VYY-DM18LE-SDC Tubular Motor

Rated Voltage(V)Rated Torque(N.m) Functional features ᱶ Jogging&tilt functionSet electronic limitSet /delete the third limit positionLow standby power Integrated radio controlSetting up+add emitter+delete emitterMotor direction setting optionResistance stop function -10 85 Emission frequency(MHz) Rated speed(RPM) 1. Please charge the battery and make sure it is fully charged before the first use 2. Don’t operate motors wheuin low wltage alarm : ᰷ Motor stop running When the supply voltage is lower than 7 v and it will restart again when the voltage is greater than 7.5V ᰸ If the voltage is less than 10v, the motor will alarm for 10 times to prompt it needs to be charged every timewhen the motor is working. 3.  Optrating ᱶ ᰷ The valid interval of the emitter button is 10s,the emitter will quit the set after 10s ᰸ The motor will run or beep for hint,please do the next step after the hint. 4. Set limit position ᱶ ᰷ After the up limit and down limit setting,and the up limit down limit and third limit position are at the same location ᰸ After limit setting with power and memory function; ᰹ Into the match-code status 2 minutes later, it will quit out the setting limits status automatically ᰺ It will delete every memory and restore the factory settings 5. When the motor running without any operation, the maximum running time is 6 minutes,it will stop automatically6. If the emitterlost,please set up again with new emitter  The motor has a built-in battery,using the charger to recharge.You can also use solar panels to charge;when the battery is low, insert thecharge,charger light shows red light.batteries isfull when the red light turns to green. Note When the battery power is low,you can hear the alarm ten "beep" every time the motor runs. It indicates the battery needs to be charged. Then plug in the charger with red light.The light turns green when the battery is fully charged. Operating temperature Parameter Type Signal wire DM18LE/S 0.2N.m 12V 433.925MHz 80RPM 1 2 PHENOMENON REASON The motor alarms when it is working PROCESSING METHOD Charge the battery The motor is not running a Activate the motor after fully charged b Set up the match code c Contact the engineers for after-sales The voltage is low in the alarm mode a The battery is not activated. b The emitter is not matched. c If press P1 button for a long time while with no reaction.may be the power is short-ciralit or the ciralit board or the motor is broken. NUMBER 1, The third limit position setting After the up limit and down limit setting, you can set the third limit point between them as the half open position; Press 2sPress 1sPress 1sPress 1s Press 5s Press 5s Press 5s Press 1s Press 1s Press 1s Press 1s Press 1s Press 1s Press 1s Press 1s Press 5s Press 1s Press 2sPress 2s Press 2s Press 2s Press 2s Run for hint x2 Run for hint x2Run for hint x2 Run for hint x2Run for hint x2 Run for hint x2 Run for hint x1 Run for hint x1 Run for hint x1 Run for hint x1 Run for hint x1 Run for hint x1 Run for hint x1 Run for hint x2 Run for hint x1 Run for hint x1 Run for hint x1 If you need to reverse the rotateon of the motor controlled by the emitter,please run the reverse of direction setting(as lists in the second point of the P1 button setting) UpStopDown Setting 3 3 3 P2 P2 P2 P2 P2 P2 2, The third limit cancel (P2 Stop Stop) 2, Set up limit 3, Set down limit ( Up Up+Stop) 3 3 3 3 3 (Down Stop+Down) Run for hint x3 Enter the limit setting mode Notes: Repetitive operation dot-move and continuous moving function switching cycle, under the dot-move function, according to the upor down button more than 2S release motor linkage operation. 3 0 3 2OZNO[S)KRR < Channel ᮰᮱ 3 Channel ᮰᮱ 3 3 or or Dot-move Continuous moving Dot-move functionContinuous movingfunction + + + + Adjust the new up limit point Adjust the new down limit point + Confirm the new up limit pointConfirm the new down limit point + + + + or Functions that can be operated under any mode Note: After setting up the up and down limit into user mode. Note: Can not be fine-tune up/down limit position at the same time. loosen P1 Display Run for hint x1 Run for hint x1 loosen P1 Set up is ok The blind run down The blind run upThe blind run down Successful change the direction 1, Enter the limit setting mode Confirm the Blindto stop in the uplimit positionConfirm the Blindto stop in the downlimit position The uplimit point The downlimit point Set up is okSet up is ok Enter fine-tune up limit mode Enter fine-tune down limit mode Press 1sPress 2s Press 2s Press 1s Press 1s Press 1s Press 1s Press 1s Long Press P1 loosen P1 Long Press P1 loosen P1 Long Press P1 loosen P1 Run for hint x2 Run for hint x2 Run for hint x1 Run for hint x1 Run for hint x2 Run for hint x1 Run for hint x1 Run for hint x1 Dot-move Continuous moving ororor or Press 1sPress 1s Press 2s Press 1s Press 2s Press 2s Already set up, down limit position Any position The third limit position(any position) The motor stops Set up is ok Set up is ok ᰸ Long press the stop button for 2s,the roller blinds will move to the third limit Method twoMethod one Note:Emitter is the one already matched code, while emitter has not Emitter adding is ok Emitter adding is ok One emitter is deleted Note:With the same method,you only can delete the emitter not the emitter 1, Activate motor for the first time2, The reverse of direction setting3, Restore factory settings Run for hint x1Run for hint x2 Set up is okSuccessful change the directionActivate is ok Recharger or solar rechargeable board port FCC STATEMENT 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 NINGBO DOOYA MECHANIC & ELECTRONIC TECHNOLOGY CO., LTD. November 19, 2015 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, NINGBO DOOYA MECHANIC & ELECTRONIC TECHNOLOGY CO., LTD. hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): DC Tubular motor Model name: DM18LE/S-0.2/80 FCC ID: VYY-DM18LE-S Sincerely, Qiwei Zhang / Manager NINGBO DOOYA MECHANIC & ELECTRONIC TECHNOLOGY CO., LTD. Address: Loutuo industrial area, Zhenhai Ningbo, Zhejiang, China Telephone: 86-574-86571666 Fax : 86-574-86580685 E-mail: [email protected]

