OUT 35 MFB 36 LED1 37 LED2 38 P24 39 P22 40 P02 41 P27 42 P05 43 1V8 44 GND 45 HCI_TXD 46 HCI_RXD 47 P16 48 VDD_IO 49 XO_P 50 XO_N 51 VCC_RF 52 TP6 53 TP5 54 RX_CLASS1 55 RTX 56 P01 / TX_CLS1 57 P03 / RX_CLS2 58 P30 59 P31 60 P20 61 P00 62 P04 63 VDD_IO 64 P35 65 GND 66 EAN 67 1V8 68 GND 69 MICP1 12 U2 IS1621N-152 C5 220PF SPKR+ SPKR/L- 3V1_O C7 220PF SPKL+ MIC- MIC+ 3V1_O C13 4.7UF C18 22nF C20 22nF C33 220PF C17 0.1UF R11 2.2K R12 2.2K 3V1_C 3 21 Q1 MMBT3904 1 2 R14 2.2K C25 1uF +5V A0 1 A1 2 A2 3 GND 4 SDA 5 SCL 6 WP 7 VCC 8 U3AT24C08 3V1_C 1V8 C39 1UF SYS_PWR C23 0.1UF ADAP_IN 1V8 B- C37 0.1UF C22 10UF L4 10uH C36 4.7UF C16 10UF RF_VCC 1 2 R10 1K MFB P24 +5V P24 1V8 MFB TXD RXD RX TX C31 0.1UF 3V1_C 4 1 3 2 X1 16MHZ CL=9P C11 10P C12 10P C30 0.1UF C10 1UF RF_VCC C81 3.9nH L3 2.2uH L2 NP L5 4.7nH 12 R13 10K ANT1 SW3 VLO_ down SW1 SW2 VLO+UP P20 P 20 E AN SPK L+ SPK R+ C29 0.1UF 3V1_C 12 R6 NC C9 0.1UF 1V8 C35 4.7uF C34 4.7uF GND +5VADAP_IN BAT+ GND C19 1UF C2 4.7UF EAN RF_VCC RF C24 10UF 1 2 LED2 R 1 2 LED1 B MIC+ MIC- 3V1_C C6 39pF C40 10pF C8 39pF C41 10pF C4 39pF C14 10pF BAT 5V - -RF GND 2010年度的最新立体声 GND 1 VOUT 2 VIN 3 U1 RT9161-50PV(300mA) C42 39pF C21 10pF SPKR/L- 3V1_O 12 R15 1R 12 R16 1R 1V8 1 2 R14 1K 12 R30 0R C80 1pF 12 R15 NC R30 0 1 2 L3 2.2nH

