User Manual For （Avvio 418S/ Avvio 418） Dear customer: Thank you for choosing this mobile phone. This mobile phone incorporates the latest world advanced functions, enabling simple and convenient operation, satisfying your special requirements. The mobile phone supports T-FLASH (memory) card and Dual SIM standby(Avvio 418S). It integrates the following available functions: SMS, MMS, MP3, MP4, Camera, FM radio, Alarm, Video recorder and Calendar, enabling you arranging your work, study and life freely; with long standby duration, as well as service, your communication will be easier and smoother; powerful file manager allows you to manage the files conveniently. In addition, the chord ringtone allows you selecting music to set as ringtone; the personalized appearance also can satisfy your selection. Note: User Manual is used to guide the user about the functionality of the phone. Some functions may vary due to modifications and upgrades of software or due to print mistakes. 2 Contents Safety precautions ........................................................................................................................... 4 About the phone .............................................................................................................................. 5 Display settings ............................................................................................................................. 5 Keys Functions .............................................................................................................................. 5 Status Icons ................................................................................................................................... 6 Getting started ................................................................................................................................. 7 First call ........................................................................................................................................ 7 Installing the SIM card .................................................................................................................. 7 Installing memory card ................................................................................................................. 8 Battery and charging ..................................................................................................................... 8 Installing the battery .................................................................................................................. 8 Charging the battery .................................................................................................................. 8 Battery status ............................................................................................................................. 8 Using battery ............................................................................................................................. 9 Switching on/off .......................................................................................................................... 10 Password ..................................................................................................................................... 10 Phone password....................................................................................................................... 10 SIM1 PIN ................................................................................................................................ 10 SIM2 PIN ................................................................................................................................ 11 Disabling password ................................................................................................................. 11 Using handsfree kit ..................................................................................................................... 11 Keypad lock ................................................................................................................................ 11 Number keys ............................................................................................................................... 12 Language and input methods ...................................................................................................... 12 Noun ............................................................................................................................................ 12 Making a DDD ........................................................................................................................ 12 Making an IDD ....................................................................................................................... 13 Calling extension..................................................................................................................... 13 Emergency call ........................................................................................................................ 13 IMEI ........................................................................................................................................ 13 Calling ............................................................................................................................................ 13 Making Calls ............................................................................................................................... 14 Make an International Call .......................................................................................................... 14 Dial Extension ............................................................................................................................. 14 Making a call from the phonebook ............................................................................................. 14 Recent Numbers Redial ..............…

Text truncated - open the document above for the full version.

Photographs of EUT Report No.: EP2N1501 Brand Name: Avvio; Model Name: Avvio 418S /Avvio 418 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 1 of 28 TEL : 86-0512-5790-0158 Report Issued Date : Nov. 29, 2012 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : WVBA418S 1. External Photograph of EUT Photographs of EUT Report No.: EP2N1501 Brand Name: Avvio; Model Name: Avvio 418S /Avvio 418 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 2 of 28 TEL : 86-0512-5790-0158 Report Issued Date : Nov. 29, 2012 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : WVBA418S Photographs of EUT Report No.: EP2N1501 Brand Name: Avvio; Model Name: Avvio 418S /Avvio 418 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 3 of 28 TEL : 86-0512-5790-0158 Report Issued Date : Nov. 29, 2012 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : WVBA418S Photographs of EUT Report No.: EP2N1501 Brand Name: Avvio; Model Name: Avvio 418S /Avvio 418 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 4 of 28 TEL : 86-0512-5790-0158 Report Issued Date : Nov. 29, 2012 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : WVBA418S Photographs of EUT Report No.: EP2N1501 Brand Name: Avvio; Model Name: Avvio 418S /Avvio 418 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 5 of 28 TEL : 86-0512-5790-0158 Report Issued Date : Nov. 29, 2012 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : WVBA418S Photographs of EUT Report No.: EP2N1501 Brand Name: Avvio; Model Name: Avvio 418S /Avvio 418 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 6 of 28 TEL : 86-0512-5790-0158 Report Issued Date : Nov. 29, 2012 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : WVBA418S Photographs of EUT Report No.: EP2N1501 Brand Name: Avvio; Model Name: Avvio 418S /Avvio 418 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 7 of 28 TEL : 86-0512-5790-0158 Report Issued Date : Nov. 29, 2012 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : WVBA418S List of Accessory: Specification of Accessory AC Adapter Brand Name Avvio Model Name GQ07-050050-BU Battery Brand Name Avvio Model Name BL-4C Earphone Brand Name N/A Model Name N/A Signal Line Type 1.06m, non-shielded cable USB Cable Brand Name N/A Model Name N/A Signal Line Type 0.9m, shielded cable, without core Remark: For accessories equipped with this EUT, please refer to the following photos. 2. Photograph of Accessory Photographs of EUT Report No.: EP2N1501 Brand Name: Avvio; Model Name: Avvio 418S /Avvio 418 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 8 of 28 TEL : 86-0512-5790-0158 Report Issued Date : Nov. 29, 2012 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : WVBA418S Photographs of EUT Report No.: EP2N1501 Brand Name: Avvio; Model Name: Avvio 418S /Avvio 418 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 9 of 28 TEL : 86-0512-5790-0158 Report Issued Date : Nov. 29, 2012 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : WVBA418S AC Adapter Photographs of EUT Report No.: EP2N1501 Brand Name: Avvio; Model Name: Avvio 418S /Avvio 418 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 10 of 28 TEL : 86-0512-5790-0158 Report Issued Date : Nov. 29, 2012 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : WVBA418S Battery Photographs of EUT Report No.: EP2N1501 Brand Name: Avvio; Model Name: Avvio 418S /Avvio 418 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 11 of 28 TEL : 86-0512-5790-0158 Report Issued Date : Nov. 29, 2012 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : WVBA418S

