X24-MOBILE-VMobile Radio

Quanzhou TYT Electronics Co., Ltd. Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Sections 0.457 and 0.459 pertaining to confidential material. Quanzhou TYT Electronics Co., Ltd. would like the following documents regarding this submission for FCC ID: X24- MOBILE-V to be kept confidential. 1. Block Diagram 2. Schematic 3. Theory of Operation 4. Part List The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely yours, Quanzhou TYT Electronics Co., Ltd. Jiamao Lin/ General Manager Fax: 595-86766928 Tel: 595-86767928 E-mail: [email protected]

Quanzhou TYT Electronics Co., Ltd. DATE: May 03, 2012 Federal Communications Commission Authorization & Evaluation Division 7435 Oakland Mills Road Colombia, Maryland 21046 FCC ID: X24-MOBILE-V Model: TH-9000VHF/TH-8900VHF/TH-9800VHF/TH-9900VHF Dear Sir/Madam, We , Quanzhou TYT Electronics Co., Ltd. acknowledge that this device will not be marketed to USA users with the frequency band which is not allowed by rule part 90.and it is a violation of FCC rules if this device is operated on unauthorised frequencies inside the U.S.A. We , Quanzhou TYT Electronics Co., Ltd. acknowledge this equipment meets the requirements of FCC Rules, Parts 90.203 (e) and (g) as applicable. Programming of this product's transmit frequencies can be performed ONLY by the manufacturer or by service or maintenance personnel. The operator cannot program transmit frequencies using the equipment's external operation. Sincerely yours, Quanzhou TYT Electronics Co., Ltd. Jiamao Lin/ General Manager Fax: 595-86766928 Te l : 595-86767928 E-mail: [email protected]

Product Similarity Declaration To Whom It May Concern, We , Quanzhou TYT Electronics Co., Ltd. hereby declare that our (Mobile Radio) Model Number: TH-9000VHF, TH-8900VHF and TH-9800VHF are electrically identical with the Model TH-9900VHF. TH-9000VHF, TH-8900VHF, TH-9800VHF and TH-9900VHF are named differently due to marketing purposes Please contact me if you have any question. Sincerely yours, Quanzhou TYT Electronics Co., Ltd. Jiamao Lin/ General Manager Fax: 595-86766928 Tel: 595-86767928 E-mail: [email protected] .

Declaration DATE: May 03, 2012 Federal Communications Commission Authorization & Evaluation Division 7435 Oakland Mills Road Colombia, Maryland 21046 FCC ID: X24-MOBILE-V Model: TH-9000VHF/TH-8900VHF/TH-9800VHF/TH-9900VHF Dear Sir/Madam, We , Quanzhou TYT Electronics Co., Ltd. acknowledge that this device will only use 12.5KHz channel separation in USA according FCC rules. Sincerely yours, Quanzhou TYT Electronics Co., Ltd. Jiamao Lin/ General Manager Fax: 595-86766928 Te l : 595-86767928 E-mail: [email protected]

Quanzhou TYT Electronics Co., Ltd. Frequency Attestation Letter DATE: May 03, 2012 FCC ID: X24-MOBILE-V IC: 10337A-MOBILEV Model: TH-9000VHF/TH-8900VHF/TH-9800VHF/TH-9900VHF Dear Sir/Madam, We, Quanzhou TYT Electronics Co., Ltd. acknowledge that this device can use the frequency bands 136-174MHz in USA and 138-174MHz in Canada. Sincerely yours, Quanzhou TYT Electronics Co., Ltd. Jiamao Lin/ General Manager Fax: 595-86766928 Tel: 595-86767928 E-mail: [email protected]

