VYYDD7602766215-channel Emitter

P2×1 3 Lock / Unlock Combo Button Operation Note: 1,Both setting buttons (P2) can be operated. 2,The factory default is unlock status, repeat same operation to switch status circulaly. 3,When the combo buttons are locked, if you press the combo buttons, the emitter won't send any signal and LED won’t flash. DOWN×1 Sun detection is disabled 1 2 Radio frequency: 433.92MHzWorking temperature: -10 ᲇ ~+50 ᲇ Battery: 3V (AAA battery×2) Battery life: >2 years Radio range: 150 meters outdoor, 35 meters indoorDimension: 144mm×45mm×14.8mm Technical specification T ≤ 6S Front Back P2 P2 UP×1 Sun detection is enabled Motor jog up JOG UP×1 1 Jog / Tilt Mode 2 Enable / Disable Sun Detection Note: 1,Press and hold the JOG DOWN button until the LED is on, the operation is valid within 6 seconds, and press STOP button to exit the setting directly. 2,The motor needs to be paired with wind-rain-sun sensor and only when the motor has a limit, the sun detection function can be enabled and disabled. Motor jog down JOG DOWN×1 Key Symbol Note: 1,The Jog up and Jog down buttons only control the channel where the current transmitter is located,Release the button to send code. 2,This function is available in all series of transmitters. Setting button P2 CH- CH+ 4rd limit button 3rd limit button 5rd limit button UP/OPEN DOWN/CLOSE STOP DD7600 Series Handheld Emitter Instruction Version: A/03 Instruction Of Buttons JOG UPJOG DOWN DD7600H Single-channel handheld emitter DD7660H Single-channel dual control handheld emitter DD7660AH Single-channel handheld emitter DD7602H 15-channel handheld emitter DD7662H 15-channel dual control handheld emitter DD7662AH 15-channel handheld emitter 1, Emitter couldn't expose to moisture or be striked heavily, or else the emitter life will be affected.2, If the emitter is not so sensitive or the radio range becomes shorter, pls check whether to change the battery.3, It's forbidden to use different type battery to avoid any dangerous risk.4, Dispose of used batteries properly.WarningFCC Warning JOG DOWN×3S LEDalwaysonLEDalwayson Press and holdSTOP buttonmore than 15s Flashesquicklyfor 3SFlashesslowlyfor 3S Lock status, combo button is invalidUnlock status, combo button is available Following 2/3/4 only apply to emitters without LCD display This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.Note:This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:—Reorient or relocate the receiving antenna.—Increase the separation between the equipment and receiver.—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.—Consult the dealer or an experienced radio/TV technician for help.NOTE 2: Any changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. or Note: 1,Both setting buttons (P2) can be operated. 2,The factory default is unlock status, repeat same operation to switch status circulaly. 3,Under lock status, the combo buttons don't work; Under unlock status, the combo buttons will work normally. Note: This operation takes 3rd limits(also as preferred position) as an example, the operation of the 4th and 5th limit is same as the 3rd limit. P2×1 P2×1 T<10S T<10S Note: The motor needs to be paired with wind-rain-sun sensor and only when the motor has a limit, the sun detection function can be enabled and disabled. Note: 1,Only the paired motor can check the battery and the current channel can only check one paired motor. 2,Only the motors which are paired by long pressing STOP button for 2S will have the battery check function. 8 Battery Check Function STOP×1 10 Multi-limit Positions(only valid for DD7662AH) T<3S 9 Motor Percentage Running 6 Lock / Unlock Combo Button Operation 4 Multi-limit Positions (only valid for DD7660AH)7 Set Number Of Channels Note: In the setting status, press UP or DOWN button to exit quickly. Repeat the same process if you want to adjust the Max. channels. 6723×1 3 4 DOWN×1 UP×1 or LED always on Note: 1, This operation takes 3rd limits(also as preferred position) as an example, the operation of the 4th and 5th limit is same as the 3rd limit. 2, When the limit is set successfully, the motor will jog once. 3, The 4th and 5th limits can only be operated with the motor that supports 4th and 5th limits. 3rd limit button×2S 3rd limit button×1 Set the current position as the 3rd limit position The motor runs to the 3rd limit position 5 Enable / Disable Sun Detevction JOG DOWN×3S Display “ ” Display “ ” Display “ ” Sun detection is enabled Sun detection is disabled Press and hold STOP button more than 15s Press and hold STOP button more than 15s Display “ ” Combo Button is locked Combo Button unlocked Release button Release button Display “ ” Display “ ” Lock status, combo button is invalid Display “ ” Unlock status, combo button is available (CH++ CH-)×1 Press CH- and CH+ and hold on Press CH+ or CH- button to select the desired channels (from 1 to 15) The effective channels has been…

