WODGKRC161170-5Radio Equipment for GSM 1900 Base Station

Ericsson Internal EXHIBIT 13 1 (2) Prepared (also subject responsible if other) No. EZELTAO WODGKRC161170-5 Uen Approved Checked Date Rev Reference CBC/XRV/E EZELTAO 2011-11-21 A Federal Communications Commission Authorization & Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Attention: Equipment Authorization Branch October 12, 2011 British Approvals Board for Telecommunications Balfour House Churchfield Road Walton-on-Thames, Surrey, KT12 2TD United Kingdom Subject: Certification for FCC ID: WODGKRC161170-5 To Whom It May Concern: Ericsson (China) Communications Company Ltd. requests a Grant of Certification (Type Acceptance) for the above mentioned FCC Identifier. This Radio Equipment (RE) is designed for use in the GSM 1900 MHz cellular telephone system. The transmitter will operate from 1930.2 to 1989.8 MHz. The receiver circuit supports 1850.2 to 1909.8 MHz. The RE operates in the 1900 MHz broadband PCS services as per 47 CFR Part 24 subpart E. It meets the requirements of GSM1900 11.10-1 version 4.19.1 specification for operation in GSM cellular systems. This RE will in normal mode operate at a nominal power out of 43 dBm for GMSK and 39.7 dBm for 8-PSK, 38.3 dBm for 16QAM, 37.9 dBm for 32QAM and 39.6 dBm for AQPSK at the antenna connector. Ericsson (China) Communications Company Ltd. requests confidentiality under Sections 0.457 and 0.459 of the Commission’s Rules. Confidentiality for the following exhibits is requested: EXHIBIT 4 Block Diagrams EXHIBIT 5 Schematics Diagrams EXHIBIT 8 Manuals EXHIBIT 9 Internal Photos EXHIBIT 10 Components and Tune Up EXHIBIT 12 Technical Circuit Description The RE is always installed and placed in an area with access only to authorize personal. Sensitive information, such as internal photos and manuals is not available for general public in any form. Only customer with a Non-Disclosure Agreement (NDA) in place will get access to sensitive information. So the only way a competitor could get technical information on the RE is from FCC records. Justification of this request is in order to protect the large investment in developing this technology Ericsson Internal EXHIBIT 13 2 (2) Prepared (also subject responsible if other) No. EZELTAO WODGKRC161170-5 Uen Approved Checked Date Rev Reference CBC/XRV/E EZELTAO 2011-11-21 A and to facilitate the circuit miniaturization utilized in this design and protect the innovative design as well as proprietary techniques which are implemented. In order to protect Ericsson’s competitive advantage on these proprietary techniques, we request the above listed exhibits be held as confidential and withheld from the Public Information File. We further certify that the applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to section 5301 of the Anti-Drug abuse Act of 1988, 21 U.S.C. Section 862. If additional information is needed, please contact me on the below listed number. Regards, Jeffrey Zhou Unit Manager, ENV&PA, RBSI&V Ericsson (China) Communications Company Ltd. Ericsson Tower No.5 Lize East Street, Chaoyang District Beijing 100102, P.R.China Telephone: +86 10 8476 7395 E-mail: [email protected]

Ericsson Internal EXHIBIT 13 1 (1) Prepared (also subject responsible if other) No. EZELTAO Approved Checked Date Rev Reference CBC/XRV/E Lynn Tao 2011-11-30 A Federal Communications Commission Authorization & Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Attention: Equipment Authorization Branch British Approvals Board for Telecommunications Balfour House Churchfield Road Walton-on-Thames, Surrey, KT12 2TD United Kingdom Exhibit 13 NDA Confidentiality Clause Confidentiality . Each party agrees that all confidential documents, work product and information (including all computer code, internal photographs of products, block diagrams, schematic diagrams, technical and/or user manuals, related materials, and the existence of this Agreement) received or otherwise obtained from the other party pursuant to this Agreement, whether before or after the Effective Date, will be, and will be deemed to have been, received in confidence and will be used only for the purpose of carrying out the obligations of, or as otherwise contemplated by, this Agreement. In addition, each party agrees that public access to all confidential equipment supplied will be restricted either by installation of the equipment in a restricted area or by physically securing the equipment by other means, including, but not limited to, using a key-lock that can only be opened by authorized personnel. Without the other party’s prior written consent, neither party may disclose any such information to any third party or grant access to the confidential equipment to any unauthorized person, and each party will disclose such information only to such of its officers, employees and agents that have a need to know such information for the purposes contemplated hereby. However, the provisions of this Section will not apply to any such information that (i) is or becomes generally available to the public without the fault or negligence of either party, (ii) is already in the possession of the receiving party without being subject to another confidentiality obligation, (iii) is or becomes available to the receiving party on a non-confidential basis from a source other than the disclosing party; provided that such source is not bound by a confidentiality obligation of the disclosing party, (iv) is required to be disclosed pursuant to an arbitration proceeding conducted in accordance with this Agreement, or (v) is required to be disclosed pursuant to a requirement of any governmental authority or any statute, rule or regulation; provided that the party required to disclose such information of the other party provide to the other party notice of such requirement of any such disclosure and cooperates with the other party to prevent or restrict any such disclosure to the extent allowed by applicable law.

