WS2-MT5C0103ARadar Product

Copyright © JORJIN TECHNOLOGIES INC. 2024 http://www.jorjin.com.tw CONFIDENTIAL a module solution provider MT5C01-03 Radar Product User Guide Revision 1.0 Copyright © JORJIN TECHNOLOGIES INC. 2024 http://www.jorjin.com.tw CONFIDENTIAL Index • Flashing Firmware: ............................................................................................................ 3 • Using TI Visualizer to Start the Radar: .............................................................................. 6 • HISTORY CHANGE .............................................................................................................. 8 Copyright © JORJIN TECHNOLOGIES INC. 2024 http://www.jorjin.com.tw CONFIDENTIAL Operating MT5C01-03 with TI Visualizer Flashing Firmware: 1. Original MT5C01-03 product outline is shows as the following (Top View) (Bottom View) 2. The inner view after detaching the case cover. 3. Switch to flash mode by shorting jumper pins J4 on the MT5C01-03. 4. Connect MT5C01-03 to the computer and verify COM Port recognition and connection in the Device Manager. Before flashing firmware, disconnect and reconnect the connection cable to reset MT5C01-03. Copyright © JORJIN TECHNOLOGIES INC. 2024 http://www.jorjin.com.tw CONFIDENTIAL 5. Open the UniFlash application (version 8.3 or above). Download link: https://www.ti.com/tool/UNIFLASH 6. Select the configuration for mmWave IWRL6432. 7. Enter the number of the Enhanced COM Port in the “Setting & Utilities” page. Copyright © JORJIN TECHNOLOGIES INC. 2024 http://www.jorjin.com.tw CONFIDENTIAL 8. On the Program page, check Meta Image1 and browse for the firmware binary file to be written, making sure to display all files, and select “aop5.4.0.1_motion_and_presence_detection_demo_aop.release.appimage”. 9. Press Load Image to start the programming process. Wait until the success message appears to complete the firmware writing process. Copyright © JORJIN TECHNOLOGIES INC. 2024 http://www.jorjin.com.tw CONFIDENTIAL Using TI Visualizer to Start the Radar: 1. Switch to normal mode by opening jumper pins J4 on the MT5C01-03. or V2 board 2. Re-assemble the board in case and then fix it by screws. 3. Connect the radar to the computer and verify COM Port recognition and connection in the Device Manager. Before running the program each time, disconnect and reconnect the connection cable to reset the radar. 4. Open TI Visualizer (recommended version: TI Radar Toolbox 2.10.00.04). File path: directory\radar_toolbox_2_10_00_04\tools\visualizers\Applications_Visualizer\I ndustrial_Visualizer\Industrial_Visualizer.exe. 5. Select the device IWRL6432, and the program will automatically search for the COM Port, or it can be manually entered. For the Demo option, please select “x432 Out of Box Demo”. Copyright © JORJIN TECHNOLOGIES INC. 2024 http://www.jorjin.com.tw CONFIDENTIAL 6. Press the “Connect” button to establish the connection. 7. Press the “Select Configuration” button to choose the radar configuration parameter file to be used. Please use the adjusted antenna configuration parameter file “aop_IWRL_Tracking_MidBw_Sensitive6x10m.cfg”. 8. Press “Start and Send Configuration” to send the command and start the radar. Copyright © JORJIN TECHNOLOGIES INC. 2024 http://www.jorjin.com.tw CONFIDENTIAL • HISTORY CHANGE Revision Date Description Revision 1.0 2024-07-03 First version. Copyright © JORJIN TECHNOLOGIES INC. 2024 http://www.jorjin.com.tw CONFIDENTIAL FCC Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: ● Reorient or relocate the receiving antenna. ● Increase the separation between the equipment and receiver. ● Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ● Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device is not to be operated on aircraft except for the conditions listed on FCC CFR §15.255 (b). IMPORTANT NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. Copyright © JORJIN TECHNOLOGIES INC. 2024 http://www.jorjin.com.tw CONFIDENTIAL IC Industry Canada This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. Cet appareil contient des émetteurs / récepteurs exempts de licence qui sont conformes au (x) RSS (s) exemptés de licence d'Innovation, Sciences et Développement économique Canada. L'opération est soumise aux deux conditions suivantes: (1) Cet appareil ne doit pas provoquer d'interférences. (2) Cet appareil doit…

Text truncated - open the document above for the full version.

