TGW206-11 www.sziton.comV0. 1- Dec.202 1 DISCLAIMER AND COPYRIGHT NOTICE Information in this document, including URL references, is subject to change without notice. This document is provided “As if” with no whatsoever, including any warranty of merchantability, noninfringement, fitness for any purpose, or any warranty otherwise arising out of any proposal, specification or samples. All liability, including liability for infringement of any proprietary rights, relating to use of information in this document is disclaimed. No licenses express or implied, by estoppel or otherwise, to any intellectual property rights are granted herein. The Bluetooth logo and symbol belong to the Bluetooth SIG Inc. The Wi-Fi Alliance Member Logo is a trademark of the Wi-Fi Alliance. All trade names, trademarks and registered trademarks mentioned in this document are property of their respective owners, and are hereby acknowledged. Copyright ITON Technology Corp. All rights reserved. TGW206-11 Wi-Fi 802.11b/g/n+ Bluetooth LE 5.0 Module TGW206-11 www.sziton.comV0. 1 -Dec ., 202 1 ITON Technology Corp.Page 2 of 7 目录 Table of contents 1. Product Features................................................................................................................................................................ 3 1.1
Describe ...................................................................................................................................................................... 3 1.2
Product Features ..................................................................................................................................................... 3 1.3
Application scenarios ........................................................................................................................................... 3 1.4
System Block Diagram................................................................................................................................................ 3 2. PIN .foot definition............................................................................................................................................................. 4 2.1
Module PIN Interface Diagram ............................................................................................................................. 4 2.2
Pin function ............................................................................................................................................................ 4 3. Reference Application and PCB Layout............................................................................................................................ 5 3.1
Application Schematic Reference ...................................................................................................................... 5 3.2
Refer to PCB Layout .......................................................................................................................................... 5 4. Reference PCB Package .................................................................................................................................................... 6 4.1
Recommended pad...................................................................................................................................................... 6 4.2
Package size ............................................................................................................................................................ 6 5. Revise history .............................................................................................................................................................. 7 TGW206-11 www.sziton.comV0. 1 -Dec ., 202 1 ITON Technology Corp.Page 3 of 7 1.Product Features 1.1 describe TGW206-11 is a smart new generation highly integrated Wi-Fi and Bluetooth LE combo chip. The wireless subsystem includes 2.4G radio, Wi-Fi 802.11b/g/n and BLE baseband/MAC design. The microcontroller subsystem contains a low-power 32-bit RISC CPU, cache and memory. The power management unit provides flexible settings to implement low-power modes and supports a variety of security features. 1.2 Product Features 802.11b/g/n, Wi-Fi+Bluetooth LE5.0 Combo, support STA, Soft AP and Sniffer Adopt open source self-controllable RISC-V CPU, 1～160MHz adjustable, 276KB SRAM Ultra-low power consumption: sleep power consumption is only 0.5uA, network standby power consumption is only 40uA (DTIM10)) Ultra-fast connection: cold start fast connection is only 70ms High security: support secure boot, secure debugging, AES 128/192/256 encryption engine, WPA3, MD5, SHA-1/224/256, PKA (RSA/ECC) encryption engine Support Wi-Fi and Bluetooth LE coexistence 1.3 Application scenarios Smart Lighting smart switch smart socket Smart Appliances Monitoring remote control 1.4 System Block Diagram TGW206-11 www.sziton.comV0. 1 -Dec ., 202 1 ITON Technology Corp.Page 4 of 7 2. PIN definition 2.1 Module PIN Interface Diagram 2.2 Pin Function NONameIO TypeDescription 1AVDD33 PPower supply. 3.3V is required 2GPIO2I/OGPIO2 3GNDPGround connections 4GPIO11I/OGPIO11 5GPIO3I/OGPIO3 6GPIO0I/OGPIO0 7GPIO4I/OGPIO4 8GPIO5I/OGPIO5 9GPIO14I/OGPIO14 10CHIP_ENI/OChip enable pin (active high) 11GPIO8I/OGPIO8 (Boot option). TGW206-11 www.sziton.comV0. 1 -Dec ., 202 1 ITON Technology Corp.Page 5 of 7 3.Reference Application and PCB Layout 3.1 Application Schematic Reference 3.2 PCB Layout Reference 3.2.1 Keep the headroom at the module antenna 3.2.2 The module is far away from strong interference sources 3.2.3 The capacitor should be increased at the power supply, and the trace should be short and thick 3.2.4The module can be attached to the PCB board, or can be soldered on the PCB board with 2.0 pin headers 3.2.5 PCB This version is an on-board antenna TGW206-11 www.sziton.comV0. 1 -Dec ., 202 1 ITON Technology Corp.Page 6 of 7 4.Reference PCB Package 4.1Recommended pad 4.2 P…

