X2PCRLU-201EMERGENCY NOTIFICATION SYSTEM

Notification Cooper Notification 7565 Commerce Court Sarasota, FL 34243 Tel.: 941.487.2300 Fax: 941.487.2387 www.coopernotification.com Version 5.6.1 WAVES NETWORK CONFIGURATION TOOL ADMINISTRATOR MANUAL Part Number P01-04912-C April 2010 Cooper Notification is WAVES Network Configuration Tool Administrator Manual v5.6.1i P/N P01-04912-C COPYRIGHT Copyright © 2010, Cooper Notification, Inc. All rights reserved. Cooper Notification and its logo are trademarks of Cooper Notification, Inc. Cooper Notification, Inc., a premier supplier of MNS to the Department of Defense and U.S. government, is part of the Cooper Notification business which also includes Cooper Wheelock, Inc., Roam Secure, Inc., and MEDC. Under the copyright laws, this manual may not be reproduced in any form without the prior written consent of Cooper Notification, Inc. No patent liability is assumed with respect to the use of the information contained herein. Any use of WAVES Software is subject to and conditioned upon [your] acceptance of the Cooper Notification, Inc. software licensing agreement. TRADEMARKS WAVES and the WAVES logo are trademarks of Cooper Notification, Inc. RSAN and RSIX are products of Roam Secure, Inc. dba Cooper Notification protected by U.S. patent 7,409,428; other patents pending. HPSA, SPT, and LMD are trademarks of Cooper Notification, Inc. in the U.S.A. and other countries. Windows is a registered trademark of Microsoft, Inc. Other brands and their products are trademarks or registered trademarks of their respective holders and should be noted as such. EXPORT This document contains technical data that may be controlled under the U.S. Export Administration Regulations and may be subject to the approval of the U.S. Department of Commerce prior to export. Any export, directly or indirectly, in contravention of the U.S. Export Administration Regulation is prohibited. DISCLAIMER This manual has been reviewed for accuracy when used in conjunction with Cooper Notification authorized administrator and/or operator training. The information contained herein was accurate for the software at the time of this manual's production. Cooper Notification assumes no liability for damages incurred directly or indirectly from errors, omissions, or discrepancies between WAVES and the manual. iiWAVES Network Configuration Tool Administrator Manual v5.6.1 P/N P01-04912-C DISCLAIMER - NCT WHEN USED WITH TRX OR CRLU Changes or modifications that are not expressly approved by Cooper Notification could void the user’s right to operate the equipment. This device complies with Part 15 of the Federal Communications Commission (FCC) Rules. Operation is subject to the following two conditions: •This device may not cause harmful interference. •This device must accept any interference received, including interference that may cause undesired operation. The following table (Table FR.1) contains a list of the approved antennae for use with a TRX or CRLU. Antenna installation is limited to those listed in Table FR.1 and may only be installed by a professional. TABLE FR.1 Antennae Approved for Use DescriptionCooper P/NManufacturer Manufacturer Part Number Antenna, 9DBI, OmnidirectionalA01-02255Mobile MarkOD9-2400 Antenna, Omni-directional, 15 DBI A01-02257Hyperlink TechnologiesHG2415U-PRO Antenna, Directional, 8DBIA01-02259Hyperlink TechnologiesRE09P-NM Antenna, Omnidirectional, 3DBIA01-02260Hyperlink TechnologiesHG2403RD-NM Antenna, Omni, 6DBIA01-02820MaxradMFB24006 Antenna, 2.4GHZ 15DBI, GRID, N-FEM CON A01-02856Hyperlink TechnologiesHG2415G-NF Antenna, 2.4 GHZ, 13.9 DBI, YAGI A01-02859Laird TechnologiesPC2415N Antenna, 2.4GHZ, 15DBI, YAGI, N-FEMALE A01-02860Hyperlink TechnologiesHG2415Y-NF Antenna, Fixed, 15DBIA03-02416Hyperlink TechnologiesHG2416P WAVES Network Configuration Tool Administrator Manual v5.6.1iii P/N P01-04912-C SAFETY SUMMARY Safety Notices, Warnings, and Cautions must be applied during operation and maintenance of the equipment. If situations arise that are not covered