Block Diagram Filter RF power amplifier and Modulator Oscillator 27.145MHz Encoder Control key 27.145MHz ANT IC1 128KHz

Guangdong Alpha Animation and Culture Co., Ltd., Address: Auldey Ind Area, Wenguan Rd., (Central), Chenghai, Shantou, Guangdong 515800, China. 2012-05-12 To whom it may concern, Letter of Agency I, an officer of Guangdong Alpha Animation and Culture Co., Ltd. do hereby authorize Intertek Testing Services (Mr. Shawn Xing) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under Part 15 and/or Part 95 of the FCC Rules until further notice. I further certify that no party (as defined in §1.2002(b) of CFR 47, 2007) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C., 862. Regards, William wang Senior Quality Engineer

External Photos

Label Artwork and Location FCC label

Internal Photos

Technical description Description Function Component Antenna Transmit modulated RF signal ANT Filter Suppression of spurious emissions L3, C5, C6 RF power amplifier and modulation Modulate the carrier and amplify the modulated RF signal Q2 Oscillator Generate 27.145 MHz carrier Q1, TX1 Encoder IC Generate code signal to modulator IC1 Type of antenna: Telescope antenna with unique antenna connector Type of modulation: Pulse modulation
