WIZEX5UR2.4 GHz Radio Control Transmitter

THE FINEST RADIO CONTROL MODELS R Instruction Manual *Specifications are subject to be changed without prior notice! Before beginning assembly, please read these instructions thoroughly. © Copyright 2009 KYOSHO CORPORATION / 82011-T01 Safety Precautions Content Equipments not included Glossary of Main Parts Before Operating Let's Drive! Operating Functions / Trouble Shooting / Specifications / Index 3~5 6 6 7 8~9 10~14 15~25 26 26 27 EX-5UR ASF 2.4GHz 09.07 EX-5UR ASF 2.4GHz 2 EX-5UR ASF 2.4GHz / About This Model http://www.kyosho.com/mini-z-support/ http://www.dnano.jp/ Thank you for purchasing the PERFEX EX-5UR. The PERFEX EX-5UR is a specially designed transmitter for high-performance mini R/C cars and uses the latest 2.4GHz ASF control system. Use together with an R/C car compatible with 2.4GHz ASF. User interface enables precision settings for each of the 27 control functions for precision tuning and optimal racing performance. To enjoy the full performance of this product, please read this instruction manu al thoroughly together with the R/C car's manual. The R/C car manual can also be downloaded from the Kyosho website below. Each example used shows the MINI-Z MR-02LM chassis. The position of parts may be different in other cars so please refer to your car's instruction manual to check the name and position of each part when operating. 3 EX-5UR ASF 2.4GHz 1 It is highly recommended that first-time builders seek advice of experienced modelers before beginning assembly. Assemble thi s kit only in places out of children’s reach! Take enough safety precautions prior to operating this model. You are responsible for this model’s assembly and safe operation! WARNING! PROHIBITED Please read carefully before assembling and operating your model. : This symbol indicates where caution is essential to avoid injury to yourself or others. : This symbol points out actions that you should NOT do to avoid possible damage or accidents. Ni-Cd Ni-MH The product you have purchased is powered by a rechargeable battery. The battery is recyclable. At the end of its useful life, under various national / state and local laws, it may be illegal to dispose of this battery into the municipal waste stream. Check with your local solid waste officials for details in your area for recycling options or proper disposal. Safety Precautions This model i s not a toy. It is designed for users over 14 years of age. 4 EX-5UR ASF 2.4GHz As the product includes small and sharp parts, assemble and store this product only in places out of the reach of children. Never disassemble the polarity required for installation. This may lead to damage and leakage. Do not store this model in a high-temperature or humid area nor under direct sunlight. 1 Safety Precautions This product emits electrical waves so do not operate: Inside an aircraft. Near automatic devices such as automatic doors and fire alarms. Inside hospitals or medical equipment. Operating may cause accidents. 6 EX-5UR ASF 2.4GHz *PERFEX EX-5UR Transmitter (Controller) *PERFEX EX-5UR *8-AA sized Alkaline Batteries or UM-3 sized NiMH (Nickel-Metal Hydride) Batteries 8 pieces Do not use any damaged batteries. *3 *38 Damaged 8 Do not use Oxyride or other special type batteries. 2 Content 3 Equipments not included 7 EX-5UR ASF 2.4GHz 4 Glossary of Main Parts Steering Wheel Antenna ET1 Lever (Steering Trim) ET2 Lever Throttle Trim Forward Key + / Enter Key - / Cancel Key Back Key Power Switch Throttle Trigger ET4 Lever (3CH Control) ET3 Lever (Steering Travel) Battery Box (Inside) Model Name (MENU 26) Transmitter voltage After certain period, voltage will be displayed. When battery level is low error alarm will sound. As the transmitter signal will became weak, it is required to change to new batteries immediately. LCD Screen (initial screen) 8 EX-5UR ASF 2.4GHz 5 Before Operating Loading Battery AA Alkaline Batteries 8 pieces 38 Note the direction. Battery Box Lid Transmitter (Bottom) Turn the Power Switch ON. Pairing is the process of registering the transmitter's ID with your chassis. If you change transmitters, please perform pairing. Pairing process is not required after the first time. / What is pairing? < >How to complete pairing To use this transmitter with a previously purchased chassis, it must undergo a p airing adjustment. 1 2 3 Forward key and Back key Power Switch While holding the Forward and Back keys down, switch the transmitter power ON. "PAIR" will flash on the LCD and a buzzer will sound. After 5 seconds the flashing and buzzer will stop. "PAIR" will be displayed, indicating pairing is complete. 9 EX-5UR ASF 2.4GHz 3 5 2 2 Chassis (Switch) 1 In rare cases pairing data may be deleted. This is not a malfunction. Simply complete the pairing process again. / If Pairing Failed Stop using wireless LAN or Bluetooth devices. Someone else close by is pairing at the same time.Complete pairing at another time. Another 2.4GHz device is being used close by. Appliances such as a microwave oven are emitting strong electrical waves are being used close by. Stop using the electrical appliance. Another radio control model using 2.4GHz is being used close by. Perform pairing in another location. Refer to your car manual and complete the paring procedure for the car. Switch transmitter power OFF. Setting takes effect the next time power is turned on. Check the LED indicator on the car. Light On: Normal pairing setup is complete. Continue to step 2. Light Flash: Pairing failed. Switch transmitter and car power off and process again. 10 EX-5UR ASF 2.4GHz Always turn the transmitter's power switch ON first! Chassis (Switch) < >For Normal Operation Keep hands away from tires! Wheels may spin freely when power is turned on. 6 Let's Drive! 1 Transmitter (Switch) 2 Check that the model name is shown on the LCD screen. When switched on, the transmitter finds open frequencies. Up to forty 2.4GHz Mini-Z Series models can be run but may be lower if other 2.4GHz devices are being used. I…

Text truncated - open the document above for the full version.

