X2VVDR000XXWireless Tunneling Valve Device Router

Eltav Wireless Monitoring System Installation and Operation Manual T/VDR Part No. VDY 23011 Revision 2. 6 March 2014 Introduction Misuse of this equipment can cause bodily harm. Operations not performed as per the instructions in this document are undertaken entirely at the user's own risk and liability. Une mauvaise utilisation de cet équipement peut causer des lésions corporelles. L’utilisateur qui ne respecte pas les directives figurant dans le présent document est entièrement responsable des risques auxquels il s’expose. To prevent bodily harm or damage to equipment, only trained, authorized personnel should install, maintain and repair the equipment. Pour éviter les lésions corporelles ou les dommages à l’équipement, seul un personnel formé et autorisé doit installer, entretenir et réparer l’équipement. This equipment has been tested and certified as being non-sparking. Please note that severe restrictions apply to this equipment in regard to its construction, installation, external wiring, maintenance and repair. Failure to abide by these restrictions could make the equipment a hazard to operate. Ce matériel a été testé et certifié comme ne produisant pas d’étincelles. Veuillez noter que des restrictions importantes s’appliquent à ce matériel au niveau de sa construction, de son installation, de son câblage externe, de sa maintenance et de sa réparation. Le non-respect de ces restrictions pourrait entraîner des risques lors de l’utilisation. To prevent damage to equipment through electrostatic charge on plastic surface of the VD / TVDR, always wipe the surface with a damp cloth. Pour éviter les dommages à l’équipement causés par la charge électrostatique présente sur la surface de plastique du dispositif de contrôle de soupapes, essuyez toujours la surface avec un chiffon humide. Introduction The installation of the equipment should be carried out by appropriately trained and qualified professional personnel with relevant expertise. The installation should not be carried out by operators or non-qualified personnel. L’installation du matériel doit être réalisée exclusivement par du personnel professionnel compétent correctement formé et disposant de l’expertise nécessaire. L’installation ne peut être réalisée par des opérateurs ou du personnel non qualifié. The installation should be carried out in accordance with the local electric code. L’installation doit être réalisée conformément à la réglementation électrique locale. Make sure that the circuit breakers installed in the power supply circuits are located in the non-hazardous areas and the power can be shut-off when abnormal conditions occur. Veillez à ce que les disjoncteurs installés dans les circuits d’alimentation soient situés dans les zones non dangereuses et veillez à ce que l’alimentation puisse être coupée en cas de problème. In order to prevent electrostatic charge, avoid any actions that cause the generation of electrostatic fields, such as rubbing with dry cloth on face of the equipment. Pour éviter toute charge électrostatique, évitez toute action qui pourrait entraîner la production de champs électrostatiques comme tout frottement avec des tissus secs contre la partie avant de l’équipement. This equipment cannot be opened in a hazardous area. Connect and disconnect the DC line and the data line before installation or disassembly or maintenance. Cet équipement ne peut être ouvert dans une zone dangereuse. Branchez et débranchez la ligne CC et la ligne de données avant l’installation, le démontage ou la maintenance. Introduction In order to prevent ingress of water and dust, always make sure that enclosure is dry and clean before opening the cover. Pour éviter toute infiltration d’eau et de poussière, veillez toujours à ce que le boîtier soit sec et propre avant d’ouvrir le couvercle. Always apply suitable rated devices to the electrical connection ports. Utilisez toujours les appareils de tension correcte lors du branchement aux ports de connexion électrique. Connector J5 contains a protective PTC component. Do not replace with an ordinary jumper. Le connecteur J5 contient un composant PTC protecteur. Ne pas le remplacer par un connecteur ordinaire. Carefully read the safety information contained in this section, and throughout this user guide, before installing, operating, or performing any maintenance task on the equipment. Lisez attentivement les consignes de sécurité contenues dans cette section et dans tout le guide d’utilisation, avant d’installer, d’utiliser l’équipement ou de réaliser des tâches d’entretien. This power supply should be in a safe area unless it has been approved for hazardous locations. Cette alimentation doit se situer dans une zone sûre sauf si elle a été approuvé pour des emplacements dangereux. Introduction FCC ID: X2VVDR000XX This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. IC: Industry Canada 8876A-VDR000XX Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must accept any interference, including interference that may cause undesired operation of the device ID FCC : X2VVDR000XX Ce dispositif est conforme à la section 15 des réglementations de la FCC. Cet appareil est soumis aux deux conditions suivantes : (1) cet appareil ne doit pas causer d’interférences nuisibles et (2) doit accepter toute interférence reçue, y compris les interférences pouvant entraîner un fonctionnement indésirable IC : Industrie Canada 8876A-VDR000XX Cet appareil est soumis aux deux conditions suivantes : (1) cet appareil ne doit pas causer d’interférences et (2) cet appareil doit accepter toute interférence reçue, y compris les interférences pouvant entraîner un fonctionnement indésirable. Introduction Revision History Docume…

Text truncated - open the document above for the full version.

