VSVJWR200Wireless Remote Control-Transmitter

Operating Instructions Manual Wireless Remote Control JWR-200 WMH TOOL GROUP 2420 Vantage Drive Elgin, Illinois 60124 Part No. M- Ph.: 800-274-6848 Revision A 12/07 www.wmhtoolgroup.com Copyright © WMH Tool Group 2 Warranty and Service WMH Tool Group, Inc., warrants every product it sells. If one of our tools needs service or repair, one of our Authorized Service Centers located throughout the United States can give you quick service. In most cases, any of these WMH Tool Group Authorized Service Centers can authorize warranty repair, assist you in obtaining parts, or perform routine maintenance and major repair on your JET ® tools. For the name of an Authorized Service Center in your area call 1-800-274-6848. MORE INFORMATION WMH Tool Group is consistently adding new products to the line. For complete, up-to-date product information, check with your local WMH Tool Group distributor, or visit jettools.com. WARRANTY JET products carry a limited warranty which varies in duration based upon the product (MW = Metalworking, WW = Woodworking). WHAT IS COVERED? This warranty covers any defects in workmanship or materials subject to the exceptions stated below. Cutting tools, abrasives and other consumables are excluded from warranty coverage. WHO IS COVERED? This warranty covers only the initial purchaser of the product. WHAT IS THE PERIOD OF COVERAGE? The general JET warranty lasts for the time period specified in the product literature of each product. WHAT IS NOT COVERED? Five Year Warranties do not cover woodworking (WW) products used for commercial, industrial or educational purposes. Woodworking products with Five Year Warranties that are used for commercial, industrial or education purposes revert to a One Year Warranty. This warranty does not cover defects due directly or indirectly to misuse, abuse, negligence or accidents, normal wear-and-tear, improper repair or alterations, or lack of maintenance. HOW TO GET SERVICE The product or part must be returned for examination, postage prepaid, to a location designated by us. For the name of the location nearest you, please call 1-800-274-6848. You must provide proof of initial purchase date and an explanation of the complaint must accompany the merchandise. If our inspection discloses a defect, we will repair or replace the product, or refund the purchase price, at our option. We will return the repaired product or replacement at our expense unless it is determined by us that there is no defect, or that the defect resulted from causes not within the scope of our warranty in which case we will, at your direction, dispose of or return the product. In the event you choose to have the product returned, you will be responsible for the shipping and handling costs of the return. HOW STATE LAW APPLIES This warranty gives you specific legal rights; you may also have other rights which vary from state to state. LIMITATIONS ON THIS WARRANTY WMH TOOL GROUP LIMITS ALL IMPLIED WARRANTIES TO THE PERIOD OF THE LIMITED WARRANTY FOR EACH PRODUCT. EXCEPT AS STATED HEREIN, ANY IMPLIED WARRANTIES OR MERCHANTABILITY AND FITNESS ARE EXCLUDED. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG THE IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU. WMH TOOL GROUP SHALL IN NO EVENT BE LIABLE FOR DEATH, INJURIES TO PERSONS OR PROPERTY, OR FOR INCIDENTAL, CONTINGENT, SPECIAL, OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OF OUR PRODUCTS. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU. WMH Tool Group sells through distributors only. The specifications in WMH catalogs are given as general information and are not binding. Members of WMH Tool Group reserve the right to effect at any time, without prior notice, those alterations to parts, fittings, and accessory equipment which they may deem necessary for any reason whatsoever. JET ® branded products are not sold in Canada by WMH Tool Group. 3 Table of Contents Warranty and Service.................................................................................................................................... 2 Table of Contents.......................................................................................................................................... 3 Introduction ................................................................................................................................................... 3 Warning ......................................................................................................................................................... 4 Operation..............................................................................................................................5 Specifications.....................................................................................................................5-6 Wiring Diagram......................................................................................................................6 Introduction This manual is provided by WMH Tool Group covering the safe operation and maintenance procedures for the JET JWR-200 Wireless Remote Control. This manual contains instructions on installation, safety precautions, general operating procedures, maintenance instructions. This tool has been designed and constructed to provide years of trouble free operation if used in accordance with instructions set forth in this manual. If there are any questions or comments, please contact either your local supplier or WMH Tool Group. WMH Tool Group can also be reached at our web site: www.wmhtoolgroup.com. Record your purchase information here for quick reference: Model No.: Stock No.: Serial No.: Purchased From: Date Purchased: 4 Warning 5 OPERATING INSTRUCTIONS Please read the manual carefully, Before using of this equipment. The person who operates it should be trained and graduated. The operator must watching the equipment…

Text truncated - open the document above for the full version.

