X27-FS-218Point to Multipoint Licensed Wireless Broadband Data Radio

Ondas Networks Inc.
Point to Multipoint Licensed Wireless Broadband Data Radio - FCC ID X27-FS-218 - Ondas Networks Inc.
Click to zoom

Application Details

Equipment Class
TNB - Licensed Non-Broadcast Station Transmitter
Date of Grant
Jan 06, 2015
Application Purpose
Original Equipment
Date of Application
Jan 06, 2015
Equipment Note
Point to Multipoint Licensed Wireless Broadband Data Radio
Frequency Range
218.50000000 - 218.50000000
Company
Ondas Networks Inc.
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗
↗

External Photos

↗

ID Label/Location Info

↗
↗

Internal Photos

↗

RF Exposure Info

↗
↗

Test Report

↗
↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

687 N. Pastoria Avenue, Sunnyvale, CA 94085, 888-350-9994 (Main) Full Spectrum Inc. Confidential as per Non-Disclosure Agreement FullMax System User Guide February 2014, Version 4.0 Copyright © 2014 Full Spectrum Inc. All rights reserved. FullMax System User Guide: 4.0 i Copyright © 2014 Full Spectrum Inc. All rights reserved. TABLE OF CONTENTS About This Guide ........................................................................................................................ v Intended Audience ................................................................................................................. v Document Conventions .......................................................................................................... v How This Guide is Organized ................................................................................................. vi Obtaining Documentation ..................................................................................................... vi Documentation Feedback ..................................................................................................... vi Chapter 1: Overview ................................................................................................................. 1 FullMax System Architecture ................................................................................................ 2 FullMax Base Stations and Remote Stations ......................................................................... 4 FullMax Base Station ......................................................................................................... 4 FullMax Fixed Remote Stations ......................................................................................... 5 FullMax Mobile Station ..................................................................................................... 6 FullMAX Base Station and Remote Station Hardware Architecture ..................................... 7 Chapter 2: Installing the FullMax System ............................................................................... 10 Base Station Installation ...................................................................................................... 10 Single Base Station installation ........................................................................................ 10 Multiple Base Station Installation ................................................................................... 11 Indoor FS4000/FS4010 Installation ................................................................................. 11 Outdoor FS4500/FS4510 Installation .............................................................................. 12 FullMax Base Stations and Remote Station Configuration ............................................. 12 Command Line Interface (CLI) for FullMAX Base Stations .................................................. 14 General ............................................................................................................................ 14 Downlink Configuration ................................................................................................... 14 FullMax System User Guide: 4.0 ii Copyright © 2014 Full Spectrum Inc. All rights reserved. IP Address Configuration ................................................................................................. 15 CLI Commands for remote Stations .................................................................................... 16 General ............................................................................................................................ 16 Channel Acquisition Table Configuration ........................................................................ 16 IP Address Configuration ................................................................................................. 17 Installing FullMax NMS ........................................................................................................ 18 Hardware Requirements ................................................................................................. 18 Database Requirements .................................................................................................. 18 Client Requirements ........................................................................................................ 18 Install Procedure .............................................................................................................. 18 Chapter 3: Operating FullMax System .................................................................................... 19 Getting Started with FullMax NMS ..................................................................................... 19 Web Client ....................................................................................................................... 19 Invoking FullMax NMS Client ........................................................................................... 19 Logging In ......................................................................................................................... 20 Logging Out ...................................................................................................................... 21 Client User Interface ........................................................................................................ 21 Adding New Devices to the NMS database ..................................................................... 22 Configuring the FullMax System ......................................................................................... 23 Working with Profiles ...................................................................................................... 23 Creating and Editing the Base Station Configuration Profile .......................................... 23 Applying Base Station Configurations ........................…

Text truncated - open the document above for the full version.

