WYR-EDS-1389Wireless 802.11n Multi-functional Storage Router

WiDRIVE DX-325 User’s Guide Copyright © 2010 EDSLAB Tech. Inc. User’s Manual Wireless 802.11n Multi-functional Storage Router DX-325 Version 0.4 WiDRIVE DX-325 User’s Guide Copyright © 2010 EDSLAB Tech. Inc. ii Table of Contents Declarations, disclaimers, instructions of guidings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii Safety and care instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iv 1 Understand Your WiDRIVE . . . . . . . . . . . . . . . . . . . . . . . . . .1 Overview of Your WiDRIVE DX-325 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 Package Content . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 The LED Status Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 Understand the LED indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 Power on Your WiDRIVE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 Shutdown Your WiDRIVE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 Mode Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 2 Setup Your WiDRIVE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 HDD Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 Connecting WiDRIVE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 3 WiDRIVE Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 Install your WiDRIVE Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 To search and operate your WiDRIVE through Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 4 WiDRIVE Web Control . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 Login . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 Overview of WiDRIVE Web Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 My Folder (Disk Management) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 Working with Folders and Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12 Quick Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15 BitTorrent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16 System Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18 Account Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22 System Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 5 WiDRIVE Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . .27 The Default Applications in your WiDRIVE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27 6 Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29 7 Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . .30 FCC Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30 CE Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30 8 Trouble Shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32 9 Contact Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33 WiDRIVE DX-325 User’s Guide Copyright © 2010 EDSLAB Tech. Inc. iii Declarations, disclaimers, instructions of guidings Note, Notice, Caution symbols among the user manual NOTE! Provides extra information for better use of the products. Notice! Indicates behaviours that might cause a potential data loss on WiDRIVE or on the device that con- nects to it. Caution! Indicates behaviours that might cause damage on product, human injury, or death. Declaration Information in this document is subject to change without notice or obligation. Copyright © 2010 EDSLAB Technologies Inc. All rights reserved. Disclaimer Any loss, corruption or destruction of data while using a WiDRIVE is the sole responsibility of the user, and under no circumstances will EDSLAB be held liable for the recovery or restoration of this data. To help prevent the loss of your data, EDSLAB highly recommends that you at least keep one copy of your data. For example, you can save the copy either on your internal hard disk or portable storage media. WiDRIVE DX-325 User’s Guide Copyright © 2010 EDSLAB Tech. Inc. iv Safety and care instructions Please read the following safety information prior to using WiDRIVE. • Only qualified personnel should service WiDRIVE. Faulty installation or service may be dangerous and may invalidate any warranty applicable to WiDRIVE. • WiDRIVE can cause…

Text truncated - open the document above for the full version.

Attestation for FCC Declaration of Conformity FCC ID: WYR-EDS-1389 Date: 2010-09-06 Please be notified that we, the undersigned, EDSLab Technologies Inc. declares that the product which bears the above FCC ID is also compliant with the FCC requirements for DoC. The test report number supporting the DoC is TS10070158-EME. Testing in regards to this report was done by Intertek Testing Services Taiwan Ltd., located at 11, Ln, 275, Ko Nan 1st Street, Shiang-Shan District, Hsinchu 300, Taiwan, R.O.C., which has been accredited in accordance to all of the requirements of 47CFR 2.948 (d) and (e) of the FCC rules and KDB349827. Sincerely, Printed name: Kwan-Han Chen Title: Manager EDSLab Technologies Inc. Tel: + 886 2 25069338 Fax: + 886 2 25151035

Lettery of Agency "I, an officer of EDSLab Technologies Inc. do hereby authorize Rico Deng, who is Chief. Engineer in Intertek Testing Services Taiwan Ltd. to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under Part 15 and Part 18 of the FCC Rules until further notice." I further certify that no party (as defined in §1.2002(b) of CFR 47, 1992) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.,853(a). By: Kwan-Han Chen Signature Printed Title: Manager Date: 2010.09.06