Von:Andrew Leimer An:Francis Lima Thema:RE: Single mode 12.5kHz Channel bandwidth in Part 90 narrow band Datum:Freitag, 1. April 2011 15:26:22 If it is not on the exclusion list, TCBs can process the application. Analog 12.5 kHz devices can be certified by TCBs. Spectral efficiency standards do not apply to analog devices. You are not permitted to certify a 25 kHz BW analog device. Regards, Andy Leimer FCC/OET/EAB From: Francis Lima [mailto:[email protected]] Sent: Friday, April 01, 2011 4:43 AM To: Andrew Leimer Subject: AW: Single mode 12.5kHz Channel bandwidth in Part 90 narrow band Hello, I have understood the exclusion list. Unfortunately, my question has not been answered. Item 1)j) refers to equal to 12.5kHz in either multi bandwidth modes or under provisions of spectrum efficiency standards. My question on the other hand relates to an analog device with 12.5kHz single bandwidth mode only whereby spectral efficiency standard is not applicable because it is an analog device. Therefore the product in question is not subject to the exclusion list. What should I do? Proceed with certification or not? Best regards / Mit freundlichen Grüßen / Cordialement Francis Lima -------------------------------------------------------------------- EMCCert DR. RAŠEK GmbH - Certification Institute - Stoernhofer Berg 15 91364 Unterleinleiter GERMANY T: + 49-9194-72279-01 F: + 49-9194-72279-06 [email protected] . Find us: www.emcc.de/location.htm. Hotel list: www.emcc.de/doc/hotels.pdf. Driving instructions: www.emcc.de/doc/company.pdf . Car rental in Forchheim: www.emcc.de/doc/Car_rental.pdf. Der Inhalt dieser E-Mail ist für den Absender rechtlich nicht verbindlich. Informieren Sie uns, wenn Sie diese E-Mail fälschlicherweise erhalten haben (F: + 49 -9194-72279-06). Löschen Sie in diesem Falle die Nachricht. Jede Form der weiteren Benutzung ist untersagt. The content of this e-mail is not legally binding upon the sender. If this e-mail was transmitted to you by error, inform us accordingly (F: + 49 -9194-72279-06). In such case you are requested to erase the message. Any use of such e-mail is strictly prohibited. EMCCert DR. RAŠEK GmbH. Stoernhofer Berg 15. 91364 Unterleinleiter. GERMANY. Handelsregister/ Companies' Register: AG Bamberg # HRB 5078. Geschäftsführer/ Managing Director: Nathalia A. M. Rašek. UST -ID Nr./ VAT-ID No.: DE 8140 108 78. Von: Andrew Leimer [mailto:[email protected]] Gesendet: Donnerstag, 31. März 2011 20:06 An: Francis Lima Betreff: RE: Single mode 12.5kHz Channel bandwidth in Part 90 narrow band The exclusion List is Published KDB 628591: https://apps.fcc.gov/oetcf/kdb/index.cfm Item 1) j) states: Transmitters operating under the provisions of Section 90.203(j)(4) with channel bandwidths of greater than or equal to 12.5 kHz operating in either multi-bandwidth modes or under the special provisions of spectrum efficiency standards specified in Section 90.203 (j)(5), or operating under the provisions of one way paging channel standards of