WVB-FXC851GSM Fixed Wireless Phone

1 PREFACE WELCOME Congratulations on the purchas e of your FXC-851 product! Please retain your original dated sales receipt for your records. For warranty service of your FXC-8 51 product, you will need to provide a copy of your dated sales receip t to confirm warranty status. Thank you for choosing Motorola product. Please read important safety instructions before use. Read and understand all instructions before use. Please retain this guide for future reference. The information contained in the FXC-851 user guide is believed to be correct at the time of printing. We reserve the right to change or modify any information, product s pecifications, f eatures or functionality without notice. The contents of the FXC-851 user guide are provided “ as is. ” Certain features may not be activat ed by your service provider, and/or their network settings may limit the feature ’ s functionality. Additionally, certain features may require a subscription. Contact your service provider for details. . 2 CONTENTS SAFETY PRECAUTIONS 5 PRECAUTIONS 5 SAFETY INFORMATION 6 PACKAGE CONTENTS 9 PACKAGE CONTENTS 9 ABOUT YOUR PHONES 10 PHONE OVERVIEW 10 INSTALLATION 11 KEY FUNCTION 13 DISPLAY INDICATORS AND ICONS 15 BASIC FUNCTION 16 BASIC OPERATION 16 USING PHONE MENUS 19 ENTER LETTERS AND NUMBERS 20 MAIN MENU 22 OVERVIEW OF MENU TREE 22 THE CONTACTS 24 READ 24 ADD 25 MEMORY STATUS 25 SERVICE DIAL 25 SPEED DIAL 25 FIXED DIAL 25 COPY 26 CLEAR ALL RECORDS 26 GROUP 27 MY NUMBER 27 MESSAGE 28 WRITE NEW 28 INBOX 29 3 OUTBOX 29 DRAFTS 30 VOICEMAIL 30 BROADCAST MESSAGE 30 MESSAGE SETTINGS 30 TEMPLATE 31 MEMORY STATUS 31 DIAL RECORDS 32 INCOMING CALL 32 OUTGOING CALL 32 MISSED CALL 32 CALL OPTIONS 32 CALL DURATION 33 SETTINGS 34 PHONE SETTINGS 34 MELODY 35 DISPLAY 36 CALL SETUP 36 NETWORK SETUP 39 SECURITY SETUP 40 FACTORY DEFAULT 41 APPLICATIONS 42 ALARM 42 CALCULATOR 42 CALENDAR 43 TO DO LIST 43 REFERENCE INFORMATION 44 TECHNICAL INFORMATION 44 TROUBEL SHOOTING 45 WARRANTY 4 5 SAFETY PRECAUTIONS PRECAUTIONS 1. Please do not try to take out the SIM card of this phone. This SIM card is a special encrypt ca rd, it cannot be used in other mobile phones. It’s the warranty of the product, if you try to rip or remove the SIM Card, the warrant will be not valid and your product will not be warranty in any case. 2. Please do not turn around the antenna at will, in order to avoid create the damage of antenna. 3. Keep the phone away from water and damp areas. Water or other liquids may cause over heating, electrical leakage, and failure of the phone. 4. Do not try to disassemble the phone. This can cause electric shock and failu re of the phone. Tampering will also void the phone’s warranty. 5. Put the phone in a safe and stable place. 6. Keep away from dust and heat ra diation (i.e. microwaves, stoves, etc.) 7. Try to use the phone away from ordinary telephones, television sets, radios, and automated office equipment to avoi d interference between the devices. 8. Use clean soft dry cloth to wi pe the phone. Do not use any chemical agents. 9. Do not put the phone near explosive or inflammable materials. 10. Use the phone only within the temperature range of -20 °C ~60 °C and humidity range of 0%~90%. 11. Keep all accessories or batteries out of the reach of small Children or babies. Please instruct children the proper ways of handling phone during usage. Shock circuit or breakdown may occur and may cause severe danger to user due to improper usage. Shock circuit or breakdown may occur and may cause severe danger to user due to improper usage. 6 7 SAFETY INFORMATION 1. EXPOSURE TO RADIO FREQUENCY (RF) ENERGY  Your phone contains a transmitter and a re ceiver. When it is ON, it receives and also sends out radio frequency (R F) signals. When you communicate with your phone, the system handling y our call controls the power level at which your phone transmits.  Your phone is designed to comply with local regulatory requirements in your country concerning exposure of human beings to RF energy. 2. OPERATIONAL PRECAUTIONS  To assure optimal phone performance and make sure human exposure to RF energy is within the guidelines set fo rth in the relevant standards; always adhere to the following procedures. 3. EXTERNAL ANTENNA CARE  Use only the supplied Motorola approved antenna. Unauthorized antennas, modifications, or attachments could damage the phone.  Do NOT hold the antenna when the phone is IN USE. Holding the antenna affects call quality and may cause the phone to operate at a higher power level than needed. In addition, use of unauthorized antennas may result in non-compliance with the local regulator y requirements in your country. 4. PHONE OPERATION  When placing or receiving a phone call, hold your phone as you would use a wireless telephone.  To maintain compliance with RF energy exposure guidelines, ensure the phone antenna is at least 10 inches ( 25centimeters) from your body when transmitting. 8 5. APPROVED ACCESSORIES  Use of accessories not approved by Mo torola, including but not limited to batteries and antennas, may cause yo ur phone to exceed RF energy exposure guidelines. 6. RF ENERGY INTERFERENCE / COMPATIBILITIES  Nearly every electronic device is susc eptible to RF energy interference from external sources if inadequately shielded, designed, or otherwise configured for RF energy compatibility. In some circumstances your phone may cause interference. 7. MEDICAL DEVICES 1) Pacemakers Pacemaker manufacturers recommend that a minimum separation of 10 inches (25centimeters) be maintai ned between the fixed wireless phone and a pacemaker. Persons with pacemakers should: Always keep the phone more than 10 inc hes (25 centimeters) from your pacemaker when the phone is turned ON. Turn OFF the phone immediately if you have any reason to suspect that interference is taking place. 2) Hearing Aids Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you ma y want to con…