Zur optimalen Anzeige dieses PDF-Portfolios sollte es in Acrobat oder Adobe Reader ab Version 9 geöffnet werden. Adobe Reader jetzt herunterladen

Zur optimalen Anzeige dieses PDF-Portfolios sollte es in Acrobat oder Adobe Reader ab Version 9 geöffnet werden. Adobe Reader jetzt herunterladen

Zur optimalen Anzeige dieses PDF-Portfolios sollte es in Acrobat oder Adobe Reader ab Version 9 geöffnet werden. Adobe Reader jetzt herunterladen

This document was signed electronically. The Center for Quality Engineering of SGS Germany GmbH is accredited by DATech for COMPONENTS TESTING ENVIRONMENTAL ENGINEERING ELECTROMAGNETIC COMPATIBILITY PRODUCT SAFETY TELECOM CONFORMANCE TESTS SGS Germany GmbH, SGS CQE, Hofmannstr. 50, D-81379 München, Phone +49 89-787475-130, Fax +49 89-787475-122, Internet www.sgs-cqe.de The test report shall not be reproduced except in full without the written approval of the testing laboratory DAT-PL-002/91-03 Center for Quality Engineering Test Report No.: D0Q80002 FCC ID: WIZEX5UR Order No.: D0Q8 Pages: 44 Munich, Jul 26, 2010 Client: Kyosho Deutschland GmbH Equipment Under Test: Kyosho Perfex EX5-UR ASF Manufacturer: Kyosho Deutschland GmbH Task: Conformance test according to the test specifications mentioned below Test Specification(s): [covered by accreditation] FCC 47 CFR Part 15 Result: The EUT complies with the requirements of the specification. The results relate only to the items tested as described in this test report. approved by: Date Signature Neuhäusler Lab Manager Wireless & Software Jul 26, 2010 Bauer Lab Manager EMC Jul 26, 2010 Test Report No.: D0Q80002 Date: Jul 26, 2010 Kyosho Perfex EX5-UR ASF page 2 / 44 The test report shall not be reproduced except in full without the written approval of the testing laboratory CONTENTS 1 Summary ..................................................................................................................................5 2 References ...............................................................................................................................6 2.1 Specifications ......................................................................................................................6 2.2 Glossary of Terms...............................................................................................................6 3 General Information ................................................................................................................7 3.1 Identification of Client..........................................................................................................7 3.2 Test Laboratory ...................................................................................................................7 3.3 Time Schedule ....................................................................................................................7 3.4 Participants .........................................................................................................................7 4 Equipment Under Test ............................................................................................................8 4.1 Description of EUT ..............................................................................................................8 4.2 Configuration of EUT...........................................................................................................8 4.3 Operating Conditions ..........................................................................................................9 4.4 Compliance Criteria.............................................................................................................9 5 General Description of Tests................................................................................................10 5.1 Tested Carrier Frequencies ..............................................................................................10 5.2 Calibration of the Test Equipment.....................................................................................10 6 Test Results ...........................................................................................................................11 6.1 Test No. 1: Conducted Emissions (§ 15.207) ...................................................................11 6.2 Test No. 2: Field strength correction for pulse operation (Duty Cycle) (§ 15.35(c)) ..........11 6.2.1 Purpose ......................................................................................................................11 6.2.2 Limits ..........................................................................................................................11 6.2.3 EUT Operating Condition ...........................................................................................11 6.2.4 Test Configuration ......................................................................................................11 6.2.5 Test Procedure and Results .......................................................................................12 6.2.6 Test Protocol ..............................................................................................................12 6.3 Test No. 3: Carrier frequency separation (§ 15.247(a1)) ..................................................13 6.4 Number of hopping channels (§ 15.247(a1)) ....................................................................13 6.5 Time of occupancy (§ 15.247(a1)) ....................................................................................13 6.6 Test No. 6: 6dB Bandwidth (§ 15.247(a2))........................................................................14 6.6.1 Purpose ......................................................................................................................14 6.6.2 Limits ..........................................................................................................................14 6.6.3 EUT Operating Condition ...........................................................................................14 6.6.4 Test Configuration ......................................................................................................14 6.6.5 Test Procedure and Results .......................................................................................15 Test Report No.: D0Q80002 Date: Jul 26, 2010 Kyosho Perfex EX5-UR ASF page 3 / 44 The test rep…

Text truncated - open the document above for the full version.

The Center for Quality Engineering of SGS Germany GmbH is accredited by DATech for COMPONENTS TESTING ENVIRONMENTAL ENGINEERING ELECTROMAGNETIC COMPATIBILITY PRODUCT SAFETY TELECOM CONFORMANCE TESTS SGS Germany GmbH, SGS CQE, Hofmannstr. 50, D-81379 München, Phone +49 89-787475-130, Fax +49 89-787475-122, Internet www.sgs-cqe.de Test Setup Photos (D0Q80002) - Field strength correction for pulse operation (Duty Cycle) (§ 15.35(c)) and - 6dB Bandwidth (§ 15.247(a2)) and - Maximum peak conducted output power (§ 15.247(b)) and - Conducted Emissions (§ 15.247(d)) and - Power spectral density (§ 15.247(e)): 2/3 - Radiated Emissions (9kHz – 30MHz) (§ 15.247(d)): - Radiated Emissions (30MHz – 1GHz) (§ 15.247(d)): 3/3 - Radiated Emissions (1GHz – 24.84GHz) (§ 15.247(d)):