Section 90.203(j) (7). Regards, Andy Leimer FCC/OET/EAB From: Francis Lima [mailto:[email protected]] Sent: Thursday, March 31, 2011 2:01 PM To: Andrew Leimer Subject: AW: Single mode 12.5kHz Channel bandwidth in Part 90 narrow band Hello, Thanks for the response. I now understand that a TCB can do certification of the analog two way radio with a single mode 12.5kHz Channel bandwidth operating in the Part 90 narrow band. Am I correct? Best regards / Mit freundlichen Grüßen / Cordialement Francis Lima -------------------------------------------------------------------- EMCCert DR. RAŠEK GmbH - Certification Institute - Stoernhofer Berg 15 91364 Unterleinleiter GERMANY T: + 49-9194-72279-01 F: + 49-9194-72279-06 [email protected] . Find us: www.emcc.de/location.htm. Hotel list: www.emcc.de/doc/hotels.pdf. Driving instructions: www.emcc.de/doc/company.pdf . Car rental in Forchheim: www.emcc.de/doc/Car_rental.pdf. Der Inhalt dieser E-Mail ist für den Absender rechtlich nicht verbindlich. Informieren Sie uns, wenn Sie diese E-Mail fälschlicherweise erhalten haben (F: + 49 -9194-72279-06). Löschen Sie in diesem Falle die Nachricht. Jede Form der weiteren Benutzung ist untersagt. The content of this e-mail is not legally binding upon the sender. If this e-mail was transmitted to you by error, inform us accordingly (F: + 49 -9194-72279-06). In such case you are requested to erase the message. Any use of such e-mail is strictly prohibited. EMCCert DR. RAŠEK GmbH. Stoernhofer Berg 15. 91364 Unterleinleiter. GERMANY. Handelsregister/ Companies' Register: AG Bamberg # HRB 5078. Geschäftsführer/ Managing Director: Nathalia A. M. Rašek. UST -ID Nr./ VAT-ID No.: DE 8140 108 78. Von: Andrew Leimer [mailto:[email protected]] Gesendet: Donnerstag, 31. März 2011 19:11 An: Francis Lima Betreff: RE: Single mode 12.5kHz Channel bandwidth in Part 90 narrow band Hello, In order to meet the spectral efficiency requirement the device must use digital modulation. The spectral efficiency requirements do not apply to analog voice. The dasic requirements are shown in the following slide (To be released next week): Regards, Andy Leimer FCC/OEWT/EAB From: Francis Lima [mailto:[email protected]] Sent: Thursday, March 31, 2011 11:48 AM To: Andrew Leimer Subject: Single mode 12.5kHz Channel bandwidth in Part 90 narrow band Importance: High Dear Mr. Leimer, I am Francis Lima, from the TCB in Germany and have been trying to get hold of you on phone in vain. I have an urgent question and hope that you can assist me. Is certification of a two way radio with single mode 12.5kHz channel bandwidth operating in the narrow band (421-512MHz) of Part 90 allowed? If yes, is it okay if the 12.5kHz BW single mode device fulfils the requirement of one voice channel/12.5kHz bandwidth {90.203j(3}) or must it also include one voice channel/6.25kHz bandwidth {90.203j(5)}? I look forward to your response. Best regards / Mit freundlichen Grüßen / Cordialement Francis Lima ----------------------------------…