Text truncated - open the document above for the full version.

Date: March 22, 2010 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 Re: Brightstar Corporation FCC ID: WVB-FXC851 FCC Part 22&24 Certification Confidentiality Request Gentlemen: This letter is to comply with 47 CFR 0.457 and 0.459 pertaining to confidentiality material. Brightstar Corporation requests that the following documents regarding this submission for FCC ID: WVB-FXC851 be kept confidential: Exhibit Type File Name Block Diagram WVB-FXC851 _Block Diagram.pdf Schematics WVB-FXC851_Schematics.pdf Operational Description WVB-FXC851_Technical description.pdf Part list WVB-FXC851_BOM.pdf Those documents contain detailed system and equipment description and related information about the product which Brightstar Corporation considers to be confidential proprietary, a custom design and, otherwise, not releasable to the general public. Since this design is a basis form which future technological products will evolve, Brightstar Corporation considers this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market.

Brightstar Corporation Date: March 22, 2010 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: The Brightstar Corporation, the undersigned, hereby authorizes Mr. Wu Xuewen from Shenzhen Morlab Communications Technology Co., Ltd., to act on the behalf of the Brightstar Corporation solely in matters relating to the application for an FCC equipment authorization for FCC ID < WVB-FXC851 >including the signing of documents in connection with this Application. Necessary acts carried out by Brightstar Corporation on our behalf of the Brightstar Corporation in connection with the Application shall have the same effect as acts of the Brightstar Corporation. The Brightstar Corporation also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Thank you for your attention to this matter. Yours Sincerely,

