X26SAS-4Accesory to wireless hearing instrument

Userguide TV-Streamer+ TableofContents Introduction4 Symbols5 Gettingtoknowyourdevice7 HowtoinstalltheTV-Streamer+10 UsingtheTV-Streamer+forthefirsttime12 DailyuseoftheTV-Streamer+17 Warnings19 Maintenance21 Technicalspecifications22 Regulatoryinformation23 Statement24 Acknowledgements27 2 Introduction NOTE:Readthisbookletcarefullybeforeusingthedevice.Askyourhearingcare professionalifyouhaveanyquestions. Intendedpurpose TheGN Hearing A/STV-Streamer+,isintendedtobeawirelessconnectiontoatelevision orotheraudiodeviceforourwirelesshearingaids. TheGN Hearing A/STV-Streamer+ReSoundMultiMicmayalsobeusedtogetherwith ApprovedPartnerProductsfromCochlearLtdorCochlearBoneAnchoredSolutionsAB. ApprovedPartnerProductreferstospecificproductsreleasedandmarketedbyCochlear LtdorCochlearBoneAnchoredSolutionsABpartners. Targetgroup TheTV-Streamer+isintendedtobeusedbylaypersons. Therapeuticindications Theaccessoryhasnotherapeuticindicationsinitself. Contra-indications Noknowncontra-indications. Intendedclinicalbenefits Theintendedclinicalbenefitisimprovedaudibilitywhenwatchingtelevisionorlisteningto soundfromotheraudiodevice. Introduction4 Symbols WARNING:Pointsouta situationthatcouldleadto seriousinjuries. Legalmanufacturer. CAUTION:Indicatesasituation thatcouldleadtominorand moderateinjuries. Dateofmanufacture. NOTE:Adviceandtips. UDI UniqueDeviceIdentification. Followinstructionsforuse.(Logo inblue) Regulatorycompliancemarkfor AustraliaandNewZealand. EquipmentincludesanRF transmitter. Regulatorycompliancemarkfor Japan. ProductisaTypeBappliedpart.Regulatorycompliancemarkfor Malaysia. Regulatorycompliancemarkfor Korea. Regulatorycompliancemarkfor Taiwan. Regulatorycompliancemarkfor EU. 5Symbols Donotdisposeofyourdevicesandbatterieswithordinaryhouseholdwaste. Yourdevicesandbatteriesshouldbedisposedofatsitesintendedforelectronic wasteorreturnedtoyourhearingcareprofessionalforsafedisposal. NOTE:Country-specificregulationsmayapply. Symbols6 Gettingtoknowyourdevice TheTV-Streamer+providesstreamedaudiofromyourTV,HiFistereo,personal computer,orsimilardevicedirectlytoyourhearingaids. DependingonyourTV,HiFistereo,personalcomputer,orotheraudiosetup,forthe installationoftheTV-Streamer+see-HowtoinstalltheTV-Streamer+.Theconnection guidewillshowyouhowtosetupthephysicalconnections.ForhowtopairtheTV- Streamer+withyourhearingaidssee-"UsingtheTV-Streamer+forthefirsttime". Unpacking—boxcontents TV-Streamer+Digital(optical)audiocable (removecableplugcovers beforeuse) USB-AtoUSB-Ccable (usedtosupplypowerfrom theTVtotheTV-Streamer+) AnalogueaudiocableHookandloopfastening tapestrip 7Gettingtoknowyourdevice DescriptionoftheTV-Streamer+ A BC A.Increasevolume/delayadjustment B.LED indicator:audiostreaming/pairing indicator C.Decreasevolume/delayadjustment E F G HD D.Pairing/delaymodebutton E.Audioinput:analogueordigital(optical) F.Serialnumber G.Powerconnection:USB-C H.LEDindicator:power Gettingtoknowyourdevice8 LEDinformation StreamingandpairinggreenLEDlightpatterns. LEDpatternsProcessDescription