Text truncated - open the document above for the full version.

External photos of the EUT

FCC Label FCC RF Warning Label

FCC Label FCC RF Warning Label

FCC Label FCC RF Warning Label

FCC Label FCC RF Warning Label

Internal photos of the EUT

MPE TEST REPORT FCC Per 47 CFR 2.1091(b)&RSS-102 Report Reference No. ..................... : FCC ID. ............................................. : IC. ...................................................... TRE1203004502 X24-MOBILE-V 10337A-MOBILEV Compiled by ( position+printed name+signature) .. : File administrators Tim Zhang Supervised by ( position+printed name+signature) .. : Test Engineer Eric Zhang Approved by ( position+printed name+signature) .. : Manager Wenliang Li Date of issue ..................................... : May 03, 2012 Testing Laboratory Name .............. : Shenzhen Huatongwei International Inspection Co., Ltd Address ............................................. : Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name ............................ : Quanzhou TYT Electronics Co., Ltd. Address ............................................. : Bldg.22, Daxiamei Industrial Area,Nan'an,Quanzhou,Fujian 362300,China Test specification: Standard ........................................... : FCC Per 47 CFR 2.1091(b) OET Bulletin 65 Supplement C[June 2001] RSS-102 TRF Originator .................................. : Shenzhen Huatongwei International Inspection CO., Ltd Master TRF ....................................... : Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : Mobile Radio Trade Mark ....................................... : Model/Type reference ....................... : TH-9000VHF Listed Models .................................. : TH-8900VHF/TH-9800VHF/TH-9900VHF Ratings .............................................. : DC 13.60 V Rated Output Power ......................... : 65 Watt(48.13 dBm)/25Watt(43.98 dBm)/10Watt(40.00 dBm) Modulation ......................................... FM Channel Separation ........................... 12.5KHz only for FCC &both 12.5KHz and 25KHz only for IC Frequency Range ............................. : From 138MHz to 174MHz only for IC From 136MHz to 174MHz only for FCC Result ................................................ : Positive Report No.: TRE1203004502 Page 2 of 8 Issued:2012-05-03 MPE T E S T R E P O R T Test Report No. : TRE1203004502 May 03, 2012 ______________________________________________________________________________________________ Date of issue Equipment under Test : Mobile Radio Model /Type : TH-9000VHF Listed Models : TH-8900VHF/TH-9800VHF/TH-9900VHF Applicant : Quanzhou TYT Electronics Co., Ltd. Address : Bldg.22, Daxiamei Industrial Area,Nan'an,Quanzhou,Fujian 362300,China Manufacturer : Quanzhou TYT Electronics Co., Ltd. Address : Bldg.22, Daxiamei Industrial Area,Nan'an,Quanzhou,Fujian 362300,China The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: TRE1203004502 Page 3 of 8 Issued:2012-05-03 Contents 1. SUMMARY ............................................................................. 4 1.1. EUT configuration 4 1.2. Product Description 4 1.3. Equipment under Test 4 1.4. Note 5 2. TEST ENVIRONMENT ............................................................... 6 2.1. Address of the test laboratory 6 2.2. Environmental conditions 6 2.3. Statement of the measurement uncertainty 6 3. METHOD OF MEASUREMENT .................................................... 6 3.1. Applicable Standard 6 3.2. Limit 7 3.3. MPE Calculation Method 7 4. CONCLUSION ........................................................................ 8 Report No.: TRE1203004502 Page 4 of 8 Issued:2012-05-03 1. SUMMARY 1.1. EUT configuration The following peripheral devices and interface cables were connected during the measurement: ● - supplied by the manufacturer ○ - supplied by the lab ● Power Cable Length (m) : 3 Shield : Unshield Detachable : Detachable ○ Multimeter Manufacturer : / Model No. : / 1.2. Product Description The Quanzhou TYT Electronics Co., Ltd. ’s Model: TH-9000VHF/TH-8900VHF/TH-9800VHF/TH-9900VHF or the “EUT” as referred to in this report; more general information as follows: Name of EUT Mobile Radio Model Number TH-9000VHF/TH-8900VHF/TH-9800VHF/TH-9900VHF Rated Output Power 65 Watt(48.13 dBm)/25Watt(43.98 dBm)/10Watt(40.00 dBm) Modilation Type FM for Analog Voice Emission Designator Analog 16K0F3E for 25KHz Channel Separation 11K50F3E for 12.5KHz Channel Separation Channel Separation Analog Voice 12.5KHz&25KHz only for IC 12.5KHz only for FCC Antenna Type External Frequency Range From 138 MHz to 174 MHz for IC From 136 MHz to 174 MHz for FCC Maximum Transmitter Power Analog/FCC 74.30 W for 12.5 KHz Channel Separation Analog/IC 73.45 W for 25 KHz Channel Separation 74.30 W for 12.5 KHz Channel Separation 1.3. Equipment under Test Power supply system utilised Power supply voltage : ○ 120V / 60 Hz ○ 115V / 60Hz ○ 12 V DC ○ 24 V DC ● Other (specified in blank below) DC 13.60 V Report No.: TRE1203004502 Page 5 of 8 Issued:2012-05-03 Test frequency list Modulation Type Channel SeparationTest Channel Test Frequency (MHz) Remark FM/Analog 12.5KHz Low 138.5000 Only for IC Review (Not For FCC Review) Middle 155.5000 High 173.5000 25KHz Low 138.5000 Middle 155.5000 High 173.5000 12.5KHz Low 138.5000 Only for FCC Review Middle 155.5000 High 173.5000 1.4. Note 1. The EUT is a 136-174 MHz frequency band Mobile Radio (TH-9000VHF/TH-8900VHF/TH-9800VHF/TH- 9900VHF),The functions of the EUT listed as below: Test Standards Reference Report Remark Radio FCC Part 90&RSS-119 TRE12030045…