External Photos 1. Front View of EUT 2. Back View of EUT 3. Side View of EUT

Internal Photos

Maximum RF Output Power： A. GSM850 1， Power up the headset and connect it with 8960 2， Set RF cable loss in 8960. 3， Set up 8960 cell band for GSM850; 128 is pilot channel ；radio configuration for （166channel, PCL 5). 4， Originate the call after the phone registration。 5， Select test item : digital average power 6， Rvs power ctrl set up ALL up bits 7， Set up Cell power -100dBm Receiver Sensitivity 1, Power up the headset and connect it with 8960 2,Set RF cable loss in 8960. 3,Set Set up 8960 cell band for GSM850; 128 is pilot channel ；radio configuration for （166channel, PCL 5). 4, Set up Cell power -102dBm 5,Originate the call after the phone registration。 6, Select test item : Frame Error Rate B. PCS1900 1， Power up the headset and connect it with 8960 2， Set RF cable loss in 8960. 3， Set up 8960 cell band for PCS1900; 512 is pilot channel ；radio configuration for （600 channel, PCL 05). 4， Originate the call after the phone registration。 5， Select test item : digital average power 6， Rvs power ctrl set up ALL up bits 7， Set up Cell power -100dBm Receiver Sensitivity 1, Power up the headset and connect it with 8960 2,Set RF cable loss in 8960. 3,Set Set up 8960 cell band for PCS1900; 512 is pilot channel ；radio configuration for （600 channel, PCL 0). 4, Set up Cell power -102dBm 5,Originate the call after the phone registration。 6, Select test item : Frame Error Rate

Report No.: SZ10010087S02 Page 2 of 131 Contents 1.GENERAL INFORMATION....................................................................................................3 1.1.Notes.........................................................................................................................................3 1.2.Organization item....................................................................................................................3 1.3.Conclusion................................................................................................................................3 2.TESTING LABORATORY.......................................................................................................4 2.1.Identification of the Responsible Testing Laboratory..........................................................4 2.2.Identification of the Responsible Testing Location..............................................................4 2.3.Accreditation Certificate........................................................................................................4 2.4.List of Test Equipments..........................................................................................................4 3.TECHNICAL INFORMATION ...............................................................................................5 3.1.Identification of Applicant......................................................................................................5 3.2.Identification of Manufacturer..............................................................................................5 3.3.Equipment Under Test (EUT)................................................................................................5 3.3.1.Photographs of the EUT..................................................................................................6 3.3.2.Identification of all used EUTs........................................................................................6 4.TEST RESULTS.........................................................................................................................6 4.1.Applied Reference Documents...............................................................................................6 