ELTAV Wireless Monitoring Ltd. 19 March 2014 Attention: Application Examiner Re: Request for confidentiality Applicant: Eltav Wireless Monitoring Ltd. FCC ID: X2VVDR000XX To whom it may concern, Permanent Confidentiality Request is hereby submitted by Eltav Wireless Monitoring Ltd. to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential:  Schematics  Detailed Block diagrams  Detailed Operational/Functional Description  Tune up procedure  Parts list Justification : (1) Device is not sold to end user. (2) Non-consumrer device inaccessible to general public. The device is mounted on valves in a chemical process lines and its location is always fenced or locked and only serviceable by the licensee or designated technicians. Rationale for request for confidentiality: Eltav Wireless Monitoring Ltd. has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. If you have questions or need further information, please contact the undersigned. Sincerely, Vice Chairman Eltav Wireless Monitoring Ltd. 19-Mar-2014 15 Hatassia St. Ranana, 43654, Israel Web: www.eltav.com email: [email protected] Tel: +972-9-7440012, Fax +972-9-7440026 i:\2005 my documents\eltav\eltav technical\emc testing\tvdr data package to fcc ic\docs to send\eltav fcc request for confidentiality.docx

ELTAV Wireless Monitoring Ltd. 26 February, 2013 15 Hatassia St. Ranana, 43654, Israel Eltav Proprietary and Confidential Web: www.eltav.com email: [email protected] Tel: +972-9-7440012, Fax +972-9-7440026 k:\2005 my documenti:\2005 my documents\eltav\eltav technical\emc testing\tvdr data package to fcc ic\docs to send\eltav letter of agency fcc.docx Letter of Agency I appoint Intertek Testing Services NA Inc. to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under the FCC rules until further notice. I further certify that no party (as defined in 1.2002 of CFR 47, 1995) to this application, including myself, is subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.,853A. Equipment: Tunneling/Valve Device Router Type T/VDR P/N VDR000XX. Dated this 25 day of February, 2013. Signature Israel Radomsky Name Vice Chairman Title Eltav Wireless Monitoring Ltd. Company +972 9 7440012 Telephone