Confidentility Letter (Permanent) Attention: Application Examiner Re: Request for confidentiality Applicant: EDSLab Technologies Inc. FCC ID: WYR-EDS-1389 To whom it may concern, Request is hereby submitted by EDSLab Technologies Inc. to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: • Schematics • Detailed Block diagrams • Detailed Operational/Functional Description Rationale for request for confidentiality: EDSLab Technologies Inc. has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. If you have questions or need further information, please contact the undersigned. Sincerely, Printed name: Kwan-Han Chen Title: Manager Company name: EDSLab Technologies Inc. Date: 2010.09.06

External photo of EUT External photo of Adapter

Label ID location FCC ID Label Location

Internal photo of EUT Antenna 1 Antenna 0

FCC ID. : WYR-EDS-1389 Report No.: TS10070160-EME Page 1 of 7 Maximum Permissible Exposure (MPE) Evaluation Report Report No. : TS10070160-EME Model No. : WiDRIVE DX-325 Issued Date : Sep. 13, 2010 Applicant: EDSLAB Technologies Inc. 4F., No. 150, Sec. 2, Nanking E Rd., Taipei City 10489, Ta i w a n Te s t M e t h o d / Standard: FCC 1.1310 Test By: Intertek Testing Services Taiwan Ltd. No. 11, Lane 275, Ko-Nan 1 Street, Chia-Tung Li, Shiang-Shan District, Hsinchu City, Taiwan It may be duplicated completely for legal use with the allowance of the applicant. It shall not be reproduced except in full, without the written approval of Intertek Laboratory. The test result(s) in this report only applies to the tested sample(s). The test report was prepared by: Sign on File Grace Lee/ Assistant These measurements were taken by: Sign on File Jacky Chen/ Engineer The test report was reviewed by: Name Rex Liao Title Engineer FCC ID. : WYR-EDS-1389 Report No.: TS10070160-EME Page 2 of 7 Table of Contents Summary of Tests ............................................................................................................. 3 1. Introduction .................................................................................................................. 4 2. RF Exposure Limit ....................................................................................................... 4 3. RF Exposure calculations ............................................................................................. 5 4 Description of EUT ....................................................................................................... 6 5. Test results .................................................................................................................... 7 FCC ID. : WYR-EDS-1389 Report No.: TS10070160-EME Page 3 of 7 Summary of Tests MPE Evaluation meet FCC OET No. 65: 1997, IEEE C95.1-2005 WiFI Storage Router-Model: DX-325 FCC ID: WYR-EDS-1388 Test Reference Results MPE Evaluation FCC Guidelines for Human Exposure IEEE C95.1 Complies FCC ID. : WYR-EDS-1389 Report No.: TS10070160-EME Page 4 of 7 1. Introduction The EUT operates in the 2.4 GHz ISM band. Due to the EUT (include antenna) at its normal operation distance is at least 20 cm from the human body, the EUT was defined as a Mobile Device. The reason to do the MPE Evaluation is to avoid the RF hazard to human body. The maximum output power and gain of the antenna were used to calculate the limited Power density (S) at 20 cm distance away from the product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 and Safety Code 6 are followed. According to 1.1307 (b)(1), systems operating under the provisions of this section shall be operated in a manner that ensure that the public is not exposed to radio frequency energy level in excess of the Commission’s guideline. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A) Limits for Occupational / Control Exposures 30-300 61.4 0.163 1.0 6 300-1500 - - F/300 6 1500-100,000 - - 5 6 (B) Limits for General Population / Uncontrolled Exposure 30-300 27.5 0.073 0.2 30 300-1500 - - F/1500 30 1500-100,000 - - 1.0 30 F= Frequency in MHz FCC ID. : WYR-EDS-1389 Report No.: TS10070160-EME Page 5 of 7 3. RF Exposure calculations From §FCC 1.1310 table 1, the maximum permissible RF exposure for an uncontrolled environment is 1 mW/(cm 2 ) (or 10 W/m 2 )* Power density (S) is calculated by the following formula: S = (P * G)/4πR 2 where, S = Power density (mW/cm 2 ) P = Output power to antenna (mW) R = Distance between radiating structure and observation point (cm) G = Gain of antenna in numeric π = 3.1416 Example: Assume a mobile device operates at 2412MHz and its maximum output power is 50mW, and the maximum gain of antenna is 1 (numeric) /0dBi. then the power density (S) = (50 * 1)/4*π*20 2 = 0.00995 (mW/cm 2 ) (or = 0.0995 W/m 2 ) FCC ID. : WYR-EDS-1389 Report No.: TS10070160-EME Page 6 of 7 4 Description of EUT The EUT is a WiFI Storage Router, and was defined as information technology equipment. 4.1 Antenna description The antenna is affixed to the EUT using a unique connector, which allows for replacement of a broken antenna, but DOES NOT use a standard antenna jack or electrical connector. Antenna 0 Antenna Gain: -3.14 dBi max Antenna Type: PCB Printed antenna Connector Type: N/A Antenna 1 Antenna Gain: -3.55dBi max Antenna Type: PCB printed antenna Connector Type: N/A FCC ID. : WYR-EDS-1389 Report No.: TS10070160-EME Page 7 of 7 5. Test results For Single Tx Mode Frequency (MHz) Antenna Gain (numeric) Output power to antenna (mW) Power density (mW/cm2) Limit of power density (mW/cm2) Distance (cm) 2412 0.49 112.72 0.010882537 1.0 20 2437 0.49 63.97 0.006176325 1.0 20 802.11b 2462 0.49 72.95 0.007042553 1.0 20 2412 0.49 228.03 0.022015581 1.0 20 2437 0.49 215.28 0.020784048 1.0 20 802.11g 2462 0.49 205.12 0.019802962 1.0 20 For 2Tx Mode Frequency (MHz) Antenna Gain0 (numeric) Antenna Gain1 (numeric) Output power to antenna 0 (mW) Output power to antenna 1 (mW) Power density (mW/cm2) Limit of power density (mW/cm2) Distance (cm) 2412 0.49 0.44 212.32 171.79 0.355903019 1.0 20 2437 0.49 0.44 166.72 161.81 0.303109042 1.0 20 802.11n HT20 2462 0.49 0.44 167.88 191.87 0.330630806 1.0 20 2422 0.49 0.44 187.93 179.47 0.339101922 1.0 20 2437 0.49 0.44 179.47 187.93 0.338366265 1.0 20 802.11n HT40 2452 0.49 0.44 187.07 171.00 0.330825982 1.0 20 The Notice in Installation Manual has been stated as below: While installing and operating this transmitter, the radio frequency exposure limit of 1 mW/ (cm 2 ) may be exceeded at distances close to the transmi…