in the General Safety Notices, Warnings, or Cautions the local authority will issue instructions as deemed necessary to resolve the situation. GENERAL SAFETY NOTICES The following safety notices supplement the specific Warnings and Cautions found throughout this manual. •Equipment must be clear of all power lines, wires, and electrical obstructions at all times. •Ensure that precautionary measures are employed to prevent applying power to equipment at any time maintenance work is in progress. •Do not touch electronic components with wet hands. •Do not make any unauthorized alterations to equipment or components. •Do not wear loose clothing while working around rotating parts of machinery. •When working near electricity do not use metal rules, flashlights, metallic pencils, or any other object having exposed conducting material. •When possible, avoid installing equipment during severe or wet conditions. Handling equipment with wet hands may cause slippage resulting in bodily injury and/or damage to equipment. •Ensure the area is well ventilated when using cleaning, gasoline, and oil products. Avoid prolonged breathing of fumes which may cause physical harm. •Proper personal protective equipment (PPE) should be used when changing a battery. This equipment includes acid resistant gloves, and safety glasses, as well as proper body acid-resistance coverings and safety shoes. OPERATING RESPONSIBILITIES It is the responsibility of the owner and/or operator of the product to ensure the following. •The equipment is correctly and safely installed. •When installed, the equipment fully complies with federal, state, and local codes. •Any person operating this equipment has been properly trained. •Any person who has not been trained on the safe use of this equipment does not have access to it. C Circuit boards are electrostatic sensitive. All Electrostatic Discharge (ESD) sensitive components contain solid state circuits that may become damaged when contacted wit…

Text truncated - open the document above for the full version.

Part number: A01-02255 Revision: A F-730-013D (Oct 08) Source/Specification Control Document Description: Antenna, 9dBi, Omnidirectional Prepared by: Tim Bliss Date: Signed: Tim Bliss Checked by: Date: Signed: Configuration Manager: Date: Signed: Approved by: Alex Parnes Engineering Manager approval only required for items over $500.00 (ex. Speakers, antennas, circuit board assemblies) Date: Signed: Alex Parnes 1. Specifications The item shall be one of the following: Manufacturer Manufacturer’s Part Number Reference Mobile Mark OD9-2400 See Attached TESSCO 41525 See Attached 2. Engineering approved equivalents only? Yes No If YES is checked, only items approved by Engineering as equivalent can be used. If NO is checked, Engineering approval is not required to use equivalent items. 3. Inspection / Acceptance Test Receiving inspection is limited to verification that items are received as ordered. No testing is required. SCD Revision History Rev. Effective Date Change Reference Engineer - Dec. 1, 2003 Initial Release Tim Bliss A Nov. 3, 2008 No change. Rev clarification for MRP implementation only Raylon Smith Form Revision History Rev. Effective Date Change Reference Engineer D October 20, 2008 Initial Release P. Lehman/L.Prymmer 35 Length/Weight: 3 dBi Models16 inches, 1.5 lbs 6 dBi Models19 inches, 1.5 lbs 9 dBi Models27 inches, 2.0 lbs 12 dBi Model41 inches, 2.5 lbs OD Series Interface:N female connector Mounting Kit:Mast mount kit included Mounting Dimensions:Use mast up to 2" OD Material:Polycarbonate with aluminum body, fiberglass radome on OD12 with aluminum body Options:Reflector Option Kit Pigtail Cable Option Part 15 Reverse Connectors
3 dBi, 6 dBi, 9 dBi & 12 dBi antennas provide uniform omni coverage
Unique design allows economical build out
Mounting kit includes all hardware needed
