X2TUSS-POWER4-A00Power 4 System

USS POWER OF 4™ Contents • About this Guide • Limitation of Warranty • System Overview • Materials Required • Installation Requirements • Set up Procedure • Specifications • Declarations About this Guide This User’s Guide provides functional overview of the Power of 4™ along with the Installation Requirements and Setup Procedure for the User. Limitation of Warranty Any deviations from the materials or procedures specified herein shall void the warranty of Universal Surveillance System with the owner/buyer. In no event shall Universal Surveillance Systems be liable for loss or damage caused by the use of materials or procedures that do not meet the specifications of Universal Surveillance Systems. Innovative Security Solutions User’s Guide . USS Products\Power of 4™\User’s Manual Page 1 System Overview The Power of 4™ is an advanced EAS System with early detection tools. It provides four levels of security, which include: • EAS Technology: The System has advanced Acousto-Magnetic Technology detection designed to detect 58 KHz hard tags and labels. Audible and visual alarms are provided for the detection. • Booster Bag/Foil Lined Bag Detection: The System includes an early detection system that triggers an alarm when a Booster Bag/Foil Lined Bag is detected. Once the Booster Bag/Foil Lined Bag is detected within the detection range, the system alerts store personnel via one or several optional notification devices. • Magnet Detection: The third level of security allows the Power of 4™ to detect when Magnetic Detachers are illegally brought into the store. • Anti-Jamming Circuit: The Power of 4™ has an intelligent anti-jamming feature which detects EAS jamming devices affecting the Power of 4™ System. Materials Required For all Power of 4™ installations, the following materials should be prepared prior to an install, in addition to basic required tools and parts: • Cables – 45 ft maximum length (to connect pedestals with control box ) • USB Dongle (to establish connection between control box and computer) • Ethernet Cable and Connector Unit (to establish Internet connection, if applicable) • Computer or Laptop (should be loaded with ‘AM Application’ Software) • CAT5 Cables (to extend alarm outputs for Voice Annunciation purpose) • 2 Low Power Transformers, 15 VAC (for Booster and Magnet Detection Systems) • Booster Bag/Foil Lined Bag, Magnetic Detacher, AM Tags, and Jammer Device (to be used for testing purpose) • Digital Multimeter Installation Requirements It is strongly recommended that a Site Survey is performed prior to the actual installation. The Survey should include pictures, actual measurements and special notes about the location. The survey enables the installer/technician to select a good location for system installation. In addition to a Site Survey, the installer/technician should also consider the following requirements: • Verify that all equipments, tools and parts have arrived in good condition, and be able to select a proper system configuration for the installation site. USS Products\Power of 4™\User’s Manual Page 2 Figure 1. USS Power of 4™ • Check the Store’s electrical supply: There should be a minimum of 4 outlets for the AM Control Box while the Electrical Line should be a dedicated 110V AC @ 60Hz. Neutral to ground voltage check should be a maximum of 0.5 VAC. WARNING! Do not install this product in hazardous areas where highly combustible or explosive products are stored or used. WARNING—RISK OF ELECTRIC SHOCK! The AC power line could be carrying 110VAC. • The Location of the Power of 4™ control box should be at maximum of 45 "cable" ft length from each pedestal. Shorter lengths are preferred and will contribute to better response of the system. USS Products\Power of 4™\User’s Manual Page 3 • Ensure good detection of all subsystems (EAS System, Booster Bag/Foil Lined Bag System, Magnet and Jammer Detector) before mounting pedestals to the ground. Spacing between pedestals should be from 5 to 6 ft and keeping appropriate distance between pedestals and doors. Power cables, computers, mirrors, and other big metal objects may affect the system operation so it is advisable to keep the pedestals away from these materials as much as possible. • Bolt the pedestals to the floor and install the cables. Pull cords should be provided in the conduit/wire trench from each pedestal location to adjacent pedestals, and from each pedestal to the control box location. • Conduit/wire trench from each pedestal will carry four (4) CAT5 low voltage signal and sync cables; the cables should originate from each pedestal and terminate near the dedicated line outlets. All pedestals can share a common conduit/wire trench, but it should be big enough to accommodate the increased number of cables. Set up Procedure • Check for correct connections of all the cables before turning the EAS System power ON. • Establish the connection between the Control Box and Computer (or laptop) using a USB Dongle. • Load the AM Application Software; then, connect the system with software by searching for an appropriate COM Port. • Set up the configuration using the software; select a proper system configuration from 8 available options (from the drop down menu) that you wish to install and confirm it by clicking ‘Set Config’. According to the chosen configuration, a picture with description of individual transmit and receive pedestal will be displayed on the computer screen. • Check the correct tuning of TX antennas and adjust the jumpers of the tuning capacitor board “TX_CAPS” for fine-tuning of TX loop into resonance, if necessary. • Factory setting of TX1 and TX2 power is 200, which is the maximum specified limit for the transmitter power. • Check for good synchronization with other systems (window “Sync”) from surroundings. If interference is seen, use “Auto Sychro” to synchronize the system with surrounding AM Systems automatically. To activate this function, it is necessary to start loading the signals fr…