The results shown in this test report refer only to the sample(s) tested unless otherwise stated and the sample(s) are retained for 30 days only. The document is issued by ENC, this document cannot be reproduced except in full with our prior written permission. The document is available on request and the brief information for its validation can be assessable and confirmed at http://www.enc-lab.com. 317/319 3/F HuiCheng Building, XiangPuTel:+86-020-2331 4234Fax:+86-020-8256 8534 Street, DongPu, TianHe, GuangZhouE-mail: enc@ enc-lab.comHttp:// www.enc-lab.com East Notice Certification FCC Radio Test Report FCC ID: VO8-R9 This report concerns (check one):■Original Grant□Class II Change For Bluetooth Headset Model Name: R9 Brand Name: Bluedio Report No.: ENC100825GZ38F1 Date of Issue: Sep.3, 2010 Prepared For Guangzhou Liwei Electronics Co., Ltd. No.33, Zhenzhongbei Road,Shenshan Industrial Park Baiyuan District Guangzhou 510460 P.R. China TEL: +86-20-8606 2626 FAX: +86-20-8606 2626-800 Prepared By East Notice Certification Service Co., Ltd. 317/319, 3/F, HuiCheng Building, XiangPu Street, DongPu, TianHe, GuangZhou, China TEL: +86-20-2331 4234 FAX: +86-20-8256 8534 The results shown in this test report refer only to the sample(s) tested unless otherwise stated and the sample(s) are retained for 30 days only. The document is issued by ENC, this document cannot be reproduced except in full with our prior written permission. The document is available on request and the brief information for its validation can be assessable and confirmed at http://www.enc-lab.com. 317/319 3/F HuiCheng Building, XiangPuTel:+86-020-2331 4234Fax:+86-020-8256 8534 Street, DongPu, TianHe, GuangZhouE-mail: enc@ enc-lab.comHttp:// www.enc-lab.com East Notice Certification Report No.:ENC100825GZ38F1 Page 1 of 83 TABLE OF CONTENTS 1 . CERTIFICATION.............................................................................................................................3 2 . SUMMARY OF TEST RESULTS.................................................................................................4 2.1 TEST FACILITY............................................................................................................................5 2.2 MEASUREMENT UNCERTAINTY..............................................................................................5 3 . GENERAL INFORMATION...........................................................................................................6 3.1 GENERAL DESCRIPTION OF EUT............................................................................................6 3.2 DESCRIPTION OF TEST MODES..............................................................................................8 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING..................................................8 3.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED.......................9 3.5 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE)..............................................10 4 . EMC EMISSION TEST.................................................................................................................11 4.1 CONDUCTED EMISSION MEASUREMENT...........................................................................11 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS.................................................................11 4.1.2 MEASUREMENT INSTRUMENTS LIST AND SETTING.....................................................11 4.1.3 TEST PROCEDURE...............................................................................................................12 4.1.4 DEVIATION FROM TEST STANDARD..................................................................................12 4.1.5 TEST SETUP...........................................................................................................................12 4.1.6 EUT OPERATING CONDITIONS...........................................................................................13 4.1.7 TEST RESULTS......................................................................................................................14 4.2 RADIATED EMISSION MEASUREMENT.....................................................................................16 4.2.1 RADIATED EMISSION LIMITS................................................................................16 4.2.2 MEASUREMENT INSTRUMENTS LIST ANS SETTING..............................................17 4.2.3 TEST PROCEDURE...............................................................................................................18 4.2.4 DEVIATION FROM TEST STANDARD..................................................................................18 4.2.5 TEST SETUP...........................................................................................................................19 4.2.6 EUT OPERATING CONDITIONS...........................................................................................19 4.2.7 TEST RESULTS (BETWEEN30 –1000 MHZ)...........................................................20 4.2.8 TEST RESULTS (ABOVE 1000 MHZ)..................................................................................22 5 . NUMBER OF HOPPING CHANNEL.........................................................................................46 5.1 APPLIED PROCEDURES / LIMIT.............................................................................................46 5.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING.....................................................46 5.1.2 TEST PROCEDURE...............................................................................................................46 5.1.3 DEVIATION FROM STANDARD............................................................................................46 5.1.4 TEST SETUP...........................................................................................................................46 5.1.5 EUT OPERATION CONDITIONS....…

Text truncated - open the document above for the full version.

The results shown in this test report refer only to the sample(s) tested unless otherwise stated and the sample(s) are retained for 30 days only. The document is issuedby ENC, this document cannot be reproduced except in full with our prior written permission. The document is available on request and the brief informationfor its validation can be assessable and confirmed athttp://www.enc-lab.com. 317/3193/FHuiCheng Building, XiangPuTel:+86-020-23314234Fax:+86-020-8256 8534 Street, DongPu, TianHe, GuangZhouE-mail: enc@ enc-lab.comHttp://www.enc-lab.com EastNoticeCertification Report No.:ENC100825GZ38F1-3 Page1of3 ATTACHMENTIII PHOTOGRAPHS OF THE TEST SETUP The results shown in this test report refer only to the sample(s) tested unless otherwise stated and the sample(s) are retained for 30 days only. The document is issuedby ENC, this document cannot be reproduced except in full with our prior written permission. The document is available on request and the brief informationfor its validation can be assessable and confirmed athttp://www.enc-lab.com. 317/3193/FHuiCheng Building, XiangPuTel:+86-020-23314234Fax:+86-020-8256 8534 Street, DongPu, TianHe, GuangZhouE-mail: enc@ enc-lab.comHttp://www.enc-lab.com EastNoticeCertification Report No.:ENC100825GZ38F1-3 Page2of3 CONDUCTED EMISSION TESTSETUP RADIATED EMISSION TEST SETUP The results shown in this test report refer only to the sample(s) tested unless otherwise stated and the sample(s) are retained for 30 days only. The document is issuedby ENC, this document cannot be reproduced except in full with our prior written permission. The document is available on request and the brief informationfor its validation can be assessable and confirmed athttp://www.enc-lab.com. 317/3193/FHuiCheng Building, XiangPuTel:+86-020-23314234Fax:+86-020-8256 8534 Street, DongPu, TianHe, GuangZhouE-mail: enc@ enc-lab.comHttp://www.enc-lab.com EastNoticeCertification Report No.:ENC100825GZ38F1-3 Page3of3 RADIATED EMISSION TEST SETUP