Justification Statement FCC ID: WS2-MT5C0103A All measurements were performed radiated and therefore additional antenna gain documentation is not required.

Certification designating a U.S. Agent for service of process: As required by section 2.911(d)(7), the applicant must designate a contact located in the United States for purposes of acting as the applicant's agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. In either scenario, the designation of the U.S. agent for service of process should be provided as an attachment to the equipment authorization application. The applicant must provide a written certification, which must: i. Be signed by both the applicant and designated agent for service of process, if the agent is different from the applicant. ii. Acknowledge the applicant's consent and the designated agent's obligation to accept service of process. iii. Provide a physical U.S. address and email for the designated agent iv. Acknowledge the applicant's acceptance to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment Unofficial information provided by FCC personnel on February 14, 2023, via the monthly call with the TCB Council: The Agent for Process of Service: • cannot be a TCB or affiliated with a TCB (e.g. could not be a person who works for a TCB or a company that owns or is owned by the TCB) • cannot be a [FCC recognised] Lab or affiliated with a test lab (e.g. could not be a person who works for a Lab or a company that owns or is owned by the Lab) ___ __ • ___ Agent_can_be_lndiYidualEntity:_or _a_Company_Entity ____ • Agent Entity must be located in US, US address/phone • Entity acting as Agent must have FRN (best practice, put FRN on Agent Letter) • Agent letter does not have to be FCC ID specific, can be general Agent for Grantee For devices being marketed or for which marketing has ceased for less than 1 year, if the Agent for Process of Service changes, then for every TC Number the TCB must request the FCC to put application into Audit Mode and Agent Letter needs to be updated (superseded). NOTE: The U.S. Agent for Service of Process should not be confused with the authorized agent used for signing the 731 form, other cover letters within the application, and/or the agent who may interface with theTCB. JORJIN TECHNOLOGIES INC. 17F-1, No.239, Sec. 1, Datong Rd., Xizhi Dist.,New Taipei City 22161, Taiwan, R.O.C. U.S. Agent Designation for Service of Process ATTENTION: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, l\1D 21046 USA REGARDING: FCC Certification-Section 2.91 l(d)(7) Information Designated U.S. Agent Company Name: Approve-IT, Inc. Contact Name: Nathan Grinager Street Address: 8011 34 th Ave South, Suite 342 City/Province/Zip: Bloomington, MN 55425 Telephone No: 651-247-1678 Email: [email protected] FRN #: 0027533835 Applicant This letter is to confirm that we ("the Designated U.S. Agent) have accepted the responsibility to act as the Designated U .S. Agent for Service of Process as required by section 47 CFR 2.91 l(d)(7) on behalf of the noted below. U.S. Agent Signature: D ate:June 30 2026 Signed by ( Printed Name/Title): Nathan Grinager / Co-President The Applicant confirms its explicit consent and acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding _ involving the equipmenLTheapplicantfurther acknowledges their responsibility to inform the FCCwhenever the - - D esignated l:J;S:-Agent informa tion - abo v e - changes :- - - -- - - - - --- --- ------ - - - - - - - - - - - - Applicant Company name: JORJIN TECHNOLOGIES INC. Service Type: original application, class 2 permissive change FCC ID: WS2-MT5C0103A Grantee FRN: 0018187252 Module type: single-modular transmitter or limited single-modular transmitter Contact Name: Alan Lin Street Address: 17F-l, No.239, Sec. 1, Datong Rd., Xizhi Dist. City/Province/Zip: New Taipei City 22161, Taiwan, R.O.C. Telephone No: +886-2-2649-0055 Ext.302 Email: [email protected] Applicant Signature: I ;J Date:June24,2026 il� t];f,1� Signed by (Printed Name/Title{�� Lin/ Engineering Vice President *By signing this letter, the client declares and agrees that the service provided by Approve-IT, Inc. will only be applicable for the module model described above. The client also declares and accepts that the service won't be applicable in any way to any host devices that could contain the module for which the service has been contracted

