WSN82-801-2Wireless Mouse

WIRELESS CARBON FIBER MOUSE MANUAL INTRODUCTION FEATURES SPECIFICATIONS CAUTIONS - Always use rechargeable batteries only when recharging your mouse - Observe polarity and the direction of battery as it may cause explosion - Stop using the mouse immediately when battery compartment encounters an overheat problem - Please charge 7 hours for first application For first time usage guidelines, please match the ID key of mouse and reciever Under normal condition, plug the receiver into the PC, pressing the right key and scroll wheel of the mouse at the SAME time (at least 10 seconds). Key matching is completed. Scroll Wheel Right Key Left Key Receiver Compartment Battery Compartment Receiver Release Button USB Mini B Type Optical Sensor Battery IndicatorInsulation Label ILLUSTRATIONS Receiver release button Retractable CableBattery installation 1. The battery needs to be recharged immediately when the battery power indicator turns red. 2. Always use rechargeable batteries only! The charge unit could not be charged with alkaline batteries and it could cause damage to the mouse and set off super heat, fire and explosion. 3. This device requires AAA rechargeable batteries ( 2 pcs ) for recharge. 4. Dispose the batteries in accordance with local regulations. 5. Replace old and weak batteries promptly. 6. As long as the recharge cable is connected to the computer, the mouse still can be used even though the battery is not enough or without any batteries inside the battery compartment. • Operating mode: 20mA / DC 2.4V • Sleep mode: 20uA / DC 2.4V / ( Note: the mouse will switch to power saving mode if not working over 3 second; and powered off automatically if not working over 10 minutes, Please press any buttons or scroll wheel of the mouse when it gets into sleep mode. ) • Low battery indicator: 2.3V • Battery type: AAA 1.2V 850mAh Ni-MH rechargeable battery X 2 pcs • Continuous working hrs: approx: 50 hrs • Battery life: under average usage, 3-4 hrs per day, the batteries should last approx. 2 weeks • Normal battery charging time: Full power / 5hrs at DC 5V • Receiver power requirement: DC 5V BATTERY CONSUMPTION & ELECTRICAL PROPERTIES BATTERY RECHARGE INSTRUCTION 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Federal Communications Commission (FCC) Statement This equipment has been tested. And it found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates and uses and radiates radio frequency energy and, if not installed and used in accordance with the instruction, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio /TV technician for help. Warning: A shielded-type power cord is required in order to meet FCC emission limits and also to prevent interference to the nearby radio and television reception. It is essential that only the supplied power cord be used. NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. WIRELESS MOUSE MODEL: 82-801 14 32 Trouble Shooting: Mouse may not be worked properly after battery power is totally used up even the USB charging cable is reconnected after. Simply follow the steps as below: (1) install the receiver back to compartment first (2) connect the charging cable again (3) release the receiver from compartment again and connect to computer (4) mouse will worked properly while recharging (5) If it still doesn't work, please enter both reset ID key of mous e and receiver This leather wireless mouse is a fashionable design that combines leather with chrome . It is a newly developed wireless 2.4GHz RF mouse including both Remote (Mouse) and Dongle (Receiver). Utilizing USB charging technology this mouse can be completely recharged simply by connecting it to USB port on your computer. 1. 3D optical mouse with 1000 dpi resolution 2. 2.4GHz radio frequency wireless transmission 3. Smart identification system detecting the operation distance 4. Battery recharge function via USB cable 5. Low battery power indicator 6. Smart identification system detecting the misuse of non-rechargeable batteries 7. Smart identification system activating over discharge batteries 8. Smart battery recharging protection system 9. Auto switch on / off function 10. Smart power management 11. LED indicator: a) Under normal condition,when taking out the USB receiver from the wireless mouse, red LED flashes 5 seconds and then light off b) When low battery: LED flashes when moving the mouse c) While charging: green LED flashes every 0.5 sec. d) Fully charged: green LED shines e) Identify non-rechargeable battery: green LED flashes every 1 sec. (receiver is not connected to PC) • Interface: USB 1.1 • Sensor report rate on mouse: 3000 frame/sec • Operation angle: 360 degrees • Operation distance: 4.5m…

Text truncated - open the document above for the full version.

Ersteller: U. Rodemeier Revision: 04 Erstelldatum: 03.08.01 Datum: 11.05.07 Seite 1 von 1 Request for Confidentiality PHOENIX TESTLAB GmbH Date: 2010-08-24 Product Certification Königswinkel 10 D 32825 Blomberg RE: Certification Application FCC ID: WSN82-801-2 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rule, the applicant hereby requests confidential treatment of information accompanying this application as outlined below: • BOM • Operation Description • Schematics • Block Diagram (XXXXX to be replaced by Schematics, Block Diagram, etc.) The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the GRANT for this application. Thank you for your attention in this matter. Applicant’s Company: Centre Testing International Corporation address : Bldg. C, Hongwei Industrial Park, Block 70, Bao’an District, Shenzhen, Guangdong, China Signature : Job Title and Dept. :EMC Engineer, EMC Lab

