VS9-EXTXEX-05 MILITARY STYLE HEADSET CRISP&DEEP

EX - 05 MILITARY STYLE HEADSET CRISP AND DEEP WIRED STEREO HEADPHONES ex05_wireless_universal_eu_manual.indd 105/09/2011 12:14 thank you Thank you for purchasing the EX-05 Military Style Headset from Gioteck. We hope that this product will go beyond your expectations for a quality made accessory. Please read this booklet thoroughly before using the product. Thank you & enjoy! precautions This product has been designed with the highest concern for safety. However, any electrical device, if used improperly, has the potential to cause harm. To help ensure risk-free operation please pay attention to the following guidelines. • Use only as intended. This is a precision product, handle with care. • Contains small parts. Not suitable for children under 3 years of age. • Store in a dry & dust free area. Do not store in areas of extreme heat or cold, and avoid direct sunlight or heat sources eg. heaters. • Do not allow the product to get wet or dirty; doing so may cause damage. • Do not clean with benzene, paint thinner, acetone, alcohol, or other such solvents. • Do not take the product apart; doing so will void your warranty and may cause electrical shock. warnings This symbol indicates important installation, operational or maintenance instructions. Always follow these instructions closely. environment Please help to conserve the environment by recycling all of the packaging of this product. This headset should NOT be disposed of in normal household waste. It should be disposed of separately. Please take it to an electrical waste collection point. 02 | CONTENTS & PRECAUTIONS CONTENTS 02 | Contents & Precautions 03 | Features & Details 05 | Set Up - Xbox 10 | Set Up - PS3 13 | Set Up - PC 14 | Pairing / Charging 15 | Troubleshooting / Legals ex05_wireless_universal_eu_manual.indd 205/09/2011 12:14 features & details The EX-05 comes with true-to-life sound acoustics that make sure you hear your enemy, before you see them. Providing high quality, true sound & using the latest cutting edge audio technology, the EX-05 comes with a lightweight headband, ergonomic adjusters and circumaural ear cups to provide outstanding comfort. headset 01 | Lightweight Headband 02 | Headset Adjusters 03 | Micro-Fibre Mufflers 04 | Flexible Rubber Mic Boom 05 | Connector Cable 06 | Connector Plug FEATURES & DETAILS | 03 01 02 06 05 03 04 TO INLINE CONTROLLER GB ex05_wireless_universal_eu_manual.indd 305/09/2011 12:14 04 | FEATURES & DETAILS wireless control box 01 | Headset Connector 02 | Wireless Control Box 03 | Power Switch ON/OFF 04 | DC Input 05 | Game Volume 06 | Xbox Live Chat Input 07 | Mute Switch 08 | Chat Volume wireless receiver 09 | Wireless Receiver 10 | USB Connector 11 | Mini Jack Cable 12 | RCA Pass Through Connectors 0102 10 030504 09 060708 11 12 features & details ex05_wireless_universal_eu_manual.indd 405/09/2011 12:14 SET UP - XBOX | 05 GB set up - xbox 360 slim using standard a/v cables Use the AV cable supplied with your Xbox 