VQQ-RK960NARControl unit A-RKE & ATAS(receiver)

S&T Remote Keyless Entry System TECHNICAL SPECIFICATION ORIGINATING CENTER: S&T Daewoo TECHNICAL CENTER FILENAME: RKE_RECEIVER.doc REVISION NO.: A0 DATE: 24 / July / 2007 SHIN BONG CHUL THCHNICAL CENTER: Phone: 082 - (0)51 – 509 – 2593 Fax: 082 - (0)51 – 508 – 3994 R&D / Automotive Electronics Title Remote Keyless Entry System Specification Spec. No. DPE-AE-RK019912S Written by Rev. No. A0 Date 24 . July. 2007 Page 2 / 23 TABLE OF CONTENTS 1. INTRODUCTION...............................................................................................................3 1.1 REMOTE KEYLESS ENTRY FUNCTION ........................................................................3 1.2 ANTI-THEFT FUNCTION ..................................................................................................3 2. SYSTEM DESCRIPTION..................................................................................................4 3. RKE FUNCTION................................................................................................................6 3.1 DOOR LOCK / UNLOCK USING TRANSMITTER..........................................................6 3.1.1 TRANSMITTER LOCK / UNLOCK/PANIC ......................................................................6 3.1.2 TRANSMITTER UNLOCK/LOCK/ TRUNK .....................................................................7 3.2 BURGLAR ALARM ............................................................................................................9 3.3 DISARMING BY KEY CYLINDER .................................................................................10 3.4 SAFETY LOCK(AUTO DOOR LOCK AFTER 30SEC) ..................................................10 3.5 SECURITY INDICATOR ..................................................................................................11 3.6 DIAGNOSTIC ....................................................................................................................11 3.7 ACTIVE RANGE ...............................................................................................................11 3.8 IPC SIGNAL CONTROL(ONSTAR FUNCTION) ...........................................................12 4. SYSTEM CONFIGRATION ...........................................................................................13 4.1 RECEIVER .........................................................................................................................13 4.1.1 FUNCTION.........................................................................................................................13 4.1.2 ELECTRIC SPEC ...............................................................................................................13 4.1.3 METHOD OF CODING TRANSMITTER ........................................................................13 4.2 TRANSMITTER.................................................................................................................14 4.2.1 ELECTRIC SPEC ...............................................................................................................14 4.2.2 DATA FORMATION .........................................................................................................14 4.2.3 TRANSMITTER FUNCTION............................................................................................15 4.2.4 BATTERY ..........................................................................................................................15 4.2.5 LED .....................................................................................................................................16 5. SYSTEM INPUT/OUTPUT CIRCUITS.........................................................................17 5.1.1 SERIAL DATA LINK(NO. A17) .......................................................................................17 5.1.2 ELECTRIC OUTPUT .........................................................................................................17 5.1.2.1 HAZARD LAMP (LEFT : A26, RIGHT : A13).................................................................17 5.1.2.2 SECURITY INDICATOR(A19).........................................................................................17 5.1.2.3 DOOR LOCK(A10) ............................................................................................................17 5.1.2.4 DOOR UNLOCK(A11) ......................................................................................................17 5.1.2.5 2 STEP UNLOCK (A16, PROVISION) .............................................................................18 5.1.2.6 HORN(A1) ..........................................................................................................................18 5.1.2.7 TRUNK RELEASE(A14) ...................................................................................................18 5.1.3 ELECTRIC INPUT .............................................................................................................18 5.1.3.1 TRUNK KEY CYLINDER UNLOCK SWITCH INPUT(A4) ..........................................19 5.1.3.2 DRIVER KEY CYLINDER LOCK SWITCH INPUT(A6, PROVISION) ........................19 5.1.3.3 PASSENGER KEY CYLINDER UNLOCK SWITCH INPUT(A22) ...............................19 5.1.3.4 HOOD OPEN SWITCH INPUT(A7) .................................................................................19 5.1.3.5 TRUNK OPEN SWITCH INPUT(A5) ...............................................................................20 5.1.3.6 DOOR OPEN SWITCH INPUT (A8) ................................................................................20 5.1.3.7 IGNITION SWITCH INPUT (A15) ...................................................................................21 5.1.3.8 KEY REMINDER SWITCH INPUT (A18) .......................................................................21 5.1.3.9 DOOR LOCK MONITORING SWITCH INPUT (A9) .................................................21 6. HORN........…

Text truncated - open the document above for the full version.