Photographs of EUT Report No.: EP2N1501 Brand Name: Avvio; Model Name: Avvio 418S /Avvio 418 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 12 of 28 TEL : 86-0512-5790-0158 Report Issued Date : Nov. 29, 2012 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : WVBA418S 3. Internal Photograph of EUT Sample 1 for Dual Card WWAN Antenna Bluetooth Antenna Photographs of EUT Report No.: EP2N1501 Brand Name: Avvio; Model Name: Avvio 418S /Avvio 418 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 13 of 28 TEL : 86-0512-5790-0158 Report Issued Date : Nov. 29, 2012 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : WVBA418S Photographs of EUT Report No.: EP2N1501 Brand Name: Avvio; Model Name: Avvio 418S /Avvio 418 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 14 of 28 TEL : 86-0512-5790-0158 Report Issued Date : Nov. 29, 2012 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : WVBA418S Photographs of EUT Report No.: EP2N1501 Brand Name: Avvio; Model Name: Avvio 418S /Avvio 418 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 15 of 28 TEL : 86-0512-5790-0158 Report Issued Date : Nov. 29, 2012 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : WVBA418S Photographs of EUT Report No.: EP2N1501 Brand Name: Avvio; Model Name: Avvio 418S /Avvio 418 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 16 of 28 TEL : 86-0512-5790-0158 Report Issued Date : Nov. 29, 2012 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : WVBA418S Photographs of EUT Report No.: EP2N1501 Brand Name: Avvio; Model Name: Avvio 418S /Avvio 418 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 17 of 28 TEL : 86-0512-5790-0158 Report Issued Date : Nov. 29, 2012 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : WVBA418S Photographs of EUT Report No.: EP2N1501 Brand Name: Avvio; Model Name: Avvio 418S /Avvio 418 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 18 of 28 TEL : 86-0512-5790-0158 Report Issued Date : Nov. 29, 2012 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : WVBA418S Photographs of EUT Report No.: EP2N1501 Brand Name: Avvio; Model Name: Avvio 418S /Avvio 418 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 19 of 28 TEL : 86-0512-5790-0158 Report Issued Date : Nov. 29, 2012 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : WVBA418S Photographs of EUT Report No.: EP2N1501 Brand Name: Avvio; Model Name: Avvio 418S /Avvio 418 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 20 of 28 TEL : 86-0512-5790-0158 Report Issued Date : Nov. 29, 2012 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : WVBA418S Sample 2 for Single Card WWAN Antenna Bluetooth Antenna Photographs of EUT Report No.: EP2N1501 Brand Name: Avvio; Model Name: Avvio 418S /Avvio 418 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 21 of 28 TEL : 86-0512-5790-0158 Report Issued Date : Nov. 29, 2012 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : WVBA418S Photographs of EUT Report No.: EP2N1501 Brand Name: Avvio; Model Name: Avvio 418S /Avvio 418 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 22 of 28 TEL : 86-0512-5790-0158 Report Issued Date : Nov. 29, 2012 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : WVBA418S Photographs of EUT Report No.: EP2N1501 Brand Name: Avvio; Model Name: Avvio 418S /Avvio 418 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 23 of 28 TEL : 86-0512-5790-0158 Report Issued Date : Nov. 29, 2012 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : WVBA418S Photographs of EUT Report No.: EP2N1501 Brand Name: Avvio; Model Name: Avvio 418S /Avvio 418 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 24 of 28 TEL : 86-0512-5790-0158 Report Issued Date : Nov. 29, 2012 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : WVBA418S Photographs of EUT Report No.: EP2N1501 Brand Name: Avvio; Model Name: Avvio 418S /Avvio 418 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 25 of 28 TEL : 86-0512-5790-0158 Report Issued Date : Nov. 29, 2012 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : WVBA418S Photographs of EUT Report No.: EP2N1501 Brand Name: Avvio; Model Name: Avvio 418S /Avvio 418 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 26 of 28 TEL : 86-0512-5790-0158 Report Issued Date : Nov. 29, 2012 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : WVBA418S Photographs of EUT Report No.: EP2N1501 Brand Name: Avvio; Model Name: Avvio 418S /Avvio 418 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 27 of 28 TEL : 86-0512-5790-0158 Report Issued Date : Nov. 29, 2012 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : WVBA418S WWAN Antenna <Tx / Rx> Photographs of EUT Report No.: EP2N1501 Brand Name: Avvio; Model Name: Avvio 418S /Avvio 418 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 28 of 28 TEL : 86-0512-5790-0158 Report Issued Date : Nov. 29, 2012 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : WVBA418S Bluetooth Antenna <Tx / Rx>

SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 1 of 30 TEL : 86-755-8637-9589 Report Issued Date : Nov. 29, 2012 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : WVBA418S FCC SAR Test Report Report No. : FA2N1501 FCC SAR Test Report APPLICANT : Brightstar Coporation EQUIPMENT : GSM mobile phone BRAND NAME : Avvio MODEL NAME : Avvio 418S/ Avvio 418 MARKETING NAME : Avvio 418S/ Avvio 418 FCC ID : WVBA418S STANDARD : FCC 47 CFR Part 2 (2.1093) ANSI/IEEE C95.1-1992 IEEE 1528-2003 FCC OET Bulletin 65 Supplement C (Edition 01-01) The product was completely tested on Nov. 26, 2012. We, SPORTON INTERNATIONAL (SHENZHEN) INC., would like to declare that the tested sample has been evaluated in accordance with the procedures and shown the compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL (SHENZHEN) INC., the test report shall not be reproduced except in full. Reviewed by: Jones Tsai / Manager SPORTON INTERNATIONAL (SHENZHEN) INC. No. 101, Complex Building C, Guanglong Village, Xili Town, Nanshan District, Shenzhen, Guangdong, P.R.C. SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 2 of 30 TEL : 86-755-8637-9589 Report Issued Date : Nov. 29, 2012 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : WVBA418S FCC SAR Test Report Report No. : FA2N1501 Table of Contents 1. Statement of Compliance ..............................................................................................................................................4 2. Administration Data .......................................................................................................................................................5 2.1 Testing Laboratory ...................................................................................................................................................5 2.2 Applicant .................................................................................................................................................................5 2.3 Manufacturer ...........................................................................................................................................................5 2.4 Application Details ...................................................................................................................................................5 3. General Information .......................................................................................................................................................6 3.1 Description of Equipment Under Test (EUT) ...........................................................................................................6 3.2 Product Photos .......................................................................................................................................................7 3.3 Applied Standard .....................................................................................................................................................7 3.4 Device Category and SAR Limits ............................................................................................................................7 3.5 Test Conditions ........................................................................................................................................................7 4. Specific Absorption Rate (SAR) ....................................................................................................................................8 4.1 Introduction .............................................................................................................................................................8 4.2 SAR Definition .........................................................................................................................................................8 5. SAR Measurement System ............................................................................................................................................9 5.1 E-Field Probe ........................................................................................................................................................10 5.2 Data Acquisition Electronics (DAE) .......................................................................................................................10 5.3 Robot .................................................................................................................................................................... 11 5.4 Measurement Server ............................................................................................................................................. 11 5.5 Phantom ................................................................................................................................................................12 5.6 Device Holder .......................................................................................................................................................12 5.7 Data Storage and Evaluation ................................................................................................................................13 5.8 Test Equipment List ...............................................................................................................................................15 6. Tissue Simulating Liquids ...........................................................................................................................................16 7. SAR Measurement Evaluation ....................................................................................................................................17 7.1 Purpose of System Performance check ...................................................................................................…

Text truncated - open the document above for the full version.

SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : C1 of C1 TEL : 86-755-8637-9589 Report Issued Date : Nov. 29, 2012 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : WVBA418S FCC SAR Test Report Report No. : FA2N1501 Appendix C. DASY Calibration Certificate The DASY calibration certificates are shown as follows. SPORTON INTERNATIONAL (SHENZHEN) INC. TEL : 86-755-8637-9589 FAX : 86-755-8637-9595 FCC Test Report D835V2, serial No. 4d091 Extended Dipole Calibrations Referring to KDB 450824, if dipoles are verified in return loss (<-20dB, within 20% of prior calibration), and in impedance (within 5 ohm of prior calibration), the annual calibration is not necessary and the calibration interval can be extended. <Justification of the extended calibration> D835V2 – serial no. 4d091 ʳ 835 Head 835 Body Date of Measurement Return-Loss (dB) Delta (%) Real Impedance (ohm) Delta (ohm) Imaginary Impedance (ohm) Delta (ohm) Return-Loss (dB) Delta (%) Real Impedance (ohm) Delta (ohm) Imaginary Impedance (ohm) Delta (ohm) 11.18.2011 -25.734 ʳ 50.867 ʳ -5.1504ʳ -22.318 ʳ47.082 ʳ -6.8594ʳ 11.17.2012 -25.917 0.7149.7731.09-5.13290.02 -22.4660.6648.683 1.60 -6.35980.50 The return loss is < -20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. SPORTON INTERNATIONAL (SHENZHEN) INC. TEL : 86-755-8637-9589 FAX : 86-755-8637-9595 FCC Test Report <Dipole Verification Data> - D835V2, serial no. 4d091 835MHz - Head 835MHz – Body SPORTON INTERNATIONAL (SHENZHEN) INC. TEL : 86-755-8637-9589 FAX : 86-755-8637-9595 FCC Test Report D1900V2, serial no. 5d118 Extended Dipole Calibrations Referring to KDB 450824, if dipoles are verified in return loss (<-20dB, within 20% of prior calibration), and in impedance (within 5 ohm of prior calibration), the annual calibration is not necessary and the calibration interval can be extended. <Justification of the extended calibration> D1900V2 – serial no. 5d118 ʳ 1900 Head 1900 Body Date of Measurement Return-Loss (dB) Delta (%) Real Impedance (ohm) Delta (ohm) Imaginary Impedance (ohm) Delta (ohm) Return-Los s (dB) Delta (%) Real Impedance (ohm) Delta (ohm) Imaginary Impedance (ohm) Delta (ohm) 11.21.2011 -22.535 ʳ 53.449 ʳ 6.9277ʳ-22.401 ʳ47.82 ʳ 7.1133ʳ ʳ11.17.2012 -22.603 0.3053.491 -0.047.10090.17-22.45 0.2246.14 -1.68 6.7234-0.39 The return loss is < -20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. SPORTON INTERNATIONAL (SHENZHEN) INC. TEL : 86-755-8637-9589 FAX : 86-755-8637-9595 FCC Test Report <Dipole Verification Data>- D1900V2, serial no. 5d118 1900MHz – Head 1900MHz - Body

SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 1 of 50 TEL : 86-0512-5790-0158 Report Issued Date : Nov. 29, 2012 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : WVBA418S FCC RF Test Report Report No. : FG2N1501 FCC RF Test Report APPLICANT : Brightstar Coporation EQUIPMENT : GSM mobile phone BRAND NAME : Avvio MODEL NAME : Avvio 418S/ Avvio 418 MARKETING NAME : Avvio 418S/ Avvio 418 FCC ID : WVBA418S STANDARD : FCC 47 CFR Part 2, 22(H), 24(E) CLASSIFICATION : PCS Licensed Transmitter Held to Ear (PCE) The product was received on Nov. 15, 2012 and completely tested on Nov. 24, 2012. We, SPORTON INTERNATIONAL (KUNSHAN) INC., would like to declare that the tested sample has been evaluated in accordance with the procedures given in ANSI / TIA / EIA-603-C-2004 and shown compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL (KUNSHAN) INC., the test report shall not be reproduced except in full. Reviewed by: Jones Tsai / Manager SPORTON INTERNATIONAL (KUNSHAN) INC. No. 3-2, PingXiang Road, Kunshan, Jiangsu Province, P.R.C. SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 2 of 50 TEL : 86-0512-5790-0158 Report Issued Date : Nov. 29, 2012 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : WVBA418S FCC RF Test Report Report No. : FG2N1501 TABLE OF CONTENTS REVISION HISTORY .......................................................................................................................................... 3 SUMMARY OF TEST RESULT ......................................................................................................................... 4 1 GENERAL DESCRIPTION .......................................................................................................................... 5 1.1 Applicant ............................................................................................................................................ 5 1.2 Manufacturer ..................................................................................................................................... 5 1.3 Feature of Equipment Under Test ..................................................................................................... 6 1.4 Maximum ERP/EIRP Power, Frequency Tolerance, and Emission Designator ............................... 7 1.5 Testing Site ....................................................................................................................................... 7 1.6 Applied Standards ............................................................................................................................. 7 1.7 Ancillary Equipment List .................................................................................................................... 7 2 TEST CONFIGURATION OF EQUIPMENT UNDER TEST ........................................................................ 8 2.1 Test Mode.......................................................................................................................................... 8 2.2 Connection Diagram of Test System ................................................................................................ 9 3 TEST RESULT ........................................................................................................................................... 10 3.1 Conducted Output Power Measurement ......................................................................................... 10 3.2 Peak-to-Average Ratio .................................................................................................................... 12 3.3 Effective Radiated Power and Effective Isotropic Radiated Power Measurement ......................... 16 3.4 Occupied Bandwidth and 26dB Bandwidth Measurement .............................................................. 19 3.5 Band Edge Measurement ................................................................................................................ 27 3.6 Conducted Spurious Emission Measurement ................................................................................. 32 3.7 Field Strength of Spurious Radiation Measurement ....................................................................... 38 3.8 Frequency Stability Measurement ................................................................................................... 45 4 LIST OF MEASURING EQUIPMENT ........................................................................................................ 49 5 UNCERTAINTY OF EVALUATION ........................................................................................................... 50 APPENDIX A. PHOTOGRAPHS OF EUT APPENDIX B. SETUP PHOTOGRAPHS SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 3 of 50 TEL : 86-0512-5790-0158 Report Issued Date : Nov. 29, 2012 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : WVBA418S FCC RF Test Report Report No. : FG2N1501 REVISION HISTORY REPORT NO. VERSION DESCRIPTION ISSUED DATE FG2N1501 Rev. 01 Initial issue of report Nov. 29, 2012 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 4 of 50 TEL : 86-0512-5790-0158 Report Issued Date : Nov. 29, 2012 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : WVBA418S FCC RF Test Report Report No. : FG2N1501 SUMMARY OF TEST RESULT Report Section FCC Rule IC Rule Description Limit Result Remark 3.1 §2.1046 N/A Conducted Output Power N/A PASS - 3.2 §24.232(d) N/A Peak-to-Average Ratio < 13 dB PASS - 3.3 §22.913(a)(2) RSS-132(4.4) SRSP-503(5.1.3) Effective Radiated Power < 7 Watts PASS - 3.3 §24.232(c) RSS-133 (6.4) SRSP-510(5.1.2) Equivalent Isotropic Radiated Power < 2 Watts PASS - 3.4 §2.1049 §22.917(a) §24.238(a) N/A Occupied BandwidthN/A PASS - 3.5 §2.1051 §22.917(a) §24.238(a) RSS-132 (4.5.1) RSS-133 (6.5.1) Band Edge Measurement < 43+10log 10 (P[Watts]) PASS - 3.6 §2.1051 §22.917(a) §24.238(a) …

Text truncated - open the document above for the full version.

SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : B1 of B2 TEL : 86-0512-5790-0158 Report Issued Date : Nov. 29, 2012 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : WVBA418S FCC RF Test Report Report No. : FG2N1501 Appendix B. Setup Photographs <Radiated Emission> H-Plane LF HF SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : B2 of B2 TEL : 86-0512-5790-0158 Report Issued Date : Nov. 29, 2012 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : WVBA418S FCC RF Test Report Report No. : FG2N1501 E2-Plane LF HF

SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : D1 of D2 TEL : 86-755-8637-9589 Report Issued Date : Nov. 29, 2012 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : WVBA418S FCC SAR Test Report Report No. : FA2N1501 A…