360 to connect your console to your TV (or sound system) as shown. This will allow you to hear your game time through your TV or EX-05 Headset. RCA TV INPUTS AV MULTI OUT WIRELESS RECEIVER (INCLUDED) MINI JACK USBAV CABLE SUPPLIED WITH XBOX 360® CONSOLE WHITEYELLOWRED ex05_wireless_universal_eu_manual.indd 505/09/2011 12:14 06 | SET UP - XBOX set up - xbox 360 using hdmi HDMI OUTPUT HDMI CABLE (NOT SUPPLIED) AV MULTI OUT USBAV CABLE S UPPLIED WITH XBOX 360® CONSOLE RC A SPLITTER CABLE (INCLUDED) HDMI TV WIRELESS RECEIVER (INCLUDED) MINI JACK ex05_wireless_universal_eu_manual.indd 605/09/2011 12:14 SET UP - XBOX | 07 GB HDMI TV ALTERNATIVE SET UP HDMI OUTPUT HDMI CABLE (NOT SUPPLIED) USB AV MULTI OUT AV CABLE (SOLD SEPERATELY) RCA SPLITTER CABLE (INCLUDED) WHITERED RCA TV OUTPUT set up - xbox 360 slim using hdmi WIRELESS RECEIVER (INCLUDED) MINI JACK ex05_wireless_universal_eu_manual.indd 705/09/2011 12:14 08 | SET UP - XBOX set up - chat on xbox 360 The EX-05 may be used to communicate with other players during XBOX live multi player gaming sessions. Plug the Mini Jack cable supplied into the Mini Jack cable port of the wireless control box (1) and connect the other end of the cable to the input of your Xbox controller (2). To customise your chat settings, follow the instructions opposite. 01 02 ex05_wireless_universal_eu_manual.indd 805/09/2011 12:14 AB BackSelect Voice Game Volume Mute Kinect 6 Voice Output Play Through Headset Play Through Speakers Play Through Both Voice VolumeSet options for in-game voice and private chat. Voice Volume adjusts how loud other people sound. Game Volume adjusts the game’s volume during chat. 10 Profile MarketplaceGamesMediaGioteck666Settings Family Settings System Settings Account Managment Turn O„ Console Preferences Xbox Guide ABXY BackSelectSign OutXbox Dashboard AB BackSelect Notifications Voice Vibration Family Timer Online Status Preferences Xbox Dashboard Xbox Guide MarketplaceGamesMediaGioteck666Settings Friends Party ABXY BackSelectSign OutXbox Dashboard Messages Chat & IM Play a Game SET UP - XBOX | 09 1. At the Xbox dashboard select the 'settings' menu. 3. Select 'voice' from the 'preferences' menu. 2. Select 'preferences' from the 'settings' menu. 4. Adjust settings. GB ex05_wireless_universal_eu_manual.indd 905/09/2011 12:14 10 | SET UP - PS3 set up - ps3 using standard a/v cables 1. After navigating to the Sound Settings' menu, press X on Audio Output Settings. 2. Press X on the icon labelled: Audio Input Connector / SCART / AV MULTI to select this option. AV MULTI OUT WIRELESS RECEIVER (INCLUDED) USB PORT AV CABLE (SUPPLIED WITH PS3™ CONSOLE) TV INPUTS YELLOWWHITERED ex05_wireless_universal_eu_manual.indd 1005/09/2011 12:14 SET UP - PS3 | 11 set up - ps3 using hdmi 1. Within the Settings' menu, press X on Sound Settings. 2. Press X on the icon labelled: Audio Multi Output and turn setting to ON. GB AV CABLE (SUPPLIED WITH PS3™ CONSOLE) HDMI TV HDMI OUTPUTAV MULTI OUT WIRELESS RECEIVER (INCLUDED) NOTE: If your TV suppor…