4.2.Test Environment/Conditions................................................................................................7 4.3.Operational Conditions During Test.....................................................................................7 4.3.1.Informations On The Testing..........................................................................................8 4.3.2.The Measurement System.............................................................................................10 4.3.3.Uncertainty Assessment.................................................................................................12 4.4.MEASUREMENT PROCEDURES....................................................................................13 4.4.1.Procedures Used To Establish Test Signal....................................................................14 4.5.Items used in the Test Results List.......................................................................................15 4.6.Test Results List.....................................................................................................................16 ANNEX AACCREDITATION CERTIFICATE..........................................................................17 ANNEX BPHOTOGRAPHS OF THE EUT ................................................................................19 ANNEX CGRAPH TEST RESULTS ...........................................................................................22 Report No.: SZ10010087S02 Page 4 of 131 2. Testing Laboratory 2.1. Identification of the Responsible Testing Laboratory Company Name: Shenzhen Electronic Product Quality Testing Center Department: Morlab Laboratory Address: 3/F, Electronic Testing Building, Shahe Road, Nanshan District, Shenzhen, 518055 P. R. China Responsible Test Lab Manager: Mr. Shu Luan Telephone: +86 755 86130268 Facsimile: +86 755 86130218 2.2. Identification of the Responsible Testing Location Name: Shenzhen Electronic Product Quality Testing Center Morlab Laboratory Address: 3/F, Electronic Testing Building, Shahe Road, Nanshan District, Shenzhen, 518055 P. R. China 2.3. Accreditation Certificate Accredited Testing Laboratory: No. CNAS L1659 (see 0) 2.4. List of Test Equipments No. Instrument Type 1 PC Dell (Pentium IV 2.4GHz, SN:X10-23533) 2 Network Emulator Rohde&Schwarz (CMU200, SN:105894) 3 Voltmeter Keithley (2000, SN:1000572) 4 Synthetizer Rohde&Schwarz (SML_03, SN:101868) 5 Amplifier Nucl udes (ALB216, SN:10800) 6 Power Meter Rohde&Schwarz (NRVD, SN:101066) 7 Probe Antennessa (SN:SN_3708_EP80) 8 Phantom Antennessa (SN:SN_36_08_SAM62) 9 Liquid Antennessa (Last Calibration:21 08 04) Report No.: SZ10010087S02 Page 5 of 131 3. Technical Information Note: the following data is based on the information by the applicant. 3.1. Identification of Applicant Company Name: Brightstar Corporation Address: 9725 NW 117th Avenue, #300 Miami, FL 33178 3.2. Identification of Manufacturer Company Name: LAKIA Networks CO., LTD. Address: 2/F,Unit A, Technology Service Building, Software Garden, 1phase, Xiamen, Fujian, China Zip: 361005 3.3. Equipment Under Test (EUT) Brand Name: MOTOROLA Type Name: MOTOROLA Marking Name: FXC-851 Hardware Version: P4 Software Version: LKW_R20.07 Frequency Bands: GSM 850MHz (channel 128:824.20MHz,channel 190:836.59MHz, channel 251:848.29MHz) PCS 1900MHz (channel 512:1850.19MHz,channel 661:1880.00MHz, channel 810:1909.80MHz) Modulation Mode: GMSK Antenna type:Build inside Development Stage: Identical prototype Battery Model: 3̔AAA600mAh 3.6V Battery specification: 600mAh 3.7V Development Stage Identical prototype Report No.: SZ10010087S02 Page 6 of 131 3.3.1. Photographs of …