Authorization Letter Date: 2011-10-12 BABT Balfour House Churchfield Road Walton-on-Thames Surrey KT12 2TD Dear Sir or Madam: We, the undersigned, hereby authorize Ms Zhang Xiaoying from TUV Product Service Limited, Beijing Branch, Unit 918, Landmark Tower 2, 8 North Dongsanhuan Road,100004 Beijing , act on our behalf, as our agent, in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. I further certify that the applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. Section 862. This authorization shall expire 3 months from original date. If you have any question regarding the authorization, please don’t hesitate to contact with me. Sincerely Name: Jeffrey Zhou Title: Unit manager, ENV&PA, RBS I&V Company: Ericsson (China) Communications Company Ltd.

KRC 161 170/5 R1E Date 2011-10-25 Page 1 of 2 External photos Front view Back view Left side Right side Top view Bottom view KRC 161 170/5 R1E Date 2011-10-25 Page 2 of 2 External photos Front view without solar shield

KRC 161 170/5 R1E Date 2011-10-25 Page 1 of 2 FCC ID FCC ID label and placement KRC 161 170/5 R1E Date 2011-10-25 Page 2 of 2

Document 75913999 Report 01 Issue 2 November 2011 Report On FCC and Industry Canada Testing of the Ericsson RRUN19-22 / KRC 161 170/5 COMMERCIAL-IN-CONFIDENCE FCC ID: WODGKRC161170-5 IC ID: 287AH-GG1611705 TÜV SÜD Product Service Ltd, Octagon House, Concorde Way, Segensworth North, Fareham, Hampshire, United Kingdom, PO15 5RL Tel: +44 (0) 1489 558100. Website: www.tuvps.co.uk COMMERCIAL-IN-CONFIDENCE Document 75913999 Report 01 Issue 2 Page 1 of 68 COMMERCIAL-IN-CONFIDENCE REPORT ON FCC and Industry Canada Testing of the Ericsson RRUN19-22 / KRC 161 170/5 Document 75913999 Report 01 Issue 2 November 2011 PREPARED FOR Ericsson (China) Communications Company Ltd. Ericsson Tower No.5 Lize East Street Chaoyang District Beijing China PREPARED BY X Zhang Test Engineer APPROVED BY S Bennett Authorised Signatory DATED 4 November 2011 This report has been up-issued to Issue 2 due to correct some typing errors. ENGINEERING STATEMENT The measurements shown in this report were made in accordance with the procedures described on test pages. All reported testing was carried out on a sample equipment to demonstrate compliance with FCC CFR 47: Part 24 and Industry Canada RSS-133. The sample tested was found to comply with the requirements defined in the applied rules. Test Engineer(s); X Zhang C Zhang COMMERCIAL-IN-CONFIDENCE Document 75913999 Report 01 Issue 2 Page 2 of 68 COMMERCIAL-IN-CONFIDENCE CONTENTS Section Page No 1 REPORT SUMMARY ................................................................................................................... 3 1.1 Introduction ................................................................................................................................... 4 1.2 Brief Summary of Results ............................................................................................................. 5 1.3 Declaration of Build Status ........................................................................................................... 7 1.4 Product Information ...................................................................................................................... 8 1.5 Test Conditions ........................................................................................................................... 13 1.6 Deviations From the Standard .................................................................................................... 13 1.7 Modification Record .................................................................................................................... 13 1.8 Alternative Test Site .................................................................................................................... 13 2 TEST DETAILS .......................................................................................................................... 14 2.1 Maximum Peak Output Power - Conducted ............................................................................... 15 2.2 Peak – Average Ratio ................................................................................................................. 18 2.3 Modulation Characteristics ......................................................................................................... 27 2.4 Occupied Bandwidth ................................................................................................................... 31 2.5 Spurious Emissions at Antenna Terminals (±1MHz) .................................................................. 35 2.6 Radiated Spurious Emissions ..................................................................................................... 41 2.7 Conducted Spurious Emissions .................................................................................................. 46 2.8 Frequency Stability Under Temperature Variations ................................................................... 54 2.9 Frequency Stability Under Voltage Variations ............................................................................ 56 2.10 Receiver Spurious Emissions ..................................................................................................... 58 3 TEST EQUIPMENT USED ......................................................................................................... 63 3.1 Test Equipment Used ................................................................................................................. 64 3.2 Measurement Uncertainty .......................................................................................................... 66 4 ACCREDITATION, DISCLAIMERS AND COPYRIGHT ............................................................ 67 4.1 Accreditation, Disclaimers and Copyright ................................................................................... 68 COMMERCIAL-IN-CONFIDENCE Document 75913999 Report 01 Issue 2 Page 3 of 68 COMMERCIAL-IN-CONFIDENCE SECTION 1 REPORT SUMMARY FCC and Industry Canada Testing of the Ericsson RRUN19-22 / KRC 161 170/5 COMMERCIAL-IN-CONFIDENCE Document 75913999 Report 01 Issue 2 Page 4 of 68 COMMERCIAL-IN-CONFIDENCE 1.1 INTRODUCTION The information contained in this report is intended to show verification of the Ericsson RRUN19-22 / KRC 161 170/5 to the requirements of FCC CFR 47 Part 24 and Industry Canada RSS-133. Testing was carried out in support of an application for Grant of Equipment Authorization in the name of RRUN19-22 / KRC 161 170/5. Objective To perform FCC and Industry Canada Testing to determine the Equipment Under Test's (EUT’s) compliance with the Test Specification, for the series of tests carried out. Manufacturer Ericsson (China) Communications Company Ltd. Product Name RRUN19-22 Part Number KRC 161 170/5 IC Model Number GG1611705 Serial Number(s) TD3G925968 Software Version CXP1040007_05R31D Hardware Version R1E Number of Samples Tested 1 Test Specification/Issue/Date FCC CFR 47 Part 24: 2010 Industry Canada RSS-133 issue 5: 2009 Incoming …
