WSG-O10Open Ear Headset

TCB CALL página 1 File FCC ID: WSG-O10 Please upload an exhibit that explains how does the TCB verify the new agent information: 1- Is the address of the agent a valid physical US mailing address (not a US post office box, not a virtual mailbox, not P.O. Boxes, not a vacant lot, not a public building, etc.) ○ We have checked if the address exists in a real and potential building (Google maps) + official US register, after this verification and the evidence below we can guarantee the following: not a US post office box not a virtual mailbox not P.O. Boxes not a vacant lot not a public building(note) ► We checked the FCC FRN Search based on the information provided by the grantee. Google: TCB CALL página 2 EIN Statement TCB CALL página 3 ► CONCLUSION by TCB: The ASOP defined and provided by grantee is VALID and confirmed. Therefore the exhibit " US Agent Letter" included in the file is ok. 2- Is the agent physically located at that valid US address such that the agent can be legally served at that address? Yes , check above 3- Has the listed agent clearly agreed in writing to serve as the agent for the grantee at that address? Yes, it is included in the exhibit " US Agent Letter"

Tony Liu

Attestation Statement. Old Code: C5266091 24 New Code: 00015544 Ed.3 Change reason: FRN is added to the Applicant information section. 1/1 TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: SKY WING Communication Electronics Co.,Ltd Grantee code: WSG FCC ID: WSG-O10 FRN: 0034489997 Contact Name: Tony Liu Address: NO.23, Xincun Road, Chigang Zone, Humen Town, Dongguan City, Guangdong, China Telephone No: 86-769-85239948 Fax No: 86-769-85239948 Email: [email protected] i. [SKY WING Communication Electronics Co.,Ltd] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [SKY WING Communication Electronics Co.,Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. SKY WING Communication Electronics Co.,Ltd certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Date: 08.17.2026 Applicant’s Name: Tony Liu Title: manager Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

SKY WING Communication Electronics Co.,Ltd Code 00018768 Ed. 2 Item 1. The device is able to install software/program installation? ☐ Yes, go to Item 2. ☒ No. In this case, the rest of the items do not apply. The device cannot support installation of Kaspersky cybersecurity or anti-virus software. Item 2. Technical Requirements for Kaspersky Cybersecurity Software: # General Requirements (For all Devices) Yes / No or N/A Comments 1 Internet connection for activation and updates (For all Operating Systems) N/A Device Open Ear Headset Company name SKY WING Communication Electronics Co.,Ltd Grantee code WSG FCC ID WSG-O10 FRN 0034489997 Contact name Tony Liu Address NO.23, Xincun Road, Chigang Zone, Humen Town, Dongguan City, Guangdong, China Telephone number 86-769-85239948 E-mail [email protected] Chipset/module information BT8932E Operating System (if applicable) N/A Storage Capacity (hard drive or other permanent memory storage, if applicable) N/A 2 # General Requirements (For Windows Devices) Yes / No or N/A Comments 1 Storage: 1500 MB free space on the hard drive N/A 2 Operating System: Microsoft Windows 8, 8.1, 10 & 11 Home / Pro / Enterprise Microsoft Windows 7 Starter / Home Basic & Premium / Professional / Ultimate SP1 or higher N/A 3 Processor: 1 GHz or higher (x86 or x64) N/A 4 Memory (RAM)1 GB (32-bit) or 2 GB (64-bit) N/A 5 Screen Resolution: Minimum resolution of 1024 x 768 N/A # General Requirements (For macOS devices) Yes / No or N/A Comments 1 Operating System macOS® 13 – 14 N/A 2 Memory (RAM)4 GB N/A 3 Storage: 3455 MB free space on the hard drive N/A # General Requirements (For Android Devices) Yes / No or N/A Comments 1 Storage: 150 MB free space N/A 2 Operating System: Android™ 10 – 14 N/A 3 Screen Resolution: Minimum resolution of 320 x 480 N/A # General Requirements (for iOS devices) Yes / No or N/A Comments 1 Storage: 150 MB free space N/A 2 Operating System: iOS® 17 N/A 3 # General Requirements (For Linux system) Yes / No or N/A Comments 1 Hard drive: 1 GB of free space N/A 2 CPU: Intel Pentium 1 GHz or higher N/A 3 RAM: 1 GB N/A 4 Minimum software requirements: AlmaLinux OS 8 or later; AlterOS 7.5 or later; Astra Linux Common Edition 2.12 or later; CentOS 6.7 or later; Debian GNU/Linux 10.0 or later; EulerOS 2.0 or later; Oracle Linux 7.3 or later ; Red Hat Enterprise Linux 6.7 or later ; Rocky Linux 8.5 or later ; SUSE Linux Enterprise Server 12.5 or later; Ubuntu 12.04 or later ; Uncom OS Home / Business / Education / Enterprise 2.2 or later; ALT Linux Workstaton / Workstation K / Server / Education 8 or later; ROSA Linux Workstation / Server 12 or later ; RED OS 7.3 and later ; N/A After reviewed the technical requirements, is the device capable of supporting the installation of Kaspersky software? ☐ Yes, go to Item 3. ☒ No. In this case, the rest of the items do not apply. The device cannot support installation of Kaspersky software 4 Item 3. Connectivity Capabilities: # Physical Interface Purpose Justification 1 1 # Wireless Interface Purpose Justification 1 1 After the review of this items, the device: ☒ Cannot support installation of any cybersecurity or anti-virus software on the covered list. ☐ Potentially can operate with any cybersecurity or anti-virus software on the covered list – additional third- party proof is provided to demonstrate compliance with requirements as of 2.911(d)5(i),(ii) – “Proof of Compliance with Covered List Software Requirements” of this document applies Signature: Name: Tony Liu Date: 8/17/2026 1 The justification field is used to justify why the software cannot be received through that interface. Check the annex for more indications.

