VW3FAST3486Cable Gateway

Safety and Certifications 253643479 11 March 2015 1 Important Information about the Sagemcom F@ST3486: Installation and Safe Usage Instructions: 1. Place the router in a horizontal orientation on a flat surface. 2. Connect the manufacturer supplied AC to DC power adapter. Only use a manufacturer supplied and approved power adapter and Ethernet cable. 3. Connect the F@ST3486 to the AC Mains in accordance with the installation instructions in this booklet, and the markings on the identification label (voltage, current, and frequency of electricity network). 4. Connect the Ethernet cable (provided) to one of the RJ45 ports on the product labeled "1", "2", "3", or "4". Then connect the other end of the Ethernet Cable to the Ethernet port of a computer. Repeat as necessary for the other available Ethernet ports. When using this device, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons including the following: 1. Do not use this product near water and avoid contact with moisture. For example, does not use near a bathtub, wash bowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool. Care should be taken so that liquids are not spilled on this equipment. 2. This equipment is for indoor use only, do not place or install in an outdoor location. 3. Place your product on a firm, solid surface, no obstacle at a minimum distance of 20cm (0.65ft). If you put it on something unsteady, it may fall and be damaged. If you place it on a soft surface, such as rug, sofa or cushion, the vents may be blocked, causing the product to overheat. 4. Never insert objects into the vents of this equipment as this can result in the risk of electrical shock or fire. 5. As the power adapter is the only way to connect to the electrical network, the product must be installed near an easily accessed power outlet. 6. This equipment should only be operated from the type of power supply (Voltage and Current) indicated on the marking label. 7. Do not overload wall outlets or extension cords. Doing so can result in the risk of fire or electrical shock. 8. Avoid blocking any vent openings or exhaust exits on this equipment. Do not place equipment in a built-in installation such as a cabinet that may impede the flow of air through the ventilation openings. 9. The equipment should be situated away from heat sources such as radiators, heat registers, stoves, or other heat producing appliances and equipment. 10. Care should be taken to ensure that the power cord is routed, so it is not likely to be walked on or pinched by items placed upon or next to it. 11. Unplug this equipment before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning only. 12. This equipment is not user serviceable and is to be serviced by qualified personnel only. Do not disassemble this equipment. If service is required, disconnect all power from the equipment and consult qualified service personnel. 13. To disconnect this equipment from AC power, unplug the power supply from the AC wall socket. 14. Connect only to in house equipment (SELV interface). It is not allowed to connect to public cable distribution or cable television network. 15. Use the product in the environment specified as below: - Air temperature between 0°C and +40°C. - Relative humidity between 20% and 90%. - Altitude: 3700 meters (12138ft) maximum. North American Cable Installer: This reminder is provided to call your attention to Article 820.93 of the National Electrical Code (Section 54 of the Canadian Electrical Code, Part 1) which provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building as close to the point of cable entry as practical. Save these Instructions! Safety and Certifications 253643479 11 March 2015 2 Federal Communications Commission (FCC) Statements This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Modifications: You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. FCC Responsible Party: Sagemcom USA 14651 N. Dallas Parkway Suite 900 Dallas, TX 75254 Phone: 972-674-4100 Radio Frequency Interference Statement Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: 1. Reorient or relocate the receiving antenna. 2. Increase the separation between the equipment and receiver. 3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. 4. Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This device produces radio frequency energy in the 2.4GHz and 5GHz spectrum. The antenna must be positioned to keep a minimum dis…

Text truncated - open the document above for the full version.

..... aGeMCOM Rueii-Malmaison, April 30, 2015 Declaration for no non-US channel operation We, SAGEMCOM SAS declare that the device does not support channel12 ~ 13 in 2.4GHz band and any non-US channels in all the operational mode(s) for the following product. FCCID:VVV3FAST3486 If you should have any question(s) regarding this declaration, please don't hesitate to contact us. Sa GeM COM Sagemcom S.A.S. au capital de 158 291 895 € 440 294 510 RCS NANTERRE Siege Social : 250, route de I' 02848 RUEIL.u~ol.llol!~!N-0EQtiiX---r FRANce Name: Jacques LEROUX Title: R&D General Methods Department Manager Tel: + 33 1 57 61 25 72 Fax: + 33 1 57 61 38 99 E-mail: [email protected] Sagemcom SAS Siege Social:250 route de I'Empereur -92646 Rueii-Malmaison Cedex-France Tel: +33( o)l 57 61 10 DO Fax: +33(0 )157 6110 01

aGeMCOM Rueii-Malmaison, on April 30, 2015 AUTHORIZATION LETTER FCCID:VVV3FAST3486 To whom it may concern: We, the undersigned Sagemcom, hereby authorize Amanda WU/Senior Specialist of Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf in all manners relating to FCC application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Amanda WU/Senior Specialist of BV CPS Taoyuan on our behalf shall have the same effect as acts of our own. If you have any questions regarding the authorization, please don't hesitate to contact us. Sincerely yours, SaGeMCOM Sagemcom S.A.S. au capital de 158 291 895 € 440 294 510 RCS NANTERRE Name: Jacques LEROUX Title: R&D General Methods Department Manager Tel: + 33 1 57 61 25 72 Fax: + 33 1 57 61 38 99 E-mail: [email protected] sagemcom SAS Siege Social:lso route de I'Empereur -91648 Rueii-Malmaison Cedex-France Tel: +33( o)1 57 6110 oo Fax: +33(0 )157 6110 01