Text truncated - open the document above for the full version.

uSSCORPORATION • November 6, 2009 CETCB .~ 114 Olinda Drive Brea, CA 92823 Gentlemen: This is a letter of authorization to accept Compatible Electronics, Inc. and its employees as Agent for USS Corporation, located at 11172 Elm Ave, Rancho Cucamonga, CA 91730, for a period of one (1) year, to sign applications and make representations before the Federal Communication Commission, and to receive and exchange data between our company and the Federal Communication Commission only in connection with the certification ofthe followingUSS Corporation product: Electronic Article Surveillance System (EAS System) under FCC Docket Number 20780 and General Docket Number 80-284 pursuant to Part 15 of FCC Rules and Regulations. Please also accept this letter as an attestation that neither USS Corporation nor any of its officers, directors, or persons holding 5% or more of the outstanding stock or shares, voting or non-voting, have been denied federal benefits under section 5301 of the Anti­ Drug-Abuse act of 1988,21 U.S.C. 853(a). In addition, USS Corporation will notify the Federal Communications Commission if, at any time, the situation changes causing USS Corporation to be denied federal benefits. If you have any further questions or need additional information, please feel free to give me a call at 1-800-488-9097. Sincerely, Adel Sayegh President & CEO INTELLIGENT SECURITY SOLUTIONS 11172 Elm Avenue • Rancho Cucamonga, CA 91730 • Tel: 909.484.7870 • 800.488.9097 • Fax: 909.484.7874 • www.universaleas.com

USSCORPORATION January 8, Z010 Compatible Electronics TCB 114 Olinda Drive Br~California 92823 Subject: TCB application submittal Gentlemen: We, USS Corporation, would like to declare that the application being submitted for the device with FCC ID: XZTUSS-POWER4-AOO has not been submitted to another TCB or FCC for certification. Ifyou hfi.ve any questi()os, please do not he~itate to <;ontact us at 1-800-488-9097. Sincerely, . €C·~ Adel Sayegh President & CEO • -INTELLIGENT SECURITY SOLUTIONS 11172 Elm Avenue • Rancho Cucamonga, CA 91730 • Tel: 909.484.7870 • 800.488.9097 • Fax: 909.484.7874 • wvvw.universaleas.com