Text truncated - open the document above for the full version.

External Photo

FCC ID: VS9‐EXTX Label: FCC ID: VS9‐EXTX Specifications: Te x t is Black in color and justified. Labels are printed in indelible ink on permanent adhesive silk‐screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Lable Location

Internal Photo

SZ11100091W03 Page 2 of 23 DIRECTORY 1. GENERAL INFORMATION .................................................................................................... 3 1.1. EUT Description ....................................................................................................................... 3 1.2. Test Standards and Results ........................................................................................................ 4 1.3. Facilities and Accreditations ..................................................................................................... 5 2. CONDUCTED EMISSION ....................................................................................................... 6 3. RADIATED EMISSION ............................................................................................................ 7 4. BAND EDGE ............................................................................................................................ 15 5. 20DB BANDWIDTH ................................................................................................................ 19 Change History Issue Date Reason for change 1.0 December 6, 2011 First edition SZ11100091W03 Page 3 of 23 1. General Information 1.1. EUT Description EUT Type ............................. : EX-05 MILITARY STYLE HEADSET CRISP& DEEP WIRELESS STEREO HEADPHONES Serial No. .............................. : (n.a, marked #1 by test site) Hardware Version ................. : N/A Software Version .................. : Applicant .............................. : Manufacturer ........................ : N/A Goodbetterbest Limited Suites 103-107 Devonshire Business Centre Works Road Letchworth Herts SG6 1GJ United Kingdom Goodbetterbest Limited Suites 103-107 Devonshire Business Centre Works Road Letchworth Herts SG6 1GJ United Kingdom Frequency Range .................. : The frequency range used is 2403MHz - 2477MHz (75 channels, at intervals of 1MHz); The frequency block is 2400MHz to 2483.5MHz. Modulation Type .................. : FHSS (GFSK(1Mbps)) Note 1: The EUT is a EX-05 MILITARY STYLE HEADSET CRISP&DEEP WIRELESS STEREO HEADPHONES, the frequencies allocated for the Module is F(MHz)=2400+1*n (3<=n<=77). The lowest, middle, highest channel numbers of the Module used and tested in this report are separately 3 (2403MHz), 40 (2440MHz) and 77 (2477MHz). Note 2: The EUT is capable of MIMO operation, it supports two transmit chains. Note 3: For a more detailed description, please refer to Specification or User’s Manual supplied by the applicant and/or manufacturer. SZ11100091W03 Page 4 of 23 1.2. Test Standards and Results The objective of the report is to perform testing according to FCC Part 15 Paragraph 15.249 (Operation within the bands 2400- 2483.5MHz) for the EUT FCC ID Certification: Test Test Requirement Test Method Class/ Severity Result Radiated Emission (30MHz to 25GHz) FCC PART 15: 2009 ANSI C63.4: 2009 Class B PA S S Conducted Emission (150KHz to 30MHz) FCC PART 15: 2009 ANSI C63.4: 2009 Class B N/A SZ11100091W03 Page 5 of 23 1.3. Facilities and Accreditations 1.3.1. Facilities Shenzhen Morlab Communications Technology Co., Ltd. Morlab Laboratory is a testing organization accredited by China National Accreditation Service for Conformity Assessment (CNAS) according to ISO/IEC 17025. The accreditation certificate number is L3572. All measurement facilities used to collect the measurement data are located at 3/F, Electronic Testing Building, Shahe Road, Xili, Nanshan District, Shenzhen, 518055 P. R. China. The test site is constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 and CISPR Publication 22; the FCC registration number is 741109. 1.3.2. Test Environment Conditions During the measurement, the environmental conditions were within the listed ranges: Temperature (°C): 15 - 35 Relative Humidity (%): 30 -60 Atmospheric Pressure (kPa): 86-106 SZ11100091W03 Page 6 of 23 2. Conducted Emission The test is not applicable, because the EUT is not switched, contains no switches, does not include inductive loads. SZ11100091W03 Page 7 of 23 3. Radiated Emission 3.1.1. Requirement The radiated emission tests were performed in the 3m Semi-Anechoic Chamber, the EUT complied with the FCC Part 15 Paragraph 15.249 standards. The specification used in this report was the FCC Part 15 Paragraph 15.249 and FCC Paragraph 15.209 (a) limits, except as provided elsewhere in this subpart, the emissions from an intentional radiator shall not exceed the field strength levels specified in the following table: A. FCC Part 15 subpart C Paragraph 15.249 Limit Fundamental Frequency Field Strength of Fundamental Field Strength of Harmonics mV/m dBμV/m μV/m dBμV/m 902- 928 MHz 50 94 500 54 2400- 2483.5 MHz 50 94 500 54 5725- 5875 MHz 50 94 500 54 24.0- 24.25GHz 250 108 2500 68 Note: (1). RF Voltage(dBμV)= 20 log RF Voltage(μV) (2). Distance refers to the distance in meters between the measuring instrument antenna and the Closed point of any part of the device or system. (3). The emission limit in this paragraph is based on measurement instrumentation employing an average detector. Measurement using instrumentation with a peak detector function, corresponding to 20dB above the maximum permitted average limit. (4). Limit fundamental is 94dBμV/m@3m(AV) and 114 dBμV/m@3m(PK) Limit field strength of harmonics: 54 dBμV/m@3m(AV) and 74 dBμV/m@3m(PK). B. Frequencies in restricted band are complied to limit on Paragraph 15.209 Frequency (MHz) Field Strength (μV/m) Measurement Distance (m) Field Strength Limitation at 3m Measurement Dist 0.009 - 0.490 2400/F(kHz) 300 20log 2400/F(KHz) + 80 0.490 - 1.705 24000/F(kHz) 30 20log 2400/F(KHz) + 40 1.705 - 30.0 30 30 20log 30 + 40 30 - 88 100 3 20log 100 88 - 216 150 3 20log 150 216 - 960 200 3 20log 200 Above 960 500 3 20log 500 Note: 1. For Above 1000MHz, the emission limit in this paragraph is based on measurement instrumentation employing an average detector, measure…

Text truncated - open the document above for the full version.

Test Setup Photos 1. CSE 2.RSE