2420 Vantage Drive | Elgin, IL 60124 | USA | 847-851-1000 | 847-851-1045 fax | http://www.wmhtoolgroup.com To Whom It May Concern: We, the undersigned WMH Tool Group , hereby authorize Max Light Technology Co. Ltd. (MLT) of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15 approval and any communication needed with the national authority. Any and all acts carried out by MLT on our behalf shall have the same effects as acts of our own. For questions regarding the authorization, please contact us. Thank you. Sincerely, Dustin Nielson Director of Product Development Material Handling WMH Tool Group 847-851-1107 [email protected] Mar 31 2008

Date: 31, March 2008 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: VSVJWR200 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: Block Diagrams Schematics Operational Descriptions The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, Dustin Nielson / Director of Product Development – Material Handling _____________________________ (Signature) (Notice: Must be signed by applicant contact cited as technical or non-technical contact on the 731 form provided to ATCB, or by the authorized agent if an appropriate authorized agent letter has bee provided. Letters Signed by applicant should be placed on applicant letterhead.)

Report Number: MLT0801P15004 PHOTOGRAPHS OF EUT Report Number: MLT0801P15004

Report Number: MLT0801P15004 Label Format: Label Position: Equipment Label 2.0cmX1.0cm This device complies with Part15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received , including Interference that may cause undesired operation. Model No. : JWR-200 FCC ID: VSVJWR200 Rear View

Report Number: MLT0801P15004 Report Number: MLT0801P15004 Report Number: MLT0801P15004