Reflector option provides directional beamshaping & increased performance OD Series Omni Antenna For WLAN, Video and Data Systems The OD Series Antennas are optimized for use in a wide variety of wireless systems. Typical uses include WLAN access points or bridge (802.11b/g), and surveillance transmitters. These antennas consist of a collinear array with elements stacked vertically. Unique phasing cancels out-of-phase current distribution, improving system performance. This design maintains an omni pattern in the horizontal plane. The OD Series are free space antennas; no ground plane is required. An option for the OD series is a reflector kit that beam shapes the omni pattern into a directional cardioid shape. This can result in improved directional gain, and isolation for reduced interference. The low profile black radome (1" diameter) makes the antennas durable and rugged. They can withstand the harshest environments of snow, wind, rain and ice. The feed assembly is made of precision machined aluminum components and is irridited for weather protection. The antennas comes with all the hardware needed to install it to a mast. The OD antennas normally terminate with a Specifications Frequency & Gain:See above Bandwidth @2:1 VSWR:See above Nominal Impedance:50 ohms Max. Power (continuous):100 watts Vertical Beamwidth (-3 dB point): 3 dBi Model55 degrees 6 dBi Model25 degrees 9 dBi Model14 degrees 12 dBi Model 7 degrees Wind Loading (flat plate equiv.):30-40 sq. inches Rated Wind Velocity:100+ mph Lightning Protection:External suggested Antenna Diameter:1", main mast female N connector. Optional models include pigtail cable with connector. For ISM, Part 15 compliant connectors are available (reverse polarized), please consult factory. Model Numbers ModelFreq.(MHz)GainApplications OD3-24002400-24853 dBiWLAN, ISM, Video OD6-24002400-24856 dBiWLAN, ISM, Video OD9-24002400-24859 dBiWLAN, ISM, Video OD12-24002400-2485 12 dBiWLAN, ISM, Video For pigtail cable options and special frequencies, please consult factory for latest model numbers and configurations. OptionsModel Add-on kit for 6 dBi modelsODR6-Kit Add-on kit for 9 dBi modelsODR9-Kit Add-on kit for 12 dBi modelsODR12-Kit Rev TNC with 1 ft Cable option add -PTA to OD model Rev BNC with 4 ft Cable option add -PT2 to OD model OD9, OD12, OD6 Shown OD9 Mounted & Reflector Kit Product Specifications US Office & Headquarters: 3900-B River Road, Schiller Park, IL 60176 Tel: 800-648-2800 or 847-671-6690 Fax: 847-671-6715 UK Office: 106 Anglesey Business Park, Hednesford, Staffs. WS12 5NR UK Tel: (+44) 1543-878343 Fax: (+44) 1543-871714 Visit our web page at www.mobilemark.com. Specifications subject to change without notice (2/2002). July 22, 2005 Log In User Name: Password: F R Product Search Keyword(s) TESSCO Part No Manufacturer Part No. Advanced Search Network InfrastructureMobile Devices & AccessoriesInstall, Test Antennas & Antenna Systems Transmission Line & Cable Tower & Site Support Telco Interface & In-Building Support Wireless Broadband Phone Accessories Two-way Radios & Accessories Data, Messaging & Location Systems Antennas, Mounts & Vehicle Equipment Site & Netwo Bench Test Work Enviro Electrical Su Repair Parts Knowledge for fast, optimum decision makin g Find & Compare Products Product Listin g What's New Publications & Events Technical Support Trainin g and Services Government Configuration of kits and products for immediate use BUY PRODUCTS Worksheet List Worksheets List Kits Application Illustrations Repair Parts & Components Phone Accessories TESSCO Outlet Delivery of what you need, when and where you need it Order Status Track Deliver y PDG (Performance Delivery Guarantee) Control of the total supply chain process and costs Print Invoices Review Order Histor y Edit Your Preferences Returns Credit & Finance Everything for Designing, Building, Running, Maintaining or Using Wirele Antennas, Microwave Products (See more) 2400-2500 MHz Fiberglass/Omni Antennas [345-61] (See View W Please LOGIN to see the "Add to Worksheet" button. Manufacturer Mobile Mark, Inc. Table OD9-2400 TESSCO Part No. 41525 In Stock Drawing Specific Freq. (MHz) 24…

Text truncated - open the document above for the full version.