Text truncated - open the document above for the full version.

Report No.: SZ10010087E02 Page 2 of 41 TABLE OF CONTENTS 1. TEST CERTIFICATION ........................................................................................................... 3 2. GENERAL INFORMATION .................................................................................................... 4 2.1 EUT Description ......................................................................................................................... 4 2.2 Test Standards and Results........................................................................................................ 6 2.3 Facilities and Accreditations ..................................................................................................... 7 3. 47 CFR PART 2, PART 22H & 24E REQUIREMENTS ........................................................ 8 3.1 Frequencies ................................................................................................................................. 8 3.2 Conducted RF Output Power .................................................................................................. 12 3.3 99% Occupied Bandwidth ....................................................................................................... 16 3.4 Frequency Stability .................................................................................................................. 20 3.5 Conducted Out of Band Emissions ......................................................................................... 22 3.6 Band Edge ................................................................................................................................. 26 3.7 Transmitter Radiated Power (EIRP/ERP) ............................................................................. 29 3.8 Radiated Out of Band Emissions ............................................................................................ 35 Change History Issue Date Reason for change 1.0 March 03, 2010 First edition Report No.: SZ10010087E02 Page 4 of 41 2. GENERAL INFORMATION 2.1 EUT Description EUT Type ............................. : Cordless Fixed Wireless Phone Model Name ......................... : FXC-851 Serial No. .............................. : (n.a, marked #1 by test site) Hardware Version ................. : P4 Software Version .................. : LKW_R20.07 Frequency Range .................. : GSM 850MHz: Tx: 824.20 - 848.80MHz (at intervals of 200kHz); Rx: 869.20 - 893.80MHz (at intervals of 200kHz) GSM 1900MHz: Tx: 1850.20 - 1909.80MHz (at intervals of 200kHz); Rx: 1930.20 - 1989.80MHz (at intervals of 200kHz) Modulation Type................... : GMSK Emission Designators ........... : 300KGXW Power Supply ....................... : Battery Model Name: 3ｘAAA600mAh 3.6V Brand name: GREPOW Capacitance: 600mAh Rated voltage: 3.6V Manufacturer: Shenzhen Grepow Battery Co., Ltd Manufacturer Address: Wushigang Chuangyi Rd., Longhua Village, Bao An District, Shenzhen, P.R.China Ancillary Equipments ........... : AC Adapter (Charger for Battery) Model Name: IVP045-050-0600 Brand Name: Innov Serial No.: (n.a. marked #1 by test site) Rated Input: 100-240V, 0.2A, Max0.3W, 50/60Hz Rated Output: 5V, 0.6A, Max5.5W Manufacturer: Innov Electronics Tech Co., Ltd. Manufacturer Address: NO.1 XIANGHONG ROAD, HI-TECHINDUSTRI ZONE XIANG-AN, XIAMEN, CHINA Note 1: The transmitter (Tx) frequency arrangement of the Cellular 850MHz band used by the EUT can be represented with the formula F(n)=824.2+0.2*(n-128), 128<=n<=251; the lowest, middle, highest channel numbers (ARFCHs) used and tested in this report are separately 128 (824.2MHz), 190 (836.6MHz) and 251 (848.8MHz). Note 2: The transmitter (Tx) frequency arrangement of the PCS 1900MHz band used by the EUT can Report No.: SZ10010087E02 Page 5 of 41 be represented with the formula F(n)=1850.2+0.2*(n-512), 512<=n<=810; the lowest, middle and highest channel numbers (ARFCHs) used and tested in this report are separately 512 (1850.2MHz), 661 (1880.0MHz) and 810 (1909.8MHz). Note 3: For a more detailed description, please refer to Specification or User’s Manual supplied by the applicant and/or manufacturer. Report No.: SZ10010087E02 Page 6 of 41 2.2 Test Standards and Results The objective of the report is to perform testing according to 47 CFR Part 2, Part 22 and Part 24 for the EUT FCC ID Certification: No. Identity Document Title 1 47 CFR Part 2 (10-1-05 Edition) Frequency Allocations and Radio Treaty Matters; General Rules and Regulations 2 47 CFR Part 22 (10-1-05 Edition) Public Mobile Services 3 47 CFR Part 24 (10-1-05 Edition) Personal Communications Services Test detailed items/section required by FCC rules and results are as below: No. Section Description Result 1 2.106 22.905 24.229 Frequencies PASS 2 2.1046 Conducted RF Output Power PASS 3 2.1049 20dB Occupied Bandwidth PASS 4 2.1055 22.355 24.235 Frequency Stability PASS 5 2.1051 2.1057 22.917 24.238 Conducted Out of Band Emissions PASS 6 2.1051 2.1057 22.917 24.238 Band Edge PASS 7 22.913 24.232 Transmitter Radiated Power (EIPR/ERP) PASS 8 2.1053 2.1057 22.917 24.238 Radiated Out of Band Emissions PASS Report No.: SZ10010087E02 Page 7 of 41 2.3 Facilities and Accreditations 2.3.1 Facilities Shenzhen Electronic Product Quality Testing Center Morlab Laboratory is a testing organization accredited by China National Accreditation Service for Conformity Assessment (CNAS) according to ISO/IEC 17025. The accreditation certificate number is L1659. All measurement facilities used to collect the measurement data are located at Electronic Testing Building, Shahe Road, Xili, Nanshan District, Shenzhen 518055 CHINA. The test site is constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 and CISPR Publication 22; the FCC registration number is 741109. 2.3.2 Test Environment Conditions During the measurement, the environmental conditions were within the listed ranges: Temperature (°C): 20 - 25 Relative Humidity (%): 40 - 60 Atmosp…

Text truncated - open the document above for the full version.

Test Setup Photos 1. CSE 2. RSE
