SPORTON INTERNATIONAL (XI’AN) INC. Page Number : 1 of 53 TEL : 86-029-8860-8767 Report Issued Date : Sep. 13, 2013 FCC ID : WVBA785X Report Version : Rev. 01 FCC SAR Test Report Report No. : FA381604 FCC SAR Test Report APPLICANT : Brightstar Corporation EQUIPMENT : Mobile Phone BRAND NAME : Avvio MODEL NAME : Avvio 785S/Avvio 785 FCC ID : WVBA785X STANDARD : FCC 47 CFR Part 2 (2.1093) ANSI/IEEE C95.1-1992 IEEE 1528-2003 The product was tested on Sep. 08, 2013. We, SPORTON INTERNATIONAL (XI’AN) INC., would like to declare that the tested sample has been evaluated in accordance with the procedures and shown the compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL (XI’AN) INC., the test report shall not be reproduced except in full. SPORTON INTERNATIONAL (XI’AN) INC. 1F, Building A3, No. 39 Chuangye Rd., Xi'an Hi-teck Zone, Shanxi Province, P.R.C. Approved by: Jones Tsai / Manager Reviewed by: Eric Huang / Deputy Manager SPORTON INTERNATIONAL (XI’AN) INC. Page Number : 2 of 53 TEL : 86-029-8860-8767 Report Issued Date : Sep. 13, 2013 FCC ID : WVBA785X Report Version : Rev. 01 FCC SAR Test Report Report No. : FA381604 Table of Contents 1. Statement of Compliance ..............................................................................................................................................4 2. Administration Data .......................................................................................................................................................5 2.1 Testing Laboratory ...................................................................................................................................................5 2.2 Applicant .................................................................................................................................................................5 2.3 Manufacturer ...........................................................................................................................................................5 2.4 Application Details ...................................................................................................................................................5 3. General Information .......................................................................................................................................................6 3.1 Description of Equipment Under Test (EUT) ...........................................................................................................6 3.2 Maximum RF output power among production units ...............................................................................................7 3.3 Applied Standard .....................................................................................................................................................8 3.4 Device Category and SAR Limits ............................................................................................................................8 3.5 Test Conditions ........................................................................................................................................................8 4. Specific Absorption Rate (SAR) ....................................................................................................................................9 4.1 Introduction .............................................................................................................................................................9 4.2 SAR Definition .........................................................................................................................................................9 5. SAR Measurement System ..........................................................................................................................................10 5.1 E-Field Probe ........................................................................................................................................................ 11 5.2 Data Acquisition Electronics (DAE) ....................................................................................................................... 11 5.3 Robot ....................................................................................................................................................................12 5.4 Measurement Server .............................................................................................................................................12 5.5 Phantom ................................................................................................................................................................13 5.6 Device Holder .......................................................................................................................................................13 5.7 Data Storage and Evaluation ................................................................................................................................14 5.8 Test Equipment List ...............................................................................................................................................16 6. Tissue Simulating Liquids ...........................................................................................................................................17 7. System Verification Procedures .................................................................................................................................18 7.1 Purpose of System Performance check ................................................................................................................18 7.2 System Setup .........................................................................................................................................…