PHOTOGRAPHS OF EUT EP4D1310 Sporton International Inc. Page No. : 1 of 4 Report Template No.: SE Ver 1.0_EP Issued Date : Jul. 21, 2026 Report Version : 01 Brand Name: Jorjin Model Name: MT5C01-03 PHOTOGRAPHS OF EUT EP4D1310 Sporton International Inc. Page No. : 2 of 4 Report Template No.: SE Ver 1.0_EP Issued Date : Jul. 21, 2026 Report Version : 01 PHOTOGRAPHS OF EUT EP4D1310 Sporton International Inc. Page No. : 3 of 4 Report Template No.: SE Ver 1.0_EP Issued Date : Jul. 21, 2026 Report Version : 01 PHOTOGRAPHS OF EUT EP4D1310 Sporton International Inc. Page No. : 4 of 4 Report Template No.: SE Ver 1.0_EP Issued Date : Jul. 21, 2026 Report Version : 01

Label and location

PHOTOGRAPHS OF EUT EP4D1310 Sporton International Inc. Page No. : 1 of 7 Report Template No.: SE Ver 1.0_EP Issued Date : Jul. 21, 2026 Report Version : 01 Brand Name: Jorjin Model Name: MT5C01-03 PHOTOGRAPHS OF EUT EP4D1310 Sporton International Inc. Page No. : 2 of 7 Report Template No.: SE Ver 1.0_EP Issued Date : Jul. 21, 2026 Report Version : 01 PHOTOGRAPHS OF EUT EP4D1310 Sporton International Inc. Page No. : 3 of 7 Report Template No.: SE Ver 1.0_EP Issued Date : Jul. 21, 2026 Report Version : 01 PHOTOGRAPHS OF EUT EP4D1310 Sporton International Inc. Page No. : 4 of 7 Report Template No.: SE Ver 1.0_EP Issued Date : Jul. 21, 2026 Report Version : 01 3RX 2TX PHOTOGRAPHS OF EUT EP4D1310 Sporton International Inc. Page No. : 5 of 7 Report Template No.: SE Ver 1.0_EP Issued Date : Jul. 21, 2026 Report Version : 01 PHOTOGRAPHS OF EUT EP4D1310 Sporton International Inc. Page No. : 6 of 7 Report Template No.: SE Ver 1.0_EP Issued Date : Jul. 21, 2026 Report Version : 01 PHOTOGRAPHS OF EUT EP4D1310 Sporton International Inc. Page No. : 7 of 7 Report Template No.: SE Ver 1.0_EP Issued Date : Jul. 21, 2026 Report Version : 01

