Performance Designed Products, LLC FCC ID.: X5B-048-032T 14144 Ventura Blvd., Suite 200 Sherman Oaks, CA 91423 USATel : 1-323-234-9911 Federal Communications Commission June 02, 2015 Authorization and Evaluation Division ATTESTATION FCC ID: X5B-048-032T Product: Afterglow Anka/AG7 wireless Dongle for XB1 We don’t provide any controls or software to allow operation outside the USA frequency band when we sell a product bearing the FCC ID: X5B-048-032T anywhere in the world. Sincerely, ---------------------------------------------------- Tom Roberts / Chief Technical Officer Performance Designed Products, LLC

Performance Designed Products, LLC FCC ID.: X5B-048-032T 14144 Ventura Blvd., Suite 200 Sherman Oaks, CA 91423 USA Tel : 1-323-234-9911 Performance Designed Products, LLC 14144 Ventura Blvd., Suite 200 Sherman Oaks, CA 91423 USA Tel : 1-323-234-9911 Fax: 1-323-234-9922 Federal Communications Commission June 02, 2015 Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant Hereby requests confidential treatment of information accompanying this Application As outlined below: Schematics: (048-032T) Schem Block Diagram: (048-032T) BlkDia Operational Description: (048-032T) OPDes The above materials contain trade secrets and proprietary information not customarily Released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, ---------------------------------------------------- Tom Roberts / Chief Technical Officer Performance Designed Products, LLC

Performance Designed Products, LLC 14144 Ventura Blvd., Suite 200 Sherman Oaks, CA91423 USA TEL No: 1-323-234-9911 FAX No: 1-323-234-9922 Attestation for FCC Declaration of Conformity FCC ID: X5B-048-032T Date: June 02, 2015 Please be notified that we, the undersigned, Performance Designed Products, LLC, declares that the product which bears the above FCC ID is also compliant with the FCC requirements for DoC. The test report number supporting the DoC is 1540398R-ITUSP01V00. Testing in regards to this report was done by QuieTek Corporation, located at 2F, No.345, Xinhu 2nd Rd., Neihu District,Taipei City 114,Taiwan,R.O.C. which has been accredited in accordance to all of the requirements of 47CFR 2.948 (d) and (e) of the FCC rules and KDB349827. Sincerely, -------------------------------------------------------- Tom Roberts / Chief Technical Officer Performance Designed Products, LLC Tel: 1-323-234-9911 Fax: 1-323-234-9922 Email: [email protected]

RF_160, Issue 04 (Performance Designed Products, LLC) Declaration of Authorization We Name: Performance Designed Products, LLC Address: 14144 Ventura Blvd., Suite 200 Sherman Oaks, CA91423 USA.  City: Oaks .. Country: United States  Declare that: Name Representative of agent: Vincent Lin (1) Agent Company name: QuieTek Corp. Address: No.5-22, Ruishukeng, Linkou Dist., New Taipei City 24451, Taiwan, R.O.C. City: New Taipei City Country Taiwan, R.O.C. is authorized to apply for Certification of the following product(s): Product description: Afterglow Anka_AG7 wireless Dongle for XB1 Type designation: 048-032T . Trademark: pdp, Afterglow Validity/ expiry date on our behalf. Date: July 24, 2015 City: Oaks Name: Tom Roberts (2) Function: Chief Technical Officer Signature: . Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

FCC, Request for non-disclosure Date: 16-Jul-10 RF_501, Issue 6 Page 1 of 1 Company Name: Performance Designed Products, LLC Address : 14144 Ventura Blvd., Suite 200 Sherman Oaks, CA91423 USA City: Oaks Country: United States To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: X5B-048-032T Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, a pplicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Planned Release Date STC: (notes 2, 3, 4, 5) Date: June 02, 2015 Name and signature of applicant: Tom Roberts Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

Report No.: 1540398R-RFUSP01V00 Page : 1 of 3 Attachment 2 : EUT Detailed Photographs (1) EUT Photo (2) EUT Photo

Performance Designed Products, LLC FCC ID.: X5B-048-032T 14144 Ventura Blvd., Suite 200 Sherman Oaks, CA 91423 USATel : 1-323-234-9911 FCC ID Label

Performance Designed Products, LLC FCC ID.: X5B-048-032T 14144 Ventura Blvd., Suite 200 Sherman Oaks, CA 91423 USATel : 1-323-234-9911 The FCC ID will be placed on the equipment as shown in the photograph below.