SKY WING Communication Electronics Co.,Ltd Product Similarity Declaration Product name: Open Ear Headset Model name: O10, O11, O12, O13, O15, O16, DC001, DC002, DC003, DC004, DC005, DC006, DC007, DC008, DC009, DC010, DC011, DC012, DC013, DC014, DC015 FCC ID: WSG-O10 We (SKY WING Communication Electronics Co.,Ltd) hereby state that all the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.,), same mechanical structure and design (including product enclosure, materials, etc.,), the only difference is the model name. Signature: Name: Tony Liu Title: manager Date: 8/17/2026

C5266091_X10_Ed.2 1/1 SKY WING Communication Electronics Co.,Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 8/17/2026 Subject: Request for Confidentiality FCC ID: WSG-O10 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☐ Internal Photos ☐ NOTE 1 ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of ______ days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. C5266091_X10_Ed.2 1/1 Sincerely, Signature: Name: Tony Liu Title: manager

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: SKY WING Communication Electronics Co.,Ltd Address: NO.23, Xincun Road, Chigang Zone, Humen Town, Dongguan City, Guangdong, China Product Name: Open Ear Headset Model Number: O10, O11, O12, O13, O15, O16, DC001, DC002, DC003, DC004, DC005, DC006, DC007, DC008, DC009, DC010, DC011, DC012, DC013, DC014, DC015 FCC Identifier: WSG-O10 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Tony Liu Date: 8/17/2026 Title: manager Signature of applicant:

Page1of4ReportNo.:MTi260601036-0101 Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China. Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected] PhotographsoftheEUT(ExternalPhotos) Model:O10 Page2of4ReportNo.:MTi260601036-0101 Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China. Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected] Page3of4ReportNo.:MTi260601036-0101 Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China. Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected] Page4of4ReportNo.:MTi260601036-0101 Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China. Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected]