SAW Filter Matching Circuits LNA Circuits Matching Circuits RF IC (Demodulation) MICOM X-tal 315MHz RK960NAR__BLOCK DIAGRAM X-TAL(10.17813 MHz)

(Contact Person/Title) S&T Daewoo Co., Ltd. 5, Songjeong-ri, Cholma-myon,Kijang-gun, Busan, South Korea Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD21046 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission's Rules (47 C.F.R) and Section §552(b)(4) of the Freedom of Information Act, S&T Daewoo Co., Ltd. requests confidentiality for the following products: FCC ID Number Product Title / Model VQQ-RK960NAR Control Unit A-RKE & ATAS/ RK960NAR For the product stated above, we request that the following information be held confidential: 1) Schematic diagrams 2) Bill of materials (Part List) No other items submitted as part of the equipment authorization filing process are deemed confidential. The above exhibits contain S&T Daewoo Co., Ltd. trade secrets and proprietary information that could be of benefit to our competitors regarding the design of our products. This material is not customarily available to the general public and we request that it be withheld from public inspection. Sincerely, KIM YUN SU / Senior Research Engineer

SK TECH CO., LTD. Page 1 of 3 SKTTRT-071019-027 FCC ID: VQQ-RK960NAR, IC: 7313A-RK960NAR External Photographs of EUT <Photograph 1: Front View> Type HB receiver Type NB receiver SK TECH CO., LTD. Page 2 of 3 SKTTRT-071019-027 FCC ID: VQQ-RK960NAR, IC: 7313A-RK960NAR <Photograph 2: Rear View> Type NB receiver Type HB receiver SK TECH CO., LTD. Page 3 of 3 SKTTRT-071019-027 FCC ID: VQQ-RK960NAR, IC: 7313A-RK960NAR <Photograph 3: Interface View>

ID Label Location & Sample LABEL LOCATION: Label will be printed on the REAR of the product LABEL Drawing Control unit A-RKE & ATAS(Receiver) MODEL: RK960NAR (RM0-100003) FCC ID: VQQ-RK960NAR IC: 7313A-RK960NAR This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Control unit A-RKE & ATAS(Receiver) MODEL: RK960NAR (RM0-100009) FCC ID: VQQ-RK960NAR IC: 7313A-RK960NAR This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Type HB receiver Type NB receiver

SK TECH CO., LTD. Page 1 of 3 SKTTRT-071019-027 FCC ID: VQQ-RK960NAR, IC: 7313A-RK960NAR Internal Photographs of EUT <Photograph 1: Cover removed_Type HB> <Photograph 2: Cover removed_Type NB> SK TECH CO., LTD. Page 2 of 3 SKTTRT-071019-027 FCC ID: VQQ-RK960NAR, IC: 7313A-RK960NAR <Photograph 3: RF Board Front View_HB> <Photograph 4: RF Board Front View_NB> SK TECH CO., LTD. Page 3 of 3 SKTTRT-071019-027 FCC ID: VQQ-RK960NAR, IC: 7313A-RK960NAR <Photograph 5: RF Board Rear View_HB > <Photograph 6: RF Board Rear View_NB >

Operational Description (Receiver function) The product, RK960NAR, has several parts as Remote Keyless Entry and Anti-Theft System. - power supply - microprocessor - EEPROM - drivers for the external status led - drivers for the external siren, flashing bulb and door lock relay unit - drivers for the external trunk open actuator - serial data link for communication with the test equipment - ignition signal input circuit - theft detection input circuit(door open, hood open, trunk open) - key cylinder lock / unlock input circuit - RF signal receiver - RF signal receiving antenna PART: RF signal receiver See block diagram and schematics. The receiver IC (U101) demodulates RF signals from the transmitter (RK950NAT) and the DATA is transmitted to microprocessor (U6). The receiver IC (U101) is a fully integrated single-chip receiver, primarily intended for use in VHF and UHF systems. It supports both Amplitude Shift Keying (ASK) and Frequency Shift Keying (FSK) demodulation. By connecting pin 10 as shown the product schematics, the IC works as an FSK receiver. The IC (U101) incorporates a crystal stabilized local oscillator, frequency multiplier, balanced mixer, post mixer amplifier, limiter, Received Signal Strength Indicator (RSSI), FSK demodulator, data filter, data slicer and power down circuit. MIXER: Matching of the RF source impedance to the mixer input (pin 23) is achieved by using 315 MHz SAW filter (SAWF1). OSCILLATOR: The oscillator frequency is controlled by the crystal (X40 – 50.7167 MHz). Off-chip capacitors between base and emitter (C111) and ground (C41) make the oscillator transistor appear as having negative resistance at small signal levels. This causes the oscillator to start. A parallel resonance circuit (L103 and C110) connected to the emitter of the oscillator transistor prevents oscillation at the fundamental frequency of the crystal. IF FILTER: IF filtering with high selectivity is achieved by means of the external ceramic filter (C/F ), which feeds the IF from the PMA to the limiter. FM DEMODULATOR: Coming from the limiter the FSK signal is fed differential to the input of the FM demodulator. After buffering the signal is fed to a phase detector. The phase shift is generated by the external LC combination connected to DEMO1 (pin 10) and DEMO2 (pin 11). The baseband is coupled out single ended via an output buffer and is fed to the FSK input of the ASK/FSK switch. Block diagram of the receiver IC (U101)