Cover Letter(s)

Full Spectrum Inc. | 687 N. Pastoria Avenue, Sunnyvale, CA 94085 | (888) 350-9994 | fullspectrumnet.com FCC Authorization November 17, 2014 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We, Full Spectrum Inc., the undersigned, Hereby authorizes Bay Area Compliance Laboratories Corporation to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Bay Area Compliance Laboratory Corporation on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely Yours, _____________________ Stewart Kantor, CEO Full Spectrum Inc. 687 N. Pastoria Ave Sunnyvale, CA. 94085 www.fullspectrumnet.com Mobile: (650) 743 - 8945 Office: (888) 350 - 9994

Cover Letter(s)

FCC Confidential Authorization 2014/12/08 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: X27- FS-218 In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, Full Spectrum Inc., hereby requests long-term confidential treatment of information accompanying this application as outlined below:  Block Diagram  Schematics  Operation Description As well as short-term confidential treatment of information accompanying this application as outlined below:  Internal Photos  User’s Manual  Test Set-up Photos The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Stewart Kantor, CEO Full Spectrum Inc. 687 N. Pastoria Ave Sunnyvale, CA 94085 www.fullspectrumnet.com Mobile: (650) 743 – 8945 Office: (888) 350 – 9994

Cover Letter(s)

Full Spectrum Inc. | 687 N. Pastoria Avenue, Sunnyvale, CA 94085 | (888) 350-9994 | fullspectrumnet.com DECLARATION OF SIMILARITY January 6, 2015 To: Bay Area Compliance Laboratories Corp. 1274 Anvilwood Ave. Sunnyvale, CA 94089 Phone: 408‐732‐9162, Fax: 408‐732‐9164 http://www.baclcorp.com Dear Sir or Madam: We Full Spectrum Inc. hereby declare that product: FullMAX, model(s): BS1010, BS1000, FS4000 and FS4010 are identical electronically except for an additional GPS module which is present at the BS1010 and at the FS4010 but not at the BS1000 and the FS4000. All 4 devices employ the same 1U enclosure and are powered by a DC power supply. We Full Spectrum Inc. hereby declare that product: FullMAX, model(s): FS4500 and FS4510 are identical electronically except for an additional GPS module which is present at the FS4510 but not at the FS4500. The 2 devices employ the same sealed enclosure and are powered by a DC power supply. We, Full Spectrum Inc., hereby declare that products: BS1010 (BS1000, FS4000, FS4010) and FS4500 (FS4510) are internally electronically identical. We would like to apply for certification for both products under FCC ID: X27‐FS‐218. Please contact me should there be need for any additional clarification or information. Best Regards, Menashe Shahar, Full Spectrum CTO 687 N. Pastoria Ave., Sunnyvale , CA

External Photos

Full Spectrum, Inc. FCC ID: X27-FS-218 Report Number: R1410272-80 Page 45 of 53 FCC Part 80 Test Report 13 Exhibit C – EUT Photographs 13.1 EUT Photo: Top View (FS4500) 13.2 EUT Photo: Bottom View (FS4500) Full Spectrum, Inc. FCC ID: X27-FS-218 Report Number: R1410272-80 Page 46 of 53 FCC Part 80 Test Report 13.3 EUT Photo: Side View 1 (FS4500) 13.4 EUT Photo: Side View 2 (FS4500) Full Spectrum, Inc. FCC ID: X27-FS-218 Report Number: R1410272-80 Page 47 of 53 FCC Part 80 Test Report 13.5 EUT Photo: Top View (BS1010) 13.6 EUT Photo: Bottom View (BS1010) Full Spectrum, Inc. FCC ID: X27-FS-218 Report Number: R1410272-80 Page 48 of 53 FCC Part 80 Test Report 13.7 EUT Photo: Side View 1 (BS1010) 13.8 EUT Photo: Side View 2 (BS1010)

Internal Photos

Full Spectrum, Inc. FCC ID: X27-FS-218 Report Number: R1410272-80 Page 49 of 53 FCC Part 80 Test Report 13.9 EUT Photo: Open Case View (FS4500) 13.10 EUT Photo: Main Board Top View (FS4500) Full Spectrum, Inc. FCC ID: X27-FS-218 Report Number: R1410272-80 Page 50 of 53 FCC Part 80 Test Report 13.11 EUT Photo: Main Board Bottom View (FS4500) 13.12 EUT Photo: Module View (FS4500) Full Spectrum, Inc. FCC ID: X27-FS-218 Report Number: R1410272-80 Page 51 of 53 FCC Part 80 Test Report 13.13 EUT Photo: Open Case View (BS1010) 13.14 EUT Photo: Main Board Top View 1(BS1010) Full Spectrum, Inc. FCC ID: X27-FS-218 Report Number: R1410272-80 Page 52 of 53 FCC Part 80 Test Report 13.15 EUT Photo: Main Board Top View 2 (BS1010) 13.16 EUT Photo: Module View (BS1010)

