VYTLP8696P802.11 b/g/n 2.4G Indoor Wireless Smart Repeater (2T2R)

Loopcomm Technology,.Inc. 6F., No. 236, Bo'ai St., Shulin Dist., New Taipei City 23845 Taiwan Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Date: May 19, 2014 To whom it may concern: We, the undersigned, hereby authorize Worldwide Testing Services (Taiwan) Co., Ltd to act on our behalf in all matters relating to applications for equipment authorization FCC ID:VYTLP8696P including the signing of all documents related to these matters. Any and all acts carried out by Worldwide Testing Services (Taiwan) Co., Ltd on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name: EZ Hsieh Title: Product Marketing Directior Company: Loopcomm Technology,.Inc. .

Loopcomm Technology,.Inc. 6F., No. 236, Bo'ai St., Shulin Dist., New Taipei City 23845 Taiwan Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Date: 04/07/14 Request for Confidentiality Company name: Loopcomm Technology,.Inc. FCC ID:VYTLP8696P FCC Part 15 Certification To whom it may concern: In accordance with 0.459 of CFR 47, Loopcomm Technology,.Inc. hereby requests confidentiality of all Block Diagrams, Schematics, Operational Description attachments for the subject application. These documents contain detailed system and equipment description and related information about the product which Loopcomm Technology,.Inc. considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, Loopcomm Technology,.Inc. considers that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, Name: EZ Hsieh Title: Product Marketing Directior Company: Loopcomm Technology,.Inc.

Registration number: W6M21405-14163-FCC FCC ID: VYTLP8696P Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 2 of 16 External Photos Antenna A Antenna B Registration number: W6M21405-14163-FCC FCC ID: VYTLP8696P Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 3 of 16 Registration number: W6M21405-14163-FCC FCC ID: VYTLP8696P Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 4 of 16 Registration number: W6M21405-14163-FCC FCC ID: VYTLP8696P Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 5 of 16 Registration number: W6M21405-14163-FCC FCC ID: VYTLP8696P Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 6 of 16 Registration number: W6M21405-14163-FCC FCC ID: VYTLP8696P Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 7 of 16

Registration number: W6M21405-14163-FCC FCC ID: VYTLP8696P Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 8 of 16 Internal Photos Registration number: W6M21405-14163-FCC FCC ID: VYTLP8696P Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 9 of 16 Registration number: W6M21405-14163-FCC FCC ID: VYTLP8696P Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 10 of 16 Registration number: W6M21405-14163-FCC FCC ID: VYTLP8696P Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 11 of 16 Registration number: W6M21405-14163-FCC FCC ID: VYTLP8696P Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 12 of 16

Loopcomm Technology,.Inc. 6F., No. 236, Bo'ai St., Shulin Dist., New Taipei City 23845 Taiwan Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Applicant’s declaration concerning RF Radiation Exposure We hereby indicate that the product Product description: 802.11 b/g/n 2.4G Indoor Wireless Smart Repeater (2T2R) Model No: LP-8696P The equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. The integral antennas used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter within the host device. A safety statement concerning minimum separation distances from enclosure of the Product : 802.11 b/g/n 2.4G Indoor Wireless Smart Repeater (2T2R) will be integrated in the user’s manual to provide end-users with transmitter operating conditions for satisfying RF exposure compliance. The appropriate information can be drawn from the test report no: W6M21405-14163-C-1 and the accompanying calculations. Company: Loopcomm Technology,.Inc. Address: 6F., No. 236, Bo'ai St., Shulin Dist., New Taipei City 23845 Taiwan Date: 2014/05/19 Signature Registration number: W6M21405-14163-C-1 FCC ID: VYTLP8696P Worldwide Testing Services(Taiwan) Co., Ltd. Page 26 of 81 3.2 Equivalent isotropic radiated power FCC Rule: 15.247(b)(3) EIRP = max. conducted output power + antenna gain 802.11b/g EIRP = 18.27 dBm + 5.71 dBi = 23.98 dBm 802.11n(20MHz), 802.11n(40MHz) EIRP = 17.63 dBm + 5.71 dBi = 23.34 dBm Limit: EIRP = +36 dBm for Antenna gain <6dBi Test equipment used: ETSTW-RE 055 3.3 RF Exposure Compliance Requirements FCC OET Bulletin 65 Edition 97.01 determines the equations for predicting RF fields and applicable limits. The prediction for power density in the far-field but will over-predict power density in the near field, where it could be used for walking a “worst case” or conservative prediction. PG S = --------- 4πR 2 S – Power Density P – Output power ERP R – Distance D – Cable Loss AG – Antenna Gain 802.11b/g Item Unit Value Remarks P mW 67.1429 Peak value D dB AG dBi 5.71 G 3.7239 Calculated Value R cm 20 Assumed value S mW/cm2 0.0497 Calculated value 802.11n(20MHz), 802.11n(40MHz) Item Unit Value Remarks P mW 57.9429 Peak value D dB AG dBi 5.71 G 3.7239 Calculated Value R cm 20 Assumed value S mW/cm2 0.0429 Calculated value Limits: Limit for General Population / Uncontrolled Exposure Frequency (MHz) Power Density (mW/cm 2 ) 1500 – 100.000 1.0

