VS9-GC2WIU-11GC2 Wireless Controller (Wii u)

Good Better Best Ltd trading as Gioteck
GC2 Wireless Controller (Wii u) - FCC ID VS9-GC2WIU-11 - Good Better Best Ltd trading as Gioteck
Click to zoom

Application Details

Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
Date of Grant
Jan 10, 2013
Application Purpose
Original Equipment
Date of Application
Dec 19, 2012
Equipment Note
GC2 Wireless Controller (Wii u)
Frequency Range
2402.00000000 - 2480.00000000
Company
Good Better Best Ltd trading as Gioteck
Country
United Kingdom

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Goodbetterbest Limited Suites 103-107, Devonshire Business Centre, Works Road, Letchworth, SG6 1GJ, United Kingdom Tel: +44(0) 1462 472390 Email: [email protected] GC2WIU GC2 Wireless Controller (Wii U) operational Manual Feature : - 8 functional buttons : x, y, a, b, L, R, ZL, ZR - + / - / Home/Power Button - SYNC Button - Directional Pad - 2 x sticks - Mini USB Jack for battery charging - Powered by built-in Li-ion Battery - Channel LED, Battery charging LED A) Connecting the GC2WIU game pad To connect the GC2WIU game pad 1. Press the “SYNC” Button on the GC2WIU game pad and press “SYNC” Button on the Wii console. The GC2WIU will select the port automatically, and the corresponding LEDs light. LED PORT 1 1 2 2 3 3 4 4 2. Now, you can enjoy the game play with Gioteck wireless game pad. 3. The GC2WIU game pad is properly set up for Wii connection. Simply press any button once to link up to Wii for all subsequent connection. 4. If Wii console in the standby state, press “Power” button once to turn on Wii and link up to Wii for all subsequent connection. B) Power Management System The GC2WIU game pad turns off if it is connected to the Wii console and is not used for 5 minutes. The GC2WIU game pad automatically turns off if it is not connected to the Wii console for 10 seconds. To turn off the GC2WIU game pad, press and hold Power button for 3 seconds to force it to turn off. To turn on the GC2WIU game pad, press any button once. The GC2WIU game pad turns on and the LED lights. C) Low battery indication When the built-in Li-ion battery in low power, the corresponding port LED flashes in 4Hz. D) Battery charging indication When the GC2WIU game pad is connected to Wii U, the battery charging LED flashes in 1 Hz. When charging is finished, the battery charging LED lights off. When the GC2WIU game pad is not connected to Wii U, the battery charging LED turns ON during charging and turns OFF when charging is completed. E) Troubleshooting i) The game pad does not wake up when USB cable is connected The USB port is for battery charging only. It does not wake up the game pad ii) The USB cable does not improve the wireless interference problem The USB cable is for battery charging. The wireless data communication with Wii remains through the Bluetooth. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment NOTE:THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT.SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device et appareil est conforme aux norms CNR exemptes de licence d’Industrie Canada. Le fonctionnement est soumis aux deux conditions suivantes: (1)cet appareil ne doit pas provoquer d’interférences et (2)cet appareil doit accepter toute interférence, y compris celles susceptibles de provoquer un fonctionnement non souhaité de l’appareil. Complies with the Canadian ICES-003 Class B specifications. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. This device complies with RSS 210 of Industry Canada. This Class B device meets all the requirements of the Canadian interference-causing equipment regulations. Cet appareil numérique de la Classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada.

External Photos

R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:VS9-GC2WIU-11 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F12252 14-1 14. PHOTOS OF THE EUT Figure 1 General Appearance of the EUT Figure 2 General Appearance of the EUT R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:VS9-GC2WIU-11 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F12252 14-2 Figure 3 General Appearance of the EUT Figure 4 General Appearance of the EUT

ID Label/Location Info

GC2 Wireless Controller (WII U) MODEL: GC2WIU DC 3.7V 20mA FCC ID.: VS9-GC2WIU-11 IC: 10670A-GC2WIU R5012SP-A MADE IN CHINA 36*24 MM N28707 GC2 Wireless Controller (WII U) MODEL: GC2WIU DC 3.7V 20mA FCC ID.: VS9-GC2WIU-11 IC: 10670A-GC2WIU R5012SP-A MADE IN CHINA N28707

Internal Photos

R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:VS9-GC2WIU-11 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F12252 14-3 Figure 5 Components Side of the PCB Figure 6 Components Side of the PCB R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:VS9-GC2WIU-11 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F12252 14-4 Figure 7 Components Side of the PCB Figure 8 Components Side of the PCB R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:VS9-GC2WIU-11 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F12252 14-5 Figure 9 Components Side of the PCB Figure 10 Components Side of the PCB R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:VS9-GC2WIU-11 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F12252 14-6 Figure 11 Battery of the EUT Figure 12 Battery of the EUT R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:VS9-GC2WIU-11 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F12252 14-7 Figure 13 USB Cable

RF Exposure Info

R 52 Block Shenzhen, Science & Industry Park, 信華科技 ( 深圳 ) 有限公司 Nantou, Shenzhen, Guangdong, China. Audix Technology (shenzhen) Co.,Ltd Tel:(0755)26639495~7 Fax:(0755)26637289 EUT: GC2 Wireless Controller (Wii U) M/N: GC2WIU RADIO FRREQUENCY EXPOSURE COMPLIANCE RESULT : PASS Test standard : FCC KDB Publication 447498 Since maximum peak output power of the transmitter is<60/f(GHz)mW, i.e.1.00mW<25(=60/2.4)mW, hence the EUT is exclueded from SAR evaluation according to FCC KDB Publication 447498 D01:Mobile Portable RF Exposure.