1 2 3 4 5 6 7 8 A DESCRIPTION VDR ATEX WITH BATTERY MARKING LABEL DWG NO LBL00046-5 SIZE A4 SHEET 1 OF 1 REV 5 AUTHOR DATE SIGN NOTE P/N LBL00046 Ronen.D 03.12.13 See notes A B B C C D D E E F F 1 2 3 4 5 6 7 8 NOTES: 1. 50.8x25.4 mm - Black font on white label. 2. Label Material: 711 By NORTEC AMI LTD (P/N:V7379i711a5P) 3. Ink Material: EE01XX104 By NORTEC AMI LTD 4. UL 696 PGJI2 FILE. MH29261 5. Font size: 2 mm 6. Ex and CE Icon size: 4x4mm II 3 G Ex nA IIC T4 Gc ITS10ATEX46918X WARNING: Do not open in a hazardous area. 50.8 mm 25.4mm Eltav Wireless Monitoring Ltd. W 15 Hatassia St. Ra'anana 43654 Israel W S.N:___________________ W LAN MAC: ___________________ D/C:__________ ZB:________________ Supply: 7-36V DC 10W Valve Device Router Model: VDR00044 (WITH BAT) Electrostatic hazard - clean only using a damp cloth. Electrostatic hazard clean only using a damp cloth. -20ºC<Ta<+40ºC WARNNING - EXPLOSION HAZARD - SUBSTITUTION OF COMPONENTS MAY IMPAIR SUITABILITY FOR CLASS I, DIVISION2 AVERTISSEMENT - RISQUE D'EXPLOSION – LA SUBSTITUTION DECOMPOSANTS PEUT RENDRE CE MATERIEL INACCEPTABLE POUR LES EM-PLACEMENTS DE CLASSE I, DIVISION 2 AVERTISSEMENT - RISQUE D'EXPLOSION-AVANT DE DECONNECTER L'EQUIPEMENT, COUPER LE COURANT OU S`ASSURER QUE L`EMPLACEMENT EST DSIGNE NON DANGEREUX 25.4mm 50.8 mm 0359 06 ! See user manual for further information and instructions ! IECEx ITS 12.0076X FCC ID# X2VVDR000XX IC:8876A-VDR00044 Use only P/N:ANT00011 antenna This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. 50.8 mm 12mm 1 2 3 4 5 6 7 8 A DESCRIPTION TVDR ATEX WITH BATTERY MARKING LABEL DWG NO LBL00047-5 SIZE A4 SHEET 1 OF 1 REV 5 AUTHOR DATE SIGN NOTE P/N LBL00047 Ronen.D 03.12.13 See notes A B B C C D D E E F F 1 2 3 4 5 6 7 8 NOTES: 1. 50.8x25.4 mm - Black font on white label. 2. Label Material: 711 By NORTEC AMI LTD (P/N:V7379i711a5P) 3. Ink Material: EE01XX104 By NORTEC AMI LTD 4. UL 696 PGJI2 FILE. MH29261 5. Font size: 2 mm 6. Ex and CE Icon size: 4x4mm II 3 G Ex nA IIC T4 Gc ITS10ATEX46918X WARNING: Do not open in a hazardous area. 50.8 mm 25.4mm Eltav Wireless Monitoring Ltd. W 15 Hatassia St. Ra'anana 43654 Israel W S.N:___________________ W LAN MAC: ___________________ D/C:__________ ZB:________________ Supply: 7-36V DC 10W Tunneling Valve Device Router (WITH BAT) Model: VDR00045 Electrostatic hazard - clean only using a damp cloth. Electrostatic hazard clean only using a damp cloth. -20ºC<Ta<+40ºC WARNNING - EXPLOSION HAZARD - SUBSTITUTION OF COMPONENTS MAY IMPAIR SUITABILITY FOR CLASS I, DIVISION2 AVERTISSEMENT - RISQUE D'EXPLOSION – LA SUBSTITUTION DECOMPOSANTS PEUT RENDRE CE MATERIEL INACCEPTABLE POUR LES EM-PLACEMENTS DE CLASSE I, DIVISION 2 AVERTISSEMENT - RISQUE D'EXPLOSION-AVANT DE DECONNECTER L'EQUIPEMENT, COUPER LE COURANT OU S`ASSURER QUE L`EMPLACEMENT EST DSIGNE NON DANGEREUX 25.4mm 50.8 mm 0359 06 ! See user manual for further information and instructions ! IECEx ITS 12.0076X IC:8876A-VDR00045 FCC ID# X2VVDR000XX Use only P/N ANT00011 Antenna This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. 