RADIO EXPOSURE TEST REPORT Report No. : FA4D1310 TEL : 886-3-656-9065 Page Number : 2 of 7 FAX : 886-3-656-9085 Issued Date : Jul. 21, 2026 Report Template No.: CB-A1_1 Ver1.1 Report Version : 01 Table of Contents History of this test report ................................................................................................................................. 3 Summary of Test Result................................................................................................................................... 4 1 General Description ............................................................................................................................. 5 1.1 EUT General Information ....................................................................................................................... 5 1.2 Antenna Information ............................................................................................................................... 5 1.3 Accessories ............................................................................................................................................ 5 1.4 Testing Location ..................................................................................................................................... 5 2 Maximum Permissible Exposure ........................................................................................................ 6 2.1 Limit of Maximum Permissible Exposure ............................................................................................... 6 2.2 MPE Calculation Method ........................................................................................................................ 6 2.3 Calculated Result and Limit .................................................................................................................... 7 Photographs of EUT v01 RADIO EXPOSURE TEST REPORT Report No. : FA4D1310 TEL : 886-3-656-9065 Page Number : 3 of 7 FAX : 886-3-656-9085 Issued Date : Jul. 21, 2026 Report Template No.: CB-A1_1 Ver1.1 Report Version : 01 History of this test report Report No. Version Description Issued Date FA4D1310 01 Initial issue of report Jul. 21, 2026 RADIO EXPOSURE TEST REPORT Report No. : FA4D1310 TEL : 886-3-656-9065 Page Number : 4 of 7 FAX : 886-3-656-9085 Issued Date : Jul. 21, 2026 Report Template No.: CB-A1_1 Ver1.1 Report Version : 01 Summary of Test Result Report Clause Ref Std. Clause Test Items Result (PASS/FAIL) Remark 2 - Exposure evaluation PA SS - Conformity Assessment Condition: 1. The test results (PASS/FAIL) with all measurement uncertainty excluded are presented against the regulation limits or in accordance with the requirements stipulated by the applicant/manufacturer who shall bear all the risks of non-compliance that may potentially occur if measurement uncertainty is taken into account. 2. The measurement uncertainty please refer to each test result in the chapter "Measurement Uncertainty". Disclaimer: The product specifications of the EUT presented in the test report that may affect the test assessments are declared by the manufacturer who shall take full responsibility for the authenticity. Reviewed by: Sam Chen Report Producer: Sophia Shiung RADIO EXPOSURE TEST REPORT Report No. : FA4D1310 TEL : 886-3-656-9065 Page Number : 5 of 7 FAX : 886-3-656-9085 Issued Date : Jul. 21, 2026 Report Template No.: CB-A1_1 Ver1.1 Report Version : 01 1 General Description 1.1 EUT General Information RF General Information Frequency Range (GHz) Operating Frequency Range (GHz) Test Frequency (GHz) Modulation 57-71 GHz 60.066~62.789 61.439 FMCW 1.2 Antenna Information Ant. Brand Model Name Antenna Type Connector Gain (dBi) Remark 1 Texas Instruments IWRL6432AOP Chip antenna N/A 20 2TX/3RX Note: The above information was declared by manufacturer. 1.3 Accessories N/A 1.4 Testing Location Testing Location Information Test Lab.：Sporton International Inc. Hsinchu Laboratory Hsinchu ADD: No.8, Ln. 724, Bo’ai St., Zhubei City, Hsinchu County 302010, Taiwan (R.O.C.) (TAF: 3787) TEL: 886-3-656-9065 FAX: 886-3-656-9085 Test site Designation No. TW3787 with FCC. Conformity Assessment Body Identifier (CABID) TW3787 with ISED. RADIO EXPOSURE TEST REPORT Report No. : FA4D1310 TEL : 886-3-656-9065 Page Number : 6 of 7 FAX : 886-3-656-9085 Issued Date : Jul. 21, 2026 Report Template No.: CB-A1_1 Ver1.1 Report Version : 01 2 Maximum Permissible Exposure 2.1 Limit of Maximum Permissible Exposure (A) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 *(100) <6 3.0-30 1842/f 4.89/f *(900/f 2 ) <6 30-300 61.4 0.163 1.0 <6 300-1500 - - f/300 <6 1500-100,000 - - 5 <6 (B) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 *(100) <30 1.34-30 824/f 2.19/f *(180/f 2 ) <30 30-300 27.5 0.073 0.2 <30 300-1500 - - f/1500 <30 1500-100,000 - - 1.0 <30 Note: f = frequency in MHz ; *Plane-wave equivalent power density 2.2 MPE Calculation Method The MPE was calculated at 20 cm to show compliance with the power density limit. The following formula was used to calculate the Power Density: E (V/m) ＝ d GP××30 Power Density: Pd (W/m²) ＝ 377 2 E E ＝ Electric field (V/m) P ＝ RF output power (W) G ＝ EUT Antenna numeric gain (numeric) d ＝ Separation distance between radiator and human body (m) The formula can be changed to Pd ＝ 2 377 30 d GP × ×× RADIO EXPOSURE TEST REPORT Report No. : FA4D1310 TEL : 886-3-656-9065 Page Number : 7 of 7 FAX : 886-3-656-9085 Issued Date : Jul. 21, 2026 Report Template No.: CB-A1_1 Ver1.1 Report Version : 01 2.3 Calculated Result and Limit Exposure Environment: General Population / Uncontrolled Exposure DG (dBi) Power (dBm…

Text truncated - open the document above for the full version.