Text truncated - open the document above for the full version.

SPORTON INTERNATIONAL (XI’AN) INC. Page Number : A1 of A1 TEL : 86-029-8860-8767 Report Issued Date : Sep. 13, 2013 FCC ID : WVBA785X Report Version : Rev. 01 FCC SAR Test Report Report No. : FA381604 Appendix A. Plots of System Performance Check The plots are shown as follows. TestLaboratory: Sporton International Inc. SAR/HAC TestingLab Date: 2013.09.08 System Check_Head_835MHz_130908 DUT: D835V2 - SN: 4d151 Communication System: CW;Frequency: 835 MHz;Duty Cycle: 1:1 Medium: HSL_835_130908 Medium parameters used: f = 835 MHz; σ = 0.88 S/m; ε r = 42.104; ρ = 1000 kg/m 3 Ambient Temperature：23.6 °C; Liquid Temperature：22.7 °C DASY5 Configuration: - Probe: EX3DV4 - SN3911; ConvF(10.05, 10.05, 10.05); Calibrated: 2013.04.11; - Sensor-Surface: 2mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1358; Calibrated: 2013.04.08 - Phantom: SAM 1; Type: QD 000 P40 C; Serial: TP-1753 - Measurement SW: DASY52, Version 52.8 (6); SEMCAD X Version 14.6.9 (7117) Pin=250mW/Area Scan (61x61x1): Interpolated grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 2.82 W/kg Pin=250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 56.779 V/m; Power Drift = -0.10 dB Peak SAR (extrapolated) = 3.33 W/kg SAR(1 g) = 2.23 W/kg; SAR(10 g) = 1.47 W/kg Maximum value of SAR (measured) = 2.82 W/kg 0 dB = 2.82 W/kg TestLaboratory: Sporton International Inc. SAR/HAC TestingLab Date: 2013.09.07 System Check_Head_1900MHz_130907 DUT: D1900V2 - SN: 5d170 Communication System: CW;Frequency: 1900 MHz;Duty Cycle: 1:1 Medium: HSL_1900_130907 Medium parameters used: f = 1900 MHz; σ = 1.44 S/m; ε r = 39.914; ρ = 1000 kg/m 3 Ambient Temperature：23.6 °C; Liquid Temperature：22.5 °C DASY5 Configuration: - Probe: EX3DV4 - SN3911; ConvF(8.25, 8.25, 8.25); Calibrated: 2013.04.11; - Sensor-Surface: 2mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1358; Calibrated: 2013.04.08 - Phantom: SAM 2; Type: QD 000 P40 C; Serial: TP-1754 - Measurement SW: DASY52, Version 52.8 (6); SEMCAD X Version 14.6.9 (7117) Pin=250mW/Area Scan (61x61x1): Interpolated grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 14.4 W/kg Pin=250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 100.3 V/m; Power Drift = -0.01 dB Peak SAR (extrapolated) = 18.0 W/kg SAR(1 g) = 9.84 W/kg; SAR(10 g) = 5.12 W/kg Maximum value of SAR (measured) = 13.9 W/kg 0 dB = 13.9 W/kg TestLaboratory: Sporton International Inc. SAR/HAC TestingLab Date: 2013.09.08 System Check_Head_2450MHz_130908 DUT: D2450V2 - SN: 908 Communication System: CW;Frequency: 2450 MHz;Duty Cycle: 1:1 Medium: HSL_2450_130908 Medium parameters used: f = 2450 MHz; σ = 1.851 S/m; ε r = 37.615; ρ = 1000 kg/m 3 Ambient Temperature：23.5 °C; Liquid Temperature：22.6 °C DASY5 Configuration: - Probe: EX3DV4 - SN3911; ConvF(7.22, 7.22, 7.22); Calibrated: 2013.04.11; - Sensor-Surface: 2mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1358; Calibrated: 2013.04.08 - Phantom: SAM 2; Type: QD 000 P40 C; Serial: TP-1754 - Measurement SW: DASY52, Version 52.8 (6); SEMCAD X Version 14.6.9 (7117) Pin=250mW/Area Scan (71x81x1): Interpolated grid: dx=12mm, dy=12mm Maximum value of SAR (interpolated) = 21.3 W/kg Pin=250mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 107.5 V/m; Power Drift = -0.02 dB Peak SAR (extrapolated) = 29.1 W/kg SAR(1 g) = 13.40 W/kg; SAR(10 g) = 6.01 W/kg Maximum value of SAR (measured) = 21.0 W/kg 0 dB = 21.0 W/kg TestLaboratory: Sporton International Inc. SAR/HAC TestingLab Date: 2013.09.04 System Check_Body_835MHz_130904 DUT: D835V2 - SN: 4d151 Communication System: CW;Frequency: 835 MHz;Duty Cycle: 1:1 Medium: MSL_835_130904 Medium parameters used: f = 835 MHz; σ = 0.974 S/m; ε r = 54.266; ρ = 1000 kg/m 3 Ambient Temperature：23.6 °C; Liquid Temperature：22.6 °C DASY5 Configuration: - Probe: EX3DV4 - SN3911; ConvF(9.93, 9.93, 9.93); Calibrated: 2013.04.11; - Sensor-Surface: 2mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1358; Calibrated: 2013.04.08 - Phantom: SAM 1; Type: QD 000 P40 C; Serial: TP-1753 - Measurement SW: DASY52, Version 52.8 (6); SEMCAD X Version 14.6.9 (7117) Pin=250mW/Area Scan (61x61x1): Interpolated grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 2.90 W/kg Pin=250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 55.022 V/m; Power Drift = -0.06 dB Peak SAR (extrapolated) = 3.35 W/kg SAR(1 g) = 2.30 W/kg; SAR(10 g) = 1.52 W/kg Maximum value of SAR (measured) = 2.87 W/kg 0 dB = 2.87 W/kg TestLaboratory: Sporton International Inc. SAR/HAC TestingLab Date: 2013.09.04 System Check_Body_1900MHz_130904 DUT: D1900V2 - SN: 5d170 Communication System: CW;Frequency: 1900 MHz;Duty Cycle: 1:1 Medium: MSL_1900_130904 Medium parameters used: f = 1900 MHz; σ = 1.532 S/m; ε r = 52.397; ρ = 1000 kg/m 3 Ambient Temperature：23.6 °C; Liquid Temperature：22.7 °C DASY5 Configuration: - Probe: EX3DV4 - SN3911; ConvF(7.7, 7.7, 7.7); Calibrated: 2013.04.11; - Sensor-Surface: 2mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1358; Calibrated: 2013.04.08 - Phantom: SAM 2; Type: QD 000 P40 C; Serial: TP-1754 - Measurement SW: DASY52, Version 52.8 (6)…