Text truncated - open the document above for the full version.

NINGBO DOOYA MECHANIC & ELECTRONIC TECHNOLOGY CO., LTD. No.168 Shengguang Road, Luotuo, Zhenhai, Ningbo, ZHEJIANG, China Date: 2024-03-06 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements Part 2.911(d) (5) (i) Filing SUBJECT: FCC Application for FCC ID:VYYDD76027662 To Whom It May Concern: NINGBO DOOYAMECHANIC & ELECTRONIC TECHNOLOGY CO., LTD. certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Signatory [xiaofang Liao, MANAGER]

NINGBO DOOYA MECHANIC & ELECTRONIC TECHNOLOGY CO., LTD. No.168 Shengguang Road, Luotuo, Zhenhai, Ningbo, ZHEJIANG, China Date: 2024-03-06 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Ref: Attestation Statements Part 2.911(d) (5) (ii) Filing SUBJECT: FCC Application for FCC ID: VYYDD76027662 To Whom It May Concern: NINGBO DOOYAMECHANIC & ELECTRONIC TECHNOLOGY CO., LTD. certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, Signatory [xiaofang Liao, MANAGER]

NINGBO DOOYA MECHANIC & ELE CTR ONIC TE CHNOLO GY CO., LTD . No.1 68 Shengguang Road, Luotuo, Zhenhai, Ningbo, ZHEJIA NG, China Date : 2024-03-06 FEDERAL COMMUNIC ATIO NS COMMIS SIO N AUTHORIZ ATIO N AND EVALUATIO N DIV IS IO N 7435 OAKLAND MIL LS ROAD COLUMBIA , MD 21046 USA Ref: Att esta tion Statements Part 2.911(d) (7) Filing Grantee Code: VYY Applic ant FRN: 0017345455 NIN GBO DOOYA MECHANIC & ELECTRONIC TECHNOLOGY CO., LTD.certi fies th at, as of th e date of th e filing of th e application,UBlo ckout, In c.is our designated U.S . agent for service of process for th e above referenced FCC ID .NIN GBO DOOYA M ECHANIC & ELECTRONIC TECHNOLOGY CO., LTD.accepts to mainta in an agent for no less th an one year afte r th e grante e has te rminate d all marketi ng and importa tion or th e conclusion of any Commission-related proceeding involving th e equipment. UBlo ckout, In c.accepts , as of th e date of th e filing of th e applicati on, th e obligati on of th e designated U.S . agent fo r service of process fo r th e above referenced FCC ID . Designate d U.S . Agent In formati on: Name:UBlo ckout, In c. U. S. Agent FRN:0033741273 Address:10580 Newkir k Street Suit e301, Dalla s, Texas 75220, Unit ed States Contact Person:Luke Boorman Tel.:(888) 441-6208 Email:lu ke@ublo ckout.c om Sincerely, Signed on behalf ofNIN GBO DOOYA MECHANIC & ELECTRONIC TECHNOLOGY CO., LTD. Signed on behalf ofUBlo ckout, In c. Name:xia ofang Lia oName:Luke Boorman Titl e:MANAGERTitl e:MANAGER

