VTO1112RG05-1TAppliance Remote Controller

– Do not store or use gasoline or other flammable vapors and liquids in vicinity of this or any other appliance. WHAT TO DO IF YOU SMELL GAS ∑ Do not try to light any appliance. ∑ Do not touch any electrical switch; do not use any phone in your building. ∑ Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions. ∑ If you cannot reach your gas supplier, call the fire department. – Installation and service must be performed by a qualified installer, service agency or the gas supplier. INSTALLER: DO NO DISCARD THIS MANUAL – LEAVE FOR HOMEOWNER’S FUTURE REFERENCE. WARNING: IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, A FIRE MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY, OR LOSS OF LIFE. PC-FBD32R-0805 CAUTION – FOR YOUR SAFETY Questions about installation, operation, or troubleshooting? Before returning to your retailer, contact our customer service department at 1-877-886-5989, 8:00 a.m.- 4:30p.m., EST, Monday-Friday or e-mail [email protected] . This is an unvented gas-fired heater. It uses air (oxygen) from the room in which it is installed. Provisions for adequate combustion and ventilation air must be provided. Refer to Air For Combustion and Ventilation section on page 7 of this manual. This appliance may be installed in an aftermarket, permanently located manufactured (mobile) home, where not prohibited by local codes. This appliance is for use with the type of gas indicated on the rating plate only. This appliance is not convertible for use with other gases. WARNING: This appliance is equipped for (Natural and Propane) gas. Field conversion is not permitted other than between natural or propane gases. VENT-FREE GAS FIREPLACE INSERT FBD32R 2 TABLE OF CONTENTS Important Safety Information...........................................................................................................................................3 Air For Combustion and Ventilation.................................................................................................................................7 Installation.....................................................................................................................................................................10 Operation.......................................................................................................................................................................20 Cleaning & Maintenance...............................................................................................................................................24 Troubleshooting.............................................................................................................................................................25 Remote Control FCC Statement ................................................................................................................................... .28 WARNING: READ THE INSTALLATION & OPERATION INSTRUCTIONS BEFORE USING THIS APPLIANCE IMPORTANT: Read instructions and warnings carefully before starting installation. Failure to follow these instructions may result in a possible fire hazard and will void the warranty. PRODUCT SPECIFICATIONS MODEL FBD32R Input Rating 32,000 BTU/Hr 32,000 BTU/Hr Gas Type Natural LP/Propane Ignition Piezo / Automatic Piezo / Automatic Manifold Pressure 4 in. W.C. 9 in. W.C. Inlet Gas Pressure (*For purposes of input adjustment) Maximum 10.5 in. 14 in. Minimum * 5 in. 11 in. Dimensions, inches(H x W x D) Heater 33.27 in. x 36.38 in. x 18.38 in. Carton 35.85 in. x 40.19 in. x 20.49 in. Weight, lbs Stove 88.2 Shipping 105.4 Replacement Parts........................................................................................................................................................29 3 IMPORTANT SAFETY INFORMATION IMPORTANT: Read this owner’s manual carefully and completely before trying to assemble, operate, or service this heater. Improper use of this heater can cause serious injury or death from burns, fire, explosion, electrical shock, and carbon monoxide poisoning. Only a qualified installer, service agent, or local gas supplier may install and service this product. WARNING: Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or any other appliance. WARNING: This appliance is for use with only the type of gas indicated on the rating plate. This appliance is not convertible for use with other gases. CARBON MONOXIDE POISONING: Early signs of carbon monoxide poisoning resemble the flu with headaches, dizziness, or nausea. If you have these signs, the heater may not be working properly. Get fresh air immediately! Have heater serviced. Some people are more affected by carbon monoxide than others. These include pregnant women, people with heart or lung disease, people who are anemic, those under the influence of alcohol, and those living in high altitudes. NATURAL AND PROPANE/LP GAS: Natural and Propane/LP gases are odorless. An odor-making agent is added to the gas. The odor helps you detect a gas leak. However, the odor added to the gas can fade. Gas may be present even though no odor exists. Make certain you read and understand all warnings. Keep this manual for reference. It is your guide to operating this heater safely. WARNING: Any change to this fireplace or its controls can be dangerous. WARNING: Do not allow fans or any other drafts that alter burner flame to blow directly into the heater. They create drafts that alter burner flame patterns, which can cause sooting. WARNING: Do not use a blower insert, heat exchange insert, or other accessory not approved for use with this heater. Due to high temperatures, the appliance should be located out of traffic and away from furniture and draperies. Do not place clothing or other flammable material on or near the appliance. Never place any objects in the heater. Heater becomes very hot when running heater. …

Text truncated - open the document above for the full version.