Report No.: 150420E01 Page No. 1 / 15 CONSTRUCTION PHOTOS OF EUT Rev 1.0 Report No.: 150420E01 Page No. 14 / 15 Rev 2.0 Report No.: 150420E01 Page No. 15 / 15

FCC ID： VW3FAST3486 LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. Label Here

Report No.: 150420E01 Page No. 2 / 15 Rev 1.0 Report No.: 150420E01 Page No. 3 / 15 Report No.: 150420E01 Page No. 4 / 15 Report No.: 150420E01 Page No. 5 / 15 Rev 1.0 Report No.: 150420E01 Page No. 6 / 15 Rev 1.0 Report No.: 150420E01 Page No. 7 / 15 Rev 1.0 Report No.: 150420E01 Page No. 8 / 15 Rev 1.0 Report No.: 150420E01 Page No. 9 / 15 Rev 1.0 Report No.: 150420E01 Page No. 10 / 15 Rev 1.0 Report No.: 150420E01 Page No. 11 / 15 Report No.: 150420E01 Page No. 12 / 15 Report No.: 150420E01 Page No. 13 / 15

Report No.: SA150420E01 Page No. 1 / 6 Report Format Version: 6.1.1 RF Exposure Report Report No.: SA150420E01 FCC ID: VW3FAST3486 Test Model: F@ST 3486 S/N: Test sample only P/N: 253641590 Received Date: Apr. 20, 2015 Test Date: Apr. 22, 2015 Issued Date: May 18, 2015 Applicant: SAGEMCOM SAS Address: 250 Route de l’Empereur - 92848 RUEIL MALMAISON CEDEX- FRANCE Manufacturer: SAGEMCOM SAS Address: 250 Route de l’Empereur - 92848 RUEIL MALMAISON CEDEX- FRANCE Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory Lab Address: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. Test Location (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. Test Location (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. The report must not be used by the client to claim product certification, approval, or endorsement by any government agencies. Report No.: SA150420E01 Page No. 2 / 6 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 3 1 Certificate of Conformity ...................................................................................................................... 4 2 RF Exposure .......................................................................................................................................... 5 2.1 Limits for Maximum Permissible Exposure (MPE) .............................................................................. 5 2.2 MPE Calculation Formula ................................................................................................................... 5 2.3 Classification ....................................................................................................................................... 5 2.4 Antenna Gain ...................................................................................................................................... 5 3 Calculation Result of Maximum Conducted Power ........................................................................... 6 Report No.: SA150420E01 Page No. 3 / 6 Report Format Version: 6.1.1 Release Control Record Issue No. Description Date Issued SA150420E01 Original release. May 18, 2015 Report No.: SA150420E01 Page No. 5 / 6 Report Format Version: 6.1.1 2 RF Exposure 2.1 Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) Limits For General Population / Uncontrolled Exposure 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2.2 MPE Calculation Formula Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 2.3 Classification The antenna of this product, under normal use condition, is at least 27cm away from the body of the user. So, this device is classified as Mobile Device. 2.4 Antenna Gain The antennas provided to the EUT, please refer to the following table: 2.4GHz Band Antenna No. PCB Chain No. Brand Model Ant. Gain(dBi) <Including cable loss> Frequency range (GHz to GHz) Antenna Type Connecter Type Cable Length (mm) E 0 wanshih NA 2.0979 2.4~2.4835 PIFA None (like solder) NA B 1 wanshih NA 2.9762 2.4~2.4835 PCB i-pex(MHF) 160 F 2 wanshih NA 2.51 2.4~2.4835 PIFA None (like solder) NA 5GHz Band Antenna No. PCB Chain No. Brand Model Ant. Gain(dBi) <Including cable loss> Frequency range (GHz to GHz) Antenna Type Connecter Type Cable Length (mm) C 0 wanshih NA 3.81 5.15~5.85 PIFA None (like solder) NA D 1 wanshih NA 3.92 5.15~5.85 PIFA None (like solder) NA A 2 wanshih NA 3.8509 5.15~5.85 PCB i-pex(MHF) 75 Report No.: SA150420E01 Page No. 6 / 6 Report Format Version: 6.1.1 3 Calculation Result of Maximum Conducted Power CDD Mode: Frequency Band (MHz) Max Power (mW) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) 2412-2462 387.091 7.31 27 0.22744 1 5180-5240 862.64 8.63 27 0.68690 1 5745-5825 528.52 8.63 27 0.42085 1 Note: 2.4GHz: Directional gain = 10 log[(10 G1/20 + 10 G2/20 + 10 G3/20 ) 2 / 3] = 7.31dBi. 5GHz: Directional gain = 10 log[(10 G1/20 + 10 G2/20 + 10 G3/20 ) 2 / 3] = 8.63dBi. Beamforming Mode: Frequency Band (MHz) Max Power (mW) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) 5180-5240 134.999 8.63 27 0.10750 1 5745-5825 396.664 8…
