VVG22TXREMOTE COOKING THERMOMETER

Shenzhen sanfuda ELECTRONICS CO.,LTD INSTRUCTION MANUAL MODEL #BB-22 PROFESSIONAL REMOTE COOKING THERMOMETER Stand – Fold up stand for easy storage. BATTERY COMPARTMENT – holds 2 AAA batteries. S – plug in for stainless steel probe sensor Voltage: DC3V Send Current: 6mA ( Transmit instantaneous current) POWER: 0.018W ( Transmit instantaneous power) Buttons 1. ON-OFF/F-C – Press and hold for 2 seconds turns transmitter on and off. Press to select temperature readings in Celsius or Fahrenheit. Registration Procedures Open the battery compartment of receiver and insert the two “AAA” batteries. Open the battery compartment of transmitter and insert the two “AAA” batteries. The Professional Remote Cooking Thermometer needs the receiver to register the radio frequency signal from the transmitter. Transmitter & Receiver are off. 1. Plug the stainless steel probe sensor into the plug in of the transmitter. 2. Turn transmitter on by pressing and holding the ON-OFF/F-C button on the side for 2 seconds. 3. Turn the receiver on by pressing and holding the ON-OFF/F-C button for 2 seconds. 4. Registration is complete when the receiver shows the probe temperature where the “---“ was. Cautions: The Professional Remote Cooking Thermometer registers temperatures as low as 14 F (- 10 C) and as high 482 F (250 C). LLL will be displayed below 14 F and HHH will be displayed above 410 F. Do not use the stainless steel probe sensor above 482 F. Doing so will deteriorate the wire. Cleaning Always wear a heat resistant glove to touch the stainless steel probe sensor or wire during or just after cooking. Do not touch with bare hands. Keep the stainless steel probe sensor and wire away from children. Wash the metal probe tip with hot soapy water and dry thoroughly. Do not immerse the probe in water while cleaning. Wipe the transmitter and receiver with damp cloth. Do not immerse either in water. FCC Statement 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Shenzhen sanfuda ELECTRONICS CO.,LTD

Shenzhen San Fu Da Electronics Co., Ltd. Nov 11, 2012 To: SIEMIC, INC. 775 Montague Expressway Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, ______Shenzhen San Fu Da Electronics Co., Ltd. ___hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product Description: REMOTE COOKING THERMOMETRE Model name: BB-22 FCC ID: VVG22TX We affirm that between SIEMIC and _ Shenzhen San Fu Da Electronics Co., Ltd. __, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities.

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Shenzhen San Fu Da Electronics Co., Ltd. Nov 11, 2012 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: VVG22TX We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application.

Label Location

Antenna Antenna

Page 1 of 29 FCC ID: VVG22TX ACCURATE TECHNOLOGY CO., LTD REPORT NO. ATE20122714 APPLICATION CERTIFICATION On Behalf of Shenzhen San Fu Da Electronics Co., Ltd. REMOTE COOKING THERMOMETER Model No.: BB-22 FCC ID: VVG22TX Prepared for : Shenzhen San Fu Da Electronics Co., Ltd. Address : 6/F., Block B, Huali Industrial Building, District 28, Baoan, Shenzhen, China Prepared by : ACCURATE TECHNOLOGY CO., LTD Address : F1, Bldg. A, Changyuan New Material Port, Keyuan Rd. Science & Industry Park, Nanshan, Shenzhen, Guangdong P.R. China Tel: (0755) 26503290 Fax: (0755) 26503396 Report Number : ATE20122714 Date of Test : Nov 28-Dec 12, 2012 Date of Report : Dec 12, 2012 Page 2 of 29 FCC ID: VVG22TX ACCURATE TECHNOLOGY CO., LTD REPORT NO. ATE20122714 TABLE OF CONTENTS Description Page Test Report Certification 1. GENERAL INFORMATION .......................................................................................................... 4 1.1. Description of Device (EUT)....................................................................................................................4 1.2. Description of Test Facility ......................................................................................................................5 1.3. Measurement Uncertainty.........................................................................................................................5 2. MEASURING DEVICE AND TEST EQUIPMENT ..................................................................... 6 3. SUMMARY OF TEST RESULTS................................................................................................... 7 4. THE FIELD STRENGTH OF RADIATION EMISSION ............................................................ 8 4.1. Block Diagram of Test Setup....................................................................................................................8 4.2. The Field Strength of Radiation Emission Measurement Limits..............................................................9 4.3. Configuration of EUT on Measurement ...................................................................................................9 4.4. Operating Condition of EUT ....................................................................................................................9 4.5. Test Procedure ........................................................................................................................................10 4.6. The Field Strength of Radiation Emission Measurement Results ..........................................................11 5. 20DB OCCUPIED BANDWIDTH ................................................................................................ 13 5.1. Block Diagram of Test Setup..................................................................................................................13 5.2. The Bandwidth of Emission Limit According To FCC Part 15 Section 15.231(c) ................................13 5.3. EUT Configuration on Measurement .....................................................................................................14 5.4. Operating Condition of EUT ..................................................................................................................14 5.5. Test Procedure ........................................................................................................................................14 5.6. Measurement Result ...............................................................................................................................15 6. RELEASE TIME MEASUREMENT............................................................................................ 16 6.1. Block Diagram of Test Setup..................................................................................................................16 6.2. Release Time Measurement According To FCC Part 15 Section 15.231(e) ..........................................16 6.3. EUT Configuration on Measurement .....................................................................................................17 6.4. Operating Condition of EUT ..................................................................................................................17 6.5. Test Procedure ........................................................................................................................................17 6.6. Measurement Result ...............................................................................................................................18 7. ANTENNA REQUIREMENT........................................................................................................ 20 7.1. The Requirement ....................................................................................................................................20 7.2. Antenna Construction .............................................................................................................................20 APPENDIX I ( TEST CURVES) (10 pages) Page 3 of 29 FCC ID: VVG22TX ACCURATE TECHNOLOGY CO., LTD REPORT NO. ATE20122714 Test Report Certification Applicant : Shenzhen San Fu Da Electronics Co., Ltd. Manufacturer : Shenzhen San Fu Da Electronics Co., Ltd. EUT Description : REMOTE COOKING THERMOMETER (A) MODEL NO.: BB-22 (B) Trade Name.: n.a (C) POWER SUPPLY: DC 3V (“AAA battery” 2×) Measurement Procedure Used: FCC Rules and Regulations Part 15 Subpart C Section 15.231 ANSI 63.10: 2009 The device described above is tested by ACCURATE TECHNOLOGY CO., LTD to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 15 Subpart C Section 15.231. The measurement results are contained in this test report and ACCURATE TECHNOLOGY CO., LTD is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the Equipment Under Test (EUT) is to be technically…

Text truncated - open the document above for the full version.

Radiated spurious emission (up to 1G): Radiated spurious emission (above 1G):