SK TECH CO., LTD. Page 1 of 13 0 Report No. : SKTTRT-071019-027 FCC ID: VQQ-RK960NAR, IC: 7313A-RK960NAR Certificate of Compliance Test Report No.: SKTTRT-071019-027 KOLAS NO.: KT191 Applicant: S&T Daewoo Co., Ltd. Applicant Address: 5, Songjeong-ri, Cholma-myon,Kijang-gun, Busan, Korea Manufacturer: S&T Daewoo Co., Ltd. Manufacturer Address: 5, Songjeong-ri, Cholma-myon,Kijang-gun, Busan, Korea Device Under Test: Control unit A-RKE & ATAS FCC ID: IC: VQQ-RK960NAR 7313A-RK960NAR Model No.: RK960NAR Receipt No.: SKTEU07-0967 Date of receipt: September 20, 2007 Date of Issue: October 19, 2007 Location of Testing: SK TECH CO., LTD. 820-2, Wolmoon-Ri, Wabu-Up, Namyangju-Si, Kyunggi-Do, Korea Test Procedure: ANSI C63.4 / 2003 Test Specification: FCC Part 15 Rules, RSS-210 Issue 7 Equipment Class: IC Equipment Category: CYY - Communications Receiver used w/Pt 15 Transmitter RSS-210 Issue 7: Category I Equipment(Licence-exempt receivers) Test Result: The above-mentioned device has been tested and passed. Tested & Reported by: Seong-Baek, Ko 2007. 10. 19 Approved by: Jong-Soo, Yoon 2007. 10. 19 Signature Date Signature Date Other Aspects: Abbreviations: · OK, Pass = passed · Fail = failed · N/A = not applicable ☞ z The above test certificate is the accredited test results by Korea Laboratory Accreditation Scheme, which signed the ILAC-MRA. z This test report is not permitted to copy partly without our permission. z This test result is dependent on only equipment to be used. z This test result is based on a single evaluation of one sample of the above mentioned. z We certify that this test report has been based on the measurement standards that is traceable to the national or International standards. SK TECH CO., LTD. Page 2 of 13 0 Report No. : SKTTRT-071019-027 FCC ID: VQQ-RK960NAR, IC: 7313A-RK960NAR >> CONTENTS << 1. GENERAL ......................................................................................................................... 3 2. TEST SITE ........................................................................................................................ 3 2.1 Location ...................................................................................................................... 3 2.2 List of Test and Measurement Instruments ................................................................. 4 2.3 Test Date ..................................................................................................................... 4 2.4 Test Environment ........................................................................................................ 4 3. DESCRIPTION OF THE EQUIPMENT UNDER TEST ............................................. 5 3.1 Rating and Physical Characteristics ........................................................................... 5 3.2 Equipment Modifications ··························································································· 5 3.3 Submitted Documents ································································································· 5 4. MEASUREMENT CONDITIONS .................................................................................. 6 4.1 Description of test configuration ................................................................................ 6 4.2 List of Peripherals .......................................................................................................6 4.3 Type of Used Cables ................................................................................................... 6 4.4 Uncertainty ................................................................................................................. 6 5. TEST AND MEASUREMENTS ...................................................................................... 7 5.1 RADIATED EMISSIONS .......................................................................................... 7 5.1.1 Regulation ............................................................................................................ 7 5.1.2 Test Procedure ..................................................................................................... 8 5.1.3 Test Results............................................................................................................ 9 Table 1: Measured values of the field strength.......................................................... 9 5.2 CONDUCTED EMISSIONS ................................................................................... 10 5.2.1 Regulation .......................................................................................................... 10 5.2.2 Test Procedure ....................................................................................................11 5.2.3 Test Results.......................................................................................................... 12 Table 2: Measured values of the conducted emissions............................................ 12 Figure 1: Plot of the Conducted Emissions ............................................................. 13 SK TECH CO., LTD. Page 3 of 13 0 Report No. : SKTTRT-071019-027 FCC ID: VQQ-RK960NAR, IC: 7313A-RK960NAR 1. GENERAL These tests were performed using the test procedure outlined in ANSI C63.4, 2003 for unintentional radiators, and in accordance with the limits set forth in FCC Part 15.109. The EUT (Equipment Under Test) has been shown to be capable of compliance with the applicable technical standards. We attest to the accuracy of data. All measurements reported herein were performed by SK TECH CO., LTD. and were made under Chief Engineer’s supervision. We assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. 2. TEST SITE SK TECH CO., LTD. 2.1 Location 820-2, Wolmoon-Ri, Wabu-Up, Namyangju-Si, Kyunggi-Do, Korea (FCC Registered Test Site Number: 90752) This test site is in compliance with ISO/IEC 17025 f…

Text truncated - open the document above for the full version.

SK TECH CO., LTD. Page 1 of 1 SKTTRT-071019-027 FCC ID: VQQ-RK960NAR, IC:7313A-RK960NAR Test set up photos <Radiated Emissions - Front View> <Radiated Emissions - Rear View>