备注：±公差0.05mm 上下居中对齐 镭 雕 Open Ear Headset Model: O10 Input: 5V 500mA Max FCC ID: WSG-O10 SN: TY2607 SKY WING Communication Electronics Co., Ltd Made In China Open Ear Headset Model: O10 Input: 5V 500mA Max FCC ID: WSG-O10 SN: TY2607 SKY WING Communication Electronics Co., Ltd Made In China 19.4mm 9.1mm * 2mm 技术要求： 1.表面丝印 2.耐醇力测试：浓度95%的酒精，0.5kg作用力，30次/分钟，涂层表面拭擦50次 （棱角弧面为20次），涂层须无任合变化； 3.耐橡皮擦测试：使用专用的橡皮擦，施加500g的载荷，以40～60次/分钟的速度， 以20mm左右的行程，在样本表面来回磨擦，磨擦次数50次 4. 带“ ”号标记为重点检验尺寸. 5.材质要求符合RoHS、reach、CA65相关标准。 0.7 0.5 0.3 0.7 0.5 0.4 0.2 0.5 0.4 0.3 0.15 0.4 0.3 0.2 0.1 0.3 0.2 0.1 0.05 180~315 80~180 30~80 6~30 0~6 315~620 0.4 0.6 0.9 天 翼 通 讯 电 子 有 限 公 司 2 1 版本 REV. 审核 Checked 制图 drawing 物料名称 机型 Model No. 材质 Material 比例/单位 Scale/Unit Unit 发行日期 ISSUE DATE 文件编号 成品料号 素材料号 采购 塑胶品管 工程 研发 SMT 修改标记修改日期 负责人 修改事由修改内容 发放部门 3 角度公差 Angular Tolerance:` 0.5~ 长度 Dimensions mm 公差 Tolerance:(` ) 1:1 skywing A0 模号 出模数 颜色 SPC X

Page1of4ReportNo.:MTi260601036-0101 Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China. Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected] PhotographsoftheEUT(InternalPhotos) Model:O10 Page2of4ReportNo.:MTi260601036-0101 Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China. Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected] Page3of4ReportNo.:MTi260601036-0101 Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China. Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected] Page4of4ReportNo.:MTi260601036-0101 Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China. Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected]