Test Report No. 09F470 Product Safety Engineering Inc., 12955 Bellamy Brothers Blvd., Dade City Florida 33525 (352)-588-2209http://www.pseinc.com Page 2 of 32 Product Description The product under test is a (2.4) GHz frequency hopping spread spectrum transceiver. The product under test is one in a family of similar products. The test sample chosen for this testing represented the product configuration that was most likely to pose of the testing was to demonstrate compliance with the test standards listed Environmental conditions during testing The ambient temperature during the testing was within the range of (50 - 104 F). oo The humidity levels during the testing was within the range of (10% - 90%) relative humidity Power supply system: 120 Volts 60 Hz SINGLE phase Test Results Summary TestRequirementMeasuredPass/FailData Page(s) Powerline conducted emissionsTable 1See dataPass12-13 Carrier frequency separation=> 490 kHz1.02 MHzPass14 Number of Hopping Frequencies >75 for 1 watt <75 for 0.125 watts 76Pass15-16 Time of Occupancy<400 mS within 30.4 S period 181.56 mSPass17 Peak Output Power< 125.89 mW (w/15 dBi antenna) 125.89 mWPass18-19 Spurious conducted emissions=>20 dB down> 20 downPass20-29 Spurious radiated emissions< 54 dBuV/m44.7 dBuV/mPass30 20 dB bandwidthNone490 kHzPass31-32 RF Exposure 1.0 mW / cm 0.79 2 mW / cm Pass 8 2 Revision History RevisionDateDescription ---12/15/2009Initial Release Test Report No. 09F470 Product Safety Engineering Inc., 12955 Bellamy Brothers Blvd., Dade City Florida 33525 (352)-588-2209http://www.pseinc.com Page 3 of 32 Test Procedures All measurements are made in accordance with ANSI C63.4:2003 •Powerline conducted interference: 15.207 Requirement - the radio frequency voltage that is conducted back onto the AC power line on any frequency or frequencies, within the band 150 kHz to 30 MHz, shall not exceed the limits in the following table, as measured using a 50 mH/50 ohms line impedance stabilization network (LISN). Compliance with the provisions of this paragraph shall be based on the measurement of the radio frequency voltage between each power line and ground at the power terminal. The lower limit applies at the boundary between the frequency ranges. Table 1 Freq. (MHz)Conducted limit PeakConducted limit (QP) 0.15 - 0.566 to 56*56 to 46* 0.5 - 55646 5 - 306050 * Decreases with the logarithm of the frequency. Procedure -Tabletop devices shall be placed on a platform of nominal size, 1 m by 1.5 m, raised 80 cm above the reference groundplane. The vertical conducting plane or wall of a screened room shall be located 40 cm to the rear of the EUT. Floor-standing devices shall be placed either directly on the reference groundplane or on insulating material. All other surfaces of tabletop or floor-standing EUTs shall be at least 80 cm from any other grounded conducting surface, including the case or cases of one or more LISNs. AC powerline adapters that are used with EUTs such as laptop or notebook computers should be placed as typically used, i.e., on the tabletop if the adapter-to-EUT cord is too short to allow the power adapter to reach the floor. Each current-carrying conductor of the EUT power cord(s), except the ground (safety) conductor(s), shall be individually connected through a LISN to the input power source. All 50 S ports of the LISN shall be resistively terminated in 50 S when not connected to the measuring instrument. When the test configuration is comprised of multiple units (EUT and associated/peripheral equipment, or EUT consisting of multiple equipment) that have their own power cords, ac powerline conducted emissions measurements shall be performed with the ac powerline cord of the particular unit under test connected to one LISN that is connected to the measuring instrument. Those power cords for the units in the remainder of the configuration not under measurement shall be connected to a LISN different from the LISN used for the power cord of the portion of the EUT being measured. This connection may be made using a multiple receptacle device. Test Report No. 09F470 Product Safety Engineering Inc., 12955 Bellamy Brothers Blvd., Dade City Florida 33525 (352)-588-2209http://www.pseinc.com Page 4 of 32 Emissions from each current-carrying conductor of the EUT shall be individually measured. Where multipleportions of the EUT receive ac power from a common power strip, which is furnished by the manufacturer as part of the EUT, measurements need only be made on the current-carrying conductors of the common power strip. Adapters or extension cords connected between the EUT power cord plug and the LISN power receptacle shall be included in the LISN setup such that the calibration of the combined adapter or extension cord with an adapter and the LISN meets the requirements. If the EUT is comprised of a number of devices that have their own separate ac power connections, e.g., a floor- standing frame with independent power cords for each shelf, that are able to connect directly to the ac power network, each current-carrying conductor of one device is measured while the other devices are connected to a second (or more) LISN(s). All devices shall be separately measured. If a power strip is provided by the manufacturer, to supply all of the devices making up the EUT, only the conductors in the common power cord to the power strip shall be measured. If the EUT is normally operated with a ground (safety) connection, the EUT shall be connected to the ground at the LISN through a conductor provided in the lead from the ac power to the LISN. The excess length of the power cord between the EUT and the LISN receptacle (or ac power receptacle where a LISN cannot be used), or an adapter or extension cord connected to and measured with the LISN, shall be folded back and forth at the center of the lead to form a bundle not exceeding 40 cm in length. If the EUT does not have a flexible power lead, the EUT shall be placed at a distance of 80 cm from the LI…

Text truncated - open the document above for the full version.
