WQRSHS-3320Low Power Communication Device Transmitter

Samsung SDS Co., Ltd.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Oct 18, 2011
Application Purpose: Original Equipment
Date of Application: Oct 17, 2011
Equipment Note: Low Power Communication Device Transmitter
Frequency Range: 13.56000000 - 13.56000000
Company: Samsung SDS Co., Ltd.
Country: South Korea

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Please review all included documentation and use the product as intended. Safety precautions must be followed to avoid personal injury or property damage. Samsung Touchscreen Door Lock SHS - 3320 User Guide Touchscreen Door Lock Introduction & Helpful Tips �� 2 Installation �� 3 Components & Tools �� 3 Door Preparation �� 4-5 Installing Lock �� 6-7 Programming �� 8 Basic Lock Operation Overview �� 8 Programming Features & Definitions �� 9-12 Programming User PIN Codes & User Cards �� 13-14 Security Functions �� 15 Miscellaneous �� 16 Miscellaneous Information �� 16 Troubleshooting �� 17-18 User Registration Table �� 19 Product Specifications �� 20 Warranty �� 21-22 Drilling Template �� 23-25 | Table of Contents Congratulations on the purchase of your Samsung Touchscreen Door Lock! Your lock has a touch sensitive number display pad and optionally a 13.56MHz Card reader. Up to 70 users can be registered to gain access with unique Codes or Access Cards (supports ISO14443A type). The touchscreen makes it convenient to enter the code and the Randomizer function helps prevent lockpicking using fingerprint traces on the touchscreen. Other convenient functions such as Automatic Locking / Sound Setting / Out-of-Home Security, etc. provide advanced security and peace of mind. You can unlock the door using video intercom’s monitor after connecting a Samsung video intercom. (Refer to page 6 for connection diagram to a video intercom). | Helpful Tips | Introduction Do not attempt to repair the product yourself. Change your codes regularly to ensure the security of your codes. Minimize the lock’s exposure to moisture including wet hands and direct contact with liquids. Do not exert excessive force or use sharp instrument on the touchscreen. Insert the batteries according to correct polarity. When the low-battery warning sounds, replace all batteries immediately. Do not mix old batteries with new batteries. Use soft, dry cloth to clean the lock and avoid cleaning with water, alcohol or other chemicals. Components & Tools Touchscreen Door Lock | Components & Tools Door Preparation ● 2-1/8 ̋(54mm) hole saw ● 1 ̋(25mm) hole saw ● 1-3/8”(35mm) hole saw ● 3/8 ̋(10mm) drill bit ● 1/8 ̋(2.5mm) drill bit ● Chisel and hammer Lock Installation ● #2 Phillips screwdriver ● Drill Components Parts Drawings Tools Adjustable Deadbolt Interior Unit Exterior Unit Interior Mounting Plate Strike Magnetic Sensor ● Exterior Unit ● Interior Unit ● Interior Mounting Plate ● Strike ● 4 AA Alkaline Batteries ● 4 User Cards or …

Text truncated - open the document above for the full version.

External Photos

CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com EUT External Photographs CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com

ID Label/Location Info

CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Label Photographs

Internal Photos

CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com EUT Internal Photographs CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com