Tel:0755-88850135-1439 Mobile:131-4343-1439（Wechatsamenumber） Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE012 Ver./Rev.：A1 Page 1 of 6 RFEXPOSURE TestReport ReportNo.:MTi260601036-0101E2 DateofIssue:2026-07-15 Applicant:SKYWINGCommunicationElectronicsCo.,Ltd Product:OpenEarHeadset Model(s):O10,O11,O12,O13,O15,O16,DC001,DC002, DC003,DC004,DC005,DC006,DC007,DC008,DC009, DC010,DC011,DC012,DC013,DC014,DC015 FCCID:WSG-O10 ShenzhenMicrotestCo.,Ltd. TESTREPORT ReportNo.:MTi260601036-0101E2 Tel:0755-88850135-1439 Mobile:131-4343-1439（Wechatsamenumber） Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE012 Ver./Rev.：A1 Page2of6 Tableofcontents 1StandaloneSARtestexclusionconsiderations.................................................................4 2SARTestExclucsionThresholds.........................................................................................5 TESTREPORT ReportNo.:MTi260601036-0101E2 Tel:0755-88850135-1439 Mobile:131-4343-1439（Wechatsamenumber） Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE012 Ver./Rev.：A1 Page3of6 TestResultCertification ApplicantSKYWINGCommunicationElectronicsCo.,Ltd ApplicantAddress NO.23,XincunRoad,ChigangZone,HumenTown,DongguanCity,Guangdong, China ManufacturerSKYWINGCommunicationElectronicsCo.,Ltd Manufacturer Address NO.23,XincunRoad,ChigangZone,HumenTown,DongguanCity,Guangdong, China Productdescription ProductnameOpenEarHeadset TrademarkN/A ModelnameO10 SeriesModel(s) O11,O12,O13,O15,O16,DC001,DC002,DC003,DC004,DC005,DC006, DC007,DC008,DC009,DC010,DC011,DC012,DC013,DC014,DC015 Standards47CFRPart2.1093 TestmethodKDB447498D01v06 TestingInformation Dateoftest2026-06-20to2026-07-13 TestResultPass Preparedby:JamesQin Reviewedby:DavidLee Approvedby:LewisLian TESTREPORT ReportNo.:MTi260601036-0101E2 Tel:0755-88850135-1439 Mobile:131-4343-1439（Wechatsamenumber） Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE012 Ver./Rev.：A1 Page4of6 1StandaloneSARtestexclusionconsiderations UnlessspecificallyrequiredbythepublishedRFexposureKDBprocedures,standalone1-g headorbodyand10-gextremitySARevaluationforgeneralpopulationexposureconditions,by measurementornumericalsimulation,isnotrequiredwhenthecorrespondingSARTest ExclusionThresholdcondition(s),listedbelow,is(are)satisfied. Thesetestexclusionconditionsarebasedonsource-basedtime-averagedmaximum conductedoutputpoweroftheRFchannelrequiringevaluation,adjustedfortune-uptolerance, andtheminimumtestseparationdistancerequiredfortheexposureconditions. Theminimumtestseparationdistancedefinedin4.1f)isdeterminedbythesmallestdistance fromtheantennaandradiatingstructuresoroutersurfaceofthedevice,accordingtothehost formfactor,exposureconditionsandplatformrequirements,toanypartofthebodyorextremity ofauserorbystander. ToqualifyforSARtestexclusion,thetestseparationdistancesappliedmustbefullyexplained andjustified,typicallyintheSARmeasurementorSARanalysisreport,bytheoperating configurationsandexposureconditionsofthetransmitterandapplicablehostplatform requirements,accordingtotherequiredpublishedRFexposureKDBprocedures. WhennootherRFexposuretestingorreportingarerequired,astatementofjustificationand compliancemustbeincludedintheequipmentapproval,inlieuoftheSARreport,toqualifyfor SARtestexclusion. Whenrequired,thedevicespecificconditionsdescribedintheotherpublishedRFexposure KDBproceduresmustbesatisfiedbeforeapplyingtheseSARtestexclusionprovisions. a)For100MHzto6GHzandtestseparationdistances≤50mm,the1-gand10-gSARtest exclusionthresholdsaredeterminedbythefollowing: [(max.powerofchannel,includingtune-uptolerance,mW)/(min.testseparationdistance, mm)]·[√f(GHz)]≤3.0for1-gSAR,and≤7.5for10-gextremitySAR,where  f (GHz) istheRFchanneltransmitfrequencyinGHz PoweranddistanceareroundedtothenearestmWandmmbeforecalculation Theresultisroundedtoonedecimalplaceforcomparison Thevalues3.0and7.5arereferredtoasnumericthresholdsinstepb)below Thetestexclusionsareapplicableonlywhentheminimumtestseparationdistanceis≤50mm, andfortransmissionfrequenciesbetween100MHzand6GHz.Whentheminimumtest separationdistanceis<5mm,adistanceof5mmaccordingto4.1f)isappliedtodetermine SARtestexclusion. b)For100MHzto6GHzandtestseparationdistances>50mm,the1-gand10-gSARtest exclusionthresholdsaredeterminedbythefollowing(alsoillustratedinAppendixB): 1){[Powerallowedatnumericthresholdfor50mminstepa)]+[(testseparation distance–50mm)·(f(MHz)/150)]}mW,for100MHzto1500MHz 2){[Powerallowedatnumericthresholdfor50mminstepa)]+[(testseparation distance–50mm)·10]}mW,for>1500MHzand≤6GHz c)Forfrequenciesbelow100MHz,thefollowingmaybeconsideredforSARtestexclusion (alsoillustratedinAppendixC): 1)Fortestseparationdistances>50mmand<200mm,thepowerthresholdatthe correspondingtestseparationdistanceat100MHzinstepb)ismultipliedby[1+ log(100/f(MHz))] TESTREPORT ReportNo.:MTi260601036-0101E2 Tel:0755-88850135-1439 Mobile:131-4343-1439（Wechatsamenumber） Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE012 Ver./Rev.：A1 Page5of6 2)Fortestseparationdistances≤50mm,thepowerthresholddeterminedbythe equationinc)1)for50mmand100MHzismultipliedby½ 3)SARmeasurementproceduresarenotestablishedbelow100MHz. WhenSARtestexclusioncannotbeapplied,aKDBinquiryisrequiredtodetermineSAR evaluationrequirementsforanySARtestresultsbelow100MHztobeacceptable. 2SARTestExclucsionThresholds Weuse5mmasseparationdistancetocalculated. BR&EDR: Transmit Frequency (GHz) Mode Meas…

Text truncated - open the document above for the full version.