Test Report

R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:VS9-GC2WIU-11 Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F12252 FCC PART 15C TEST REPORT FOR CERTIFICATION On Behalf of Goodbetterbest Limited GC2 Wireless Controller (Wii U) Model Number: GC2WIU FCC ID: VS9-GC2WIU-11 Prepared for : Goodbetterbest Limited Suites 103-107, Devonshire Business Centre, Works Road, Letchworth, SG6 1GJ, United Kingdom Prepared By : Audix Technology (Shenzhen) Co., Ltd. No. 6, Ke Feng Rd., 52 Block, Shenzhen Science & Industrial Park, Nantou, Shenzhen, Guangdong, China Tel: (0755) 26639496 Report Number : ACS-F12252 Date of Test : Nov.07~20, 2012 Date of Report : Dec.05, 2012 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:VS9-GC2WIU-11 Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F12252 TABLE OF CONTENTS Description Page 1. SUMMARY OF STANDARDS AND RESULTS.......................................................... 1-1 1.1. Description of Standards and Results .................................................................................. 1-1 2. GENERAL INFORMATION ......................................................................................... 2-1 2.1. Description of Device (EUT) ............................................................................................... 2-1 2.2. Tested Supporting System Details ....................................................................................... 2-2 2.3. Block Diagram of connection between EUT and simulators ............................................... 2-2 2.4. Test Facility ......................................................................................................................... 2-3 2.5. Measurement Uncertainty (95% confidence levels, k=2) .................................................... 2-3 3. POWER LINE CONDUCTED EMISSION TEST ....................................................... 3-1 3.1. Test Equipments................................................................................................................... 3-1 3.2. Block Diagram of Test Setup ............................................................................................... 3-1 3.3. Power Line Conducted Emission Test Limits...................................................................... 3-1 3.4. Configuration of EUT on Test ............................................................................................. 3-1 3.5. Operating Condition of EUT................................................................................................ 3-2 3.6. Conducted Disturbance at Mains Terminals Test Results.................................................... 3-2 4. RADIATED EMISSION TEST ...................................................................................... 4-1 4.1. Test Equipment .................................................................................................................... 4-1 4.2. Block Diagram of Test Setup ............................................................................................... 4-1 4.3. Radiated Emission Limit Standard: FCC 15.209 and 15.247 .............................................. 4-2 4.4. EUT Configuration on Test.................................................................................................. 4-3 4.5. Operating Condition of EUT................................................................................................ 4-3 4.6. Test Procedure...................................................................................................................... 4-3 4.7. Radiated Emission Test Results ........................................................................................... 4-3 5. CONDUCTED SPURIOUS EMISSIONS...................................................................... 5-1 5.1. Test Equipment .................................................................................................................... 5-1 5.2. Limit..................................................................................................................................... 5-1 5.3. Test Procedure...................................................................................................................... 5-1 5.4. Test result ............................................................................................................................. 5-1 6. CARRIER FREQUENCY SEPARATION TEST ........................................................ 6-1 6.1. Test Equipment .................................................................................................................... 6-1 6.2. Limit..................................................................................................................................... 6-1 6.3. Test Results. ......................................................................................................................... 6-1 7. 20 DB BANDWIDTH TEST ........................................................................................... 7-1 7.1. Test Equipment .................................................................................................................... 7-1 7.2. Limit..................................................................................................................................... 7-1 7.3. Test Results .......................................................................................................................... 7-1 8. NUMBER OF HOPPING FREQUENCY TEST .......................................................... 8-1 8.1. Test Equipment .................................................................................................................... 8-1 8.2. Limit..................................................................................................................................... 8-1 8.3. Test Results .............................................................................................................…

Text truncated - open the document above for the full version.

Test Setup Photos

R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:VS9-GC2WIU-11 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F12252 13-1 13. PHOTOGRAPH OF TEST 13.1.Photos of Conducted Disturbance at Mains Terminals Test R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:VS9-GC2WIU-11 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F12252 13-2 13.2.Photos of Radiated Emission Test (30-1000MHz) R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:VS9-GC2WIU-11 page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F12252 13-3 (Above 1000MHz)

Contact Information

Applicant

Stephen Withers(Consultant)
[email protected]+16503364157Fax: +16503364157

Technical Contact

AUDIX Technology(Shenzhen) Co., Ltd.Sunny Lu
[email protected]86-755-26639497

52 Block Shenzhen Science & Industry · Shenzhen · China

Test Firm

Audix Technology (Shenzhen) Co.Smart Tsai
[email protected]86-755-663-9495Fax: 86-755-663-2877

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.40 GHz - 2.48 GHz900.00 µW
Confidentiality
Long Term
Grant Notes
Power Output listed is conducted. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
