How to Place ThermoSENSOR™ (TSS-24XX) Identify an area for ThermoSENSOR™ (TSS-24XX) to be pasted. 1. Place 3 fingers down from the navel. Refer to diagram. 2. Place the first layer of adhesive dressing about half the distance from the center to the side of the body. Refer to diagram. 3. Place ThermoSENSOR™ on another layer of adhesive dressing*. The second layer of dressing should be pasted over the front of the sensor. Do not paste the dressing on the metal part of the sensor. You may use any suitable medical adhesive dressing e.g. 3M tegaderm 4. Place ThermoSENSOR™ (with the second layer of adhesive dressing) over the first layer of adhesive dressing. 5. For cleaning before use, wipe the ThermoSENSOR™ with an alcohol swab. Please Note: Cadi Scientific recommends 3M Tegederm dressing for use with the ThermoSENSOR as it has been tested to have no adverse effect on the user/ThermoSENSOR. Please Note: Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment. 3 fingers down

EUT PHOTOGRAPHS Front View Rear View S07EEC00276

The label shown will be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. Sample Label& Physical Location of FCC Label on EUTforSTG-2400 Sample Label & Physical Location of FCC Label on EUT forTSS-2400

EUT PHOTOGRAPHS Internal View S07EEC00276 EUT PHOTOGRAPHS Main-BoardPCB–View 1 S07EEC00276 EUT PHOTOGRAPHS Main-BoardPCB–View 2 S07EEC00276 EUT PHOTOGRAPHS RF Module Circuit S07EEC00276 RF Antenna RF Module