Text truncated - open the document above for the full version.

FCCsinglemoduleApprovalRequest Tot heFCCorFCCTCBhandlingthisapplication Herebywe, Company(grantee)ItonTechnologyCorp. Address7FloorEast,BuildingC,ShenzhenInternational,InnovationCenter,No.1006ShennanRd.FutianDist, Shenzhen,China City/ZIP/State/CountryShenzhen,China requestlimitedmodularapprovalforthecertificationofourequipmentwithinthisapplication,identifiedby: FCCID:VYV-TGW206-11P Thetablebelowcontainsjustificationformodularapprovalofthisequipment. RequirementperDA00-1407Explanationfromgrantee 1.ThemodulartransmittermusthaveitsownRFshielding. HasRFshielding. Themodulartransmittermusthavebufferedmodulation/datainputs(ifsuchinputsare provided)toensurethatthemodulewillcomplywithPart15requirementsunderconditions ofexcessivedataratesorover-modulation. Themodularhavebuffered modulation/datainputs. 2.Themodulartransmittermusthaveitsownpowersupplyregulation.Themodulartransmitterhaveitsown powersupplyregulation.(DC3.3V) ThemodulartransmittermustcomplywiththeantennarequirementsofSection15.203and 15.204(c).Theantennamusteitherbepermanentlyattachedoremploya“unique”antenna coupler(atallconnectionsbetweenthemoduleandtheantenna,includingthecable).. Themodelnumberofthereplaceable antennaisspecifiedinthemanual. 3.Themodulartransmittermustbetestedinastand-aloneconfiguration,i.e.,themodule mustnotbeinsideanotherdeviceduringtesting.Thisisintendedtodemonstratethatthe moduleiscapableofcomplyingwithPart15emissionlimitsregardlessofthedeviceinto whichitiseventuallyinstalled. Themodulewastestedinastand-alone configuration,pleaserefertotheSetup Photoforthedetail 4.ThemodulartransmittermustbelabeledwithitsownFCCIDnumber,and,iftheFCCID isnotvisiblewhenthemoduleisinstalledinsideanotherdevice,thentheoutsideofthe deviceintowhichthemoduleisinstalledmustalsodisplayalabelreferringtotheenclosed module.Thisexteriorlabelcanusewordingsuchasthefollowing:“ContainsTransmitter ModuleFCCID:VYV-TGW206-11P”or“ContainsFCCID:VYV-TGW206-11P.”Anysimilar wordingthatexpressesthesamemeaningmaybeused.TheGranteemayeitherprovide suchalabel,anexampleofwhichmustbeincludedintheapplicationforequipment authorization,or,mustprovideadequateinstructionsalongwiththemodulewhichexplain thisrequirement.Inthelattercase,acopyoftheseinstructionsmustbeincludedinthe applicationforequipmentauthorization. Pleaserefertolabelsampleexhibit-host labelingisdescribedinintegrationmanual 5.Themodulartransmittermustcomplywithanyspecificruleoroperatingrequirements applicabletothetransmitterandthemanufacturermustprovideadequateinstructionsalong withthemoduletoexplainanysuchrequirements.Acopyoftheseinstructionsmustbe includedintheapplicationforequipmentauthorization.Forexample,thereareverystrict operationalandtimingrequirementsthatmustbemetbeforeatransmitterisauthorizedfor operationunderSection15.231.Forinstance,datatransmissionisprohibited,exceptfor operationunderSection15.231(e),inwhichcasethereareseparatefieldstrengthleveland timingrequirements.Compliancewiththeserequirementsmustbeassured. TherequiredFCCrulehasbeenfulfilled andalltheinstructionsforthemaintaining compliancehavebeenclearlystatedinthe UserManual. 6.ThemodulartransmittermustcomplywithanyapplicableRFexposurerequirements.For example,FCCRulesinSections2.1091,2.1093andspecificSectionsofPart15,including 15.319(i),15.407(f),15.253(f)and15.255(g),requirethatUnlicensedPCS,UNIIand millimetrewavedevicesperformroutineenvironmentalevaluationforRFExposureto demonstratecompliance.Inaddition,spreadspectrumtransmittersoperatingunderSection 15.247arerequiredtoaddressRFExposurecomplianceinaccordancewithSection 15.247(b)(4).ModulartransmittersapprovedunderotherSectionsofPart15,when necessary,mayalsoneedtoaddresscertainRFExposureconcerns,typicallybyproviding specificinstallationandoperatinginstructionsforusers,installersandotherinterestedparties toensurecompliance. TheMPEevaluationwith20cmdistance restrictionissubmittedforthecompliance ofRFExposurerequirement. Attestation(bygrantee) CityandCountry:Date:Name: (thismustbeaperson) Function:Signature: (orofficialcompanystamp) Shenzhen/China2022-07-14ZhanchiZhaProductManager

