W7DMB130Remote Controlled LED Light

1. Remove front cover of Spotlight by rotating count- er-clockwise as shown above. Pull face out from cup to reveal battery holder. Spot light features: F ully Adjustable: Light can be rotated 360° as well as up and down Light Coverage: up to 400 sq ft Durable, Weather Resistant: Tight seals and UV resistant material allow the light to work in all weather conditions Remote Control: Control from up to 70 ft away 2 . Push down on battery door tab to release. Insert 3 D-Cell batteries into Spotlight. Attach battery door by matching the tabs to the rectangular holes and then push down on front until door clicks into place. 4. Match arrows then turn clock- wise. Make sure unit is securely closed with arrow pointing at the lock symbol to ensure weather proof seal is tight. 10. Loosen larger thumb screw that connects Spotlight head to mounting base and adjust Spotlight head to proper direction as shown above. Tight- en thumb screw. 3 2333 Aurora Rd. Suite 100 Solon, OH 44139 877.298.9082 I nstallation Instructions C ustomizable Wireless Spotlight with Motion Sensor and Remote Control MB130 • 1 S mall Screwdriver • 3 D-Cell Alkaline Batteries • 1 Remote Controlled Spotlight • Mounting Base • 3 Screws & 3 Anchors • 1 Remote Control with Mounting Bracket + 2 screws • (1) 3V Coin Battery L ED Light Mounting Base Mounting Base Thumb Screw Knuckle Screw Motion & Light Sensor Dim Bright Motion Control Indicator Light Mounting Bracket Syncing your light W hat you need to install: What is included per light: w ww.mrbeams.com 5 . Determine location for mount- ing Spotlight. NOTE: For best performance, Spotlight should be positioned so motion sensor is on top and light is on bottom. 6. Remove mounting base by turning thumb screw counter- clockwise. 7. Pull mounting base off stem. 8. Drive three screws into the three holes located on mounting base. 9. Insert spotlight stem back into mounting base pointed in desired direction and tighten thumb screw in base. T ips: • U se only new alkaline D-Cell batteries with 1.5V rating. • D o not mix old and new batteries. If batteries are not new, it may cause light to malfunction. • I nstall batteries with polarity in correct position. • Antenna is only connected at one end. It acts as a receptor for the remote. * 1 year limited warranty. See enclosed card for details. * Visit our website to view installation video. Battery Caution: 1) Do not mix old and new batteries 2) Do not mix Alkaline, Standard (Carbon-Zinc) or Rechargeable (Nickel Cadmium) or (Nickel Metal Hydride) batteries 3) Do not dispose of batteries in fire 4)Batteries should be recycled or disposed of as per state and local guidelines 1 . The remote is paired to work only with the Spotlight it is packaged with. To sync additional spotlights to a single remote, press the exposed black button on the spotlight next to the battery compartment for 3 seconds while pressing the ON button on the remote. 1 . Open the Remote Control with a small coin and insert one flat 3V battery (included) as shown on the inside of the Remote Control. Smooth side of battery should be facing up. 2. Determine placement for bracket for remote and attach to wall using two screws (included) or tape. 3. Slide Remote into bracket as shown above. Patent # 8,203,445 Using the remote Set up S potlight will activate when motion is sensed from up to 30 ft away. Motion sensor only activates in darkness to conserve energy. Activate light with the remote. Hold the motion sensor button down until light blinks. When it blinks 2x the motion sensor has been disabled. When it blinks 4x, the motion sensor has been enabled. Light will remember your last brightness setting. Spotlight can be turned on or off by pressing the remote control. Activat- ing the remote will override the light sensor, and light can be activated at any time. Default mode is motion sensor on 30 second auto shut-off. First activate the light with remote control. Next, hold the ON button down until light blinks. When it blinks 1x, auto shut off is set to 1 hour. When it blinks 2x, it is set to 4 hours. First activate the light with remote control. Next, press the Bright or Dim button on the remote to adjust the brightness. Brightness Options: 60, 90, or 140 lumens. C ustomize your remote settings M otion Sensor Activation Disable Motion Remote Control Activation 2 Auto Shut-off Options 3 Brightness Modes Power supply: DC 3V Operating Frequency:433.7MHz FCC ID: W7DMB130 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 Wireless Environment LLC ______________________________________________________ 2014-04-25 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, _____ Wireless Environment LLC _____hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product Name: Remote Controlled LED Light Model name: MB130 FCC ID: W7DMB130 We affirm that between SIEMIC and ____ Wireless Environment LLC ___, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature ： Client’s name / title ： Michael Recker/ Chief Technology Officer Contact information / address: Wireless Environment LLC 57 E. Washington Street

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Wireless Environment LLC ______________________________________________________ 2014-04-25 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: W7DMB130 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature ： Client’s name / title ： Michael Recker/ Chief Technology Officer Contact information / address: Wireless Environment LLC 57 E. Washington Street