Text truncated - open the document above for the full version.

MPE TEST REPORT FCC Per 47 CFR 2.1091(b) Report Reference No. ..................... : FCC ID . ............................................ : TRE1203004503 X24-MOBILE-V Compiled by ( position+printed name+signature) .. : File administrators Tim Zhang Supervised by ( position+printed name+signature) .. : Test Engineer Eric Zhang Approved by ( position+printed name+signature) .. : Manager Wenliang Li Date of issue ..................................... : May 03, 2012 Testing Laboratory Name .............. : Shenzhen Huatongwei International Inspection Co., Ltd Address............................................. : Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name ............................ : Quanzhou TYT Electronics Co., Ltd. Address............................................. : Bldg.22, Daxiamei Industrial Area,Nan'an,Quanzhou,Fujian 362300,China Test specification: Standard ........................................... : FCC Per 47 CFR 2.1091(b) TRF Originator .................................. : Shenzhen Huatongwei International Inspection CO., Ltd Master TRF ....................................... : Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Mobile Radio Trade Mark ....................................... : Model/Type reference ....................... : TH-9000VHF Listed Models .................................. : TH-8900VHF/TH-9800VHF/TH-9900VHF Ratings.............................................. : DC 13.60 V Rated Output Power ......................... : 65 Watt(48.13 dBm)/25Watt(43.98 dBm)/10Watt(40.00 dBm) Modulation ......................................... FM Channel Separation ........................... 12.5KHz only for FCC Frequency Range ............................. : From 136MHz to 174MHz Result ................................................ : Positive Report No.: TRE1203004503 Page 2 of 11 Issued:2012-05-03 FCC ID: X24-MOBILE-V MPE T E S T R E P O R T Test Report No. : TRE1203004503 May 03, 2012 ______________________________________________________________________________________________ Date of issue Equipment under Test : Mobile Radio Model /Type : TH-9000VHF Listed Models : TH-8900VHF/TH-9800VHF/TH-9900VHF Applicant : Quanzhou TYT Electronics Co., Ltd. Address : Bldg.22, Daxiamei Industrial Area,Nan'an,Quanzhou,Fujian 362300,China Manufacturer : Quanzhou TYT Electronics Co., Ltd. Address : Bldg.22, Daxiamei Industrial Area,Nan'an,Quanzhou,Fujian 362300,China The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: TRE1203004503 Page 3 of 11 Issued:2012-05-03 FCC ID: X24-MOBILE-V Contents 1. MEASUREMENT UNCERTAINTY ................................................. 4 2. METHOD OF MEASUREMENT .................................................... 4 2.1. EME measurements made on trunk mounted antennas 4 2.1.1. External vehicle EME measurement .............................................................................. 4 2.1.2. Internal vehicle EME measurement ............................................................................... 4 2.2. EME measurements made on center roof mounted antennas 4 2.2.1. External vehicle EME measurement .............................................................................. 4 2.2.2. Internal vehicle EME measurement ............................................................................... 4 3. TEST RESULT ........................................................................ 5 4. CONCLUSION ........................................................................ 7 5. ANTENNA LOCATION DRAWING ................................................ 8 Report No.: TRE1203004503 Page 4 of 11 Issued:2012-05-03 FCC ID: X24-MOBILE-V 1. Measurement Uncertainty The information below presents an estimate of the possible errors that are associated with the measurement system. Description Error NARDA Survey Meter ± 3% Repeatability Accuracy ± 7% 2. Method of measurement 2.1. EME measurements made on trunk mounted antennas 2.1.1. External vehicle EME measurement (Antenna mounted in trunk center) With the survey meter and probe, take ten (10) measurements, at the standard test distance of 60 cm to the antenna, from the back of the vehicle in a vertical line and then average the results. These measurements are taken and recorded at every twenty (20) centimeters over a range starting at twenty (20) centimeters above ground and ending at 2.0 meters. 2.1.2. Internal vehicle EME measurement (Antenna mounted in trunk center) While rotating survey meter probe through 180 degrees to ensure that the highest level is found, scan the inside of the vehicle, both front and back seating areas, for the highest level in each location. After the highest level is found, scan vertically making two (2) additional measurements within an area approximately 40 cm wide (representing the width of a person) so as to have a total of three (3) measured points as indicated below that will be averaged . a) Head area b) Chest area c) Lower Trunk area 2.2. EME measurements made on center roof mounted antennas 2.2.1. External vehicle EME measurement With the survey meter and probe, take ten (10) measurements, at the standard test distance of 110 cm from the vehicle-mounted antenna, in a vertical line and then average the results. These measurements are taken and recorded at every twenty (20) centimeters over a r…

Text truncated - open the document above for the full version.