FCC label information: LABEL

Report No. : SZEE100927430908 Page 1 of 24 ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION Product Name : Wireless Mouse Model Number : 82-801 Trade Name : Earth Trek FCC ID : WSN82-801-2 Report Number : SZEE100927430908 Date : Oct. 20, 2010 Prepared for Earth Trek (Hong Kong) Limited Unit 503, 5/F, Silvercord Tower 2, 30 Canton Road, Tsimshatsui, Kln., Hong Kong TEL: 00852-3113 7800 FAX: 00852-3113 7803 Prepared by CENTRE TESTING INTERNATIONAL (SHENZHEN) CORPORATION Building C, Hongwei Industrial Zone, Baoan 70 District, Shenzhen, Guangdong, China TEL: 86-755-3368 3362 FAX: 86-755-3368 3368 This report shall not be reproduced, except in full, without the written approval of CENTRE TESTING INTERNATIONAL (SHENZHEN) CORPORATION Building C, Hongwei Industrial Zone, Baoan 70 District, Shenzhen Standards Results 47 CFR FCC Part 15 Subpart C 15.249 PASS Report No. : SZEE100927430908 Page 2 of 24 TABLE OF CONTENTS 1. GENERAL INFORMATION .........................................................................................3 2. TEST SUMMARY........................................................................................................4 3. MEASUREMENT UNCERTAINTY ..............................................................................4 4. TEST EQUIPMENT LIST.............................................................................................4 5. SUPPORT EQUIPMENT LIST ....................................................................................4 6. PRODUCT INFORMATION.........................................................................................5 7. CONDUCTED EMISSION (CE) ...................................................................................6 7.1 LIMITS............................................................................................................6 7.2 BLOCK DIAGRAM OF TEST SETUP............................................................6 7.3 TEST PROCEDURE.......................................................................................6 7.4 TEST RESULT................................................................................................6 7.5 GRAPHS AND DATA.....................................................................................7 8. 20DB BANDWIDTH MEASUREMENT........................................................................9 8.1 LIMITS............................................................................................................9 8.2 BLOCK DIAGRAM OF TEST SETUP............................................................9 8.3 TEST PROCEDURE.......................................................................................9 8.4 TEST RESULT................................................................................................9 9. RADIATED EMISSIONS MEASUREMENT ..............................................................12 9.1 LIMITS..........................................................................................................12 9.2 BLOCK DIAGRAM OF TEST SETUP..........................................................12 9.4 TEST RESULT..............................................................................................14 10. BAND EDGE EMISSION MEASUREMENT ............................................................17 10.1 LIMITS........................................................................................................17 10.2 BLOCK DIAGRAM OF TEST SETUP........................................................17 10.3 TEST PROCEDURE...................................................................................17 10.4 TEST RESULT............................................................................................17 APPENDIX 1 PHOTOGRAPHS OF TEST SETUP .......................................................19 APPENDIX 2 PHOTOGRAPHS OF EUT ......................................................................21 (Note: N/A means not applicable) Report No. : SZEE100927430908 Page 3 of 24 1. GENERAL INFORMATION The above equipment was tested by CENTRE TESTING INTERNATIONAL (SHENZHEN) CORPORATION for compliance with the requirements set forth in FCC Rules and the measurement procedure according to ANSI C63.4-2009. The test results of this report relate only to the tested sample identified in this report. Prepared by : Christy Chen Reviewed by : Louisa Lu Approved by : Lily Yan Supervisor Date : Oct. 20, 2010 Applicant: Earth Trek (Hong Kong) Limited Unit 503, 5/F, Silvercord Tower 2, 30 Canton Road, Tsimshatsui, Kln., Hong Kong Manufacturer: Earth Trek (Hong Kong) Limited Unit 503, 5/F, Silvercord Tower 2, 30 Canton Road, Tsimshatsui, Kln., Hong Kong Sample Description: Wireless Mouse Technical Date: DC 2.4V Model Name: 82-801 Trade Name: Earth Trek FCC ID: WSN82-801-2 Report Number: SZEE100927430908 Date of Test: Sep. 27, 2010 to Oct. 20, 2010 Report No. : SZEE100927430908 Page 4 of 24 2. TEST SUMMARY The complete list of measurements is given below: Clause Test Item Rule Result 7 Conducted Emission FCC 15.207 PASS 8 20dB Bandwidth FCC 15.215(c) PASS 9 Radiated Emission FCC 15.209 FCC 15.249(a) (d) PASS 10 Out of Band Emission FCC 15.249 (d) PASS 3. MEASUREMENT UNCERTAINTY This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using a coverage factor of k=2. Measurement items Uncertainty Radiated Emissions / Band edge Emission 4.6 dB Conducted disturbance 2.6 dB 4. TEST EQUIPMENT LIST Equipment Manufacturer Model Number Serial Number Due Date 3M Chamber & Accessory Equipment ETS-LINDGREN FACT-3 3510 01/19/2011 Spectrum Analyzer Agilent E4443A MY46185649 01/19/2011 Biconilog Antenna ETS-LINGREN 3142C 920250 01/19/2011 Multi device Controller ETS-LINGREN 2090 00057230 01/19/2011 Horn Antenna ETS-LINDGREN 3117 00057407 07/31/2011 Loop Antenna ETS-LINDGREN 6502 00071730 08/24/2011 Receiver R&S ESCI 100009 07/10/2011 LISN R&S ENV216 100098 07/10/2011 5. SUPPORT EQUI…