LABEL Loction Remote Controlled LED Light Model: MB130 Power supply: DC 3V Operating Frequency:433.7MHz FCC ID: W7DMB130 Made in china Bestek Electronics Co., Ltd

Report No.: EVRF1405001 Page 1 of 20 FCC TEST REPORT For Wireless Environment LLC Remote Controlled LED Light Model No. : MB130 FCC ID : W7DMB130 Operating Frequency : 433.7MHz Applicant : Wireless Environment LLC 32333 Aurora Rd. Suite 100, Solon OH 44139 USA Regulation : FCC Part 15 Subpart C Section 15.231 Test Laboratory : Shenzhen CTL Testing Technology Co., Ltd. Certificated by FCC, Registration No.: 970318 Address : Floor 1-A, Baisha Technology Park, No. 3011, Shahexi Road, Nanshan Shenzhen Guangdong China Test Date : May 10-11, 2014 Date of Report : May 11-12, 2014 Report No.: EVRF1405001 Page 2 of 20 TABLE OF CONTENT Description Page Test Report Declaration 1. GENERAL INFORMATION .................................................................................................. 4 1.1 General Information .................................................................................................................... 4 1.2 Test Facility .................................................................................................................................. 4 1.3 Test Summary ............................................................................................................................. 5 2. TEST INSTRUMENT USED ................................................................................................. 6 3. RADIATION INTERFERENCE ............................................................................................ 8 3.1. Radiated Emission Limits(FCC Part 15.209). ........................................................................ 8 3.2. Test Procedure ............................................................................................................................ 9 3.3. Test Setup .................................................................................................................................. 10 3.4. Test Results ............................................................................................................................... 11 4. 20DB BANDWIDTH ............................................................................................................. 12 4.1. The 20dB Bandwidth of Emission limit according to FCC part 15 Section 15.231(c) .... 12 4.2. Test Procedure .......................................................................................................................... 12 4.3. Test Setup .................................................................................................................................. 12 4.4. Test Result ................................................................................................................................. 13 5. TRANSMITTER TIME .......................................................................................................... 14 5.1. Transmitter Time Measurement According To FCC Part 15 Section 15.231(a) ............. 14 5.2. Test Procedure .......................................................................................................................... 14 5.3. Test Setup .................................................................................................................................. 14 5.4. Test result .................................................................................................................................. 15 6. AVERAGE FACTOR MEASUREMENT ........................................................................... 16 6.1. Average Factor Measurement According to ANSI C63.4:2009 ......................................... 16 6.2. Test Procedure .......................................................................................................................... 16 6.3. Test Setup .................................................................................................................................. 17 6.4. Test Result ................................................................................................................................. 17 7. ANTENNA REQUIREMENT ............................................................................................... 19 8. PHOTOGRAPH OF TEST .................................................................................................. 20 Report No.: EVRF1405001 Page 3 of 20 TEST REPORT DECLARATION Applicant : Wireless Environment LLC Manufacturer : Bestek Electronics Co., Ltd EUT Description : Remote Controlled LED Light (1)Mode NO.: MB130 (2)Trade Name: Mr Beams (3)Power supply: DC 3V Test Procedure Used: FCC Rules and Regulations Part 15 Subpart C Section 15.231 ANSI C63.4-2009 The device described above is test by Shenzhen CTL Testing Technology Co., Ltd. To Determine the maximum emission levels emanating from the device. The maximum emission Levels are compared to FCC part 15 Subpart C Section 15.231. The measurement results Are contained in this test report and Shenzhen CTL Testing Technology Co., Ltd. Is assumed full responsibility for the accuracy and completeness of these measurements, Also, this report shows that the Equipment Under Test (EUT) is to be technically compliant with the FCC requirements. This report applies to above tested sample only. This report shall not be reproduced in part Without written approval of Shenzhen CTL Testing Technology Co., Ltd Date of Test: April 15-20, 2014 Prepared by: Project Engineer Reviewer : Project Manager Report No.: EVRF1405001 Page 4 of 20 1. GENERAL INFORMATION 1.1 General Information EUT Description : Remote Controlled LED Light Model No. :MB130 Type of Antenna : Permanent attached Applicant : Wireless Environment LLC 32333 Aurora Rd. Suite 100, Solon OH 44139 USA Manufacturer : Bestek Electronics Co., Ltd Building 21, 3 rd Industrial Zone, Xueyuan Road, Longxi, Longgang, Shenzhen, China 1.2 Test Facility Test Firm : Shenzhen CTL Testing Technology Co., Ltd. Certificated by FCC, Registration No.: 970318 Address : Floor 1-A, Baisha Technology Park, No.…

Text truncated - open the document above for the full version.

9KHz-30MHz 30MHz-1000MHz Above 1GHz