Text truncated - open the document above for the full version.

FCC ID. :WYR-EDS-1389 Report No.: TS10070159-EME Page 1 of 90 EMC TEST REPORT Report No. : TS10070159-EME Model No. : WiDRIVE DX-325 Issued Date : Aug. 09, 2010 Applicant: EDSLAB Technologies Inc. 4F., No. 150, Sec. 2, Nanking E Rd., Taipei City 10489, Taiw an Test Method/ Standard: 47 CFR FCC Part 15.247 & ANSI C63.4 2003 Test By: Intertek Testing Services Taiwan Ltd. No. 11, Lane 275, Ko-Nan 1 Street, Chia-Tung Li, Shiang-Shan District, Hsinchu City, Taiwan It may be duplicated completely for legal use with the allowance of the applicant. It shall not be reproduced except in full, without the written approval of Intertek Laboratory. The test result(s) in this report only applies to the tested sample(s). The test report was prepared by: Sign on File Grace Lee/ Assistant These measurements were taken by: Sign on File Jacky Chen/ Engineer The test report was reviewed by: Name Rex Liao Title Engineer FCC ID. :WYR-EDS-1389 Report No.: TS10070159-EME Page 2 of 90 Table of Contents 1. Summary of Test Data................................................................................................................. 3 2. General Information.................................................................................................................... 4 3. Maximum 6 dB Bandwidth......................................................................................................... 6 4. 99% Occupied Bandwidth ........................................................................................................ 17 5. Maximum Output Power........................................................................................................... 28 6. Power Spectral Density............................................................................................................. 30 7. RF Antenna conducted Spurious...............................................................................................41 8. Radiated Spurious Emission ..................................................................................................... 51 9. Emission on Band Edge ............................................................................................................ 65 Appendix A: Test Equipment List................................................................................................. 90 FCC ID. :WYR-EDS-1389 Report No.: TS10070159-EME Page 3 of 90 1. Summary of Test Data Test/Requirement Description Applicable Rule Result Minimum 6dB Bandwidth 15.247(a)(2) Pass Maximum Output Power 15.247(b) Pass Power Spectral Density 15.247(e) Pass RF Antenna Conducted Spurious 15.247(d) Pass Radiated Spurious Emission 15.247(d), 15.205, 15.209 Pass Emission on the Band Edge 15.247(d) Pass AC Power Line Conducted Emission 15.207 Pass FCC ID. :WYR-EDS-1389 Report No.: TS10070159-EME Page 4 of 90 2. General Information Identification of the EUT Product: WiFI Storage Router Model No.: WiDRIVE DX-325 FCC ID.: WYR-EDS-1389 Frequency Range: 2412 MHz ~ 2472 MHz Channel Number: 1. 13 channels for 802.11b, 802.11g, 802.11n HT20 2. 9 channels for 802.11n HT40 Rated Power: DC 5 V, from adapter Model: JF015WR-0500200U V, I/P: 100-240 Vac, 50/60 Hz, 0.5 A Power Cord: N/A Sample Received: Jul. 23, 2010 Test Date(s): Jul. 28, 2010 ~ Aug. 02, 2010 Note 1: This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Note 2: When determining the test conclusion, the Measurement Uncertainty of test has been considered. FCC ID. :WYR-EDS-1389 Report No.: TS10070159-EME Page 5 of 90 Description of EUT The EUT is a WiFI Storage Router, and was defined as information technology equipment. For more detail features, please refer to User's manual as file name “Installation guide.pdf” Antenna description The antenna is affixed to the EUT using a unique connector, which allows for replacement of a broken antenna, but DOES NOT use a standard antenna jack or electrical connector. Antenna 0 Antenna Gain: -3.14 dBi max Antenna Type: PCB Printed antenna Connector Type: N/A Antenna 1 Antenna Gain: -3.55dBi max Antenna Type: PCB printed antenna Connector Type: N/A FCC ID. :WYR-EDS-1389 Report No.: TS10070159-EME Page 6 of 90 3. Maximum 6 dB Bandwidth Name of Test Maximum 6dB Bandwidth Base Standard FCC 15.247 (a)(2) Test Result: Complies Measurement Data: See Table & plots below Method of Measurement: Reference FCC document: KDB558074 A portion of the transmitted signal is coupled to a Spectrum Analyzer with a resolution bandwidth of at least 1 % of the bandwidth of the transmitted signal. The resolution bandwidth is chosen so as not to reduce the peak level of the measured waveform. The appropriate bandwidth mask is applied to the output waveform to verify compliance. Test Diagram: Note: The EUT was tested while in a continuous transmit mode and the worst case data rates are 1 Mbps data rate for 802.11b mode, 6 Mbps data rate for 802.11g mode, 6.5 Mbps data rate for 802.11n HT20 mode and 13 Mbps data rate for 802.11n HT40 mode. The EUT was tuned to a low, middle and high channel. Spectrum Analyzer Attenuator & DC block EUT FCC ID. :WYR-EDS-1389 Report No.: TS10070159-EME Page 7 of 90 Tabl…

Text truncated - open the document above for the full version.

Conducted Emission Test Set-up photo DISK mode DISK mode AP mode AP mode Radiated Emission Test set-up photo
