X5B-PL6390ATron PS3 Wireless Controller-Dongle

Thank you for purchasing the Game Stop wireless controller for the PLAYSTATION 3 video game system. Contents: 1 Wireless Controller for PS3 1 USB Dongle (found attached to the controller) 1 USB Cable 1 Manual Set up: 1) Remove the USB receiver that is attached to the bottom of the controller and plug it into one of the free ports of your PLAYSTATION 3 2) USB receiver LED will flash rapidly while looking for positive connection with the controller. USB receiver light will light up solid when the connection is established 3) Place the power switch is in “ON” position 4) Press the “HOME” button, the controller will be automatically assigned a player number. (you can change the controller player number by pressing and holding the HOME button and then changing the player number from the PS3 menu – refer to your console manual for more information 5) The battery of the controller is low when its LED start flashing. Power Save Mode: Controller will go into Power Save Mode after 3 (three) minutes of inactivity. You need to press the START button to turn it back to the ACTIVE mode Important Notice 1. Recommended user age range 14+. 2. Adult supervision is necessary when controller is used by child CAUTION: Changes or modifications to this equipment not expressly approved by the manufacturer could void the users authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. FCC ID for Controller: X5B-PL6390 FCC ID for Dongle: X5B-PL6390A This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. © 2010 Performance Designed Products LLC. All rights reserved. PDP and AFTERGLOW™ are trademarks of Performance Designed Products LLC. PlayStation 3® is a registered trademark of Sony Computer Entertainment, Inc. This product is not designed, manufactured, sponsored or endorsed by Sony Computer Entertainment. Please keep this information for future reference.

RF_160, Issue 03 Declaration of Authorization We Name: Performance Designed Products, LLC Address: 14144 Ventura Blvd, Suite 200 Sherman. City: Oaks Country: United States Declare that: Name Representative of agent: Ms. Cathy Wang Agent Company name: Neutron Engineering, Inc. Address: No.3 Jinshagang 1 st Road, Shixia, Dalang Town City: Dongguan Country: China is authorized to apply for Certification of the following product(s): Product description: Tron PS3 Wireless Controller-Dongle Type designation: PL-6390A Trademark: NA on our behalf. Date: 2011-11-28 City: Oaks Name: Tom Roberts Function: Chief Technical Officer Signature: Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

FCC, Request for non-disclosure Date: 16-Jul-10 RF_501, Issue 6 Page 1 of 1 Company Name: Performance Designed Products, LLC Address : 14144 Ventura Blvd, Suite 200 Sherman. City: Oaks Country: United States To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: X5B-PL6390A Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, a pplicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Planned Release Date STC: (notes 2, 3, 4, 5) Date: 2011-11-28 Name and signature of applicant: Tom Roberts Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period FCC, Request for non-disclosure Date: 16-Jul-10 RF_501, Issue 6 Page 1 of 1

Neutron Engineering Inc. Project No.: 1111C094A Page 2 of 7 1111C094A 1111C094A Neutron Engineering Inc. Project No.: 1111C094A Page 2 of 7 1111C094A 1111C094A Neutron Engineering Inc. Project No.: 1111C094A Page 3 of 7 1111C094A 1111C094A Neutron Engineering Inc. Project No.: 1111C094A Page 3 of 7 1111C094A 1111C094A

Neutron Engineering Inc. Project No.: 1111C094A Page 4 of 7 1111C094A 1111C094A Neutron Engineering Inc. Project No.: 1111C094A Page 4 of 7 1111C094A 1111C094A Neutron Engineering Inc. Project No.: 1111C094A Page 5 of 7 1111C094A 1111C094A Neutron Engineering Inc. Project No.: 1111C094A Page 5 of 7 1111C094A 1111C094A Neutron Engineering Inc. Project No.: 1111C094A Page 6 of 7 1111C094A 1111C094A Neutron Engineering Inc. Project No.: 1111C094A Page 6 of 7 1111C094A 1111C094A Neutron Engineering Inc. Project No.: 1111C094A Page 7 of 7 1111C094A 1111C094A Neutron Engineering Inc. Project No.: 1111C094A Page 7 of 7 1111C094A 1111C094A

Neutron Engineering Inc. FCC RF EXPOSURE REPORT FCC ID: X5B-PL6390A Project No. : 1110C094A Equipment : Tron PS3 Wireless Controller-Dongle Model : PL-6390A Applicant : Performance Designed Products, LLC Address : 14144 Ventura Blvd, Suite 200 Sherman, Oaks, United States According: : FCC Guidelines for Human Exposure IEEE C95.1 Neutron Engineering Inc. No.3, Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. GENERAL CONCULUSION: No evaluation required if power is below this threshold: F(GHz) P(mW) Low 2.042 High 2.480 24.19 Maximum measured transmitter power: Out Power (dBm) Out Power (mW) Conducted Power -12.00 0.000063 EIRP Power -10.24 0.000095 Note: Table for Filed Antenna Ant. Brand Model Name Antenna Type Connector Gain (dBi) 1 N/A N/A Printed Antenna N/A 1.58 Threshold for no SAR evaluation is 24.19 mW. Transmitter power is 0.000063 mW. Conclusion: No SAR evaluation required since transmitter power is below FCC threshold