RF Exposure Info

Full Spectrum, Inc. FCC ID: X27-FS-218 Report Number: R1410272-80 Page 10 of 53 FCC Part 80 Test Report 4 FCC §2.1091 - RF Exposure 4.1 Applicable Standard According to FCC §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 * (100) 30 1.34-30 824/f 2.19/f * (180/f 2 ) 30 30-300 27.5 0.073 0.2 30 300-1500 / / f/1500 30 1500-100,000 / / 1.0 30 f = frequency in MHz * = Plane-wave equivalent power density 4.2 MPE Prediction Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 S = PG/4R² Where: S = power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna 4.3 MPE Results BS1010: Maximum peak output power at antenna input terminal (dBm): 43.68 Maximum peak output power at antenna input terminal (W): 23.334 Prediction distance (cm): 150 Prediction frequency (MHz): 217.25 Maximum Antenna Gain, typical (dBi): 0 Maximum Antenna Gain (numeric): 1 Power density of prediction frequency at 20.0 cm (mW/cm 2 ): 0.0825 MPE limit for uncontrolled exposure at prediction frequency (mW/cm 2 ): 0.2 Full Spectrum, Inc. FCC ID: X27-FS-218 Report Number: R1410272-80 Page 11 of 53 FCC Part 80 Test Report FS4500: Maximum peak output power at antenna input terminal (dBm): 43.60 Maximum peak output power at antenna input terminal (W): 22.908 Prediction distance (cm): 150 Prediction frequency (MHz): 217.75 Maximum Antenna Gain, typical (dBi): 0 Maximum Antenna Gain (numeric): 1 Power density of prediction frequency at 20.0 cm (mW/cm 2 ): 0.081 MPE limit for uncontrolled exposure at prediction frequency (mW/cm 2 ): 0.2 The EUT complies with FCC MPE limit at 150 cm distance.

RF Exposure Info

Full Spectrum, Inc. FCC ID: X27-FS-218 Report Number: R1410272-95 Page 11 of 46 FCC Part 95 Test Report 5 FCC §2.1091– RF Exposure 5.1 Applicable Standard According to FCC §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 * (100) 30 1.34-30 824/f 2.19/f * (180/f 2 ) 30 30-300 27.5 0.073 0.2 30 300-1500 / / f/1500 30 1500-100,000 / / 1.0 30 f = frequency in MHz * = Plane-wave equivalent power density 5.2 MPE Prediction Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 S = PG/4R² Where: S = power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna 5.3 MPE Results BS1010: Maximum peak output power at antenna input terminal (dBm): 44.30 Maximum peak output power at antenna input terminal (W): 26.915 Prediction distance (cm): 150 Prediction frequency (MHz): 218.5 Maximum Antenna Gain, typical (dBi): 0 Maximum Antenna Gain (numeric): 1 Power density of prediction frequency at 150 cm (mW/cm 2 ): 0.0951 MPE limit for uncontrolled exposure at prediction frequency (mW/cm 2 ): 0.2 Full Spectrum, Inc. FCC ID: X27-FS-218 Report Number: R1410272-95 Page 12 of 46 FCC Part 95 Test Report FS4500: Maximum peak output power at antenna input terminal (dBm): 44.91 Maximum peak output power at antenna input terminal (W): 30.974 Prediction distance (cm): 150 Prediction frequency (MHz): 218.5 Maximum Antenna Gain, typical (dBi): 0 Maximum Antenna Gain (numeric): 1 Power density of prediction frequency at 150 cm (mW/cm 2 ): 0.1095 MPE limit for uncontrolled exposure at prediction frequency (mW/cm 2 ): 0.2 The device compliances with FCC MPE limit at 150 cm distance.