FCC PART 90 & RSS-119 TEST REPORT FCC Part 90 and RSS-119 Report Reference No. ..................... : FCC ID. ............................................. : IC. ...................................................... TRE1203004501 X24-MOBILE-V 10337A-MOBILEV Compiled by ( position+printed name+signature) .. : File administrators Tim Zhang Supervised by ( position+printed name+signature) .. : Test Engineer Eric Zhang Approved by ( position+printed name+signature) .. : Manager Wenliang Li Date of issue ..................................... : May 03, 2012 Testing Laboratory Name .............. : Shenzhen Huatongwei International Inspection Co., Ltd Address............................................. : Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name ............................ : Quanzhou TYT Electronics Co., Ltd. Address............................................. : Bldg.22, Daxiamei Industrial Area,Nan'an,Quanzhou,Fujian 362300,China Test specification: Standard ........................................... : FCC Part 90/FCC Part 2 RSS-119/RSS-Gen/RSS-102 TRF Originator .................................. : Shenzhen Huatongwei International Inspection CO., Ltd Master TRF ....................................... : Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Mobile Radio Trade Mark ....................................... : Model/Type reference ....................... : TH-9000VHF Listed Models .................................. : TH-8900VHF/TH-9800VHF/TH-9900VHF Ratings.............................................. : DC 13.60 V Rated Output Power ......................... : 65 Watt(48.13 dBm)/25Watt(43.98 dBm)/10Watt(40.00 dBm) Modulation ......................................... FM Channel Separation ........................... 12.5KHz only for FCC &both 12.5KHz and 25KHz only for IC Frequency Range ............................. : From 138MHz to 174MHz only for IC From 136MHz to 174MHz only for FCC Result ................................................ : Positive Report No.: TRE1203004501 Page 2 of 108 Issued:2012-05-03 FCC ID: X24-MOBILE-V IC: 10337A-MOBILEV T E S T R E P O R T Test Report No. : TRE1203004501 May 03, 2012 ______________________________________________________________________________________________ Date of issue Equipment under Test : Mobile Radio Model /Type : TH-9000VHF Listed Models : TH-8900VHF/TH-9800VHF/TH-9900VHF Applicant : Quanzhou TYT Electronics Co., Ltd. Address : Bldg.22, Daxiamei Industrial Area,Nan'an,Quanzhou,Fujian 362300,China Manufacturer : Quanzhou TYT Electronics Co., Ltd. Address : Bldg.22, Daxiamei Industrial Area,Nan'an,Quanzhou,Fujian 362300,China Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: TRE1203004501 Page 3 of 108 Issued:2012-05-03 FCC ID: X24-MOBILE-V IC: 10337A-MOBILEV Contents 1. TEST STANDARDS 4 2. SUMMARY 5 2.1. General Remarks 5 2.2. Product Description 5 2.3. Equipment under Test 5 2.4. Short description of the Equipment under Test (EUT) 6 2.5. EUT Configuration 6 2.6. EUT operation mode 6 2.7. EUT configuration 6 2.8. Related Submittal(s) / Grant (s) 6 2.9. Modifications 6 2.10. Note 6 3. TEST ENVIRONMENT 7 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 8 3.4. Configuration of Tested System 8 3.5. Discription of Tested Modes 8 3.6. Statement of the measurement uncertainty 8 3.7. Test Description 9 3.8. Equipments Used during the Test 9 4. TEST CONDITIONS AND RESULTS 11 4.1. Conducted Emissions 11 4.2. Occupied Bandwidth & Emission Mask 16 4.3. Transmitter Radiated Spurious Emssion 28 4.4. Spurious Emssion on Antenna Port 33 4.5. Modulation Charcateristics 59 4.6. Frequency Stability 64 4.7. Maximum Transmitter Power 66 4.8. Transmitter Frequency Behavior 79 4.9. Receiver Radiated Spurious Emssion 84 4.10. Receiver Conducted Spurious Emssion 94 5. TEST SETUP PHOTOS OF THE EUT 101 6. EXTERNAL AND INTERNAL PHOTOS OF THE EUT 103 Report No.: TRE1203004501 Page 4 of 108 Issued:2012-05-03 FCC ID: X24-MOBILE-V IC: 10337A-MOBILEV 1. TEST STANDARDS The tests were performed according to following standards: FCC Rules Part 90: PRIVATE LAND MOBILE RADIO SERVICES. TIA/EIA 603: Land Mobile FM or PM Communications Equipment Measurement and Performance Standards. FCC Rules Part 15 Subpart B: RADIO FREQUENCY DEVICES-Unintertional Radiators FCC Part 2: FREQUENCY ALLOCA-TIONS AND RADIO TREATY MAT-TERS; GENERAL RULES AND REG-ULATIONS RSS-119 Issue 11 June 2011: Radio Transmitters and Receivers Operating in the Land Mobile and Fixed Services in the Frequency Range 27.41-960 MHz RSS-Gen Issue 3 December 2010: General Requirements and Information for the Certification of Radio Apparatus Report No.: TRE1203004501 Page 5 of 108 Issued:2012-05-03 FCC ID: X24-MOBILE-V IC: 10337A-MOBILEV 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Mar 05, 2012 Testing commenced on : Mar 05, 2012 Testing concluded on : May 03, 2012 2.2. Product Description The Quanzhou TYT Electronics Co., Ltd. ’s Model: TH-9000VHF/TH-8900VHF/TH-9800VHF/TH-9900VHF or the “EUT” as referred to in this report; more general information as follows: Name of EUT Mobile Radio Model Number TH-9000VHF/TH-8900VHF/TH-9800VHF/TH-9900VHF Rated Output Power 65 Watt(48.13 dBm)/25Watt(43.98 dBm)/10Watt(40.00 dBm) Modila…

Text truncated - open the document above for the full version.

Test setup photos of the EUT