constant ON StreamingConstantON Stand-byConstantOFF PairingmodeFlashing SuccessfulpairingConstantONfor3seconds FirmwareupdateFastflashing AdjustabledelaymodeLongflashing Startingerror3mediumflashesrepeating Firmwareupdate completed ConstantONfor3seconds 9Gettingtoknowyourdevice HowtoinstalltheTV-Streamer+ FollowthebelowinstructionstoinstallandsetuptheTV-Streamer+. ConnecttheTV-Streamer+toapower source Thedevicecanbepowereddirectlybythe TVUSB-AsocketviathesuppliedUSB-A toUSB-Ccable.TheUSB-Aplugcan alternativelybeinsertedintoanysuitable powersource. TheUSB-Cplugisinsertedintothe TV- Streamer+. TheLEDlightonthebackoftheTV-Streamer+willshowwhitetoindicateactivationafter thepowercablehasbeeninsertedtoapowersource. HowtoinstalltheTV-Streamer+10 Youcanuseeithertheanalogueaudiocableordigital(optical)audiocabletosupplyan audiosignalintotheTV-Streamer+. Analoguecableconnection ForTVwithanalogueaudio:insertthe2- into-1audioplugsintotheLandRAUDIO socketsonyourTVandtheotherendinto theTV-Streamer+. LR AUDIO LR Digitalcableconnection Thedigital(optical)cablehasacoveron eachendofthecablethatmustbe removedbeforeuse. InsertthesquareplugintotheTVDIGITAL AUDIOOUTsocketandroundplugintothe TV-Streamer+. OPTICAL 11HowtoinstalltheTV-Streamer+ UsingtheTV-Streamer+forthefirsttime BeforeyoucanstartusingyourTV-Streamer+tostreamsoundtoyourhearingaids,the TV-Streamer+mustbeconnectedtoapoweroutlet,connectedtotheTV,andpairedwith yourhearingaids. NOTE:ItisrecommendedtoaffixtheTV-Streamer+ontheTVbackpanelafter connectingallcablesandafterpairingthedevicewithyourhearingaids UsingtheTV-Streamer+forthefirsttime12 PairingtheTV-Streamer+toyourhearingaids TotransmitsoundfromtheTV-Streamer+toyourhearingaidsyouneedtopairthe devices. NOTE:Toavoidaccidentalpairing,turnoffallothernearbyhearingaids.Ifitisnot possibletoturnoffthehearingaidsnottobepaired,placethematleast1 metre (3 feet)fromtheTV-Streamer+. Topairthedevices: 1.TheTV-Streamer+andthehearing aidsmustbeturnedONandbe within5cm(2")ofeachother. 2.Paringmodewillbeactivatedby pressingtheparingbuttononback oftheTV-Streamer+.Pressthe buttonuntilthefrontLEDstarts flashinggreeninshortintervals. Thehearingaidswillbepairedoneat thetime.TheLEDwillstopflashingfor 3secondsafterthefirsthearingaidis pairedandthenautomaticallycontinue topairthesecondhearingaid. 5 cm (2”) maximum distance 13UsingtheTV-Streamer+forthefirsttime ThepairingLEDsequence •FlashingLED=firstpairing(about12seconds) •LEDconstantON •FlashingLED=secondpairing(about12seconds) •LEDconstantON •FlashingLED=searchingformorehearingaids(about15seconds) •LEDconstantON=streaming. NOTE:TheTV-Streamer+pairingoptionisopenfor3minutes,butstreamingcan startbeforethepairingsearchhasfinished. Adjustingthevolume TheTV-Streamer+soundlevelissettoprovide acomfortablelisteninglevelfromthemomentit isactivated.However,foryourconvenience, youmayadjustthesoundlevelontheTV- Streamer+atanytime. Tochangethevolume:pressthe'+'buttonto raisethevolumeor'-'buttontolowerthe volume. Itisadvisedtosetthevolume…