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1111C094A Page 1 of 60 FCC Radio Test Report FCC ID: X5B-PL6390A This report concerns (check one) : Original Grant Class II Change Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory : (Steven Lu) Neutron Engineering Inc. No.3,Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Issued Date : Dec. 22, 2011 Project No. : 1111C094A Equipment : Tron PS3 Wireless Controller-Dongle Model Name : PL-6390A Applicant : Performance Designed Products, LLC Address : 14144 Ventura Blvd. Suite 200, Sherman Oaks, CA 91423 Manufacturer : Performance Designed Products, LLC Address : 14144 Ventura Blvd. Suite 200, Sherman Oaks, CA 91423 Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Nov. 11, 2011 Date of Test: Nov. 11, 2011 ~ Dec. 20, 2011 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1111C094A Page 2 of 60 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C., or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FCCP-1-1111C094A Page 3 of 60 Table of Contents Page 1 . CERTIFICATION 6 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 3 . GENERAL INFORMATION 9 3.1 GENERAL DESCRIPTION OF EUT 9 3.2 DESCRIPTION OF TEST MODES 11 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 11 3.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 3.5 DESCRIPTION OF SUPPORT UNITS 13 4 . EMC EMISSION TEST 14 4.1 CONDUCTED EMISSION MEASUREMENT 14 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 14 4.1.2 MEASUREMENT INSTRUMENTS LIST AND SETTING 14 4.1.3 TEST PROCEDURE 15 4.1.4 DEVIATION FROM TEST STANDARD 15 4.1.5 TEST SETUP 15 4.1.6 EUT OPERATING CONDITIONS 15 4.1.7 TEST RESULTS 16 4.2 RADIATED EMISSION MEASUREMENT 18 4.2.1 RADIATED EMISSION LIMITS 18 4.2.2 MEASUREMENT INSTRUMENTS LIST ANS SETTING 19 4.2.3 TEST PROCEDURE 21 4.2.4 DEVIATION FROM TEST STANDARD 21 4.2.5 TEST SETUP 22 4.2.6 EUT OPERATING CONDITIONS 23 4.2.7 TEST RESULTS (BELOW 30MHZ) 24 4.2.8 TEST RESULTS (BETWEEN30 – 1000 MHZ) 25 4.2.9 TEST RESULTS (ABOVE 1000 MHZ) 27 5 . NUMBER OF HOPPING CHANNEL 39 5.1 APPLIED PROCEDURES / LIMIT 39 5.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 39 5.1.2 TEST PROCEDURE 39 5.1.3 DEVIATION FROM STANDARD 39 5.1.4 TEST SETUP 39 5.1.5 EUT OPERATION CONDITIONS 39 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1111C094A Page 4 of 60 Table of Contents Page 5.1.6 TEST RESULTS 40 6 . AVERAGE TIME OF OCCUPANCY 41 6.1 APPLIED PROCEDURES / LIMIT 41 6.1.1 MEASUREMENT INSTRUMENTS LIST 41 6.1.2. TEST PROCEDURES 41 6.1.3. TEST SETUP LAYOUT 41 6.1.4. TEST DEVIATION 41 6.1.5. EUT OPERATION DURING TEST 41 6.1.6. TEST RESULTS 42 7 . HOPPING CHANNEL SEPARATION MEASUREMENT 44 7.1 APPLIED PROCEDURES / LIMIT 44 7.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 44 7.1.2 TEST PROCEDURE 44 7.1.3 DEVIATION FROM STANDARD 44 7.1.4 TEST SETUP 44 7.1.5 EUT OPERATION CONDITIONS 44 7.1.6 TEST RESULTS 45 8 . BANDWIDTH TEST 46 8.1 APPLIED PROCEDURES / LIMIT 46 8.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 46 8.1.2 TEST PROCEDURE 46 8.1.3 DEVIATION FROM STANDARD 46 8.1.4 TEST SETUP 46 8.1.5 EUT OPERATION CONDITIONS 46 8.1.6 TEST RESULTS 47 9 . PEAK OUTPUT POWER TEST 49 9.1 APPLIED PROCEDURES / LIMIT 49 9.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 49 9.1.2 TEST PROCEDURE 49 9.1.3 DEVIATION FROM STANDARD 49 9.1.4 TEST SETUP 49 9.1.5 EUT OPERATION CONDITIONS 49 9.1.6 TEST RESULTS 50 10 . ANTENNA CONDUCTED SPURIOUS EMISSION 52 10.1 APPLIED PROCEDURES / LIMIT 52 10.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 52 10.1.2 TEST PROCEDURE 52 10.1.3 DEVIATION FROM STANDARD 52 10.1.4 TEST SETUP 52 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1111C094A Page 5 of 60 Table of Contents Page 10.1.5 EUT OPERATION CONDITIONS 52 10.1.6 TEST RESULTS 53 11 . EUT TEST PHOTO 59 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1111C094A Page 6 of 60 1. CERTIFICATION E q u i p m e n t : Tron PS3 Wireless Controller-Dongle Brand Name : N/A Model Name : PL-6390A A p p l i c a n t : Performance Designed Products, LLC Factory : Performance Designed Products, LLC Address : 14144 Ventura Blvd. Suite 200, Sherman Oaks, CA 91423 Date of Test : Nov. 11, 2011 ~ Dec. 20, 2011 T e s t I t e m : ENGINEERING SAMPLE Standards : FCC Part15, Subpart C(15.247) / ANSI C63.4 : 2003 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-1-1111C…

Text truncated - open the document above for the full version.

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1111C094A Page 59 of 60 10.1.7. EUT TEST PHOTO Conducted Measurement Photos Neutron Engineering Inc. Report No.: NEI-FCCP-1-1111C094A Page 59 of 60 10.1.7. EUT TEST PHOTO Conducted Measurement Photos Neutron Engineering Inc. Report No.: NEI-FCCP-1-1111C094A Page 60 of 60 Radiated Measurement Photos Neutron Engineering Inc. Report No.: NEI-FCCP-1-1111C094A Page 60 of 60 Radiated Measurement Photos
