W2MXQJ02TX27R/C Toys

DATE：May 14, 2012 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Yaping Shen of “CENTRE TESTING INTERNATIONAL (Shenzhen) LIMITED” /Building C, Hongwei Industrial Zone, Baoan 70 District Corporation,. to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with _ CENTRE TESTING INTERNATIONAL (Shenzhen) /Building C, Hongwei Industrial Zone, Baoan 70 District _ Dated this Agency agreement expiration date: May 16, 2012 to Dec. 30, 2012 By: ChengLiang Signature Printed Title: general manager On behalf of : XQ ARTS TOYS CO.LTD. Telephone: 0754-85513333

DATE : May 14, 2012 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID:___ W2MXQJ02TX27_________ Product Name:__ R/C Toys _________ Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) • Schematics • Block diagram • Operational Description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this Agency agreement expiration date: May 16, 2012 to Dec. 30, 2012 By: ChengLiang Signature Printed Title: general manager On behalf of : XQ ARTS TOYS CO.LTD. Telephone: 0754-85513333

EXTERNAL PHOTOGRAPHS OF EUT Front View of EUT Rear View of EUT

FCC ID : W2MXQJ02TX27 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1.This device may not cause harmful interference, and 2.This device must accept any interference received, including interference that may cause undesired operation. Label Location Label Contents Label Size: L36mm*W12mm

INTERNAL PHOTOGRAPHS OF EUT Internal View of EUT Front View of PCB Rear View of PCB

Report No.: EESZE05090004 Page 2 of 17 TABLE OF CONTENTS Description Page 1. GENERAL INFORMATION ...................................................................................................................... 3 2. TEST SUMMARY ..................................................................................................................................... 3 3. MEASUREMENT UNCERTAINTY ........................................................................................................... 3 4. PRODUCT INFORMATION ...................................................................................................................... 4 5. FACILITIES AND ACCREDITATIONS ..................................................................................................... 4 5.1 TEST FACILITY................................................................................................................................ 4 5.2 TEST EQUIPMENT LIST.................................................................................................................. 4 6. SYSTEM TEST CONFIGURATION.......................................................................................................... 5 6.1 JUSTIFICATION............................................................................................................................... 5 6.2 EUT EXERCISING SOFTWARE ...................................................................................................... 5 7. RADIATED EMISSIONS MEASUREMENT ............................................................................................. 6 7.1 LIMITS .............................................................................................................................................. 6 7.2 BLOCK DIAGRAM OF TEST SETUP............................................................................................... 6 7.3 TEST PROCEDURE ........................................................................................................................ 7 7.4 TEST RESULT AND GRAPHS......................................................................................................... 8 8. OUT OF BAND EMISSION MEASUREMENT ....................................................................................... 13 8.1 LIMITS ............................................................................................................................................ 13 8.2 BLOCK DIAGRAM OF TEST SETUP............................................................................................. 13 8.3 TEST PROCEDURE ......................................................................................................................13 8.4 TEST RESULT ............................................................................................................................... 13 8.5 TEST GRAPH................................................................................................................................. 13 APPENDIX 1 PHOTOGRAPHS OF TEST SETUP......................................................................................... 14 APPENDIX 2 EXTERNAL PHOTOGRAPHS OF EUT ................................................................................... 15 APPENDIX 3 INTERNAL PHOTOGRAPHS OF EUT..................................................................................... 16 N/A means not applicable. Report No.: EESZE05090004 Page 3 of 17 1. GENERAL INFORMATION Applicant: XQ arts toys CO., LTD North of Xing Ye Road, Lai Mei Industrial District, Cheng Hai, Shan Tou Guang Dong, China Manufacturer: XQ arts toys CO., LTD North of Xing Ye Road, Lai Mei Industrial District, Cheng Hai, Shan Tou Guang Dong, China Equipment Authorization: FCC Part 15 Certification FCC ID: W2MXQJ02TX27 Product Name: R/C TOYS Trade Name: XQ Model Name: 1:18 Serial Number: Not Applicable Report Number: EESZE05090004 Date of Test: May 09, 2012 to May 15, 2012 The above equipment was tested by Centre Testing International for compliance with the requirements set forth in the FCC Rules and Regulations Part 15, Subpart C and the measurement procedure according to ANSI C63.4:2009. 2. TEST SUMMARY Clause Test Item Rule Result 1 Radiated Emission FCC 15.209 PASS 2 Out of Band Emission FCC 15.227(b) PASS 3 Antenna Requirements FCC 15.203 PASS* * Telescope-type antenna with unique antenna connector. 3. MEASUREMENT UNCERTAINTY This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using a coverage factor of k=2. Measurement items Uncertainty Radiated Emissions / Out of Band Emission 4.5 dB Report No.: EESZE05090004 Page 4 of 17 4. PRODUCT INFORMATION Items Description Rating DC 9V EUT type Intentional Transmitter Modulation FSK Operated Frequency 27.145MHz 5. FACILITIES AND ACCREDITATIONS 5.1 TEST FACILITY All test facilities used to collect the test data are located at Hongwei Industrial Zone, Bao’an 70 District, Shenzhen, Guangdong, China. The site and apparatus are constructed in conformance with the requirements of ANSI C63.4, CISPR 16-1-1 and other equivalent standards. 5.2 TEST EQUIPMENT LIST Instrumentation: The following list contains equipments used at CTI for testing. The calibrations of the measuring instruments, including any accessories that may effect such calibration, are checked frequently to assure their accuracy. Adjustments are made and correction factors applied in accordance with instructions contained in the manual for the measuring instrument. Equipment used during the tests: 3M Semi-anechoic Chamber - Radiated Emission Test Equipment Manufacturer Model Serial No. Due Date 3M Chamber & Accessory Equipment ETS-LINDGRENFACT-3 3510 07/09/2012 Spectrum Analyzer Agilent E4440A MY46185649 03/07/2013 Biconilog Antenna schwarzbeck VULB9136 401 07/06/2012 Multi device Controller ETS-LINGREN 2090 00057230 N/A Loop Antenna ETS-LINDGERN6502 71730 07/06/2013 Report No.: EESZE05090004 Page 5 of 1…

Text truncated - open the document above for the full version.

PHOTOGRAPHS OF TEST SETUP TEST SETUP OF RADIATED EMISSION (9kHz-30MHz) TEST SETUP OF RADIATED EMISSION (30MHz-1GHz)