USSCORPORATION • January 8.2010 Compatible Electronics TCB 114 Olinda Drive Brea, Califomra 92823 Subject: Modifications to the device CETCB 114 Olinda Drive Brea, CA 92823 Gentlemen: This letter is to ·formally notify you that the following modification had been completed by Compatible Electronics; Inc. to our Power of 41M USS-POWER4-A VO.O during FCC certification, and will be implemented in production. Modification: Add a Clamp Filter on to the Power Cable of the Controller Unit. The Clamp Fllter, Part No. ECRH-(AE03-B, manufactured by Coils Electronic Co. Ltd. will be added on to the Power Cable of the device Controller Unit. \,c.t reIY , <S=­7S?C:::-z: =s--- Adel Sayegh President & CEO INTELLIGENT SECURITY SOLUTIONS 11172 Elm Avenue • Rancho Cucamonga, CA 91730 • Tel: 909.484.7870 • 800.488.9097 • Fax: 909.484.7874 • www.universaleas.com

usSCORPORATION ( • November 6, 2009 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Subject: Request for withholding from public disclosure the schematics, block diagrams, and operational description pursuant to an application for certification Gentlemen: We, USS Corporation, would like to request that all schematics, block diagrams, and operational descriptions submitted with the application for certification be withheld from public disclosure as per Section 0.459 of FCC Rules. This request is made under the provisions of Section 0.457 (d) of the Commission's Rules, and Section 552 (b)(4) of the Freedom oflnformation Act. These sections authorize the withholding from public inspection, those materials which would be privileged as a matter of law if retained by the person submitting them, and materials which would not customarily be released to the public by that person. Ifyou have any questions, please do not hesitate to contact us at 1-800-488-9097. Sincerely, Adel Sayegh President & CEO INTELLIGENT SECURITY SOLUTIONS 11172 Elm Avenue • Rancho Cucamonga, CA 91730 • Tel: 909.484.7870 • 800.488.9097 • Fax: 909.484.7874 • www.universaleas.com

1 Scott McCutchan From: Scott McCutchan [[email protected]] Sent: Friday, April 09, 2010 9:59 AM To: '[email protected]' Cc: '[email protected]'; 'Jeff Klinger' Subject: FCC ID: X2TUSS-POWER4-A00 Mr. Fujimoto: In order for processing of this certification application (FCC ID: X2TUSS-POWER4-A00) to continue, the following issue(s) will have to be addressed: 1) The document submitted as the operational description is the reference manual, for which confidentiality is requested. It appears as thou gh this reference manual would be distributed to the end user of the device, and therefore could not be held confidential. Please justify how this document qualifies for confidentiality under the FCC’s policies (CFR 47, Section 0.459). 2) The internal photos must show the internal construction of the device. The photos submitted show only the front and back of each board. Please submit additional photos. 3) Since the device was modified during the testing, please submit a letter from the applicant, stating that the modifications will be implemented into all manufactured units. The item(s) indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 60 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Please upload responses and/or exhibits to the electronic filing website. Your correspondence number is X2TUSS-POWER4-A00-1. Best regards, Scott McCutchan Operations Manager Compatible Electronics TCB

Correspondence by Project Project Number: 1265945693 Correspondence Number Memo X2TUSS-POWER4-A00- 1 1) The document submitted as the operational description is the reference manual, for which confidentiality is requested. It appears as though this reference manual would be distributed to the end user of the device, and therefore could not be held confidential. Please justify how this document qualifies for confidentiality under the FCC’s policies (CFR 47, Section 0.459). Response: The Reference Manual which is submitted as the Operational Description, is intended for internal use only and will not be distributed to the end user therefore, USS Corporation prefers the reference manual to be ‘Confidential’. 2) The internal photos must show the internal construction of the device. The photos submitted show only the front and back of each board. Please submit additional photos. Response: The internal photos showing the internal construction have been uploaded. 3) Since the device was modified during the testing, please submit a letter from the applicant, stating that the modifications will be implemented into all manufactured units. Response: The modification letter has been uploaded. The item (s) indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 60 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Please upload responses and/or exhibits to the electronic filing website. Your correspondence number is X2TUSS- POWER4-A00-1.

