VTO1112RG03-1TAppliance Remote Controller

 Vent-free Gas Stove MODEL NO. SSU220RHN-GB & SSU220RHL-GB Questions about installation, operation, or troubleshooting? Before returning to your retailer, call our customer service department toll-free at (877)886-5989 PRGHO [[EMSHJ PC-SSU220R653-0805 This appliance may be installed in an aftermarket, permanently located manufactured (mobile) home, where not prohibited by local codes. This appliance is for use with the type of gas indicated on the rating plate only. This appliance is not convertible for use with other gases. CAUTION - FOR YOUR SAFETY WARNING: IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY, OR LOSS OF LIFE. -- Do not store or use gasoline or other flammable vapors and liquids in vicinity of this or any other appliance. WHAT TO DO IF YOU SMELL GAS Do not try to light any appliance. Do not touch any electrical switch; do not use any phone in your building. Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions. If you cannot reach your gas supplier, call the fire department. -- Installation and service must be performed by a qualified installer, service agency or the gas supplier. This is an unvented gas-fired heater. It uses air (oxygen) from the room in which it is installed. Provisions for adequate combustion and ventilation air must be provided. Refer to Air For Combustion and Ventilation section on page 6 of this manual. INSTALLER: DO NOT DISCARD THIS MANUAL – LEAVE FOR HOMEOWNER’S FUTURE REFERENCE. 2 2 TABLE OF CONTENTS Figure - Vent - Free Gas Stove S [[EMSHJ Important Safety Information ...........................................................................................................................3 Air for Combustion & Ventilation ....................................................................................................................6 Product Features ..............................................................................................................................................8 Preparing for Installation .................................................................................................................................8 Installation .....................................................................................................................................................0 Connecting To Gas Supply ......................................................................................................................10 Checking Gas Connections .....................................................................................................................11 Log Placement .........................................................................................................................................13 Operating Heater .............................................................................................................................................4 Care and Maintenance ..................................................................................................................................9 Troubleshooting ............................................................................................................................................2 Remote Control FCC Statement.......................................................................................................................24 WARNING: READ THE INSTALLATION & OPERATION INSTRUCTIONS BEFORE USING THIS APPLIANCE IMPORTANT: Read instructions and warnings carefully before starting installation. Failure to fol- low these instructions may result in a possible fire hazard and will void the warranty. PRODUCT SPECIFICATIONS MODEL NO SSU220RHL-GBSSU220RHN-GB Btu (Variable)22,00022,000 Gas TypeLP GasNatural Gas IgnitionAutomatic or ElectronicAutomatic or Electronic Manifold Pressure8” W.C.3” W.C. Inlet Gas Pressure (In. of water)* Maximum14 in.10.5 in. Minimum11 in.5 in. Dimensions, Inches (H×W×D) Heater26 1/8” × 28” ×16 7/8”26 1/8” × 28” ×16 7/8” Carton31 1/8”×31 3/8” ×20 1/2”31 1/8”×31 3/8” ×20 1/2” Weight, lbs Stove7373 Shipping8585 Volts120120 Watts1919 *For purposes of input adjustment TABLE OF CONTENTS Replacement Parts ..........................................................................................................................................25 333 IMPORTANT SAFETY INFORMATION IMPORTANT: Read instructions and warnings carefully before starting installation. Failure to follow these instructions may result in possible electric shock or fire hazard and will void the warranty. Improper use of this heater can cause seri- ous injury or death from burns, fire, explosion, electrical shock, and carbon monoxide poisoning. Refer to this manual for correct installation and operational procedures. For assistance or additional information consult a qualified installer, service agency, local gas supplier, or customer service. Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appli- ance. WHAT TO DO IF YOU SMELL GAS Do not try to light any appliance. Do not touch any electrical switch; do not use any phones in your building. Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions. If you cannot reach your gas supplier, call the fire department. Installation and service must be performed by a qualified installer, service agency, or local gas supplier. WARNING: This is an unvented gas-fired heater. It uses air (oxygen) from the room in which it is installed. Provisions for adequate combustion and ventilation air must be provided. Refer to Air For Combustion and Venti- lation section on page 6 of this manual. This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not convertible for use with other gases. DANGER: Carbon monoxide po…

Text truncated - open the document above for the full version.