FCCID:VYV-TGW206-11P

LabelLocationOnEUT TGW206-11P 14.1 x8.6mm 字体： Arial Regular 1.6pt 字体高度：0.405 mm 备注* 二维码：唯一MAC地址码 例如：703E97A99510 Date code：生产厂家代码01+生产日期 单位：mm HZB size unit: mm Model： TGW206-11P FCC ID:VYV-TGW206-11P MAC:703E97A99510 Date code:0120220506 Firmware Ver:xxx Model：TGW206-11P xxxxxxxxx 97A99510 Date code:0120220506 Firmware Ver:xxx 1 . 5 m m 1.7 mm 3 . 5 m m 14.1 mm 8 . 4 6 m m 1 . 2 m m 3.5 mm 5.58 mm 5.3 mm FCC ID:x 5.7 mm MAC:703E 6.3 mm 4.7 mm 0.4 mm 0.4 mm 1.5 mm 1.0 mm 3.9 mm 8.52 mm 1 . 5 m m 1 . 1 m m

FCCID:VYV-TGW206-11P ANT

version01 ItonTechnologyCorp. DeclarationconcerningAntennaSpecification Itisherebydeclaredthattheproduct ModelNo.:TGW206-11P FCCID:VYV-TGW206-11P fulfillstherequirementinFCCtestrelatingtotheantennatype. ThedevicespecifiedaboveconfirmstotheFCCrecommendationsfor internal antennatype(s) describedbelow: ModelNo.ofantenna:N/A Typeofantenna:PCBantenna Gainoftheantenna:2dBi Frequencyrange:BLE:2402~2480MHz WiFi2.4G:2412~2462MHz Themountingoftheantennaisfixedtotheradiomoduleandnootherantennashouldbeused. Companyname:ItonTechnologyCorp. Address:7FloorEast,BuildingC,ShenzhenInternational,InnovationCenter, No.1006ShennanRd.FutianDist,Shenzhen,China City:Shenzhen ZIP/Postalcode:/ Country:China Place:Date:7/14/2022 Signature:

RFEXPOSUREEVALUATION AccordingtoFCC1.1310:Thecriterialistedinthefollowingtableshallbeusedto evaluatetheenvironmentimpactofhumanexposuretoradiofrequency(RF)Radiation asspecifiedin§1.1307(b) FCCID:VYV-TGW206-11P EUTSpecification EUTTGW206-11P Frequencyband(Operating)WLAN:2.412GHz~2.462GHz WLAN:5.18GHz~5.24GHz WLAN:5.745GHz~5.825GHz Others:BLE:2.402GHz~2.480GHz DevicecategoryPortable(<20cmseparation) Mobile(>20cmseparation) Others___ ExposureclassificationOccupational/Controlledexposure(S=5mW/cm2) GeneralPopulation/Uncontrolledexposure(S=1mW/cm2) AntennadiversitySingleantenna Multipleantennas Txdiversity Rxdiversity Tx/Rxdiversity Max.outputpowerBLE:1.08dBm(0.0013W) WiFi2.4G:17.93dBm(0.0621W) Antennagain(Max)BLE/WiFi2.4G:2dBi EvaluationappliedMPEEvaluation SAREvaluation LimitsforMaximumPermissibleExposure(MPE) Frequency Range(MHz) ElectricField Strength(V/m) MagneticField Strength(A/m) Power Density(mW/cm 2 ) Average Time (A)LimitsforOccupational/ControlExposures 300-1500----F/3006 1500-100000----56 (B)LimitsforGeneralPopulation/UncontrolExposures 300-1500----F/15006 1500-100000----130 Friistransmissionformula:Pd=(Pout*G)\(4*pi*R2) Where Pd=PowerdensityinmW/cm 2 Pout=outputpowertoantennainMw G=gainofantennainlinearscale Pi=3.1416 R=distancebetweenobservationpointandcenteroftheradiatorincm PdthelimitofMPE,1mW/cm2.Ifweknowthemaximumgainoftheantennaand totalpowerinputtotheantenna,throughthecalculation,wewillknowthedistance wheretheMPElimitisreached. MaxMeasurementResult Operating Mode Measured Power Tuneup tolerance Max.Tune upPower Antenna Gain Powerdensity at20cm Powerdensity Limits (mW/cm2) (dBm)(dBm)(dBm)(dBi)(mW/cm2) BLE1.081.08±12.0820.00051 WiFi2.4G17.9317.93±118.9320.02471 TheWLAN2.4GandBLEcan’ttransmitsimultaneously.

Page1of22 AppendixTestData ReportNo.:18220WC20125701TestSampleNo.:1-2-2 StartTestDate:2022.6.14FinishTestDate:2022.6.21 TestEngineer:Auditor: Temperature:24.3 °C RelativeHumidity:56.5% Pressure:1012hPa AppendixA:DTSBandwidth TestResult TestModeAntennaChannelDTSBW[MHz]FL[MHz]FH[MHz]Limit[MHz]Verdict BLE_1MAnt1 24020.6762401.6762402.352≥0.5PASS 24400.6762439.6682440.344≥0.5PASS 24800.6762479.6722480.348≥0.5PASS Page2of22 TestGraphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 Page3of22 Page4of22 AppendixB:OccupiedChannelBandwidth TestResult TestModeAntennaChannelOCB[MHz]FL[MHz]FH[MHz]Limit[MHz]Verdict BLE_1MAnt1 24021.03792401.4962402.534---PASS 24401.02822439.5002440.528---PASS 24801.03652479.4962480.533---PASS Page5of22 TestGraphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 Page6of22 Page7of22 AppendixC:Maximumconductedoutputpower TestResult TestModeAntennaChannelResult[dBm]Limit[dBm]Verdict BLE_1MAnt1 24020.48≤30PASS 24401.08≤30PASS 24800.8≤30PASS Page8of22 TestGraphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 Page9of22 Page10of22 AppendixD:Maximumpowerspectraldensity TestResult TestModeAntennaChannelResult[dBm/3kHz]Limit[dBm/3kHz]Verdict BLE_1MAnt1 2402-14.71≤8PASS 2440-14.24≤8PASS 2480-14.59≤8PASS Page11of22 TestGraphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 Page12of22 Page13of22 AppendixE:Bandedgemeasurements TestResult TestModeAntennaChNameChannelRefLevel[dBm]Result[dBm]Limit[dBm]Verdict BLE_1MAnt1 Low2402-0.15-52.43≤-20.15PASS High24800.17-48.88≤-19.83PASS Page14of22 TestGraphs BLE_1M_Ant1_Low_2402 BLE_1M_Ant1_High_2480 Page15of22 AppendixF:ConductedSpuriousEmission TestResult TestModeAntennaChannel FreqRange [MHz] RefLevel [dBm] Result[dBm]Limit[dBm]Verdict BLE_1MAnt1 2402 Reference-0.24-0.24---PASS 30~1000-0.24-51.24≤-20.24PASS 1000~26500-0.24-53.96≤-20.24PASS 2440 Reference0.230.23---PASS 30~10000.23-50.77≤-19.77PASS 1000~265000.23-52.72≤-19.77PASS 2480 Reference0.090.09---PASS 30~10000.09-50.96≤-19.91PASS 1000~265000.09-53.21≤-19.91PASS Page16of22 TestGraphs BLE_1M_Ant1_2402_0~Reference BLE_1M_Ant1_2402_30~1000 BLE_1M_Ant1_2402_1000~26500 Page17of22 BLE_1M_Ant1_2440_0~Reference BLE_1M_Ant1_2440_30~1000 Page18of22 BLE_1M_Ant1_2440_1000~26500 BLE_1M_Ant1_2480_0~Reference BLE_1M_Ant1_2480_30~1000 Page19of22 BLE_1M_Ant1_2480_1000~26500 Page20of22 AppendixG:DutyCycle TestResult TestModeAntennaChannel ONTime [ms] Period [ms] XDC[%]XFactor LimitVerdict BLE_1MAnt1 24020.390.630.619061.902.08---PASS 24400.390.630.619061.902.08---PASS 24800.390.630.619061.902.08---PASS Page21of22 TestGraphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 Page22of22 ---End---