of Applicant: Loopcomm Technology,.Inc. Address: 6F., No. 236, Bo'ai St., Shulin Dist., New Taipei City 23845 Taiwan Tested and Prepared by Worldwide Testing Services (Taiwan) Co., Ltd. FCC Registration No.: 930600 Industry Canada filed test laboratory Reg. No. IC 5679A-1 A2LA Accredited No.: 2732.01 Report No.: W6M21405-14163-C-1 6F, NO. 58, LANE 188, RUEY-KUANG RD., NEIHU TAIPEI 114, TAIWAN, R.O.C. TEL: 886-2-66068877 FAX: 886-2-66068879 E-mail: [email protected] FCC PART 15 SUBPART C TEST REPORT for 802.11 b/g/n 2.4G Indoor Wireless Smart Repeater (2T2R) Model No.: LP-8696P FCC ID: VYTLP8696P Registration number: W6M21405-14163-C-1 FCC ID: VYTLP8696P Worldwide Testing Services(Taiwan) Co., Ltd. Page 1 of 81 TABLE OF CONTENTS 1 GENERAL INFORMATION ................................................................................................... 2 1.1 NOTES................................................................................................................................... 2 1.2 TESTING LABORATORY......................................................................................................... 3 1.2.1 Location .......................................................................................................................3 1.2.2 Details of accreditation status ..................................................................................... 3 1.3 DETAILS OF APPROVAL HOLDER............................................................................................ 3 1.4 APPLICATION DETAILS.......................................................................................................... 4 1.5 G ENERAL INFORMATION OF TEST ITEM................................................................................. 4 1.6 T EST STANDARDS.................................................................................................................. 6 2 TECHNICAL TEST ..................................................................................................................7 2.1 SUMMARY OF TEST RESULTS................................................................................................. 7 2.2 T EST ENVIRONMENT............................................................................................................. 7 2.3 TEST EQUIPMENT LIST.......................................................................................................... 8 2.4 GENERAL TEST PROCEDURE............................................................................................... 10 3 TEST RESULTS (ENCLOSURE) ......................................................................................... 12 3.1 P EAK OUTPUT POWER (TRANSMITTER) ............................................................................... 13 3.2 EQUIVALENT ISOTROPIC RADIATED POWER......................................................................... 26 3.3 RF EXPOSURE COMPLIANCE REQUIREMENTS..................................................................... 26 3.4 TRANSMITTER RADIATED EMISSIONS IN RESTRICTED BANDS............................................. 27 3.5 S PURIOUS EMISSIONS (TX) .................................................................................................. 28 3.6 R ADIATED EMISSION ON THE BAND EDGE........................................................................... 42 3.7 MINIMUM 6 dB BANDWIDTH............................................................................................... 51 3.8 PEAK POWER SPECTRAL DENSITY...................................................................................... 64 3.9 R ADIATED EMISSION FROM DIGITAL PART......................................................................... 77 3.10 POWER LINE CONDUCTED EMISSION.................................................................................. 78 APPENDIX.............................................................................................................................. 81 Registration number: W6M21405-14163-C-1 FCC ID: VYTLP8696P Worldwide Testing Services(Taiwan) Co., Ltd. Page 2 of 81 1 General Information 1.1 Notes The purpose of conformity testing is to increase the probability of adherence to the essential requirements or conformity specifications, as appropriate. The complexity of the technical specifications, however, means that full and thorough testing is impractical for both technical and economic reasons. Furthermore, there is no guarantee that a test sample which has passed all the relevant tests conforms to a specification. Neither is there any guarantee that such a test sample will interwork with other genuinely open systems. The existence of the tests nevertheless provides the confidence that the test sample possesses the qualities as maintained and that is performance generally conforms to representative cases of communications equipment. The test results of this test report relate exclusively to the item tested as specified in 1.5. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the Worldwide Testing Services(Taiwan) Co., Ltd. Specific Conditions: Usage of the hereunder tested device in combination with other integrated or external antennas requires at least additional output power measurements, spurious emission measurements, conducted emission measurements (AC supply lines) and radio frequency exposure evaluations for each individual configuration performed, for certification by FCC. The test sample is able to work according IEEE 802.11 b/g/n. This report is related to FCC Part 15 C (DSSS and OFDM device). Tester: May 19, 2014 Robert Ren Date WTS-Lab. Name Signature Technical responsibility for area of testing: May 19, 2014 Kevin Wang Date WTS Name Signature Registration number: W6M21405-14163-C-1 FCC ID: VYTLP8696P Worldwide Testing Services(Taiwan) Co., Ltd. Page 3 of 81 1.2 Testing laboratory 1.2.1 Locatio…

Text truncated - open the document above for the full version.

Registration number: W6M21405-14163-FCC FCC ID: VYTLP8696P Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 13 of 16 Set Up Photo of Radiated Emission EMI Below 1GHz Registration number: W6M21405-14163-FCC FCC ID: VYTLP8696P Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 14 of 16 Above 1GHz Registration number: W6M21405-14163-FCC FCC ID: VYTLP8696P Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 15 of 16 RF Registration number: W6M21405-14163-FCC FCC ID: VYTLP8696P Worldwide Testing Services(Taiwan) Co., Ltd. Appendix Page 16 of 16 Set Up Photo of Conducted Emission