Text truncated - open the document above for the full version.

GN Hearing A/S GN Hearing A/S | Lautrupbjerg 7 | DK-2750 Ballerup | +45 45 75 00 00 Co. Reg. no. 55082715 | [email protected] | www.gn.com Date: 2023-07-04 Designated Agent Letter – 47 CFR, Section 2.911(d)(7) US Designated Agent Company Name: GN Hearing Care Corporation Contact Name: Thomas Brockway Street Address: 8001E Bloomington Freeway Bloomington MN 55420 United States Telephone No: +1 9527698048 Email: [email protected] Applicant Company name: GN Hearing A/S FCC FRN: 0019433481 Contact Name: Nichlas Brown Holm Address: Lautrupbjerg 7, 2750 Ballerup, Denmark Telephone No: +45 23421388 Email: [email protected] GN Hearing A/S, hereby appoint GN Hearing Care Corporation as our Designated US Agent in all matters relating to FCC’s Equipment Authorization Program. GN Hearing Care Corporation, hereby accept to act as Designated US Agent and accept the obligations relating to service of process in all matters relating to FCC’s Equipment Authorization Program. The agreement is valid for below listed equipment for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Product: Accessory to hearing aid (TV Streamer) Type designation: SAS-4 FCC ID: X26SAS-4 Sincerely, Applicant Designated Agent _________________________ _________________________ Nichlas Brown Holm Thomas Brockway Regulatory Certification Manager Senior QA Engineer Regulatory Certification Bloomington Quality GN Hearing A/S Lautrupbjerg 7 2750 Ballerup, Denmark 8001E Bloomington Freeway Bloomington MN 55420 United States Telephone: +45 23421388 Telephone: +1 9527698048 e-mail: [email protected] e-mail: [email protected] DocuSign Envelope ID: 88F4ADDF-9DEB-496D-BFC0-1C19ACFB7DAC GN Hearing A/S GN Hearing A/S | Lautrupbjerg 7 | DK-2750 Ballerup | +45 45 75 00 00 Co. Reg. no. 55082715 | [email protected] | www.gn.com Date: 2023-07-04 “Covered List” Attestation – 47 CFR, Section 2.911(d)(5)(i) GN Hearing A/S, the applicant, hereby certifies that below listed equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Product: Accessory to hearing aid (TV Streamer) Type designation: SAS-4 FCC ID: X26SAS-4 ________________________________ Nichlas Brown Holm Regulator Certification Manager GN Hearing A/S Lautrupbjerg 7 2750 Ballerup, Denmark e-mail: [email protected] Telephone: +45 23421388 DocuSign Envelope ID: 88F4ADDF-9DEB-496D-BFC0-1C19ACFB7DAC GN Hearing A/S GN Hearing A/S | Lautrupbjerg 7 | DK-2750 Ballerup | +45 45 75 00 00 Co. Reg. no. 55082715 | [email protected] | www.gn.com Date: 2023-07-04 “Covered List” Attestation – 47 CFR, Section 2.911(d)(5)(ii) GN Hearing A/S, the applicant, hereby certifies that, as of the date of the filing of the application of below listed equipment, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Product: Accessory to hearing aid (TV Streamer) Type designation: SAS-4 FCC ID: X26SAS-4 ________________________________ Nichlas Brown Holm Regulator Certification Manager GN Hearing A/S Lautrupbjerg 7 2750 Ballerup, Denmark e-mail: [email protected] Telephone: +45 23421388 DocuSign Envelope ID: 88F4ADDF-9DEB-496D-BFC0-1C19ACFB7DAC

SAS-4 – External photographs External Front side External Back side External Top side External Bottom side Analouge Audio Cable Connected Optical Audio Cable Connected

1 A 1 2 2 A This document may not be reproduced or distributed in any way without the consent of GN Hearing A/S. B B Template: A4_LANDSCAPE_ASM-PAINT GN Hearing A/S 2177600 -- HSG,SAS-4,PTD Drawing Number:Drawing Name: 1 A. 08-Jun-23Design Date: 1 of 1 Sheet: Unit: mm NGu Designed by: 1:1 Scale: Drw Rev: CPH Design site: A4 DRW size:Projection: Drw. Rev.Description Date Updated by (dd.mm.yyyy) APreliminary. 08.06.2023leajoe PRELIMINARY SCALE 1:2 Notes: 1. Text shown on drawing is "outline", but should be "filled" during marking. 2. General tolerances on dimensions are
#0.20 mm and angles
#2
$ mm unless otherwise specified. 3. Cosmetic specifications are defined in GN ReSound documents 0007510 (Corporate cosmetic insp. proc.) 4. See BOM for color and material. 5. The following dimensions have been deleted from the drawing: None 6. Measurement planes for the part are defined by the Datum reference frame: A B A B 5,00

PCB- A Component sidet PCB-A Back SAS-4 – Internal photographs PCB-A Shielding Can Removed PCB-A Under Shielding Can Radio

DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 71728RAN.002 2023-08-11 Test report No: NIE: 71728RAN.002 Assessment report RF EXPOSURE REPORT ACCORDING TO FCC 47 CFR Part 2.1091; FCC 47 CFR Part 2.1093 FCC 47 CFR Part 1.1307; FCC 47 CFR Part 1.1310 (*) Identification of item under evaluation Accessory to wireless hearing instrument (*) Trademark GN Hearing (*) Model and /or type reference SAS-4 (*) Other identification of the product HW version: PCBA, SAS-4 MAIN BOARD,V2 SW version: Farlander5 FCC ID: X26SAS-4 IC: 6941C-SAS4 (*) Features Bluetooth LE (*) Manufacturer GN Hearing A/S Lautrupbjerg 7, 2750 Ballerup, Denmark Test method requested, standard FCC 47 CFR Part 2.1091 Radiofrequency radiation exposure evaluation: mobile devices. FCC 47 CFR Part 2.1093 Radiofrequency radiation exposure evaluation: portable devices. FCC 47 CFR Part 1.1307: Actions that may have a significant environmental effect, for which Environmental Assessments (EAs) must be prepared. FCC 47 CFR Part 1.1310: Radiofrequency radiation exposure limits. Summary IN COMPLIANCE Approved by (name / position & signature) Rafael López Regulatory Lab.Technical Office Manager Date of issue 2023-08-11 Report template No FAN36_02 (*) “Data provided by the client” DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 71728RAN.002 Page 2 of 9 2023-08-11 Index Competences and guarantees .................................................................................................... 3 General conditions ...................................................................................................................... 3 Data provided by the client .......................................................................................................... 3 Identification of the client............................................................................................................. 3 Document history ........................................................................................................................ 3 Appendix A: FCC RF Exposure assessment result ..................................................................... 4 General description of the device under evaluation ................................................................ 5 Evaluation Results .................................................................................................................. 6 Appendix B: FCC RF Exposure information ................................................................................ 7 RF Exposure determination of exemption ............................................................................... 8 DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 71728RAN.002 Page 3 of 9 2023-08-11 Competences and guarantees In order to assure the traceability to other national and international laboratories, DEKRA Testing and Certification, S.A.U. has a calibration and maintenance program for its measurement equipment. DEKRA Testing and Certification, S.A.U. guarantees the reliability of the data presented in this report, which is the result of the measurements and the tests performed to the item under test on the date and under the conditions stated on the report and, it is based on the knowledge and technical facilities available at DEKRA Testing and Certification, S.A.U. at the time of performance of the test. DEKRA Testing and Certification, S.A.U. is liable to the client for the maintenance of the confidentiality of all information related to the item under test and the results of the test. The results presented in this Assessment Report apply only to the particular item under test established in this document. IMPORTANT: No parts of this report may be reproduced or quoted out of context, in any form or by any means, except in full, without the previous written permission of DEKRA Testing and Certification, S.A.U. General conditions 1. This report is only referred to the item that has undergone the assessment. 2. This report does not constitute or imply on its own an approval of the product by the Certification Bodies or competent Authorities. 3. This document is only valid if complete; no partial reproduction can be made without previous written permission of DEKRA Testing and Certification, S.A.U. 4. This test report cannot be used partially or in full for publicity and/or promotional purposes without previous written permission of DEKRA Testing and Certification, S.A.U. and the Accreditation Bodies Data provided by the client The following data has been provided by the client: 1. Information relating to the description of the sample ("Identification of the item under evaluation", "Trademark", "Model and/or type reference", “General description of the device”, “Other identification of the product”). 2. Antenna gain and use distance information. 3. The device under evaluation consists of an accessory to wireless hearing instrument, which is capable of streaming Audio from a Television or other audio device, to multiple hearing instrument. DEKRA Testing and Certification S.A.U. declines any responsibility with respect to the information provided by the client and that may affect the validity of results. Identification of the client GN Hearing A/S Lautrupbjerg 7, 2750 Ballerup, Denmark Document history Report number Date Description 71728RAN.002 2023-08-11 First release DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 71728RAN.002 Page 4 of 9 2023-08-11 Appendix A: FCC RF Exposure assessment result DEKRA Testing and Certification, S.A.U. …

Text truncated - open the document above for the full version.

DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: 71728RRF.001A1 2023-08-23 ISED CABid: ES1909 Lab. Company Number: 4621A Test Report No: 71728RRF.001A1 Test Report USA FCC Part 15.247, 15.209 CANADA RSS-247, RSS-Gen (*) Identification of item tested Accessory to wireless hearing instrument (*) Trademark GN Hearing (*) Model and /or type reference SAS-4 Other identification of the product FCC ID: X26SAS-4 IC: 6941C-SAS4 (*) Features Features: Bluetooth LE HW version: PCBA, SAS-4 MAIN BOARD,V2 SW version: Farlander5 Manufacturer GN Hearing A/S Lautrupbjerg 7, 2750 Ballerup, Denmark Test method requested, standard USA FCC Part 15.247 (10-1-21 Edition): Operation within the bands 902 - 928 MHz, 2400 -2483.5 MHz, and 5725 - 5850 MHz. USA FCC Part 15.209 (10-1-21 Edition): Radiated emission limits; general requirements. CANADA RSS-247 Issue 2 (February 2017). CANADA RSS-Gen Issue 5 amendment 2 (February 2021). Guidance for Performing Compliance Measurements on Digital Transmission System, Frequency Hopping Spread Spectrum System, and Hybrid Systems Devices Operating Under Section 15.247 of the FCC Rules. 558074 D01 Meas Guidance v05r02 dated April 2, 2019. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices. Summary IN COMPLIANCE Approved by (name / position & signature) Antonio José Jurado Industrial & Automotive EMC Lab. Manager Date of issue 2023-08-23 Report template No FDT08_24 (*) “Data provided by the client” DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: 71728RRF.001A1 Page 2 of 92 2023-08-23 Index INDEX ........................................................................................................................................................................... 2 ACRONYMS ................................................................................................................................................................. 3 COMPETENCES AND GUARANTEES ....................................................................................................................... 3 GENERAL CONDITIONS ............................................................................................................................................. 4 UNCERTAINTY ............................................................................................................................................................ 4 DATA PROVIDED BY THE CLIENT ............................................................................................................................ 4 USAGE OF SAMPLES ................................................................................................................................................. 5 TEST SAMPLE DESCRIPTION ................................................................................................................................... 6 IDENTIFICATION OF THE CLIENT ............................................................................................................................. 7 TESTING PERIOD AND PLACE .................................................................................................................................. 7 DOCUMENT HISTORY ................................................................................................................................................ 7 ENVIRONMENTAL CONDITIONS ............................................................................................................................... 7 REMARKS AND COMMENTS ..................................................................................................................................... 8 TESTING VERDICTS ................................................................................................................................................... 8 LIST OF EQUIPMENT USED DURING THE TEST ..................................................................................................... 9 SUMMARY .................................................................................................................................................................... 9 APPENDIX A: TEST RESULTS. BLUETOOTH LOW ENERGY 5.0 (1M, 2M) ......................................................... 11 DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: 71728RRF.001A1 Page 3 of 92 2023-08-23 Acronyms Acronym ID Acronym Description BW Bandwidth Detector Detector used Ebw Emission Bandwidth Equipment Equipment Type Freq Frequency Freq Rng Frequency Range Inband Peak Lvl Inband Peak Level Lvl Level MP Measurement Point Mod Modulation Mode MIMO Mode Occ Ch BW Occupied Channel Bandwidth PSD Power Spectrum Density PeakPower Maximum Peak Conducted Output Power Pol Polarization Port Active Port Unwanted Freq Unwanted Emissions Frequency Unwanted Lvl Unwanted Emissions Level Competences and guarantees DEKRA Testing and Certification S.A.U. is a testing laboratory accredited by the National Accreditation Body (ENAC -Entidad Nacional de Acreditación), to perform the tests indicated in the Certificate No. 51/LE 147. DEKRA Testing and Certification S.A.U. is an FCC-recognized accredited testing laboratory with appropriate scope of accreditation that covers the performed tests in this report. DEKRA Testing and Certification S.A.U. is an ISED-recognized accredited testing laboratory, CABid: ES1909, Company Number: 4621A, with the appropriate scope of accreditation that covers the performed tests in this report. In order to assure the traceability to other national and international laboratories, DEKRA Testing and Certification S.A.U. has a calibration and maintenance program for its measu…

Text truncated - open the document above for the full version.

SAS-4 Antenna Diagram Manufacturer: GN Hearing A/S Device Type : SAS-4 Antenna type: 2192549rA Max. antenna gain: 2 dBi Frequency range 2402 – 2480 MHz Antenna construction: Integral antenna Antenna Diagram Max EIRP 10.45 dBm [120.0, 90.0] f [MHz] Max EIRP (dBm) Max EIRP Angle (Theta, Phi) 2404 10.03 [30.0, 270.0] 2440 10.45 [120.0, 90.0] 2478 10.10 [60.0, 120.0]

DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: 71728RRF.001A1 2023-08-23 Photographs EQUIPMENT FOR CONDUCTED TESTS DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: 71728RRF.001A1 Page 2 of 4 2023-08-23 EQUIPMENT FOR RADIATED TESTS DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: 71728RRF.001A1 Page 3 of 4 2023-08-23 TEST SETUP FOR RADIATED MEASUREMENTS DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: 71728RRF.001A1 Page 4 of 4 2023-08-23 TEST SETUP FOR CONDUCTED MEASUREMENTS