50.8 mm 12 mm 1 2 3 4 5 6 7 8 A DESCRIPTION VDR ATEX NO BATTERY MARKING LABEL DWG NO LBL00048-5 SIZE A4 SHEET 1 OF 1 REV 5 AUTHOR DATE SIGN NOTE P/N LBL00048 Ronen.D 03.12.13 See notes A B B C C D D E E F F 1 2 3 4 5 6 7 8 NOTES: 1. 50.8x25.4 mm - Black font on white label. 2. Label Material: 711 By NORTEC AMI LTD (P/N:V7379i711a5P) 3. Ink Material: EE01XX104 By NORTEC AMI LTD 4. UL 696 PGJI2 FILE. MH29261 5. Font size: 2 mm 6. Ex and CE Icon size: 4x4mm II 3 G Ex nA IIC T4 Gc ITS10ATEX46918X WARNING: Do not open in a hazardous area. 50.8 mm 25.4mm Eltav Wireless Monitoring Ltd. W 15 Hatassia St. Ra'anana 43654 Israel W S.N:___________________ W LAN MAC: ___________________ D/C:__________ ZB:________________ Supply: 7-36V DC 10W Valve Device Router Model: VDR00054 (NO BAT) Electrostatic hazard - clean only using a damp cloth. Electrostatic hazard clean only using a damp cloth. -40ºC<Ta<+80ºC WARNNING - EXPLOSION HAZARD - SUBSTITUTION OF COMPONENTS MAY IMPAIR SUITABILITY FOR CLASS I, DIVISION2 AVERTISSEMENT - RISQUE D'EXPLOSION – LA SUBSTITUTION DECOMPOSANTS PEUT RENDRE CE MATERIEL INACCEPTABLE POUR LES EM-PLACEMENTS DE CLASSE I, DIVISION 2 AVERTISSEMENT - RISQUE D'EXPLOSION-AVANT DE DECONNECTER L'EQUIPEMENT, COUPER LE COURANT OU S`ASSURER QUE L`EMPLACEMENT EST DSIGNE NON DANGEREUX 25.4mm 50.8 mm 0359 06 ! See user manual for further information and instructions ! IECEx ITS 12.0076X FCC ID# X2VVDR000XX IC:8876A-VDR00054 Use only P/N ANT00011 Antenna This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. 50.8 mm 12 mm 1 2 3 4 5 6 7 8 A DESCRIPTION TVDR ATEX NO BATTERY MARKING LABEL DWG NO LBL00049-5 SIZE A4 SHEET 1 OF 1 REV 5 AUTHOR DATE SIGN NOTE P/N LBL00049 Ronen.D 03.12.13 See notes A B B C C D D E E F F 1 2 3 4 5 6 7 8 NOTES: 1. 50.8x25.4 mm - Black font on white label. 2. Label Material: 711 By NORTEC AMI LTD (P/N:V7379i711a5P) 3. Ink Material: EE01XX104 By NORTEC AMI LTD 4. UL 696 PGJI2 FILE. MH29261 5. Font size: 2 mm 6. Ex and CE Icon size: 4x4mm II 3 G Ex nA IIC T4 Gc ITS10ATEX46918X WARNING: Do not open in a hazardous area. 50.8 mm 25.4mm Eltav Wireless Monitoring Ltd. W 15 Hatassia St. Ra'anana 43654 Israel W S.N:___________________ W LAN MAC: ___________________ D/C:__________ ZB:________________ Supply: 7-36V DC 10W Tunneling…

Text truncated - open the document above for the full version.

