VSMWT830TC15Wireless Zone thermostat

WT830 and ZN020 Wireless Zone Thermostat Instruction Manual Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Ru les. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radi o frequency energy and, if not installed and used in accordance with the instructi ons, may cause harmful interference to radio communications. However, there is no guarantee that interference wi ll not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by on e or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help. Room Sensor unit installation Installation Location The room sensor should be mounted on an inner wall ~1.5m above the floor in a position where it is readily a ffected by changes of the general room temperature with freely circulating air. Opening the Cover Pull out the battery drawer and use a screwdriver t o press on the spot shown below in order to detach the front shell from its base as shown in the below Figure. Mounting Ensure that the surface is level. Drilling 2 holes at wall and fix the wall anchor. Fasten the thermostat with 2 pcs of long screws thr ough the 2 mounting holes. Insert two fresh AAA alkaline batteries into the dr awer according to the polarity marked inside, then slide the drawer b ack into the place as shown in the above Figure. Zone output unit installation Mounting ZN020 can be mounted on Din rail or mounted on wall directly Drilling 2 holes at wall and fix the wall anchor. Fasten the Zone output unit with 2 pcs screws at to p housing. Wiring connection Wiring power and device according to the label R 24Vac input C 24Vac common input Z1 Zone 1 dry contact Z2 Zone 2 dry contact Z3 Zone 3 dry contact Z4 Zone 4 dry contact All damper outputs are dry contact Add Room sensor to Zone output unit 1. Use dip switch to select system option Pole Selection 1 RF channel address 1 2 RF channel address 2 3 RF channel address 3 4 RF channel address 4 5 Reserved 6 Reserved 2. Select any combination of RF channel from pole 1 st to 4 th 3. Power up ZN020 with 24Vac 4. Press and hold <SW1> button to enter add/drop mode Release button until all LED flashing 5. Power up Room sensor unit, the room sensor should b e not added or finished dropping. If there are any display or functional errors, plea se remove the batteries for about 30 sec to reset the thermostat. 6. Room sensor display “no C” when it is not connected 7. Press Up /Down to select Zone area 1 to Zone area 4 Please select Area 1 for the first adding. 8. Press SET to confirm, room unit will search the Zone output unit 9. LCD shows “done” and the zone area, press Next for initial internal setting. 10. Repeat step 4 to 9 for other Room unit On/ Off mode User can press <MODE> key to select OFF or ON mode OFF mode: Zone damper will be off and Room unit only display room temperature, set point cannot be changed in this mode On mode: HEAT will be activated, this is based on the operation mode setting in Area 1 room unit Room unit display the set point value at the top left corner User can press up/down to change set point. When user enter setting mode, room unit display SETTING icon. The top left corner value will be room temperature. Press <SET> key to confirm the changes and back to normal page Press<ENT> key back to normal page without changing set point Internal Setting Hold <SET> Key to enter internal setting mode Press <Up/Down> to select C scale of F scale Press <SET> to confirm Press Up/Down to select heater delay time. Sdy: 10 seconds Ldy: 3 minutes If selected Ldy and heater is off, damper output cannot be turned on within 3 minutes. Press SET to confirm Pr ess Up/Down to select the span 1 o C(2 o F) or 2 o C(4 o F) Press SET to confirm and back to normal mode Drop Room sensor from Zone output unit 1. Press and hold SW1 button to enter add/drop mode Release button until all LED flashing 2. Press<MODE> and <SET> key to enter drop mode 3. Press <SET> to confirm Press<ENT> to cancel and exit drop mode 4. Room unit display “done” and “no c” after finish the dropping 5. Press “Next”, the room unit is ready for adding Specification: Room unit sensor Input Voltage: 3Vdc, 2* 1.5V AAA alkaline batteries Transmit Frequency: 918-924MHz Operating Temperature: 32 – 122 °F / 0 – 50 °C Storage Temperature: 23 – 140 °F / -5 – 60 °C Operating Humidity: 5-95% RH non-condensing Temperature Accuracy: +/- 1 °F / 0.5 °C Zone output unit: Input Voltage: 24Vac +/- 20% Relay Contact Voltage: 24 Vac +/-20% Rated Current: 24Vac,1A (each output) Terminals: 18-24AWG Transmit Frequency: 918-924MHz Operating Temperature: 32 – 122 °F / 0 – 50 °C Storage Temperature: 23 – 140 °F / -5 – 60 °C Operating Humidity: 5-95% RH non-condensing