ReportNo.:18220WC20125701FCCID:VYV-TGW206-11PPage1of33 Code:AB-RF-05-a FCCTESTREPORT ClientName:ItonTechnologyCorp. Address: 7FloorEast,BuildingC,ShenzhenInternational, InnovationCenter,No.1006ShennanRd.FutianDist, Shenzhen,China ProductName:TGW206-11P Date:Jul.14,2022 ShenzhenAnbotekComplianceLaboratoryLimited ReportNo.:18220WC20125701FCCID:VYV-TGW206-11PPage2of33 Code:AB-RF-05-a Contents 1.GeneralInformation ..............................................................................................................................................5 1.1.ClientInformation .......................................................................................................................................5 1.2.DescriptionofDevice(EUT) ....................................................................................................................5 1.3.AuxiliaryEquipmentUsedDuringTest ...................................................................................................6 1.4.DescriptionofTestModes ........................................................................................................................6 1.5.Listofchannels ..........................................................................................................................................6 1.6.DescriptionOfTestSetup .........................................................................................................................7 1.7.TestEquipmentList ...................................................................................................................................8 1.8.MeasurementUncertainty ........................................................................................................................9 1.9.DescriptionofTestFacility ........................................................................................................................9 2.SummaryofTestResults ...................................................................................................................................10 3.ConductedEmissionTest ..................................................................................................................................11 3.1.TestStandardandLimit ..........................................................................................................................11 3.2.TestSetup .................................................................................................................................................11 3.3.TestProcedure .........................................................................................................................................11 3.4.TestData ...................................................................................................................................................11 4.RadiationSpuriousEmissionandBandEdge ...............................................................................................14 4.1.TestStandardandLimit ..........................................................................................................................14 4.2.TestSetup .................................................................................................................................................14 4.3.TestProcedure .........................................................................................................................................15 4.4.TestData ...................................................................................................................................................16 5.MaximumPeakOutputPowerTest ..................................................................................................................24 5.1.TestStandardandLimit ..........................................................................................................................24 5.2.TestSetup .................................................................................................................................................24 5.3.TestProcedure .........................................................................................................................................24 5.4.TestData ...................................................................................................................................................24 6.6DBOccupyBandwidthTest .............................................................................................................................25 6.1.TestStandardandLimit ..........................................................................................................................25 6.2.TestSetup .................................................................................................................................................25 6.3.TestProcedure .........................................................................................................................................25 6.4.TestData ...................................................................................................................................................25 7.PowerSpectralDensityTest .............................................................................................................................26 7.1.TestStandardandLimit ..........................................................................................................................26 7.2.TestSetup .................................................................................................................................................26 7.3.TestProcedure .........................................................................................................................................26 7.4.TestData ...................................................................................................................................................26 8.100kHzBandwi…
