DATE：May 14, 2012 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Yaping Shen of “CENTRE TESTING INTERNATIONAL (Shenzhen) LIMITED” /Building C, Hongwei Industrial Zone, Baoan 70 District Corporation,. to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with _ CENTRE TESTING INTERNATIONAL (Shenzhen) /Building C, Hongwei Industrial Zone, Baoan 70 District _ Dated this Agency agreement expiration date: May 16, 2012 to Dec. 30, 2012 By: ChengLiang Signature Printed Title: general manager On behalf of : XQ ARTS TOYS CO.LTD. Telephone: 0754-85513333

DATE : May 14, 2012 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID:___ W2MXQJ02RX49________ Product Name:__ R/C Toys _________ Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) • Schematics • Block diagram • Operational Description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this Day of 20 Agency agreement expiration date: May 16, 2012 to Dec. 30, 2012 By: ChengLiang Signature Printed Title: general manager On behalf of : XQ ARTS TOYS CO.LTD. Telephone: 0754-85513333

EXTERNAL PHOTOGRAPHS OF EUT Front View of EUT Rear View of EUT

FCC ID : W2MXQJ02RX49 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1.This device may not cause harmful interference, and 2.This device must accept any interference received, including interference that may cause undesired operation. Label Location Label Contents Label Size: L36mm*W12mm

INTERNAL PHOTOGRAPHS OF EUT Internal View of EUT Front View of PCB Rear View of PCB

Report No. : EESZE05090005-2 Page 2 of 15 TABLE OF CONTENTS Description Page 1. GENERAL INFORMATION ..........................................................................................3 2. TEST SUMMARY .........................................................................................................3 3. MEASUREMENT UNCERTAINTY ...............................................................................3 4. PRODUCT INFORMATION AND TEST SETUP ..........................................................4 4.1. PRODUCT INFORMATION........................................................................................................................ 4 4.2. TEST SETUP CONFIGURATION.............................................................................................................. 4 5. FACILITIES AND ACCREDITATIONS .........................................................................4 5.1. TEST FACILITY............................................................................................................................................ 4 5.2. TEST EQUIPMENT LIST............................................................................................................................. 4 6. SYSTEM TEST CONFIGURATION...............................................................................5 6.1. JUSTIFICATION........................................................................................................................................... 5 6.2. EUT EXERCISING SOFTWARE................................................................................................................ 5 7. RADIATED EMISSION TEST.......................................................................................6 7.1. LIMITS............................................................................................................................................................ 6 7.2. BLOCK DIAGRAM OF TEST SETUP ..................................................................................................... 6 7.3. PROCEDURE OF RADIATED EMISSION TEST.................................................................................... 6 7.4. GRAPHS AND DATA.................................................................................................................................. 8 APPENDIX 1 PHOTOGRAPHS OF TEST SETUP............................................................12 APPENDIX 2 EXTERNAL PHOTOGRAPHS OF EUT ......................................................13 APPENDIX 3 INTERNAL PHOTOGRAPHS OF EUT .......................................................14 (Note: N/A means not applicable) Report No. : EESZE05090005-2 Page 3 of 15 1. GENERAL INFORMATION Applicant: XQ ARTS TOYS CO.LTD. North of Xing Ye Road, Lai Mei Industrial District, Cheng Hai, Shan Tou, Guang Dong, China Manufacturer: XQ ARTS TOYS CO.LTD. North of Xing Ye Road, Lai Mei Industrial District, Cheng Hai, Shan Tou, Guang Dong, China Equipment Authorization: FCC Part 15 Certification FCC ID: W2MXQJ02RX49 Product Name: R/C TOYS Trade Name: XQ Model Name: 1:18 Serial Number: Not Applicable Report Number: EESZE05090005-2 Date of Test: May 15, 2012 2. TEST SUMMARY The EUT has been tested according to the following specifications: Standard Test Item Test FCC 15.109 Radiated Emission Yes 3. MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4-2. This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using a coverage factor of k=2. Test item Value (dB) Radiated Emission 4.5 Report No. : EESZE05090005-2 Page 4 of 15 4. PRODUCT INFORMATION AND TEST SETUP 4.1. PRODUCT INFORMATION Technical Data: DC 6V Product Description: The equipment under test (EUT) is a receiver for a RC Car operating at 49.86 MHz. The EUT is powered by 6V DC (1.5V*4AA battery). The EUT has a power switch. When the power switch is “ON”, the EUT can be controlled to run forward, backward, turning left and right directions by the corresponding controller. Related Submittal(s) Grants: This is a single application for certification of a receiver. The transmitter for this receiveris authorized by Certification procedure with FCC ID: W2MXQJ02TX49. 4.2. TEST SETUP CONFIGURATION See test photographs attached in Appendix 1 for the actual connections between EUT and support equipment. Notes: 1. All the equipment/cables were placed in the worst-case configuration to maximize the emission during the test. 2. Grounding was established in accordance with the manufacturer’s requirements and conditions for the intended use. 5. FACILITIES AND ACCREDITATIONS 5.1. TEST FACILITY All test facilities used to collect the test data are located at Hongwei Industrial Zone, Bao’an 70 District, Shenzhen, Guangdong, China. The site and apparatus are constructed in conformance with the requirements of ANSI C63.4, CISPR 16-1-1 and other equivalent standards. 5.2. TEST EQUIPMENT LIST Instrumentation: The following list contains equipments used at CTI for testing. The calibrations of the measuring instruments, including any accessories that may effect such calibration, are checked frequently to assure their accuracy. Adjustments are made and correction factors applied in accordance with instructions contained in the manual for the measuring instrument. Report No. : EESZE05090005-2 Page 5 of 15 Equipment used during the tests: 3M Semi-anechoic Chamber - Radiated Emission Test Equipment Manufacturer Model Serial No. Due Date 3M Chamber & Accessory Equipment ETS-LINDGRENFACT-3 3510 07/09/2012 Spectrum Analyzer Agilent E4440A MY46185649 03/07/2013 Biconilog Antenna schwarzbeck VULB9136 401 07/06/2012 Multi device Controller ETS-LINGREN 2090 00057230 N/A Support Equipment List: 3M Semi-anechoic Chamber - Radiated Emission Test Equipment Manufacturer Model Serial No. Due Date Signal Generator IFR 2023B 202307/883 …

Text truncated - open the document above for the full version.

PHOTOGRAPHS OF TEST SETUP RADIATED EMISSION TEST SETUP