The label size is 20x50mm and will be installed as described in picture below: 58 KHz Transmitter (FCC ID: X2TUSS-POWER4-A00) FCC ID: X2TUSS-POWER4-A00 This device complies with Part 15 of the FCC Rules. Operation is subjected to the following two conditions: (1) This device may not cause harmful interference and (2) This device must accept any interference received, including interference that may cause undesired operation.

Report Number: B91216A1 FCC Part 15 Subpart B and FCC Section 15.209 Test Report Power 4 System Model: USS-POWER4-A Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 16 FCC PART 15 SUBPART B and C TEST REPORT for POWER 4 SYSTEM Model: USS-POWER4-A Prepared for UNIVERSAL SURVEILLANCE SYSTEMS CORPORATION 11172 ELM AVENUE RANCHO CUCAMONGA, CALIFORNIA 91730 Prepared by:_____________________ KYLE FUJIMOTO Approved by:____________________ MICHAEL CHRISTENSEN COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: JANUARY 7, 2010 REPORT APPENDICES TOTAL BODY A B C D E PAGES 16 2 2 2 15 36 73 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B91216A1 FCC Part 15 Subpart B and FCC Section 15.209 Test Report Power 4 System Model: USS-POWER4-A Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 16 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 4 1. PURPOSE 5 2. ADMINISTRATIVE DATA 6 2.1 Location of Testing 6 2.2 Traceability Statement 6 2.3 Cognizant Personnel 6 2.4 Date Test Sample was Received 6 2.5 Disposition of the Test Sample 6 2.6 Abbreviations and Acronyms 6 3. APPLICABLE DOCUMENTS 7 4. DESCRIPTION OF TEST CONFIGURATION 8 4.1 Description of Test Configuration – EMI 8 4.1.1 Cable Construction and Termination 9 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 10 5.1 EUT and Accessory List 10 5.2 EMI Test Equipment 11 6. TEST SITE DESCRIPTION 12 6.1 Test Facility Description 12 6.2 EUT Mounting, Bonding and Grounding 12 6.3 Facility Environmental Characteristics 12 7. TEST PROCEDURES 13 7.1 Conducted Emissions Test 13 7.2 Radiated Emissions (Spurious, Fundamental, and Harmonics) Test 14 8. CONCLUSIONS 16 Report Number: B91216A1 FCC Part 15 Subpart B and FCC Section 15.209 Test Report Power 4 System Model: USS-POWER4-A Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 16 LIST OF APPENDICES APPENDIX TITLE A Laboratory Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagram, Charts, and Photos • Test Setup Diagram • Antenna and Amplifier Factors • Radiated Emissions Photos E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Conducted Emissions Test Setup For Floor Standing Units 2 Conducted Emissions Test Setup For Tabletop Units 3 Plot Map and Layout of the Radiated Test Site Report Number: B91216A1 FCC Part 15 Subpart B and FCC Section 15.209 Test Report Power 4 System Model: USS-POWER4-A Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 16 GENERAL REPORT SUMMARY Compatible Electronics Inc. generates this electromagnetic emission test report, which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP, NIST or any other agency of the U.S. Government. Device Tested: Universal Surveillance Systems Corporation Model: USS-POWER4-A S/N: N/A Product Description: See Expository Statement Modifications: The EUT was modified in order to meet the specifications. Please see list located in Appendix B. Customer: Universal Surveillance Systems Corporation 11172 Elm Avenue Rancho Cucamonga, California 91730 Test Date(s): December 14, 15, and 16, 2009 Test Specifications: EMI requirements CFR Title 47, Part 15 Subpart B; and Subpart C, Sections 15.205 and 15.209 Test Procedure: ANSI C63.4 Test Deviations: The test procedure was not deviated from during the testing. SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions 150 kHz to 30 MHz Complies with the Class A limits of CFR Title 47, Part 15, Subpart B; and Subpart C Section 15.207. Highest reading in relation to spec limit: 58.02 (QP) dBuV @ 6.288 MHz (*U = 1.68 dB) 2 Radiated RF Emissions 9 kHz – 1000 MHz Complies with the Class A limits of CFR Title 47, Part 15, Subpart B; and Subpart C Sections 15.205 and 15.209. Highest reading in relation to spec limit: 42.31 (QP) dBuV @ 200.043 MHz (*U = 4.43 dB) *U = Expanded Uncertainty with a coverage factor of k=2 Report Number: B91216A1 FCC Part 15 Subpart B and FCC Section 15.209 Test Report Power 4 System Model: USS-POWER4-A Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 16 1. PURPOSE This document is a qualification test report based on the Electromagnetic Interference (EMI) tests performed on the Power 4 System, Model: USS-POWER4-A. The EMI measurements were perfor…