NINGBO DOOYA MECHANIC & ELECTRONIC TECHNOLOGY CO., LTD. No.168 Shengguang Road, Luotuo, Zhenhai, Ningbo, ZHEJIANG, China Date: 2024-03-06 FEDERAL COMMUNICATIONS COMMISSION AUTHORIZATION AND EVALUATION DIVISION 7435 OAKLAND MILLS ROAD COLUMBIA, MD 21046 SUBJECT: FCC Application for FCC ID: VYYDD76027662 POWER OF ATTORNEY To Whom It May Concern: We, the undersigned, hereby authorize Waltek Testing Group (Shenzhen) Co., Ltd. Jandy So on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Waltek Testing Group (Shenzhen) Co., Ltd. Jandy So on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. We, NINGBO DOOYA MECHANIC & ELECTRONIC TECHNOLOGY CO., LTD. are not subject to a denial of federal benefits pu rsuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Sincerely, Signatory [xiaofang Liao, MANAGER]

Reference No.: WTN23X12271230W Page 2 of 35 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 2 - EUT EXTERNAL PHOTOGRAPHS Model: DD7602H EUT View 1 EUT View 2 Reference No.: WTN23X12271230W Page 3 of 35 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 3 EUT View 4 Reference No.: WTN23X12271230W Page 4 of 35 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 5 EUT View 6 Reference No.: WTN23X12271230W Page 5 of 35 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 1 EUT View 2 Reference No.: WTN23X12271230W Page 6 of 35 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 3 EUT View 4 Reference No.: WTN23X12271230W Page 7 of 35 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 5 EUT View 6 Reference No.: WTN23X12271230W Page 8 of 35 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Model: DD7662AH EUT View 1 EUT View 2 Reference No.: WTN23X12271230W Page 9 of 35 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 3 EUT View 4 Reference No.: WTN23X12271230W Page 10 of 35 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 5 EUT View 6 Reference No.: WTN23X12271230W Page 11 of 35 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 1 EUT View 2 Reference No.: WTN23X12271230W Page 12 of 35 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 3 EUT View 4 Reference No.: WTN23X12271230W Page 13 of 35 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 5 EUT View 6 Reference No.: WTN23X12271230W Page 14 of 35 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Model: DD7662H EUT View 1 EUT View 2 Reference No.: WTN23X12271230W Page 15 of 35 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 3 EUT View 4 Reference No.: WTN23X12271230W Page 16 of 35 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 5 EUT View 6 Reference No.: WTN23X12271230W Page 17 of 35 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 1 EUT View 2 Reference No.: WTN23X12271230W Page 18 of 35 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 3 EUT View 4 Reference No.: WTN23X12271230W Page 19 of 35 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 5 EUT View 6

Reference No.: WTN23X12271230W Page 1 of 35 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn ANNEX EXHIBIT 1 - PRODUCT LABELING Proposed FCC ID Label Format Specifications: The label shall be securely affixed to a permanently attached part of the device, in a location where it is visible or easily accessible to the user, and shall not be readily detachable. The label shall be sufficiently durable to remain fully legible and intact on the device in all normal conditions of use throughout the device’s expected lifetime. Proposed Label Location on EUT FCC ID Label Location

Reference No.: WTN23X12271230W Page 20 of 35 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 3 - EUT INTERNAL PHOTOGRAPHS Model: DD7602H EUT Housing and Board View 1 EUT Housing and Board View 2 Reference No.: WTN23X12271230W Page 21 of 35 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 1 Solder Board-Component View 2 Reference No.: WTN23X12271230W Page 22 of 35 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT Housing and Board View 1 EUT Housing and Board View 2 Reference No.: WTN23X12271230W Page 23 of 35 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 1 Solder Board-Component View 2 Reference No.: WTN23X12271230W Page 24 of 35 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Model: DD7662AH EUT Housing and Board View 1 EUT Housing and Board View 2 Reference No.: WTN23X12271230W Page 25 of 35 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 1 Solder Board-Component View 2 Reference No.: WTN23X12271230W Page 26 of 35 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT Housing and Board View 1 EUT Housing and Board View 2 Reference No.: WTN23X12271230W Page 27 of 35 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 1 Solder Board-Component View 2 Reference No.: WTN23X12271230W Page 28 of 35 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Model: DD7662H EUT Housing and Board View 1 EUT Housing and Board View 2 Reference No.: WTN23X12271230W Page 29 of 35 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 1 Solder Board-Component View 2 Reference No.: WTN23X12271230W Page 30 of 35 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT Housing and Board View 1 EUT Housing and Board View 2 Reference No.: WTN23X12271230W Page 31 of 35 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 1 Solder Board-Component View 2 Reference No.: WTN23X12271230W Page 32 of 35 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Antenna View Antenna

