X2TUSS-AMBLADE58 kHz Pedestal

BLADE MANUAL Software Version 39.6 Document Version 1.14 Date 25 J anuary 2015 1. G10V SYSTEM OVERVIEW.....................................................................................................................................4 1.1. DESCRIPTION................................................................................................................................................4 1.2. SPECIFICATIONS............................................................................................................................................4 1.2.1. TRANSCEIVER.......................................................................................................................................4 1.2.2. RECEIVER..............................................................................................................................................4 1.2.3. POWER SUPPLY....................................................................................................................................4 1.3. TABLE: SYSTEM / DETECTION / NOISE............................................................................................................5 2. HARDWARE..........................................................................................................................................................6 2.1. TRANSCEIVER BOARD...................................................................................................................................6 2.2. RX BOARD....................................................................................................................................................7 2.3. POWER SUPPLY.............................................................................................................................................8 3. QUICK TUNING.....................................................................................................................................................9 3.1. QUICK INSTALLATION....................................................................................................................................9 3.1.1. PREVIOUS............................................................................................................................................9 3.1.2. SYSTEM INSTALLATION.........................................................................................................................9 3.2. TROUBLESHOOTING.....................................................................................................................................9 3.2.1. NO DETECTION.....................................................................................................................................9 3.2.2. TOO MUCH DETECTION........................................................................................................................9 3.2.3. FALSE ALARM.......................................................................................................................................9 3.2.4. MAKES OTHER SYSTEMS FALSE ALARM.................................................................................................9 3.3. SYNCHRONIZATION PROBLEM.....................................................................................................................10 3.4. NOISE PROBLEM.........................................................................................................................................11 3.5. DEAD TRANSMITTER...................................................................................................................................13 3.6. DEAD RECEIVER..........................................................................................................................................14 3.7. FALSE ALARM (OR UNKNOWN ALARM).......................................................................................................15 4. CONFIGURATION................................................................................................................................................16 4.1. CONNECTION METHOD...............................................................................................................................16 4.1.1. ANTENNA CABLES AND CONNECTION.................................................................................................16 MATERIAL....................................................................................................................................................16 PROCESS......................................................................................................................................................16 4.1.2. POWER SUPPLY CABLE AND CONNECTION...........................................................................................17 MATERIAL....................................................................................................................................................17 PROCESS......................................................................................................................................................17 4.2. CONFIGURATION EXAMPLES.......................................................................................................................18 4.2.1. TRANSCEIVER BOARDS.......................................................................................................................18 4.2.2. RECEIVER BOARDS..............................................................................................................................18 4.2.3. DUAL SYSTEM CONFIGURATION (RX-TX)..............................................................................................19 4.2.4. SPLIT SYSTEM CONFIGURATION (RX-TX-RX).........................................................................................20 5.SOFTWARE.........................................................................................…

Text truncated - open the document above for the full version.