Intertek House, Cleeve Road Leatherhead, Surrey KT22 7SB, United Kingdom Telephone: +44 1372 370900 Facsimile: +44 1372 370999 www.intertek.com Intertek Testing & Certification Ltd, Registered office: Academy Place, 1-9 Brook Street, Brentwood, Essex, CM14 5NQ, United Kingdom Registered No: 3272281 (England), VAT No: GB 672-7639-96. EMC TEST REPORT COMPANY: ELTAV Wireless Monitoring Limited PRODUCT: Tunnelling Valve Device Router (TVDR) REPORT NO: 100923093LHD-001 WRITTEN BY: G Aldridge REVIEWED BY: D Legge TEST ENGINEER: G Aldridge ISSUE: 3 DATE: 12 th February 2014 TOTAL PAGES: 167 This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Report No.: 100923093LHD-001 Page: 2 of 167 Product: Tunnelling Valve Device Router Issue Date: 12 th February 2014 Model No.: TVDR Issue No.: 3 Contents Page No. 1. JOB DESCRIPTION........................................................................................ 9 2. TEST SUMMARY..........................................................................................10 2.1. Standard: CRF 47 Part 15:249 .............................................................. 10 2.2. RSS210 Issue 8 & RSS-Gen Issue 3..................................................... 10 2.3. Modifications .......................................................................................... 10 3. EQUIPMENT UNDER TEST (EUT) .............................................................. 11 3.1. Description of the EUT ........................................................................... 11 3.2. EUT Modes of Operation ....................................................................... 11 3.3. EUT Configuration Diagram ................................................................... 12 3.4. EUT Support Equipment ........................................................................ 12 3.5. Cables Associated With the EUT........................................................... 12 4. RADIATED EMISSIONS ............................................................................... 13 4.1. Radiated Emissions Test Method .......................................................... 13 4.2. Radiated Emissions Test Results .......................................................... 13 4.3. Radiated Emissions Conclusions........................................................... 13 4.4. Measurement Uncertainty ...................................................................... 13 5. – 6dB Bandwidth ......................................................................................... 158 6. Transmitter Peak Output Power (Conducted) ............................................. 160 7. Power Spectral Density (Conducted) .......................................................... 161 8. Uncertainty Budget Calculations ................................................................. 162 9. TEST EQUIPMENT..................................................................................... 163 10. PHOTOGRAPHS..................................................................................... 164 11. ANNEX A: RF EXPOSURE EVALUATION ............................................. 165 12. ANNEX B: REGISTRATION .................................................................... 166 Report No.: 100923093LHD-001 Page: 3 of 167 Product: Tunnelling Valve Device Router Issue Date: 12 th February 2014 Model No.: TVDR Issue No.: 3 TABLES Table 1 Radiated Emissions Test Results – Mode 1 – Receive Ch11 – Horizontal.14 Table 2 Radiated Emissions Test Results – Mode 1 – Receive Ch11 – Vertical. 16 Table 3 Radiated Emissions Test Results – Mode 1 – Receive Ch11 – Horizontal – 1 to 25GHz. ................................................................................................ 18 Table 4 Radiated Emissions Test Results – Mode 1 – Receive Ch11 – Vertical – 1 to 25GHz. ................................................................................................... 28 Table 5 Radiated Emissions Test Results – Mode 2 – Receive Ch18 – Horizontal – 30 to 1GHz. ................................................................................................ 38 Table 6 Radiated Emissions Test Results – Mode 2 – Receive Ch18 – Vertical – 30 to 1GHz. ................................................................................................... 40 Table 7 Radiated Emissions Test Results – Mode 2 – Receive Ch18 – Horizontal – 1 to 25GHz. ................................................................................................ 42 Table 8 Radiated Emissions Test Results – Mode 2 – Receive Ch18 – Vertical – 1 to 25GHz. ................................................................................................... 52 Table 9 Radiated Emissions Test Results – Mode 3 – Receive Ch26 – Horizontal.62 Table 10 Radiated Emissions Test Results – Mode 3 – Receive Ch26 – Vertical.64 Table 11 Radiated Emissions Test Results – Mode 3 – Receive Ch26 – Horizontal – 1 to 25GHz. ............................................................................... 66 Table 12 Radiated Emissions Test Results – Mode 3 – Receive Ch26 – Vertical – 1 to 25GHz. ......…

Text truncated - open the document above for the full version.