External photos: ---The End---

Internal photos: ---The End---

TRF NO. FCC Part 15 /A Page 1 of 23 Report No.: ES151110020E Ver.1.0 FCC TEST REPORT For NINGBO DOOYA MECHANIC & ELECTRONIC TECHNOLOGY CO., LTD. DC Tubular Motor Model No.: DM18LE/S-0.2/80 FCC ID:VYY-DM18LE-S Prepared for : Ningbo Dooya Mechanic & Electronic Technology Co., Ltd. Address : Loutuo Industrial Area, Zhenhai, Ningbo, Zhejiang,China Prepared by : SHENZHEN EMTEK CO., LTD Address : Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China Tel: 0086-755-26954280 Fax: 0086-755-26954282 Report Number : ES151110020E Date of Test : November 10, 2015 to November 19, 2015 Date of Report : November 20, 2015 TRF NO. FCC Part 15 /A Page 2 of 23 Report No.: ES151110020E Ver.1.0 TABLE OF CONTENT TEST REPORT DESCRIPTION PAGE 1. SUMMARY OF TEST RESULT ...................................................................................................... 5 2. GENERAL INFORMATION ............................................................................................................. 6 2.1. Description of Device (EUT) ..................................................................................................... 6 2.2. Description of Test Facility ........................................................................................................ 6 2.3. Support Device ........................................................................................................................... 6 2.4. Measurement Uncertainty ......................................................................................................... 6 3. MEASURING DEVICE AND TEST EQUIPMENT ....................................................................... 7 3.1. For Power Line Conducted Emission ..................................................................................... 7 3.2. For Radiated Emission Measurement .................................................................................... 7 4. POWER LINE CONDUCTED EMISSION MEASUREMENT .................................................... 8 4.1. Block Diagram of Test Setup .................................................................................................... 8 4.2. Measuring Standard ................................................................................................................... 8 4.3. Power Line Conducted Emission Limits (Class B) ............................................................... 8 4.4. EUT Configuration on Measurement ...................................................................................... 8 4.5. Operating Condition of EUT ..................................................................................................... 8 4.6. Test Procedure ........................................................................................................................... 9 4.7. Measurement Results ............................................................................................................... 9 5. RADIATED EMISSION MEASUREMENT .................................................................................. 12 5.1. Block Diagram of Test ............................................................................................................. 12 5.2. Measuring Standard ................................................................................................................. 13 5.3. Radiated Emission Limits (class B) ....................................................................................... 13 5.4. EUT Configuration on Test ...................................................................................................... 13 5.5. Operating Condition of EUT ................................................................................................... 13 5.6. Test Procedure ......................................................................................................................... 13 5.7. Measuring Results ................................................................................................................... 13 6. PHOTOGRAPH OF TEST ............................................................................................................. 17 6.1. Photo of Conducted Emission Measurement ...................................................................... 17 6.2. Photo of Radiation Emission Measurement......................................................................... 18 APPENDIX I TRF NO. FCC Part 15 /A Page 3 of 23 Report No.: ES151110020E Ver.1.0 TEST REPORT DESCRIPTION Applicant : Ningbo Dooya Mechanic & Electronic Technology Co., Ltd. Manufacturer : Loutuo Industrial Area, Zhenhai, Ningbo, Zhejiang,China Trade Mark : N/A EUT : DC Tubular Motor Model No. : DM18LE/S-0.2/80 Input Voltage : DC 12V Measurement Procedure Used: FCC Rules and Regulations Part 15 Subpart B Class B & FCC / ANSI C63.4-2014 The device described above is tested by SHENZHEN EMTEK CO., LTD. to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The measurement results are contained in this test report and SHENZHEN EMTEK CO., LTD. is assumed full of responsibility for the accuracy and completeness of these measurements. Also, this report shows that the EUT (Equipment Under Test) is technically compliant with the FCC requirements. This report applies to above tested sample only and shall not be reproduced in part without written approval ofSHENZHEN EMTEK CO., LTD. Date of Test : November 10, 2015 to November 19, 2015 Prepared by : Jack Li/Editor Reviewer : Joe Xia/Supervisor Approved & Authorized Signer : Lisa Wang/Manager TRF NO. FCC Part 15 /A Page 4 of 23 Report No.: ES151110020E Ver.1.0 Modified History Version Report No. Revision date Summary Ver.1.0 ES151110020E \ Original Report TRF NO. FCC Part 15 /A Page 5 of 23 Report No.: ES151110020E Ver.1.0 1. SUMMARY OF TEST RESULT Emission Description of test item Standard & Limi…

Text truncated - open the document above for the full version.

Radiated Conducted: ---The End---