Tel:0755-88850135-1439 Mobile:131-4343-1439（Wechatsamenumber） Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE038 Ver./Rev.：A1 Page 1 of 88 TestReport ReportNo.:MTi260601036-0101E1 Dateofissue:2026-07-15 Applicant:SKYWINGCommunicationElectronicsCo.,Ltd Product:OpenEarHeadset Model(s):O10,O11,O12,O13,O15,O16,DC001,DC002, DC003,DC004,DC005,DC006,DC007,DC008, DC009,DC010,DC011,DC012,DC013,DC014, DC015 FCCID:WSG-O10 ShenzhenMicrotestCo.,Ltd. TESTREPORT ReportNo.:MTi260601036-0101E1 Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE038 Ver./Rev.：A1 Page 2 of 88 Tableofcontents 1GeneralDescription.......................................................................................................................4 1.1DescriptionoftheEUT.........................................................................................................4 1.2Descriptionoftestmodes.....................................................................................................4 1.3EnvironmentalConditions.....................................................................................................6 1.4Descriptionofsupportunits..................................................................................................6 1.5Measurementuncertainty.....................................................................................................6 2SummaryofTestResult................................................................................................................7 3TestFacilitiesandaccreditations................................................................................................8 3.1Testlaboratory......................................................................................................................8 4Listoftestequipment....................................................................................................................9 5EvaluationResults(Evaluation).................................................................................................11 5.1Antennarequirement..........................................................................................................11 6RadioSpectrumMatterTestResults(RF)................................................................................12 6.120dBBandwidth..................................................................................................................12 6.2MaximumConductedOutputPower..................................................................................14 6.3ChannelSeparation............................................................................................................15 6.4NumberofHoppingFrequencies.......................................................................................17 6.5DwellTime..........................................................................................................................19 6.6RFconductedspuriousemissionsandbandedgemeasurement....................................21 6.7Bandedgeemissions(Radiated).......................................................................................22 6.8Radiatedemissions(below1GHz).....................................................................................26 6.9Radiatedemissions(above1GHz)....................................................................................30 Photographsofthetestsetup...........................................................................................................35 PhotographsoftheEUT.....................................................................................................................36 AppendixA:20dBEmissionBandwidth..........................................................................................38 AppendixB:Maximumconductedoutputpower...........................................................................44 AppendixC:Carrierfrequencyseparation......................................................................................50 AppendixD:Timeofoccupancy.......................................................................................................53 AppendixE:Numberofhoppingchannels.....................................................................................61 AppendixF:Bandedgemeasurements...........................................................................................64 AppendixG:ConductedSpuriousEmission..................................................................................70 TESTREPORT ReportNo.:MTi260601036-0101E1 Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE038 Ver./Rev.：A1 Page 3 of 88 TestResultCertification ApplicantSKYWINGCommunicationElectronicsCo.,Ltd ApplicantAddress NO.23,XincunRoad,ChigangZone,HumenTown,DongguanCity, Guangdong,China ManufacturerSKYWINGCommunicationElectronicsCo.,Ltd Manufacturer Address NO.23,XincunRoad,ChigangZone,HumenTown,DongguanCity, Guangdong,China Productdescription ProductnameOpenEarHeadset TrademarkN/A ModelnameO10 SeriesModel(s) O11,O12,O13,O15,O16,DC001,DC002,DC003,DC004,DC005,DC006, DC007,DC008,DC009,DC010,DC011,DC012,DC013,DC014,DC015 Standards47CFRPart15.247 TestMethod KDB558074D0115.247MeasGuidancev05r02 ANSIC63.10-2020+Cor.1-2023+C63.10a-2024+ErratatoC63.10a-2024 TestingInformation Dateoftest2026-06-20to2026-07-13 TestresultPass Preparedby:JamesQin Reviewedby:DavidLee Approvedby:LewisLian TESTREPORT ReportNo.:MTi260601036-0101E1 Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)…

Text truncated - open the document above for the full version.