Text truncated - open the document above for the full version.

HOW THE EUT MEETS THE REQUIREMENTS OF 15.31 (e) FOR THE UNIVERSAL SURVEILLANCE SYSTEMS CORPORATION POWER 4 SYSTEM MODEL: USS-POWER4-A FCC ID: X2TUSS-POWER4-A00 The fundamental was maximized on the Lab A test site using a normal test setup with the AC Adapter for the power for the EUT connected directly to the AC public mains (115 Vac). Next, The AC Adapter for the EUT was then connected to the Staco Energy Products Variable Auto Transformer Model: 3PN1010. The Variable Auto Transformer allows the Vac input to be varied. The AC input was then dropped to 85% (97.75 Vac) and raised to 115% (132.25 Vac). The actual AC input was measured using a calibrated Fluke Multimeter Model: 87, Serial Number: 956410240, Calibration Due Date: May 28, 2010. The fundamental was then verified again to see that the amplitude did not change. Test Result: The EUT does NOT change amplitude at the fundamental when the AC input voltage is varied between 85% and 115% of the input nominal rated supply voltage.

FRONT VIEW UNIVERSAL SURVEILLANCE SYSTEMS CORPORATION POWER 4 SYSTEM Model: USS-POWER4-A FCC 15.209 – RADIATED EMISSIONS PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS REAR VIEW UNIVERSAL SURVEILLANCE SYSTEMS CORPORATION POWER 4 SYSTEM Model: USS-POWER4-A FCC 15.209 – RADIATED EMISSIONS PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS FRONT VIEW UNIVERSAL SURVEILLANCE SYSTEMS CORPORATION POWER 4 SYSTEM Model: USS-POWER4-A FCC SUBPART B – RADIATED EMISSIONS PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS REAR VIEW UNIVERSAL SURVEILLANCE SYSTEMS CORPORATION POWER 4 SYSTEM Model: USS-POWER4-A FCC SUBPART B – RADIATED EMISSIONS PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS FRONT VIEW UNIVERSAL SURVEILLANCE SYSTEMS CORPORATION POWER 4 SYSTEM Model: USS-POWER4-A FCC 15.207 and FCC SUBPART B – CONDUCTED EMISSIONS – CONTROLLER BOX PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS REAR VIEW UNIVERSAL SURVEILLANCE SYSTEMS CORPORATION POWER 4 SYSTEM Model: USS-POWER4-A FCC 15.207 and FCC SUBPART B – CONDUCTED EMISSIONS – CONTROLLER BOX PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS FRONT VIEW UNIVERSAL SURVEILLANCE SYSTEMS CORPORATION POWER 4 SYSTEM Model: USS-POWER4-A FCC 15.207 and FCC SUBPART B – CONDUCTED EMISSIONS – POWER 4 BOOSTER RX PEDESTAL PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS REAR VIEW UNIVERSAL SURVEILLANCE SYSTEMS CORPORATION POWER 4 SYSTEM Model: USS-POWER4-A FCC 15.207 and FCC SUBPART B – CONDUCTED EMISSIONS – POWER 4 BOOSTER RX PEDESTAL PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS
