VVA2580004LAMBORGHINI SESTO ELEMENTO

Block

Guangdong Alpha Animation and Culture Co., Ltd., Address: Auldey Ind Area, Wenguan Rd., (Central), Chenghai, Shantou, Guangdong 515800, China. 2012-05-12 To whom it may concern, Letter of Agency I, an officer of Guangdong Alpha Animation and Culture Co., Ltd. do hereby authorize Intertek Testing Services (Mr. Shawn Xing) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under Part 15 and/or Part 95 of the FCC Rules until further notice. I further certify that no party (as defined in §1.2002(b) of CFR 47, 2007) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C., 862. Regards, William wang Senior Quality Engineer

External Photos

1 Label Artwork FCC label

Internal Photos

Technical description: Description Function Component Antenna Transmit modulated RF signal ANT Filter Suppression of spurious emissions C5, C6, C7, C8, L3 RF power amplifier Modulate the carrier and amplify the Q2 and modulation modulated RF signal Oscillator Generate 49.860 MHz carrier TX1, Q1 Encoder IC Generate code signal to modulator IC1 Type of antenna: telescope antenna with unique antenna connector Type of modulation: Pulse modulation

• -The test results reported in this test report shall refer only to the sample actually tested and shall not refer or be deemed to refer to bulk from which such a sample may be said to have been obtained. • This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to copy or distribute this report. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results referenced from this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. • For Terms And Conditions of the services, it can be provided upon request. • The evaluation data of the report will be kept for 3 years from the date of issuance. TRF No.: FCC IC_C_b Intertek Testing Services Shenzhen Ltd. Kejiyuan Branch 6F, D Block, Huahan Building, Langshan Road, Nanshan District, Shenzhen, P. R. China Tel: (86 755) 8601 6288 Fax: (86 755) 8601 6751 Guangdong Alpha Animation and Culture Co.,Ltd. Application For Certification FCC ID: VVA2580004 LAMBORGHINI SESTO ELEMENTO Model: LC258040 (6000815) Transmitter Report No.: SZ12070304-1 We hereby certify that the sample of the above item is considered to comply with the requirements of FCC Part 15, Subpart C for Intentional Radiator, mention 47 CFR [10-1-11] Prepared and Checked by: Approved by: Sign on file Chris Chen Engineer Billy Li Supervisor Date: August 08, 2012 INTERTEK TESTING SERVICES Report No.: SZ12070304-1 FCC ID: VVA2580004 TRF No.: FCC IC_C_b i GENERAL INFORMATION Guangdong Alpha Animation and Culture Co.,Ltd. MODEL: LC258040 (6000815) FCC ID: VVA2580004 Grantee: Guangdong Alpha Animation and Culture Co.,Ltd. Grantee Address: Auldey Ind Area,Wenguan Rd.,(central), Chenghai,shantou,Guangdong,China Contact Person: William Wang Tel: 86-754-85862278*8302 Manufacturer: Shantou Alpha Toy Co., Ltd Manufacturer Address: Xingchen Printing, Wenguan Rd., Chenghai, Shantou, Guangdong province, PRC Model: LC258040(6000815) Type of EUT: Transmitter Description of EUT: LAMBORGHINI SESTO ELEMENTO Serial Number: N/A FCC ID : VVA2580004 Date of Sample Submitted: July 31, 2012 Date of Test: August 08, 2012 Report No.: SZ12070304-1 Report Date: August 08, 2012 Environmental Conidtions: Temperature: +10 to +40°C Humidity: 10 to 90% INTERTEK TESTING SERVICES Report No.: SZ12070304-1 FCC ID: VVA2580004 TRF No.: FCC IC_C_b ii SUMMARY OF TEST RESULT Guangdong Alpha Animation and Culture Co.,Ltd. Model: LC258040 (6000815) FCC ID: VVA2580004 TEST SPECIFICATION REFERENCE RESULTS Maximum Peak Output Power 15.247(b), (c) / RSS-210 A8.4 N/A Hopping Channel Carrier Frequencies Separation (for 2.4GHz Digital) 15.247(e) / RSS-210 A8.1 N/A 20dB Bandwidth of the Hopping Channel 15.247(a) / RSS-210 A8.1 N/A Number of Hopping Frequencies 15.247(e) / RSS-210 A8.1 N/A Average Time of Occupancy of Hopping Frequency 15.247(e) / RSS-210 A8.1 N/A Anteann Conducted Spurious Emissions 15.247(d) / RSS-210 A8.5 N/A Radiated Spurious Emissions 15.247(d) / RSS-210 A8.5 N/A RF Exposure Compliance 15.247(i) / RSS-Gen 5.5 N/A Transmitter Power Line Conducted Emissions 15.207 / RSS-Gen 7.2.2 N/A Transmitter Field Strength (for 27MHz) 15.227 / RSS-310 3.8 N/A Transmitter Field Strength (for 40MHz) 15.229 / RSS-210 A2.7 N/A Transmitter Field Strength, Bandwidth and Timing Requirement 15.231(a) / RSS-210 A1.1.1 N/A Transmitter Field Strength, Bandwidth and Timing Requirement (for 433MHz) 15.231(e) / RSS-210 A1.1.5 N/A Transmitter Field Strength and Bandwidth Requirement(for 88-108MHz) 15.239 / RSS-210 A2.8 N/A Transmitter Field Strength and Bandwidth Requirement 15.249 / RSS-210 A2.9 N/A Transmitter Field Strength and Bandwidth Requirement (for 49MHz) 15.235 / RSS-310 3.9 Pass Receiver / Digital Device Radiated Eissions 15.109 / ICES-003 N/A Digital Device Conducted Emissions 15.107 / ICES-003 N/A Note: 1. The EUT uses an telescope antenna with unique antenna connector with unique antenna connector with unique antenna connector which, in accordance to section 15.203, is considered sufficient to comply with the pervisions of this section. 2. Pursuant to FCC part 15 Section 15.215(c), the 20 dB bandwidth of the emission was contained within the frequency band designated (mentioned as above) which the EUT operated. The effects, if any, from frequency sweeping, frequency hopping, other modulation techniques and frequency stability over excepted variations in temperature and supply voltage were considered. INTERTEK TESTING SERVICES Report No.: SZ12070304-1 FCC ID: VVA2580004 TRF No.: FCC IC_C_b iii Table of Contents 1.0 General Description....................................................................................... 1 1.1 Product Description .......................................................................................... 1 1.2 Related Submittal(s) Grants.............................................................................. 1 1.3 Test Methodology............................................................................................. 1 1.4 Test Facility ...................................................................................................... 1 2.0 System Test Configuration ............................................................................ 2 2.1 Justification ...................................................................................................... 2 2.2 EUT Exercising Software................................................................…

Text truncated - open the document above for the full version.

Radiated Photos
