VYJ-LYNX524ADSL2+ 802.11b/g 4 Port Managed Switch Router

Starbridge Lynx 524 Wireless ADSL Router User Manual Wireless ADSL Router USER MANUAL NOTICE This document contains proprietary information protected by copyright, and this Manual and all the accompanying hardware, software, and documentation are copyrighted. All rights are reserved. No part of this document may be photocopied or reproduced by mechanical, electronic, or other means in any form. The manufacturer does not warrant that the hardware will work properly in all environments and applications, and makes no warranty or representation, either expressed or implied, with respect to the quality, performance, merchantability, or fitness for a particular purpose of the software or documentation. The manufacturer reserves the right to make changes to the hardware, software, and documentation without obligation to notify any person or organization of the revision or change. All brand and product names are the trademarks of their respective owners. © Copyright 2009 All rights reserved. Content 1 OVERVIEW........................................................................................................................1 1.1 FEATURES........................................................................................................................... 1 1.2 PACKET CONTENTS............................................................................................................ 3 1.3 SYSTEM REQUIREMENTS.................................................................................................... 3 1.4 FACTORY DEFAULTS........................................................................................................... 4 1.5 WARNINGS AND CAUTIONS................................................................................................. 4 2 HARDWARE DESCRIPTION.............................................................................................5 3 HARDWARE INSTALLATION...........................................................................................7 4 PC CONFIGURATION GUIDE...........................................................................................8 4.1 LOCAL PC CONFIGURATION IN WINDOWS 95, 98, ME, XP................................................. 8 4.2 LOCAL PC CONFIGURATION IN WINDOWS 2000................................................................. 8 5 WEB-BASED MANAGEMENT GUIDE..............................................................................9 5.1 LAN SETTING PAGE............................................................................................................ 9 5.2 INTERNET ACCESS CONFIGURATION................................................................................... 9 QUICK SETUP............................................................................................................................. 9 5.3 WIRELESS SETTING.......................................................................................................... 20 APPENDIX: FREQUENT ASKED QUESTIONS.................................................................24 Wireless ADSL Router USER MANUAL 1 1 Overview Thank you for choosing our product. The Starbridge Lynx 524 Wireless ADSL Router uses Broadcom’s CPE solution that fully complies with ADSL, ADSL2 ADSL2+ and IEEE802.11b/g standards. It will provide your SOHO with convenient Internet access. 1.1 Features 1.1.1 Data Rate z Downstream data rate up to 24 Mbps z Upstream data rate up to 1Mbps 1.1.2 ADSL Compliance z ITU G.992.1 (G.DMT) z ITU G.992.2 (G.Lite) z ITU G.992.3 (G.DMT.BIS) z ITU G.992.4 (G.lite.bis) z ITU G.992.5 z ITU G.994.1 (G.hs) z Compatible with all T1.413 issue 2 (full rate DMT over analog POTS), and CO DSLAM equipment z TR-069 compliant with ACS 1.1.3 Wireless z Fully IEEE 802.11b & IEEE 802.11g compatible z Wireless data rate up to 54 Mbps z Operating in the unlicensed 2.4 GHz ISM band z Supports 64/128 bits WEP security and user authentication 1.1.4 Network Protocol & Features z Ethernet to ADSL Self-Learning Transparent Bridging z Internet Control Message Protocol (ICMP) z IP Static Routing Wireless ADSL Router USER MANUAL 2 z Routing Information Protocol (RIP, RIPv2) z Network Address Translation (NAT) z Virtual Server, Port Forwarding z Dynamic Host Configuration Protocol (DHCP) z DNS Relay, DDNS z IGMP Proxy z Simple Network Time Protocol (SNTP) z VPN pass-through (IPSec/PPTP/L2TP) z Parent control 1.1.5 ATM Capabilities z RFC 1483 Multi-protocol over ATM “Bridged Ethernet” compliant z RFC 2364 PPP over ATM compliant z RFC 2516 PPP over Ethernet compliant z ATM Forum UNI3.1/4.0 PVC - Up to 8 PVCs z VPI Range: 0-255 z VCI Range: 32-65535 z UNI 3.0 & 3.1 Signaling z ATM AAL5 (Adaption Layer type 5) z OAM F4/F5 1.1.6 FIREWALL z Built-in NAT z MAC Filtering z Packet Filtering z Stateful Packet Inspection (SPI) z Denial of Service Prevention (DoS) z DMZ Wireless ADSL Router USER MANUAL 3 1.1.7 Management Support z Web Based GUI z Upgrade or update via FTP/HTTP z Command Line Interface via Telnet z Diagnostic Test z Firmware upgrade-able for future feature enhancement 1.1.8 Operating System Support z WINDOWS 98/SE/ME/2000/XP/VISTA z Macintosh z LINUX 1.1.9 Environmental z Operating humidity: 10%-90% non-condensing z Non-operating storage humidity: 5%-95% non-condensing 1.2 Packet Contents The packet contents are as the following: z ADSL ROUTER x 1 z External Splitter x 1 z Power Adapter x 1 z Telephone Line x 1 z Ethernet Cable x 1 z User Manual (CD) x 1 1.3 System Requirements Before using this ROUTER, verify that you meet the following requirements: z Subscription for ADSL service. Your ADSL service provider should provide you with at least one valid IP address (static assignment or dynamic assignment via dial-up connection). z One or more computers, each contains an Ethernet 10/100M Base-T network interface card (NIC). Wireless ADSL Router USER MANUAL 4 z A hub or switch, if you are connecting the device to more than one computer. z For system configurat…

Text truncated - open the document above for the full version.

External Photos Enclosure of EUT Enclosure of EUT Photo of adapter

Internal Photos Internal of EUT PCB of EUT PCB of EUT Radio Part

Radiated emission Below 1GHz: Above 1GHz: Conducted emission