Test Report

Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. This report must not be used by the customer to claim product certification, approval, or endorsement by A2LA*, NIST, or any agency of the Federal Government. * This report may contain data that are not covered by the A2LA accreditation and are marked with an asterisk “*” (Rev.2) FCC PART 80 TEST AND MEASUREMENT REPORT For Full Spectrum Inc. 687 N. Pastoria Ave., Sunnyvale, CA 94085, USA FCC ID: X27-FS-218 Report Type: Original Report Product Type: Base Station and Remote Station Radios Prepared By Chen Ge Test Engineer Report Number R1410272-80 Report Date 2014-12-23 Reviewed By Bo Li RF Lead Bay Area Compliance Laboratories Corp. 1274 Anvilwood Avenue, Sunnyvale, CA 94089, USA Tel: (408) 732-9162 Fax: (408) 732-9164 Full Spectrum, Inc. FCC ID: X27-FS-218 Report Number: R1410272-80 Page 2 of 53 FCC Part 80 Test Report TABLE OF CONTENTS 1 General Description ..................................................................................................................................................... 5 1.1 Product Description for Equipment Under Test (EUT) ...................................................................................... 5 1.2 Mechanical Description of EUT ......................................................................................................................... 5 1.3 Objective ............................................................................................................................................................. 5 1.4 Related Submittal(s)/Grant(s) ............................................................................................................................. 5 1.5 Test Methodology ............................................................................................................................................... 5 1.6 Measurement Uncertainty ................................................................................................................................... 5 1.7 Test Facility ........................................................................................................................................................ 6 2 System Test Configuration.......................................................................................................................................... 7 2.1 Justification ......................................................................................................................................................... 7 2.2 EUT Exercise Software....................................................................................................................................... 7 2.3 Special Equipment .............................................................................................................................................. 7 2.4 Equipment Modifications.................................................................................................................................... 7 2.5 Local Support Equipment ................................................................................................................................... 7 2.6 EUT Internal Configuration Details .................................................................................................................... 7 2.7 Power Supply List and Details ............................................................................................................................ 8 3 Summary of Test Results ............................................................................................................................................ 9 4 FCC §2.1091 - RF Exposure ....................................................................................................................................... 10 4.1 Applicable Standard .......................................................................................................................................... 10 4.2 MPE Prediction ................................................................................................................................................. 10 4.3 MPE Results ..................................................................................................................................................... 10 5 FCC §2.1046 & §80.215(h) – Output Power .............................................................................................................. 12 5.1 Applicable Standard .......................................................................................................................................... 12 5.2 Test Procedure .................................................................................................................................................. 12 5.3 Test Equipment List and Details ....................................................................................................................... 12 5.4 Test Environmental Conditions ........................................................................................................................ 12 5.5 Test Results ....................................................................................................................................................... 13 6 FCC §2.1047 & §80.211 – Emission Limit ................................................................................................................. 16 6.1 Applicable Standard .......................................................................................................................................... 16 6.2 Test Procedure ................................................................................................................................................…

Text truncated - open the document above for the full version.