SMD CERAMIC ANTENNA Data Sheet CS-2450-16-B For 2400-2500MHz 1.6x0.8x0.4mm [EIA1608] Chip Antenna Feature nLight weight, compact nWide bandwidth, low cost nBuilt-in antenna with high gain nOperating Temp. : -40°C~+85°C Application nBluetooth nWLAN 2.4 nWiFi 5/6/6E nUWB CS-2450-16-B Electrical Characteristics per line(TA=25°C) Parameter Specification Units Frequency Band 2400~2500 MHz Polarization Linear *Peak Gain 2.78 dBi *Peak Efficiency 80.25 % Impendance 50 Ω Test condition: Test board size 70*60 mm; Matching circuit: Pi matching circuit will be required. Product Dimension TECHNOLOGY Units:mm W A L A H LWHA 1.60±0.200.80±0.200.40±0.100.2±0.07 501, Haibin Science and Technology Building, Gushu Community, Baoan District, Shenzhen City Recommend PCB Layout1 Chip Antenna Test condition: Test board size 70*60 mm; Top Layer (unit mm) Bottom Layer (unit mm) Feeding line:50Ω Chip Antenna E1(0201) 1.5 3.5 1.0 0.5 0.5 0.5 2.0 E2(0201) 1.5 3.5 2.0 E3(0201) 0.5 TECHNOLOGY ANT 1.1 Note:The spacing between antenna pads should not be ＜ 1.1mm 注意:天线焊盘内间距不能＜1.1mm 6.5 6.5 1.1 0.5 0.8 Recommend PCB Layout2 Chip Antenna Test condition: Test board size 70*60 mm; Chip Antenna TECHNOLOGY Top Layer (unit mm) Bottom Layer (unit mm) Feeding line:50Ω E1(0201) 1.5 2.0 0.5 0.5 0.5 10 1.5 10 E2(0201) E3(0201) 0.5 Note:The spacing between antenna pads should not be ＜ 1.1mm 注意:天线焊盘内间 距不能＜1.1mm 1 . 1 1.1 0.5 0.8 ANT PAD E2(0201) 2.0 1.5 Typical Characteristics Fig. 1 Return Loss Radiation Pattern The Gain pattern is measured in FAR -field chamber. DUT is placed on the table of rotator , a standard horn antenna and Vector Network Analyzer is used to collect data. Fig.2 FAR-field Chamber Chip Antenna TECHNOLOGY Chip Antenna Equivalent circuit: Chip Antenna RF chip ANT E1 E2 E3 Frequency 2400MHz2450MHz2500MHz Avg. gain - 1.92- 1.35- 1.56 Peak gain 1.792.782.66 Efficiency 74.5580.2576.98 Radiation Performance: 2D Gain Pattern X-Y Plane Y-Z Plane X-Z Plane TECHNOLOGY 2400MHz2450MHz2500MHz Item Condition Specification Thermal shock 1. 30±3 minutes at -40 ° C±5 ° C , 2. Convert to +105 ° C (5 minutes) 3. 30±3 minutes at +105 ° C±5 ° C , 4. Convert to -40 ° C (5 minutes) 5 . Total 100 continuous cycles No apparent damage Fulfill the electrical spec. after test. Humidity resistance 1. Humidity: 85% R.H. 2 . Temperature: 85±5 ° C 3 . Time: 1000 hours . No apparent damage Fulfill the electrical spec. after test. High temperature resistance No apparent damage Fulfill the electrical spec. after test. 1 . Temperature: 150 ° C±5 ° C 2 . Time: 1000 hours . Low temperature resistance 1 . Temperature: -40 ° C±5 ° C 2 . Time: 1000 hours . No apparent damage Fulfill the electrical spec. after test. Soldering heat resistance 1. Solder bath temperature : 260±5°C 2. Bathing time: 10±1 seconds No apparent damage Solderability The dipped surface of the terminal shall be at least 95% covered with solder after dipped in solder bath of 245±5°C for 3±1 seconds . No apparent damage (2) Storage Condition (a)At warehouse: The temperature should be within 0 ~ 30°C and humidity should be less than 60% RH.The product should be used within 1 year from the time of elivery. (b)On board: The temperature should be within -40 ~85°C and humidity should be less than 85% RH. ( 3) Operating Temperature Range Operating temperature range : -40°C to +85°C . Recommended Reflow Solder curve Chip Antenna TECHNOLOGY External Dimensions L*W (mm) 1.6*0.8 Central Frequency 2450 MHz Product Series: Chip Antenna Marking Part Number System CS - 2450 - 16-B Package Information Chip Antenna ( 1) Soldering Gun Procedure Note the follows, in case of using solder gun for replacement. (a) The tip temperature must be less than 350°C for the period within 3 seconds by using soldering gun under 30 W. (b) The soldering gun tip s hall not touch this product directly. (2) Soldering Volume Note that excess of soldering vol…