Report No.: 1540398R-RFUSP01V00 Page : 2 of 3 (3) EUT Photo (4) EUT Photo Antenna Antenna RF Module Report No.: 1540398R-RFUSP01V00 Page : 3 of 3 (5) EUT Photo (6) EUT Photo

Report No.: 1540398R-RFUSP25V00 Page: 1 of 1 RF Exposure Evaluation declaration Product Name : Afterglow Anka/AG7 wireless Dongle for XB1 Model No. : 048-032T FCC ID : X5B-048-032T Applicant : Performance Designed Products, LLC Address : 14144 Ventura Blvd., Suite 200 Sherman Oaks, CA91423 USA Date of Receipt : Apr. 17, 2015 Date of Declaration: June 01, 2015 Report No. : 1540398R-RFUSP25V00 The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration report of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by TAF or any agency of the government. The test report shall not be reproduced without the written approval of QuieTek Corporation. Report No.: 1540398R-RFUSP25V00 Page: 2 of 2 1. RF Exposure Evaluation 1.1. Limits According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (Minutes) (A) Limits for Occupational/ Control Exposures 300-1500 -- -- F/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/ Uncontrolled Exposures 300-1500 -- -- F/1500 6 1500-100,000 -- -- 1 30 F= Frequency in MHz Friis Formula Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. 1.2. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. The temperature and related humidity: 18°Cand 78％ RH. Report No.: 1540398R-RFUSP25V00 Page: 3 of 3 1.3. Test Result of RF Exposure Evaluation Product : Afterglow Anka/AG7 wireless Dongle for XB1 Test Item : RF Exposure Evaluation Test Site : No.3 OATS Operation Frequency 2403.35 – 2479.35MHz Maximum Conducted output power 2.15dBm Antenna gain 2.12dBi Output Power Into Antenna & RF Exposure Evaluation Distance: Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm2) 1.6406 0.000004 Power density is lower than the limit (1 mW/cm2).

Report No.: 1540398R-RFUSP25V00 Page : 1 of 42 FCC Test Report Product Name Afterglow Anka/AG7 wireless Dongle for XB1 Model No 048-032T FCC ID. X5B-048-032T Applicant Performance Designed Products, LLC Address 14144 Ventura Blvd., Suite 200 Sherman Oaks, CA91423 USA Date of Receipt Apr. 17, 2015 Issue Date June 01, 2015 Report No. 1540398R-RFUSP25V00 Report Version V1.0 The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration report of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by TAF or any agency of the government. The test report shall not be reproduced without the written approval of QuieTek Corporation. Report No.: 1540398R-RFUSP25V00 Page : 2 of 42 Test Report Issue Date: June 01, 2015 Report No.: 1540398R-RFUSP25V00 Product Name Afterglow Anka/AG7 wireless Dongle for XB1 Applicant Performance Designed Products, LLC Address 14144 Ventura Blvd., Suite 200 Sherman Oaks, CA91423 USA Manufacturer Performance Designed Products, LLC Model No. 048-032T EUT Rated Voltage DC 5V (Power by USB) EUT Test Voltage AC 120V/60Hz Trade Name pdp, Afterglow Applicable Standard FCC CFR Title 47 Part 15 Subpart C: 2014 ANSI C63.4: 2009, ANSI C63.10: 2009 KDB 558074 D01 DTS Meas Guidance v03r02 Test Result Complied Documented By : ( Senior Engineering Adm. Specialist / Anita Chou) Tested By : ( Engineer / Eason Chen) Approved By : ( Director / Vincent Lin) Report No.: 1540398R-RFUSP25V00 Page : 3 of 42 TABLE OF CONTENTS Description Page 1. GENERAL INFORMATION ................................................................................................5 1.1. EUT Description ......................................................................................................................5 1.2. Operational Description ...........................................................................................................7 1.3. Tested System Details ..............................................................................................................8 1.4. Configuration of Tested System ...............................................................................................8 1.5. EUT Exercise Software ............................................................................................................8 1.6. Test Facility ..............................................................................................................................9 2. Conducted Emission .............................................................................................................10 2.1. Test Equipment.......................................................................................................................10 2.2. Test Setup ...............................................................................................................................10 2.3. Limits .....................................................................................................................................11 2.4. Test Procedure ........................................................................................................................11 2.5. Uncertainty .............................................................................................................................11 2.6. Test Result of Conducted Emission .......................................................................................12 3. Peak Power Output...............................................................................................................14 3.1. Test Equipment.......................................................................................................................14 3.2. Test Setup ...............................................................................................................................14 3.3. Limit .......................................................................................................................................14 3.4. Test Procedure ........................................................................................................................14 3.5. Uncertainty .............................................................................................................................14 3.6. Test Result of Peak Power Output..........................................................................................15 4. Radiated Emission ................................................................................................................16 4.1. Test Equipment.......................................................................................................................16 4.2. Test Setup ...............................................................................................................................16 4.3. Limits .....................................................................................................................................17 4.4. Test Procedure ........................................................................................................................18 4.5. Uncertainty .............................................................................................................................18 4.6. Test Result of Radiated Emission...........................................................................................19 5. RF Antenna Conducted Test ................................................................................................23 5.1. Test Equipment.......................................................................................................................23 5.2. Test Setup ...............................................................................................................................23 5.3. Limits ..................…
