WQRSHN-WDS700DIGITAL DOORLOCK

Samsung SDS Co., Ltd.

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Mar 12, 2013
Application Purpose: Original Equipment
Date of Application: Mar 12, 2013
Equipment Note: DIGITAL DOORLOCK
Frequency Range: 2405.00000000 - 2480.00000000
Company: Samsung SDS Co., Ltd.
Country: South Korea

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Please review all included documentation and use the product as intended. Safety precautions must be followed to avoid personal injury or property damage. Samsung Smart Door Lock User Guide SHN-WDS700 Smart Door Lock SHN-WDS700 Introduction & Helpful Tips �� 2 Installation �� 3 Components & Tools �� 3 Door Preparation �� 4-5 Preparing the parts �� 6 Installing Lock �� 7 Setting of Right-Handed / Left Handed �� 10 Programming �� 11 Basic Lock Operation Overview �� 11 Programming Features & Definitions �� 12-15 Programming User PIN Codes & User Cards �� 16-17 Security Functions �� 18 Miscellaneous �� 19 Miscellaneous Information �� 19 Troubleshooting �� 20-21 User Registration Table �� 22 Product Specifications �� 23 Warranty �� 24-25 Drilling Template �� 27-30 Tailpiece Setting �� 31 | Table of Contents Congratulations on the purchase of your Samsung Smart Door Lock! Your lock has a touch sensitive number display pad and optionally a 13.56MHz Card reader. Up to 70 users can be registered to gain access with unique Codes or Access Cards (supports ISO14443A type). The touchscreen makes it convenient to enter the code and the Randomizer function helps prevent lockpicking using fingerprint traces on the touchscreen. Other convenient functions such as Automatic Locking / Sound Setting / Out-of-Home Security, etc. provide advanced security and peace of mind. You can unlock the door using video intercom’s monitor after connecting a Samsung video intercom. (Refer to page 9 for connection diagram to a video intercom). | Helpful Tips | Introduction Do not attempt to repair the product yourself. Change your codes regularly to ensure the security of your codes. Minimize the lock’s exposure to moisture including wet hands and direct contact with liquids. Do not exert excessive force or use sharp instrument on the touchscreen. Insert the batteries according to correct polarity. When the low-battery warning sounds, replace a…

Text truncated - open the document above for the full version.

External Photos

CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com EUT External Photographs CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com

ID Label/Location Info

CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Label Photographs

Internal Photos

1.MainPBALayout 1.1TOP 1.2Bottom 2.KEYPBALayout 2.1TOP 2.2Bottom 3.ANTPBALayout 4.ZDT100Layout

Internal Photos

CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com EUT Internal Photographs CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com RFID Antenna Zigbee Antenna

RF Exposure Info

CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Page 1 of 2 RF EXPOSURE EVALUATION Applicant : SAMSUNG SNS CO., LTD. Applicant Address : 207, Gangdong-daero, Gangdong-gu, Seoul, Korea Kind of Product : Digital Doorlock Equipment model name : SHN-WDS700 Antenna type : Chip antenna Gain : 1.79 dBi Frequency Range : 2405 – 2480 MHz Number of channels : 16 CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Page 2 of 2 ** MPE Calculations ** The EUT will only be used with a separation of 20 centimeters or greater between the antenna and the body of the user. The MPE calculation for this exposure is shown below. The peak radiated output power (EIRP) is calculated as follows: EIRP = P + G EIRP = 9.34 + 1.79 = 11.13 dBm Where, P = Power input to the antenna (mW) G = Power gain of the antenna (dBi) The numeric gain(G) of the antenna with a gain specified in dB is determined by: G = Log -1 (dB antenna gain / 10) G = Log -1 (1.79 / 10) G = 2.57 Power density at the specific separation: S = PG/(4R 2 π) S = (8.59 * 1.51)/(4 * 20 2 * π) S =0.0026 mW/cm 2 Where, S = Maximum power density (mW/cm 2 ) P = Power input to the antenna (mW) G = Numeric power gain of the antenna R = Distance to the center of the radiation of the antenna (20cm = limit for MPE) The Maximum permissible exposure (MPE) for the general population is 1 mW/cm 2 . The power density at 20cm does not exceed the 1 mW/cm 2 limit. Estimated safe separation: R = √(PG / 4π) R = √(8.59 * 1.51 / 4π) R = 2.03 cm Where, P = Power input to the antenna (mW) G = Numeric power gain of the antenna R = Distance to the center of the radiation of the antenna (20cm = limit for MPE)