Confidentiality Request

2012.04.30

Antenna

FCC ID: VTO1112RG05-1T Report No.: PRA-11DE0161VBTY-A2 1 FCC TEST REPORT REPORT NO.: PRA-11DE0161VBTY-A2 MODEL NO.: RG05-1T RECEIVED: Dec. 19, 2011 ISSUED: Feb. 02, 2012 APPLICANT: ProCom Electric Appliances (Shanghai) Co., Ltd. ADDRESS: #1118 Huicheng Road,Nanhui Industrial Park,Pudong New District 201300,Shanghai,China. ISSUED BY: BUREAU VERITAS ADT (Shanghai) Corporation ADDRESS: 2F, Building C, No.1618, Yishan rd., 201103, Shanghai, China This test report consists of 25 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by A2LA or any government agencies. The test results in the report only apply to the tested sample. The test results in this report are traceable to the national or international standards. This report contains data that were produced under Laboratory ADT (Shanghai) Corporation. FCC ID: VTO1112RG05-1T Report No.: PRA-11DE0161VBTY-A2 2 Table of Contents 1 CERTIFICATION .......................................................................................... 3 2 SUMMARY OF TEST RESULTS .................................................................. 4 2.1 MEASUREMENT UNCERTAINTY............................................................... 4 3 GENERAL INFORMATION........................................................................... 5 3.1 GENERAL DESCRIPTION OF EUT ............................................................ 5 3.2 DESCRIPTION OF TEST MODES .............................................................. 5 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.............................. 7 3.4 DESCRIPTION OF SUPPORT UNITS ........................................................ 7 4 EMISSION TEST.......................................................................................... 8 4.1 CONDUCTED EMISSION MEASUREMENT............................................... 8 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ............................ 8 4.1.2 TEST RESULTS .......................................................................................... 8 4.2 DEACTIVATION TIME ................................................................................. 9 4.2.1 LIMITS OF DEACTIVATION TIME MEASUREMENT .................................. 9 4.2.2 TEST INSTRUMENTS................................................................................. 9 4.2.3 TEST PROCEDURES ................................................................................. 9 4.2.4 DEVIATION FROM TEST STANDARD........................................................ 9 4.2.5 TEST SETUP............................................................................................... 9 4.2.6 TEST RESULTS ........................................................................................ 10 4.3 RADIATED EMISSION MEASUREMENT.................................................. 11 4.3.1 LIMITS OF RADIATED EMISSION MEASUREMENT ............................... 11 4.3.2 TEST INSTRUMENTS............................................................................... 13 4.3.3 TEST PROCEDURE.................................................................................. 14 4.3.4 DEVIATION FROM TEST STANDARD...................................................... 14 4.3.5 TEST SETUP............................................................................................. 15 4.3.6 EUT OPERATING CONDITIONS .............................................................. 15 4.3.7 TEST RESULTS ........................................................................................ 16 4.4 20DB OCCUPIED BANDWIDTH MEASUREMENT .................................. 22 4.4.1 LIMITS OF BAND EDGES MEASUREMENT ............................................ 22 4.4.2 TEST INSTRUMENTS............................................................................... 22 4.4.3 TEST PROCEDURES ............................................................................... 23 4.4.4 DEVIATION FROM TEST STANDARD...................................................... 23 4.4.5 TEST SETUP............................................................................................. 23 4.4.6 TEST RESULTS ........................................................................................ 24 5 APPENDIX - INFORMATION ON THE TESTING LABORATORY ............. 25 FCC ID: VTO1112RG05-1T Report No.: PRA-11DE0161VBTY-A2 3 1 CERTIFICATION PRODUCT: Wireless remote control MODEL NO.: RG05-1T APPLICANT: ProCom Electric Appliances (Shanghai) Co., Ltd. TESTED: Dec. 20, 2011~Jan. 12, 2012 TEST ITEM: ENGINEERING SAMPLE STANDARDS: FCC Part 15:2011, Subpart C (Section 15.209 and 15.231), ANSI C63.4-2003 We, BUREAU VERITAS ADT (Shanghai) Corporation, declare that the equipment above has been tested in our facility and found compliance with the requirement limits of applicable standards. The test record, data evaluation and Equipment Under Test (EUT) configurations represented herein are true and accurate under the standards herein specified. PREPARED BY : , DATE:Feb.02, 2012 Fish YE Report Engineer TECHNICAL ACCEPTANCE : , DATE:Feb.02, 2012 Joy Zhu Lab Manager APPROVED BY : , DATE:Feb.02, 2012 Zhaoqian YU Director of Operations FCC ID: VTO1112RG05-1T Report No.: PRA-11DE0161VBTY-A2 4 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C Standard Paragraph Test Type ResultRemarks 15.207 Conducted Emission Test N/A Please refer to 4.1.2. 15.231(a) De-activation Time PASS Meet the requirement of limit 15.209 15.231(b) Radiated Emission Test PASS Minimum passing margin is –3.08 dB at 304.02 MHz 15.231(c) 20dB Occupied Bandwidth Measurement PASS Meet the requirement of limit 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for …