Page: 1/27 Report Number: MLT0801P15004 (FCC : Part 15 Subpart C / ANSI C63.4-2003) Product :Wireless Remote Control-Transmitter Trade Name :JET Model No. :JWR-200 Applicant :WMH Tool Group Applicant Address :2420 Vantage Dr Elgin, IL 60124 Page: 2/27 Report Number: MLT0801P15004 Report Number MLT0801P15004 Applicant WMH Tool Group Product Wireless Remote Control-Transmitter Sample Received Date 2008/01/10 Report Prepared By Jesse Tien Signature Date Prepared 2008/01/11 ～ 2008/03/25 Report Authorized By Roger Chen Signature Date Authorized 2008/03/25 Test By Max Light Technology Co., Ltd. Room 5, 8F, No.125, Section 3 Roosevelt Road, Taipei, Taiwan., R.O.C. Office : Tel: 886-2-2363-2447 Fax: 886-2-2363-2597 Lab. : Tel: 886-2-2663-3486 Fax: 886-2-2663-3582 I I t t m m a a y y b b e e d d u u p p l l i i c c a a t t e e d d c c o o m m p p l l e e t t e e l l y y f f o o r r l l e e g g a a l l u u s s e e w w i i t t h h t t h h e e a a l l l l o o w w a a n n c c e e o o f f t t h h e e a a p p p p l l i i c c a a n n t t . . I I t t s s h h a a l l l l n n o o t t b b e e r r e e p p r r o o d d u u c c e e d d e e x x c c e e p p t t i i n n f f u u l l l l , , w w i i t t h h o o u u t t t t h h e e w w r r i i t t t t e e n n a a p p p p r r o o v v a a l l o o f f o o u u r r l l a a b b o o r r a a t t o o r r y y . . Page: 3/27 Report Number: MLT0801P15004 Table of Contents : 1. General 5. 2. Conducted Emissions Requirements 7 3. Radiated Emissions Requirements 8. 4. Transmitter Bandwidth Measurements 18. 5. Transmitter Duty Cycle Measurements 20. 6. Verification of De-activation after 5 seconds 24. Appendix I ( EUT Test Setup ) 26. Appendix II ( Brand / Trade Name & Model No. Multiple Listee ) 27. Page: 4/27 Report Number: MLT0801P15004 CERTIFICATION We here by verify that : The test data, data evaluation, test procedures and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4-2003. All test were conducted by MLT(Max Light Technology Co.,Ltd) Room 5, 8F, No.125, Section 3 Roosevelt Road, Taipei, Taiwan, R.O.C Also, we attest to the accuracy of each. We further submit that the energy emitted by the sample EUT tested as described in the report is in compliance with radiated emission limit of FCC Rules Part 15 Subpart C Section 15.231. Applicant Name WMH Tool Group Applicant Address 2420 Vantage Dr Elgin, IL 60124 Manufacturer Name Zhejiang Shuangniao Machinery Co. Ltd Manufacturer Address No.2 YuLong Rd. SanWang HuangZe Town ShengZhou ZheJiang China 312455 Equipment Wireless Remote Control-Transmitter Model No JWR-200 FCC ID VSVJWR200 Report Prepared By Jesse Tien Signature Report Authorized By Roger Chen Signature Page: 5/27 Report Number: MLT0801P15004 1. GENERAL 1.1 Introduction The following measurement report is submitted on behalf of WMH Tool Group In support of an Intentional Periodic Radiator certification in accordance with Part 2 Subpart J and Part 15 Subpart A And C of the Commission’s and Regulations. 1.2 Customer Details Applicant Name WMH Tool Group Applicant Address 2420 Vantage Dr Elgin, IL 60124 Manufacturer Name Zhejiang Shuangniao Machinery Co. Ltd Manufacturer Address No.2 YuLong Rd. SanWang HuangZe Town ShengZhou ZheJiang China 312455 1.3 Technical data of EUT Equipment Wireless Remote Control-Transmitter Model No JWR-200 FCC ID VSVJWR200 Power Type Powered By DC 1.5V(AAA)*2 The EUT (JWR-200 ) is remote Transmitter. The operation frequency is 431Mhz. Press the button on remote Transmitter, can set the Program START / STOP / UP / DOWN / LEFT / RIGHT. 1.4 Description of Support Equipment The EUT itself forms a system. No support equipment is required for its normal operation. Page: 6/27 Report Number: MLT0801P15004 1.5 Configuration of System Under Test 1.6 Test Procedure All measurements contained in this report were performed according to the techniques described in Measurement procedure ANSI C63.4: 2003 "Measurement of Intentional Radiators." 1.7 General Test Condition The conditions under which the EUT operates were varied to determine their effect on the equipment's emission characteristics. The final configuration of the test system and the mode of operation used during these tests was chosen as that which produced the highest emission levels. However, only those conditions which the EUT was considered likely to encounter in normal use were investigated. EUT Page: 7/27 Report Number: MLT0801P15004 2. Conducted Emissions Requirements The EUT operates solely by the battery. According to the rule of Section 15.207(c), the EUT exempt to the power line conducted test. Page: 8/27 Report Number: MLT0801P15004 3. Radiated Emissions Requirements 3.1 General Configuration: Prior to open-field testing, the EUT was placed in a shielded enclosure and scanned at a close distance to determine its emission characteristics. The physical arrangement of the EUT was varied (within the scope of arrangements likely to be encountered in actual use) to determine the effect on the unit's emanations in amplitude, directivity, and frequency. The exact system configuration which produced the highest emissions was noted so it could be reproduced later during the open-field tests. This was done to ensure that the final measurements would demonstrate the worst-case interference potential of the EUT. 3.2 General Configuration: Final radiation measurements were made on a three-meter, open-field test site. The EUT system was placed on a nonconductive turntable which is 0.8 meters height, top surface 1.0 x 1.5 meter. The spectrum was examined from 250 MHz to 2.5 GHz in order to cover the whole spectrum below 10th harmonic which could generate from the EUT. During the test, EUT was set to transmit continuously & Measurements spectrum range from 30 MHz to5 GHz is investigated. For measurements below 1 GHz the resolution bandwidth is set to 100 kHz for peak detection measurements or 120 kHz for quasi-peak detection measurements. Peak det…

Text truncated - open the document above for the full version.

Report Number: MLT0801P15004 Radiated Measurement Photos Front View of The Test Configuration Report Number: MLT0801P15004 Rear View of The Test Configuration