Test Report

CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: CTK-2013-00278 Date: 2013-02-26 Page 1 of 30 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 Subpart C(Rev.2) TEST REPORT For FCC Test Report No. : CTK-2013-00278 Date of Issue : 2013-02-26 FCC ID : WQRSHN-WDS700 Model/Type No. : SHN-WDS700 Kind of Product : Digital Doorlock Applicant : SAMSUNG SNS CO., LTD. Applicant Address : 207, Gangdong-daero, Gangdong-gu, Seoul, Korea Manufacturer : VEGATECH Co., Ltd. Manufacturer Address : 146-7 Sangdaewondong, Jungwongu, Sungnamsi, Kyungki-Do Korea Contact Person : Jinhee Kim / Senior Engineer Telephone : +82-2-2225-6883 Received Date : 2013-02-08 Test period : Start : 2013-02-12 End : 2013-02-26 The test results presented in this report relate only to the object tested. Tested by Reviewed by Won-Jae, Hwang Test Engineer Young-Joon, Park Technical Manager Date: 2013-02-26 Date: 2013-02-26 CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: CTK-2013-00278 Date: 2013-02-26 Page 2 of 30 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 Subpart C(Rev.2) REPORT REVISION HISTORY Date Revision Page No 2013-02-26 Issued (CTK-2013-00278) All This report shall not be reproduced except in full, without the written approval of CTK Co., Ltd. This document may be altered or revised by CTK Co., Ltd. personnel only, and shall be noted in the revision section of the document. Any alteration of this document not carried out by CTK Co., Ltd. will constitute fraud and shall nullify the document. CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: CTK-2013-00278 Date: 2013-02-26 Page 3 of 30 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 Subpart C(Rev.2) TABLE OF CONTENTS REPORT REVISION HISTORY...........................................................................................2 1.0 General Product Description................................................................................4 1.1 Tested Frequency...............................................................................................4 1.2 Device Modifications...........................................................................................5 1.3 Peripheral Devices.............................................................................................5 1.4 Calibration Details of Equipment Used for Measurement.........................................5 1.5 Test Facility.......................................................................................................5 1.6 Laboratory Accreditations and Listings..................................................................6 2 Summary of tests....................................................................................................7 2.1 Technical Characteristic Test......................................................................................8 2.1.1 6dB Bandwidth............................................................................................8 2.1.2 Maximum peak Conducted Output Power......................................................11 2.1.3 Power Spectral Density...............................................................................14 2.1.4 Band - edge..............................................................................................17 2.1.5 Field Strength of Emissions.........................................................................24 2.1.6 AC Conducted Emissions.............................................................................27 APPENDIX A – Test Equipment Used For Tests.................................................................30 CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: CTK-2013-00278 Date: 2013-02-26 Page 4 of 30 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 Subpart C(Rev.2) 1.0 General Product Description Equipment model name SHN-WDS700 Serial number Prototype EUT condition Pre-production, not damaged Frequency Range 2405 MHz - 2480 MHz RF output power 9.34 dBm Number of channels 16 Transfer Rate 250 Kbps Type of Modulation DSSS Channel Spacing 5 MHz Duty cycle TX power 1.0 Power Source 6 Vdc (4 AA Alkaline 1.5 V Batteries (LR6)) Antenna Type Chip antenna Gain : 1.79 dBi 1.1 Tested Frequency LOW MID HIGH Frequency (MHz) 2405 2445 2480 CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: CTK-2013-00278 Date: 2013-02-26 Page 5 of 30 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 Subpart C(Rev.2) 1.2 Device Modifications The following modifications were necessary for compliance: Not applicable 1.3 Peripheral Devices Device Manufacturer Model No. Serial No. Note Computer DELL INC. Inspiron 6400 - Switching Adapter2 DDongguang Lite Power 2nd Plant LA65NS0-00 - 1.4 Calibration Details of Equipment Used for Measurement Test equipment and test accessories are calibrated on regular basis. The maximum time between calibrations is one year or what is recommended by the manufacturer, whichever is less. All test equipment calibrations are traceable to the Korea Research Institute of Standards and Science (KRISS), therefore, all test data recorded in this report is traceable to KRISS. 1.5 Test Facility The measurement facility is located at 386-1, Ho-dong, Cheoin-gu, Yongin-si,…

Text truncated - open the document above for the full version.

Test Setup Photos

CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Test Setup Photos and Configuration Radiated Electric Field Emissions (9 kHz ~ 30 MHz) (30 MHz ~ 1000 MHz) CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com (above 1 GHz) Frequency Stability

Contact Information

Applicant

Kim jin hee

[email protected]82-2-2225-6883Fax: 82-2-2225-6999

Test Firm

CTK Co., Ltd.Young-Joon Park

[email protected]82-31-339-9871Fax: 82-31-624-9501

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.40 GHz - 2.48 GHz	9.00 mW

Confidentiality

Long Term

Grant Notes

Power listed is conducted.