Test Report

Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. This report must not be used by the customer to claim product certification, approval, or endorsement by A2LA*, NIST, or any agency of the Federal Government. * This report may contain data that are not covered by the A2LA accreditation and are marked with an asterisk “*” (Rev.2) FCC PART 95 TEST AND MEASUREMENT REPORT For Full Spectrum Inc. 687 N. Pastoria Ave., Sunnyvale, CA 94085, USA FCC ID: X27-FS-218 Report Type: Original Report Product Type: Base Station and Remote Station Radios Prepared By Chen Ge Test Engineer Report Number R1410272-95 Report Date 2014-12-23 Reviewed By Bo Li RF Lead Bay Area Compliance Laboratories Corp. 1274 Anvilwood Avenue, Sunnyvale, CA 94089, USA Tel: (408) 732-9162 Fax: (408) 732-9164 Full Spectrum, Inc. FCC ID: X27-FS-218 Report Number: R1410272-95 Page 2 of 46 FCC Part 95 Test Report TABLE OF CONTENTS 1 General Description ..................................................................................................................................................... 5 1.1 Product Description for Equipment Under Test (EUT) ...................................................................................... 5 1.2 Mechanical Description of EUT ......................................................................................................................... 5 1.3 Objective ............................................................................................................................................................. 5 1.4 Related Submittal(s)/Grant(s) ............................................................................................................................. 5 1.5 Test Methodology ............................................................................................................................................... 5 1.6 Measurement Uncertainty ................................................................................................................................... 5 1.7 Test Facility ........................................................................................................................................................ 6 2 System Test Configuration.......................................................................................................................................... 7 2.1 Justification ......................................................................................................................................................... 7 2.2 EUT Exercise Software....................................................................................................................................... 7 2.3 Special Equipment .............................................................................................................................................. 7 2.4 Equipment Modifications.................................................................................................................................... 7 2.5 Local Support Equipment ................................................................................................................................... 7 2.6 EUT Internal Configuration Details .................................................................................................................... 7 2.7 Power Supply List and Details ............................................................................................................................ 8 3 Summary of Test Results ............................................................................................................................................ 9 4 FCC §95.859 – Antenna Requirement ....................................................................................................................... 10 4.1 Applicable Standard .......................................................................................................................................... 10 4.2 Antenna Description ......................................................................................................................................... 10 5 FCC §2.1091– RF Exposure ........................................................................................................................................ 11 5.1 Applicable Standard .......................................................................................................................................... 11 5.2 MPE Prediction ................................................................................................................................................. 11 5.3 MPE Results ..................................................................................................................................................... 11 6 FCC §2.1046 & §95.855 – Output Power ................................................................................................................... 13 6.1 Applicable Standard .......................................................................................................................................... 13 6.2 Test Procedure .................................................................................................................................................. 13 6.3 Test Equipment List and Details ....................................................................................................................... 13 6.4 Test Environmental Conditions ........................................................................................................................ 13 6.5 Test Results ......................................................................................................................................................…

Text truncated - open the document above for the full version.

Test Setup Photos

Full Spectrum, Inc. FCC ID: X27-FS-218 Report Number: R1410272-80 Page 41 of 53 FCC Part 80 Test Report 12 Exhibit B – Test Setup Photographs 12.1 Radiated Emission below 1 GHz Front View (FS4500) 12.2 Radiated Emission below 1 GHz Rear View (FS4500) Full Spectrum, Inc. FCC ID: X27-FS-218 Report Number: R1410272-80 Page 42 of 53 FCC Part 80 Test Report 12.3 Radiated Emission above 1 GHz Front View (FS4500) 12.4 Radiated Emission above 1 GHz Rear View (FS4500) Full Spectrum, Inc. FCC ID: X27-FS-218 Report Number: R1410272-80 Page 43 of 53 FCC Part 80 Test Report 12.5 Radiated Emission below 1 GHz Front View (BS1010) 12.6 Radiated Emission below 1 GHz Rear View (BS1010) Full Spectrum, Inc. FCC ID: X27-FS-218 Report Number: R1410272-80 Page 44 of 53 FCC Part 80 Test Report 12.7 Radiated Emission above 1 GHz Front View (BS1010) 12.8 Radiated Emission above 1 GHz Rear View (BS1010)

Contact Information

Applicant

Stewart Kantor(President)
[email protected]650-743-8945Fax: 650-743-8945

Test Firm

Bay Area Compliance Laboratories Corp.Lisa Tang
[email protected]408-732-9162Fax: 408 732 9164

Technical Specifications

#Rule PartsFrequency RangePower OutputEmissionTolerance
295F218.5 MHz - 218.5 MHz18.88 W754KW7D5 ppm
Confidentiality
Long Term
Grant Notes
Output power listed is conducted for Part 80 and EPR for Part 95. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 150cm from all persons during normal operation. RF exposure compliance may need to be addressed at the time of licensing, as required by the responsible FCC Bureau(s), including antenna co-location requirements of §1.1307(b)(3). Installers must be provided with appropriate antenna installation instructions and device operating conditions for satisfying RF exposure compliance.