INTERTEK TESTING SERVICES External Photos Test Report Number: 15050764HKG-001 FCC ID: VSMWT830TC15

DATE REV DESCRIPTION NAME APRVD 150810 1 符合2011/95/EC指令 L i m i t o f R o H S ( R o H S 的 限 量 指 標 ) 鎘 C a d m i u m ( C d ) < 0 . 0 1 % 鉛 L e a d ( P b ) < 0 . 1 % 汞 M e r c u r y ( H g ) < 0 . 1 % 六 價 鉻 H e x a v a l e n t c h r o m i u m ( C r ) < 0 . 1 % 多 溴 聯 苯 P o l y b r o m i n a t e d b i p h e n y l s ( P B B ) < 0 . 1 % 多 溴 二 苯 醚 P o l y b r o m i n a t e d b i p h e n y l s e t h e r s ( P B D E ) < 0 . 1 % 四 種 鄰 苯 二 甲 酸 酯 4 P h t h a l a t e s ( D E H P , D B P , B B P , D I B P ) < 0 . 1 % 6 + Drawing no: WEXCEL World Excel Company Limited File:ZN020.TC.WORK.1.150810.11.CDR CORELDRAW File Edition: ANNY NG 2015-08-10 Page 1/1 REV 1 WORLD EXCEL ZN020/TC WORKINST 生產資料 ZN020.TC.WORK.1.150810.11.CDR C MODEL(型號):WT830 FCC ID LABEL(FCC底殼貼紙) SIZE(尺寸): 68(W) X 20(H)mm +/-0.5mm公差 COLOR(要求顏色): BLACK ON WHITE(白底黑字) MATERIAL(物料完成): PP COATING, STRONG ADHESIVE RoHS PART NUMBER(物料編號): EWT830~~92 貼在此處 WT01~ PART NO.:9WT01~~495 BOTTOM HOUSING ABS757 WHITE RAL9003 RoHS FCC ID: FCC STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. VSMWT830TC15 FCC ID: FCC STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. VSMWT830TC15

INTERTEK TESTING SERVICES Internal photos Test Report Number: 15050764HKG-001 FCC ID: VSMWT830TC15 INTERTEK TESTING SERVICES Internal photos Test Report Number: 15050764HKG-001 FCC ID: VSMWT830TC15 INTERTEK TESTING SERVICES Internal photos Test Report Number: 15050764HKG-001 FCC ID: VSMWT830TC15 INTERTEK TESTING SERVICES Internal photos Test Report Number: 15050764HKG-001 FCC ID: VSMWT830TC15 INTERTEK TESTING SERVICES Internal photos Test Report Number: 15050764HKG-001 FCC ID: VSMWT830TC15

Analysis Report Report No.: 15050764HKG-001 The WT830/TC is a Room Sensor Unit. It operates at frequency range of 918MHz to 924MHz with 25 channels. It is powered on by 3.0VDC (2 x 1.5 AAA Batteries). The EUT can be communicated with the Zone Output Unit (ZN020/TC). In OFF mode, zone damper will be off and the EUT only display room temperature. In ON mode, the EUT display the set point value at the top left corner. User can press up/ down to change set point. The EUT can also enter Internal Setting mode, add/drop mode by pressing the relating button by following the User Manual. Antenna Type: Internal integral antenna Antenna Gain: 0dBi Nominal conducted power: 5dBm Maximum allowed conducted power of production tolerance: +2dB / - 2dB According to the KDB 447498: Based on the Maximum allowed conducted power of production tolerance was 7dBm in frequency 924MHz, thus; Conducted Power = 5.012mW The SAR Exclusion Threshold Level: = 3.0 * (min. test separation distance, mm) / sqrt(freq. in GHz) = 3.0 * 5 / sqrt (0.924) mW = 15.6 mW Since the above conducted output power is well below the SAR Exclusion threshold level, so the EUT is considered to comply with SAR requirement without testing.

