Atmel Norway AS Vestre Rosten 79 TRONDHEIM, 7075 Norway Tel: 91-44-45401182 Attestation Letter D ecember 9, 2015 To: Bay Area Compliance Laboratories Corp. 1274 Anvilwood Avenue Sunnyvale, CA 94089 Dear Sir or Madam: ATREB215-XPRO board with model number A09-1980 and FCC ID: VW4A091980 which supports 2.4GHz and 915MHz ISM bands as per IEEE 802.15.4-2011 and IEEE 802.15.4g-2012. This FCC ID is applicable only for the 2.4GHz band mentioned above. The sub-1GHz band of the REB215-XPRO shall only be used by technically qualified professional electronics experts inside lab environment for conducted measurements and not for radiated measurements in the North American band. Sincerely, Saravanakumar Marudhachalam Staff Engineer
Atmel Norway AS Vestre Rosten 79 TRONDHEIM, 7075 Norway Tel: FCC Confidential Authorization 12/07/2015 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: VW4A091980 In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, (Atmel Norway AS) hereby requests long-term confidential treatment of information accompanying this application as outlined below: Block Diagram Circuit Description Detailed Circuit Schematics of EUT The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Signature: Saravanakumar Marudhachalam Staff Engineer +91 44 30637229
Atmel Norway AS Vestre Rosten 79 TRONDHEIM, 7075 Norway Tel: Limited Modular Approval Letter 12/07/2015 Dear Application Examiner: Atmel Norway AS is submitting this application for certification of their ATREB215-XPRO under FCC ID: VW4A091980. It is seeking limited modular approval. The radio meets most of the requirements for modular approval as detailed in FCC 15.212. Compliance to each of the requirements is described below: 1. “The modular transmitter must have its own RF shielding.” The radio part of modular has no RF shielding 2. “The modular transmitter must have buffered modulation/data inputs.” Buffered data inputs stage has been integrated in chip (Model: AT86RF215) 3. “The modular transmitter must have its own power supply regulation.” DC 3.3V supplied by system 4. “The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204(c).” The module has one 2.4GHz rubber stubby antenna with SMA male straight. 5. “The modular transmitter must be tested in a stand-alone configuration.” The EUT was tested in a stand-alone configuration. 6. “The modular transmitter must be labeled with its own FCC ID number.” The module will be labeled with its own FCC ID number. Please see FCC ID label & location exhibit 7. “The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements.” The necessary explanation to be complied with this requirement is contained in the use manual, and please refers to the Use manual. 8. “The modular transmitter must comply with any applicable RF exposure requirements.” The EUT will comply with any applicable RF exposure requirements in its final configuration. Sincerely, Signature: Saravanakumar Marudhachalam Staff Engineer +91 44 30637229
EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS EUT – Top View EUT – Bottom View
EXHIBIT A - FCC ID LABEL AND LOCATION FCC ID Label FCC ID Label Location Information The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)
EXHIBIT C - EUT INTERNAL PHOTOGRAPHS EUT – Top View EUT – Bottom View EUT – Antenna Port View
