WSUBT2F1013CFL

User manual 1. Purpose Homelite’s CFL has implemented three phosphors together into one compact fluorescent. It is a new type of light resource of green environment. The product’s applications are practical for supermarkets, shopping centers, retail stores, and gymnasium. 2. Characteristics Homelite’s CFL provides instant start, long-life and high lumen output. The lamp is designed to perform up to the industry standards by using less electricity. Lamp can operate under -18 °C below zero degrees Celsius. From Homelite’s testing results shows the self ballast lamp only uses 20% of the electricity and it is compared and equivalent to a regular incandescent bulb. 3. Directions 1) For Safety purposes, the lamp fixture must be powered off before being installed, changed or being cleaned 2) This self ballast lamp cannot be operated with dimmer device. In order to keep the lamp’s high performance it should be used in defined voltage. 3) This Lamp can be performed under environmental areas in temperature from -18° C to 45° C, it cannot be used in enclosed fixture or wet areas. 4) Please check the power, voltage and contacts of the lamp incase the lamp performs abnormal signs such as the light blinking or the light turns off suddenly 5) Do not hold the tube by the hands while changing or cleaning the lamp. The proper way is to hold the lamp by the plastic housing. 4 Warnning This device complies with Part 18 of the FCC Rules. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This product may cause interference to radio equipment and should not be installed near maritime safety communications equipment or other critical navigation or communication equipment operating between 0.45–30 MHz. If this occurs, please change outlet or move the lamp far away from other appliance. Homelite limited No.319 Jiugan Rd , Sijing Town ,Songjiang District , Shanghai , China. 201601

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007

SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006

APPENDIX III External Photos EUT - General View (HLT2F09W) EUT - General View (HLT2F13W) EUT - General View (HLT2F20W) EUT - General View (HLT2F23W)

APPENDIX I FCC ID Label FCC ID: WSUBT2F1013

APPENDIX II FCC ID Label Location FCC ID Label Location

APPENDIX IV Internal Photos EUT – Uncovered View (HLT2F09W) EUT –Components View (HLT2F09W) EUT–Solder View (HLT2F09W) EUT – Uncovered View (HLT2F13W) EUT –Components View (HLT2F13W) EUT–Solder View (HLT2F13W) EUT – Uncovered View (HLT2F20W) EUT –Components View (HLT2F20W) EUT–Solder View (HLT2F20W) EUT – Uncovered View (HLT2F23W) EUT –Components View (HLT2F23W) EUT–Solder View (HLT2F23W)

Homelite Limited. FCC ID: WSUBT2F1013 Report No.BTR66.180.10.030.26 Page 2 of 14 FCC Part 18 Report TABLE OF CONTENTS GENERAL INFORMATION........................................................................................................................................3 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT)................................................................................3 OBJECTIVE..................................................................................................................................................................3 RELATED SUBMITTAL(S)/GRANT(S)............................................................................................................................3 TEST METHODOLOGY.................................................................................................................................................3 TEST FACILITY.............................................................................................................................................................3 SYSTEM TEST CONFIGURATION...........................................................................................................................4 JUSTIFICATION.............................................................................................................................................................4 SCHEMATICS / BLOCK DIAGRAM.................................................................................................................................4 EQUIPMENT MODIFICATIONS......................................................................................................................................4 CONFIGURATION OF TEST SYSTEM............................................................................................................................4 TEST SETUP BLOCK DIAGRAM....................................................................................................................................4 CONDUCTED EMISSIONS TEST DATA.................................................................................................................5 APPLICABLE STANDARD..............................................................................................................................................5 MEASUREMENT UNCERTAINTY...................................................................................................................................5 EUT SETUP.................................................................................................................................................................5 TEST EQUIPMENTS......................................................................................................................................................6 TEST PROCEDURE......................................................................................................................................................6 SUMMARY OF TEST RESULTS.....................................................................................................................................6 CONDUCTED EMISSIONS TEST DATA AND PLOTS......................................................................................................7 Homelite Limited. FCC ID: WSUBT2F1013 Report No.BTR66.180.10.030.26 Page 3 of 14 FCC Part 18 Report GENERAL INFORMATION Product Description for Equipment under Test (EUT) The Homelite Limited’s model HLT2F09W,HLT2F13W,HLT2F20W,HLT2F23W or the “EUT” as referred to in this report is CFL, rated input voltage: AC 120V/60Hz, operation frequency between 40 KHz to 60 KHz. Model HLT2F09W Electrical Power 9W Model HLT2F13W Electrical Power 13W Model HLT2F20W Electrical Power 20W Model HLT2F23W Electrical Power 23W The test data was only good for the test sample. It may have deviation for other test sample. Objective The following test report is prepared on behalf of Homelite Limited. in accordance with Part 2, Subpart J, and Part 18, Subparts A, B, and C of the Federal Communication Commissions rules and regulations. The objective of the manufacturer is to demonstrate compliance with FCC Part 18 limit requirements for Industrial, Scientific, and Medical Equipment. Related Submittal(s)/Grant(s) No Related Submittals. Test Methodology All measurements contained in this report were conducted with MP-5 1986, FCC Method of measurements of radio noise emission from Industrial, Scientific and Medical equipments. Test Facility All measurement facilities used to collect the data are located at Huatongwei Building , Keji Rd, 12 S, high-Tech Park, Nanshan District, Shenzhen, China. The sites are constructed in conformance with the requirements of ANSI C63.7/634 and CISPR 22, The site was accredited by FCC (662850), A2LA( 2243.01) and CNAL (L1225) Homelite Limited. FCC ID: WSUBT2F1013 Report No.BTR66.180.10.030.26 Page 4 of 14 FCC Part 18 Report SYSTEM TEST CONFIGURATION Justification The EUT was tested under normal mode as used by a common (typical) user. Schematics / Block Diagram N/A. Equipment Modifications No modifications were made by BEST Test Service Shenzhen Co., Ltd. to ensure the EUT to comply with the application limits and requirements. Configuration of Test System Test Setup Block Diagram 1.5 Meters E U T P o w e r C o r d E x t e n s i o n LISN1 Non-conducting table 80 cm above Ground Plane EUT 1 Meter 1.5 Meter Homelite Limited. FCC ID: WSUBT2F1013 Report No.BTR66.180.10.030.26 Page 5 of 14 FCC Part 18 Report CONDUCTED EMISSIONS TEST DATA Applicable Standard For the following equipment, when designed to be connected to the public utility (AC) power line the radio frequency voltage that is conducted back onto the AC power line on any frequency or frequencies shall not exceed the limits in the following tables. Compliance with the provisions of this paragraph shall be based on the measurement of the radio frequency voltage between each power line and ground at the power…

Text truncated - open the document above for the full version.

APPENDIX V Test Setup Photos Test Setup – Front View Test Setup – Side View