Issuing Laboratory: Intertek Testing Services Hong Kong Limited HKAS has accredited this laboratory (HOKLAS 005 – TEST) under HOKLAS for specific laboratory activities as listed in the HOKLAS directory of accredited laboratories. Test Report Number: 15050764HKG-001 Page 1 of 31 FCC ID: VSMWT830TC15 Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com GENERAL INFORMATION Applicant Name: World Excel Company Ltd. Applicant Address: Room B, 26/F., Capital Trade Centre, 62 Tsun Yip Street, Hong Kong FCC Specification Standard: FCC Part 15, October 1, 2013 Edition FCC ID: VSMWT830TC15 FCC Model(s): WT830/TC Type of EUT: Digital Transmission System Description of EUT: Room Sensor Unit Serial Number: N/A Sample Receipt Date: May 14, 2015 Date of Test: May 14, 2015 to May 26, 2015 Report Date: July 07, 2015 Environmental Conditions: Temperature: +10 to 40°C Humidity: 10 to 90% Issuing Laboratory: Intertek Testing Services Hong Kong Limited HKAS has accredited this laboratory (HOKLAS 005 – TEST) under HOKLAS for specific laboratory activities as listed in the HOKLAS directory of accredited laboratories. Test Report Number: 15050764HKG-001 Page 2 of 31 FCC ID: VSMWT830TC15 Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com Table of Contents 1.0 Summary of Test Results........................................................................................ 4 1.1 Statement of Compliance ........................................................................................ 4 2.0 General Description................................................................................................. 6 2.1 Product Description ................................................................................................. 6 2.2 Test Methodology.................................................................................................... 7 2.3 Test Facility............................................................................................................. 7 3.0 System Test Configuration...................................................................................... 9 3.1 Justification ............................................................................................................. 9 3.2 EUT Exercising Software....................................................................................... 10 3.3 Details of EUT and Description of Accessories ...................................................... 11 3.4 Measurement Uncertainty ..................................................................................... 11 4.0 Test Results............................................................................................................ 13 4.1 Maximum Conducted Output Power at Antenna Terminals .................................... 13 4.2 Minimum 6dB RF Bandwidth ................................................................................. 15 4.3 Maximum Power Spectral Density ......................................................................... 17 4.4 Out of Band Conducted Emissions ........................................................................ 19 4.5 Field Strength Calculation...................................................................................... 22 4.6 Transmitter Radiated Emissions in Restricted Bands and Spurious Emissions....... 23 4.6.1 Radiated Emission Configuration Photograph..................................................... 23 4.6.2 Radiated Emission Data ..................................................................................... 23 4.6.3 Transmitter Duty Cycle Calculation ..................................................................... 28 4.7 AC Power Line Conducted Emission ..................................................................... 29 5.0 Equipment List....................................................................................................... 31 Issuing Laboratory: Intertek Testing Services Hong Kong Limited HKAS has accredited this laboratory (HOKLAS 005 – TEST) under HOKLAS for specific laboratory activities as listed in the HOKLAS directory of accredited laboratories. Test Report Number: 15050764HKG-001 Page 3 of 31 FCC ID: VSMWT830TC15 Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com EXHIBIT 1 SUMMARY OF TEST RESULTS & STATEMENT OF COMPLIANCE Issuing Laboratory: Intertek Testing Services Hong Kong Limited HKAS has accredited this laboratory (HOKLAS 005 – TEST) under HOKLAS for specific laboratory activities as listed in the HOKLAS directory of accredited laboratories. Test Report Number: 15050764HKG-001 Page 4 of 31 FCC ID: VSMWT830TC15 Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com 1.0 Summary of Test Results Test Items FCC Part 15 Section Results Details see section Antenna Requirement 15.203 Pass 2.1 Max. Conducted Output Power (peak) 15.247(b)(3)&(4) Pass 4.1 Min. 6dB RF Bandwidth 15.247(a)(2) Pass 4.2 Max. Power Density (peak) 15.247(e) Pass 4.3 Out of Band Antenna Conducted Emission 15.247(d) Pass 4.4 Radiated Emission in Restricted Bands and Spurious Emissions 15.247(d), 15.209 & 15.109 Pass 4.6 AC Power Line Conducted Emission 15.207 & 15.107 NA 4.7 Note: Pursuant to FCC Part 15 Section 15.215(c), the 20dB bandwidth of the emission was contained within the frequency band designated (mentioned as above) which the EUT operated. The effects, if any, from frequency sweeping, frequency hopping, other modulation techniques and frequency stability over…