Test Report No. S07EEC00276/01 dated 15 Jan 2008 Note: This report is issued subject to TÜV SÜD PSB's "Terms and Conditions Governing Technical Services". The terms and conditions governing the issue of this report are set out as attached within this report. LA-2007-0380-A LA-2007-0380-A-1 LA-2007-0381-F LA-2007-0382-B LA-2007-0383-G LA-2007-0384-G LA-2007-0385-E LA-2007-0386-C The results reported herein have been performed in accordance with the laboratory’s terms of accreditation under the Singapore Accreditation Council - Singapore Laboratory Accreditation Scheme. Tests/Calibrations marked "Not SAC-SINGLAS Accredited" in this Report are not included in the SAC-SINGLAS Accreditation Schedule for our laboratory. Laboratory: TÜV SÜD PSB Pte. Ltd. Testing Services No.1 Science Park Drive Singapore 118221 Phone : +65-6885 1333 Fax : +65-6776 8670 E-mail: [email protected] www.tuv-sud-psb.sg Co. Reg : 199002667R Regional Head Office: TÜV SÜD Asia Pacific Pte. Ltd. 3 Science Park Drive, #04-01/05 The Franklin, Singapore 118223 Page 1 of 41 FORMAL REPORT ON TESTING IN ACCORDANCE WITH FCC Parts 15B & C : 2007 OF A ThermoSENSOR [ Model : TSS-2400 ] [ FCC ID : VPE-TSS2400 ] TEST FACILITY TÜV SÜD PSB Pte Ltd, Electrical & Electronics Centre (EEC), Product Services, 1 Science Park Drive, Singapore 118221 FCC REG. NO.90937 (3m & 10m OATS) 99142 (10m Anechoic Chamber) 871638 (3m Anechoic Chamber) 325572 (10m Anechoic Chamber) C-2305 (C.E @ Lab 6), C-2306 (C.E @ Lab 3) T-212 (Telecom Ports @ Lab 6), T-213 (Telecom Ports @ Lab 3) IND. CANADA REG. NO.IC 4257 (3m and 10m Anechoic Chambers) PREPARED FORMr Ng Wai Mun Cadi Scientific Pte Ltd 1003 Bukit Merah Central #04-40 Singapore 159836 Tel : (65)6276 2676Fax : (65)6276 6216 QUOTATION NUMBER56Q0700440 JOB NUMBERS07EEC00276 TEST PERIOD03 Jan 2008 – 09 Jan 2008 PREPARED BYAPPROVED BY ____________________ Quek Keng Huat Associate Engineer ____________________ Lim Cher Hwee Assistance Vice President Cadi Scientific Pte LtdPage 2 of 41 ThermoSENSOR [ Model : TSS-2400 ] [ FCC ID : VPE-TSS2400 ] Test Report No.S07EEC00276/01 dated 15 Jan 2008 TABLE OF CONTENTS TEST SUMMARY PRODUCT DESCRIPTION SUPPORTING EQUIPMENT DESCRIPTION EUT OPERATING CONDITIONS RADIATED EMISSION (SPURIOUS EMISSIONS INCLUSIVE RESTRICTED BANDS REQUIREMENT) TEST RADIATED EMISSION (FUNDAMENTAL AND HARMONICS) TEST BAND EDGE COMPLIANCE (RADIATED) TEST DUTY CYCLE FACTOR COMPUTATION ANNEX A-EUT PHOTOGRAPHS / DIAGRAMS ANNEX B- FCC LABEL & POSITION ANNEX C- USER MANUAL, TECHNICAL DESCRIPTION, BLOCK & CIRCUIT DIAGRAMS Cadi Scientific Pte LtdPage 3 of 41 ThermoSENSOR [ Model : TSS-2400 ] [ FCC ID : VPE-TSS2400 ] Test Report No.S07EEC00276/01 dated 15 Jan 2008 TEST SUMMARY The product was tested in accordance with the customer's specifications. Test Results Summary Test StandardDescriptionPass / Fail FCC Part 15: 2007 15.107(a), 15.207Conducted EmissionsNot Applicable * See Note 4 15.109(a), 15.205, 15.209 Radiated Emissions (Spurious Emissions inclusive Restricted Bands Requirement) Pass 15.249(a)Radiated Emissions (Fundamental and Harmonics) Pass 15.249(d)Band Edge Compliance (Radiated) - @ Restricted Bands Pass 15.35(c)Duty Cycle Factor ComputationRef er to page 27 for details Notes 1. Three channels as listed below, which respectively represent the lower, middle and upper channels of the Equipment Under Test (EUT) were chosen and tested. For each channel, the EUT was configured to operate in the test mode. Transmit Channel Frequency (GHz) Channel12.402 Channel 32.450 Channel 52.481 2. The EUT is a Class B device when in non-transmitting state and meets the FCC Part15B Class B requirements. 3. All test measurement procedures are according to ANSI C63.4: 2003. 4. The Equipment Under Test (EUT) is a battery operated device and contains no provision for public utility connections. 5. The declaration of Cadi Scientific Pte Ltd is shown below: The models STG-2400 and TSS-2400 are identical models in term of components, circuitry design, PCB layout and mechanical structure, and the differences between these models are: a. Casing b. Temperature measuring functions. The modelTSS-2400is the worst case model between the declared models in view of EMC, and if the modelTSS-2400passes the EMC test, the declared modelSTG-2400is deemed to pass the same test. Cadi Scientific Pte LtdPage 4 of 41 ThermoSENSOR [ Model : TSS-2400 ] [ FCC ID : VPE-TSS2400 ] Test Report No.S07EEC00276/01 dated 15 Jan 2008 TEST SUMMARY Modifications No modifications were made. Cadi Scientific Pte LtdPage 5 of 41 ThermoSENSOR [ Model : TSS-2400 ] [ FCC ID : VPE-TSS2400 ] Test Report No.S07EEC00276/01 dated 15 Jan 2008 PRODUCT DESCRIPTION Description: The Equipment Under Test (EUT) is a ThermoSENSOR.The EUT is able to transmit temperature information wirelessly via RF or Infra- Red (IR). Manufacturer: Cadi Scientific Pte Ltd 1003 Bukit Merah Central #04-40 Singapore 159836 Model Number: TSS-2400 FCC ID:VPE-TSS2400 Serial Number: Nil Microprocessor: PIC16F690 Operating / Transmitting Frequency : 2.402GHz - 2.481GHz Clock / Oscillator Frequency:31kHz,8MHz& 16MHz Modulation: Frequency Shift Key (FSK) Antenna Gain: 0 dBi Port / Connectors: Nil Rated Input Power:2.3Vdc-3.6Vdc Accessories: Nil Cadi Scientific Pte LtdPage 6 of 41 ThermoSENSOR [ Model : TSS-2400 ] [ FCC ID : VPE-TSS2400 ] Test Report No.S07EEC00276/01 dated 15 Jan 2008 SUPPORTING EQUIPMENT DESCRIPTION The EUT was tested as a stand-alone unit without any supporting equipment. Cadi Scientific Pte LtdPage 7 of 41 ThermoSENSOR [ Model : TSS-2400 ] [ FCC ID : VPE-TSS2400 ] Test Report No.S07EEC00276/01 dated 15 Jan 2008 EUT OPERATING CONDITIONS FCCPart 15 1.Conducted Emissions 2. Radiated Emissions (Spurious Emissions inclusive Restricted Bands Requirement) 3. Radiated Emissions (Fundamental and Harmonics) 4. Duty Cycle Factor Computation The EUT was exercised by in following modes during the test: RF Mode The maximum RF continuous transmission / receiving, i.e transmitting / rec…

Text truncated - open the document above for the full version.

RADIATED EMISSION TEST Radiated Emissions Test Setup (Front View) Radiated Emissions Test Setup (Rear View)