2012.04.30

Antenna

FCC ID: VTO1112RG03-1T Report No.: PRA-11DE0161VBTY-A1 1 FCC TEST REPORT REPORT NO.: PRA-11DE0161VBTY-A1 MODEL NO.: RG03-1T RECEIVED: Dec. 19, 2011 ISSUED: Feb. 02, 2012 APPLICANT: ProCom Electric Appliances (Shanghai) Co.,Ltd. ADDRESS: #1118 Huicheng Road,Nanhui Industrial Park,Pudong New District 201300,Shanghai,China. ISSUED BY: BUREAU VERITAS ADT (Shanghai) Corporation ADDRESS: 2F, Building C, No.1618, Yishan rd., 201103, Shanghai, China This test report consists of 25 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by A2LA or any government agencies. The test results in the report only apply to the tested sample. The test results in this report are traceable to the national or international standards. This report contains data that were produced under Laboratory ADT (Shanghai) Corporation. FCC ID: VTO1112RG03-1T Report No.: PRA-11DE0161VBTY-A1 2 Table of Contents 1 CERTIFICATION .......................................................................................... 3 2 SUMMARY OF TEST RESULTS .................................................................. 4 2.1 MEASUREMENT UNCERTAINTY............................................................... 4 3 GENERAL INFORMATION........................................................................... 5 3.1 GENERAL DESCRIPTION OF EUT ............................................................ 5 3.2 DESCRIPTION OF TEST MODES .............................................................. 5 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.............................. 7 3.4 DESCRIPTION OF SUPPORT UNITS ........................................................ 7 4 EMISSION TEST.......................................................................................... 8 4.1 CONDUCTED EMISSION MEASUREMENT............................................... 8 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ............................ 8 4.1.2 TEST RESULTS .......................................................................................... 8 4.2 DEACTIVATION TIME ................................................................................. 9 4.2.1 LIMITS OF DEACTIVATION TIME MEASUREMENT .................................. 9 4.2.2 TEST INSTRUMENTS................................................................................. 9 4.2.3 TEST PROCEDURES ................................................................................. 9 4.2.4 DEVIATION FROM TEST STANDARD........................................................ 9 4.2.5 TEST SETUP............................................................................................... 9 4.2.6 TEST RESULTS ........................................................................................ 10 4.3 RADIATED EMISSION MEASUREMENT.................................................. 11 4.3.1 LIMITS OF RADIATED EMISSION MEASUREMENT ............................... 11 4.3.2 TEST INSTRUMENTS............................................................................... 13 4.3.3 TEST PROCEDURE.................................................................................. 14 4.3.4 DEVIATION FROM TEST STANDARD...................................................... 14 4.3.5 TEST SETUP............................................................................................. 15 4.3.6 EUT OPERATING CONDITIONS .............................................................. 15 4.3.7 TEST RESULTS ........................................................................................ 16 4.4 20DB OCCUPIED BANDWIDTH MEASUREMENT .................................. 22 4.4.1 LIMITS OF BAND EDGES MEASUREMENT ............................................ 22 4.4.2 TEST INSTRUMENTS............................................................................... 22 4.4.3 TEST PROCEDURES ............................................................................... 23 4.4.4 DEVIATION FROM TEST STANDARD...................................................... 23 4.4.5 TEST SETUP............................................................................................. 23 4.4.6 TEST RESULTS ........................................................................................ 24 5 APPENDIX - INFORMATION ON THE TESTING LABORATORY ............. 25 FCC ID: VTO1112RG03-1T Report No.: PRA-11DE0161VBTY-A1 3 1 CERTIFICATION PRODUCT: Wireless remote control MODEL NO.: RG03-1T APPLICANT: ProCom Electric Appliances (Shanghai) Co.,Ltd. TESTED: Dec. 20, 2011~Jan. 12, 2012 TEST ITEM: ENGINEERING SAMPLE STANDARDS: FCC Part 15:2011, Subpart C (Section 15.209 and 15.231), ANSI C63.4-2003 We, BUREAU VERITAS ADT (Shanghai) Corporation, declare that the equipment above has been tested in our facility and found compliance with the requirement limits of applicable standards. The test record, data evaluation and Equipment Under Test (EUT) configurations represented herein are true and accurate under the standards herein specified. PREPARED BY : , DATE:Feb.02, 2012 Yuki Tao Report Engineer TECHNICAL ACCEPTANCE : , DATE:Feb.02, 2012 Joy Zhu Lab Manager APPROVED BY : , DATE:Feb.02, 2012 Zhaoqian YU Director of Operations FCC ID: VTO1112RG03-1T Report No.: PRA-11DE0161VBTY-A1 4 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C Standard Paragraph Test Type ResultRemarks 15.207 Conducted Emission Test N/A Please refer to 4.1.2. 15.231(a) De-activation Time PASS Meet the requirement of limit 15.209 15.231(b) Radiated Emission Test PASS Minimum passing margin is -2.8 dB at 912.70 MHz 15.231(c) 20dB Occupied Bandwidth Measurement PASS Meet the requirement of limit 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for te…