Test Report

CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: 2011100031 Date: October 13, 2011 Page 1 of 19 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15(Rev.3.3) TEST REPORT For FCC Test Report No. : 2011100031 Date of Issue : October 13, 2011 FCC ID : WQRSHS-3320 Model/Type No. : SHS-3320 Kind of Product : Digital Doorlock Applicant : SEOUL COMMTECH Co., Ltd. Applicant Address : 448-11, Seongnae 3dong,Gangdong-gu, Seoul,Korea 134-033 Manufacturer : VEGATECH Co., Ltd. Manufacturer Address : 146-7 Sangdaewondong, Jungwongu, Sungnamsi, Kyungki-Do Korea Contact Person : Jinhee Kim / Senior Engineer Telephone : +82-2-2225-6883 Received Date : September 26, 2011 Test period : Start : September 26, 2011 End : October 13, 2011 Test Results : In Compliance Not in Compliance The test results presented in this report relate only to the object tested. Tested by Reviewed by Won-Jae, Hwang Test Engineer Young-Joon, Park Technical Manager Date: October 13, 2011 Date: October 13, 2011 CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: 2011100031 Date: October 13, 2011 Page 2 of 19 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15(Rev.3.3) REPORT REVISION HISTORY Date Revision Revision October 13, 2011 Issued (2011100031) This report shall not be reproduced except in full, without the written approval of CTK Co., Ltd. This document may be altered or revised by CTK Co., Ltd. personnel only, and shall be noted in the revision section of the document. Any alteration of this document not carried out by CTK Co., Ltd. will constitute fraud and shall nullify the document. CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: 2011100031 Date: October 13, 2011 Page 3 of 19 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15(Rev.3.3) TABLE OF CONTENTS REPORT REVISION HISTORY...........................................................................................2 1.0 General Product Description................................................................................4 1.1 Model Differences..............................................................................................4 1.2 Device Modifications...........................................................................................4 1.3 EUT Configuration(s)..........................................................................................5 1.4 Test Software....................................................................................................5 1.5 EUT Operating Mode(s)......................................................................................5 1.6 Configuration....................................................................................................6 1.7 Calibration Details of Equipment Used for Measurement.........................................7 1.8 Test Facility.......................................................................................................7 1.9 Measurement Procedure.....................................................................................7 1.10 Laboratory Accreditations and Listings..................................................................8 2.0 Emissions Test Regulations.................................................................................9 2.1 Radiated Electric Field Emissions - 15.225(a)......................................................10 2.2 Radiated Electric Field Emissions - 15.225(b)(c)..................................................12 2.3 Radiated Electric Field Emissions - 15.225(d)......................................................13 2.4 Frequency Stability – 15.225(e)........................................................................15 2.5 Conducted Voltage Emissions – 15.207...............................................................17 APPENDIX A – TEST DATA.............................................................................................18 Radiated Electric Field Emissions (Quasi-Peak reading)...............................................18 Bandwidth of the Operating Frequency.....................................................................19 CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: 2011100031 Date: October 13, 2011 Page 4 of 19 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15(Rev.3.3) 1.0 General Product Description 1.0.1 Tested Equipment Unless otherwise indicated, all tests were conducted on Model SHS-3320 Tests performed on Model were considered to be representative of Model(s) . 1.0.2 Equipment Size, Mobility and Identification Dimensions: 68(W) by 180(L) by 29.5(H) mm (Outdoor Unit) 68(W) by 180(L) by 36.1(H) mm (Indoor Unit) Mobility: Portable Table-top Built-in Floor-standing Serial No.: Prototype 1.0.3 Electrical Ratings Input : 6 Vdc (4 AA Alkaline 1.5 V Batteries (LR6)) Output : - 1.0.4 Test Voltage & Frequency Unless indicated otherwise on the individual data sheet or test results, the test voltage and frequency was as indicated below. Voltage: 6 Vdc (Battery) Frequency: - 1.0.5 Clock & Other Frequencies Utilized 8 MHz, 13.56 MHz 1.1 Model Differences Not applicable 1.2 Device Modifications Not applicable CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: 2011100031 Date: October 13, 2011 Page 5 of 19 This Report shall not be reproduce…

Text truncated - open the document above for the full version.

Test Setup Photos

CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Test Setup Photos and Configuration Radiated Electric Field Emissions (9 kHz ~ 30 MHz) (30 MHz ~ 1000 MHz) CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Frequency Stability

Contact Information

Applicant

Kim jin hee

[email protected]82-2-2225-6883Fax: 82-2-2225-6999

Technical Contact

CTK., Co. Ltd.Hwang

[email protected]

South Korea

Test Firm

CTK Co., Ltd.Young-Joon Park

[email protected]82-31-339-9871Fax: 82-31-624-9501

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	13.56 MHz - 13.56 MHz	-

Confidentiality

Long Term