RADIO TEST REPORT Report No. : FR4D1310 TEL : 886-3-656-9065 Page Number : 2 of 43 FAX : 886-3-656-9085 Issued Date : Jul. 21, 2026 Report Temp.late No.: CB-A9_3 Ver1.0 Report Version : 01 Table of Contents History of this test report ................................................................................................................................. 3 Summary of Test Result................................................................................................................................... 4 1 General Description ............................................................................................................................. 5 1.1 Information .............................................................................................................................................. 5 1.2 Applicable Standards ........................................................................................................................... 10 1.3 Testing Location ................................................................................................................................... 10 2 Test Configuration of Equipment under Test .................................................................................. 11 2.1 Parameters of Test Software Setting ................................................................................................... 11 2.2 Conformance Tests and Related Test Frequencies............................................................................. 11 2.3 EUT Operation during Test .................................................................................................................. 11 2.4 Accessories .......................................................................................................................................... 12 2.5 Support Equipment ............................................................................................................................... 13 2.6 Far Field Boundary Calculations .......................................................................................................... 13 2.7 Test Setup Diagram ............................................................................................................................. 14 3 Transmitter Test Result ..................................................................................................................... 17 3.1 AC Power Conducted Emissions ......................................................................................................... 17 3.2 Occupied Bandwidth ............................................................................................................................ 22 3.3 EIRP Power .......................................................................................................................................... 25 3.4 Transmitter Spurious Emissions ........................................................................................................... 28 3.5 Frequency Stability ............................................................................................................................... 36 3.6 Operation Restriction and Group Installation ....................................................................................... 39 4 Test Equipment and Calibration Data .............................................................................................. 40 5 Measurement Uncertainty ................................................................................................................. 43 Appendix A. Test Photos Photographs of EUT v01 RADIO TEST REPORT Report No. : FR4D1310 TEL : 886-3-656-9065 Page Number : 3 of 43 FAX : 886-3-656-9085 Issued Date : Jul. 21, 2026 Report Temp.late No.: CB-A9_3 Ver1.0 Report Version : 01 History of this test report Report No. Version Description Issued Date FR4D1310 01 Initial issue of report Jul. 21, 2026 RADIO TEST REPORT Report No. : FR4D1310 TEL : 886-3-656-9065 Page Number : 4 of 43 FAX : 886-3-656-9085 Issued Date : Jul. 21, 2026 Report Temp.late No.: CB-A9_3 Ver1.0 Report Version : 01 Summary of Test Result Report Clause Ref Std. Clause Test Items Result (PASS/FAIL) Remark 3.1 15.207 AC Power Conducted Emissions PA SS - 3.2 15.255(e) Occupied Bandwidth PA SS - 3.3 15.255(c) EIRP Power PA SS - 3.4 15.255(d) Transmitter Spurious Emissions PA SS - 3.5 15.255(f) Frequency Stability PA SS - 3.6 15.255(a),(h) Operation Restriction and Group Installation PA SS - Conformity Assessment Condition: 1. The test results (PASS/FAIL) with all measurement uncertainty excluded are presented against the regulation limits or in accordance with the requirements stipulated by the applicant/manufacturer who shall bear all the risks of non-compliance that may potentially occur if measurement uncertainty is taken into account. 2. The measurement uncertainty please refer to each test result in the chapter "Measurement Uncertainty". Disclaimer: The product specifications of the EUT presented in the test report that may affect the test assessments are declared by the manufacturer who shall take full responsibility for the authenticity. Reviewed by: Sam Chen Report Producer: Sophia Shiung RADIO TEST REPORT Report No. : FR4D1310 TEL : 886-3-656-9065 Page Number : 5 of 43 FAX : 886-3-656-9085 Issued Date : Jul. 21, 2026 Report Temp.late No.: CB-A9_3 Ver1.0 Report Version : 01 1 General Description 1.1 Information 1.1.1 RF General Information RF General Information Frequency Range (GHz) Operating Frequency Range (GHz) Test Frequency (GHz) Modulation 57-71 GHz 60.066~62.789 61.439 FMCW 1.1.2 Antenna Information Ant. Brand Model Name Antenna Type Connector Gain (dBi) Remark 1 Texas Instruments IWRL6432AOP Chip antenna N/A 20 2TX/3RX Note: The above information was declared by manufacturer. 1.1.3 Power Levels Applicable power levels Conducted EIRP Frequency (GHz) Highest (P high ): Mode Peak Power (dBm) 61.439 FMCW …

Text truncated - open the document above for the full version.

Test Photos Appendix A Sporton International Inc. Hsinchu Laboratory Page No. : 1 of 4 Report No. : FR4D1310 1. Photographs of AC Power Conducted Emissions Test Configuration FRONT VIEW REAR VIEW Test Photos Appendix A Sporton International Inc. Hsinchu Laboratory Page No. : 2 of 4 Report No. : FR4D1310 2. Photographs of Transmitter Spurious Emissions Test Configuration Test Configuration: Below 1GHz / Test mode: Mode 3 FRONT VIEW REAR VIEW Test Photos Appendix A Sporton International Inc. Hsinchu Laboratory Page No. : 3 of 4 Report No. : FR4D1310 Test Configuration: 1GHz~40GHz FRONT VIEW REAR VIEW Test Photos Appendix A Sporton International Inc. Hsinchu Laboratory Page No. : 4 of 4 Report No. : FR4D1310 Test Configuration: Above 40GHz FRONT VIEW ─────THE END─────