1. RF Exposure Requirements 1.1 General Information Client Information Applicant: Ningbo Dooya Mechanic&Electronic Technology Co.,Ltd Address of applicant: NO.168 shengguang road Luotuo street Zhenhai district Ningbo，P.R.China Manufacturer: Ningbo Dooya Mechanic&Electronic Technology Co.,Ltd Address of manufacturer: NO.168 shengguang road Luotuo street Zhenhai district Ningbo，P.R.China General Description of EUT: Product Name: 15-channel Emitter Trade Name: / Model No.: DD7602H Adding Model(s): DD7662AH, DD7662H, DD7602Y, DD7662Y Rated Voltage: DC 3V Power Adaptor : / FCC ID: VYYDD76027662 Equipment Type: Portable device Technical Characteristics of EUT: Frequency Range: 433.92MHz Max. Field Strength: 433.92MHz: 82.30dBuV/m(3m) Data Rate: / Modulation: FSK Antenna Type: PCB Antenna Antenna Gain: 0dBi 1.2 RF Exposure Exemption According to §1.1307(b)(3) and KDB 447498 D04 Interim General RF Exposure Guidance v01, system operating under the provisions of this section shall be operating in a manner that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. Option A: FCC Rule Part 1.1307 (b)(3)(i)(A):The available maximum time-averaged power is no more than 1mW, regardless of separation distance. Option B: FCC Rule Part 1.1307 (b)(3)(i)(B): The available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold P th (mW) described in the following formula. P th is given by: Option C: FCC Rule Part 1.1307 (b)(3)(i)(C): The minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. R must be at least λ/2π, where λ is the free-space operating wavelength in meters. Single RF Sources Subject to Routine Environmental Evaluation RF Source frequency (MHz) Threshold ERP (watts) 0.3-1.34 1,920 R 2 1.34-30 3,450 R 2 /f 2 30-300 3.83 R 2 300-1,500 0.0128 R 2 f 1,500-100,000 19.2R 2 For Multiple RF sources: FCC Rule Part 1.1307(b)(3)(ii): (A) The available maximum time-averaged power of each source is no more than 1 mW and there is a separation distance of two centimeters between any portion of a radiating structure operating and the nearest portion of any other radiating structure in the same device, except if the sum of multiple sources is less than 1 mW during the time-averaging period, in which case they may be treated as a single source (separation is not required). (B) In the case of fixed RF sources operating in the same time-averaging period, or of multiple mobile or portable RF sources within a device operating in the same time averaging period, if the sum of the fractional contributions to the applicable thresholds is less than or equal to 1 as indicated in the following equation. 1.3 Calculated Result Radio Access Technology Prediction Frequency Max. Field Strength Antenna Gain Output Power Tune-Up Power ERP (MHz) (dBuV/m) (dBi) (dBm) (dBm) (dBm) SRD 433.92 82.30 0 -12.96 -12.00 -14.15 Frequency Option Min. Distance Max. Power Exposure Limit Ratio Result (MHz) (cm) (dBm) (mW) (mW) Pass/Fail 433.92 B 0.5 -12.00 0.06 23.17 0.01 Pass Note: 1. EIRP= E-104.8+20logD; Output Power=EIRP- Antenna Gain; ERP=EIRP-2.15dB 2. Option A, B and C refers as clause 1.2. 3. For option B, Max (time-averaged power, effective radiated power (ERP)) converts to Max. Power. For option C, ERP converts to Max. Power; 4. For option B, P th (mW) converts to Exposure Limit (mW); For option C, ERP (W) converts to Exposure Limit (mW). 5. Ratio= Tune-Up ERP (mW)/ Exposure Limit (mW) Mode for Simultaneous Multi-band Transmission: Radio Access Technology Ratio 1 Ratio 2 Ratio 3 Simultaneous Ratio Limit Result Pass/Fail / / / / / / / Result: Pass