Report Number: B50406A1 FCC Part 15 Subpart B and FCC Section 15.209 Test Report 58 kHz Pedestal System Model: USS-BLADE Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 17 FCC PART 15, SUBPART B and C TEST REPORT for 58 kHz PEDESTAL SYSTEM MODEL: USS-BLADE Prepared for UNIVERSAL SURVEILLANCE SYSTEMS, LLC 11172 ELM AVENUE RANCHO CUCAMONGA, CALFORNIA 91730 Prepared by:_____________________ KYLE FUJIMOTO Approved by:____________________ JAMES ROSS COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: MAY 18, 2015 REPORT APPENDICES TOTAL BODY A B C D E PAGES 17 2 2 2 12 17 52 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B50406A1 FCC Part 15 Subpart B and FCC Section 15.209 Test Report 58 kHz Pedestal System Model: USS-BLADE Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 17 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 5 1. PURPOSE 6 2. ADMINISTRATIVE DATA 7 2.1 Location of Testing 7 2.2 Traceability Statement 7 2.3 Cognizant Personnel 7 2.4 Date Test Sample was Received 7 2.5 Disposition of the Test Sample 7 2.6 Abbreviations and Acronyms 7 3. APPLICABLE DOCUMENTS 8 4. DESCRIPTION OF TEST CONFIGURATION 9 4.1 Description of Test Configuration - Emissions 9 4.1.1 Cable Construction and Termination 9 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 10 5.1 EUT and Accessory List 10 6. TEST SITE DESCRIPTION 12 6.1 Test Facility Description 12 6.2 EUT Mounting, Bonding and Grounding 12 7. TEST PROCEDURES 13 7.1 RF Emissions 13 7.1.1 Radiated Emissions (Spurious and Harmonics) Test – Lab A 13 7.1.2 Conducted Emissions Test 15 7.1.3 RF Emissions Test Results 16 8. CONCLUSIONS 17 Report Number: B50406A1 FCC Part 15 Subpart B and FCC Section 15.209 Test Report 58 kHz Pedestal System Model: USS-BLADE Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 17 LIST OF APPENDICES APPENDIX TITLE A Laboratory Accreditations and Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagrams and Charts  Test Setup Diagrams  Antenna and Effective Gain Factors E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Plot Map And Layout of Radiated Site 2 Conducted Emissions Test Setup LIST OF TABLES TABLE TITLE 1.0 Radiated Emission Results 2.0 Conducted Emission Results Report Number: B50406A1 FCC Part 15 Subpart B and FCC Section 15.209 Test Report 58 kHz Pedestal System Model: USS-BLADE Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 17 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product certification, approval or endorsement by NVLAP, NIST or any agency of the federal government. Device Tested: 58 kHz Pedestal System Model: USS-BLADE S/N: N/A Product Description: See Expository Statement. Modifications: The EUT was not modified during the testing. Customer: Universal Surveillance Systems, LLC 11172 Elm Avenue Rancho Cucamonga, California 91730 Test Date: April 6, 2015 Test Specifications : Emissions requirements CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.207, and 15.209. Test Procedure: ANSI C63.4 Test Deviations: The test procedure was not deviated from during the testing. Report Number: B50406A1 FCC Part 15 Subpart B and FCC Section 15.209 Test Report 58 kHz Pedestal System Model: USS-BLADE Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 17 SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Spurious Radiated RF Emissions, 10 kHz – 1,000 MHz (Transmitter and Digital portion) Complies with the Class A limits of CFR Title 47, Part 15 Subpart B; and the limits of CFR Title 47, Part 15, Subpart C, section 15.205 and 15.209 2 Conducted RF Emissions, 150 kHz to 30 MHz Complies with the Class A limits of CFR Title 47, Part 15 Subpart B; and the limits of CFR Title 47, Part 15, Subpart C, section 15.207. Report Number: B50406A1 FCC Part 15 Subpart B and FCC Section 15.209 Test Report 58 kHz Pedestal System Model: USS-BLADE Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake For…

Text truncated - open the document above for the full version.

HOW THE EUT MEETS THE REQUIREMENTS OF 15.31 (e) FOR THE UNIVERSAL SURVEILLANCE SYSTEMS, LLC 58 kHz PEDESTAL SYSTEM MODEL: USS-BLADE, FCC ID: X2TUSS-AMBLADE The fundamental was maximized on the Lab A test site using a normal test setup with the AC Adapter of the laptop connected directly to the AC public mains (115 Vac). Next, the power supply of the EUT was then connected to the Staco Energy Products Variable Auto Transformer Model: 3PN1010. The Variable Auto Transformer allows the Vac input to be varied. The AC Adapter of the laptop was then connected to the Staco Energy Products Variable Auto Transformer Model: 3PN1010. The AC input was then dropped to 85% (97.75 Vac) and raised to 115% (132.25 Vac). The actual AC input was measured using a calibrated Fluke Multimeter Model: 87, Serial Number: 58450372, Calibration Due Date: May 22, 2015. The fundamental was then verified again to see that the amplitude did not change. Test Result: The EUT does NOT change amplitude at the fundamental when the AC input voltage is varied between 85% and 115% of the input nominal rated supply voltage.
